P.123)

• Operating the wireless remote

control function (



P.115)

Mechanical keys
Key number plate

■

When riding in an aircraft

When bringing an electronic key

onto an aircraft, make sure you do

not press any buttons on the elec-

tronic key while inside the aircraft

cabin. If you are carrying an elec-

tronic key in your bag, etc., ensure

that the buttons are not likely to be

pressed accidentally. Pressing a

button may cause the electronic key

to emit radio waves that could inter-

fere with the operation of the air-

craft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2

years.

●

If the battery becomes low, an

alarm will sound in the cabin and a

message will be shown on the

multi-information display when the

hybrid system is stopped.

●

To reduce key battery depletion

when the electronic key is to not

be used for long periods of time,

set the electronic key to the bat-

tery-saving mode. (



P.125)

●

As the electronic key always

receives radio waves, the battery

will become depleted even if the

electronic key is not used. The fol-

lowing symptoms indicate that the

electronic key battery may be

depleted. Replace the battery

when necessary. (

P.443)

• The smart key system or the wire-

less remote control does not oper-

ate.

• The detection area becomes

smaller.

• The LED indicator on the key sur-

face does not turn on.

●

To avoid serious deterioration, do

not leave the electronic key within

3 ft. (1 m) of the following electri-

cal appliances that produce a

magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones

and battery chargers

• Recharging cellular phones or

cordless phones

• Table lamps

• Induction cookers

●

If the electronic key is near the

vehicle for longer than necessary,

even if the smart key system is not

operated, the key battery may

become depleted faster than nor-

mal.

■

Replacing the battery



P.443

■

If “A New Key has been Regis-

tered Contact Your Dealer for

Details” is shown on the

multi-information display

This message will be displayed

each time the driver’s door is

opened when the doors are

unlocked from the outside for

approximately 10 days after a new

electronic key has been registered.

Keys

The keys

115

3-1. Key information

Before driv

ing

If this message is displayed but you

have not had a new electronic key

registered, ask your Toyota dealer to

check if an unknown electronic key

(other than those in your posses-

sion) has been registered.

The keys are equipped with the
following wireless remote con-
trol:

Locks the doors (



Unlocks the doors (

Opens the windows

(



Opens the trunk (



P.122)

Sounds the alarm (



P.116)

: This setting must be customized

at your Toyota dealer.

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject

them to strong shocks or bend

them.

●

Do not expose the keys to high

temperatures for long periods of

time.

●

Do not get the keys wet or wash

them in an ultrasonic washer

etc.

●

Do not attach metallic or mag-

netic materials to the keys or

place the keys close to such

materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or any-

thing else to the surface of the

key.

●

Do not place the keys near

objects that produce magnetic

fields, such as TVs, audio sys-

tems and induction cookers.

●

Do not place the keys near

medical electrical equipment

such as low-frequency therapy

equipment or microwave ther-

apy equipment, and do not

receive medical attention with

the keys on your person.

■

Carrying the electronic key

on your person

Carry the electronic key 3.9 in.

(10 cm) or more away from elec-

tric appliances that are turned on.

Radio waves emitted from electric

appliances within 3.9 in. (10 cm)

of the electronic key may interfere

with the key, causing the key to

not function properly.

■

In case of a smart key system

malfunction or other

key-related problems

P.495

■

When an electronic key is lost

P.494

Wireless remote control

116

3-1. Key information

■

Panic mode

When

is pressed for longer

than about one second, an alarm

will sound intermittently and the

vehicle lights will flash to deter any

person from trying to break into or

damage your vehicle.
To stop the alarm, press any button

on the electronic key.

To take out the mechanical key,
slide the release button and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one
side. If the key cannot be
inserted in a lock cylinder, turn it
over and re-attempt to insert it.
After using the mechanical key,
store it in the electronic key.
Carry the mechanical key
together with the electronic key.
If the electronic key battery is
depleted or the entry function
does not operate properly, you
will need the mechanical key.
(

■

If you lose your mechanical

keys



P.494

■

If a wrong key is used

The key cylinder rotates freely, iso-

lated from the internal mechanism.

Using the mechanical key

117

3-2. Opening, closing and locking the doors

Before driv

ing

3-2.Opening, closing and locking the doors

■

Smart key system

Carry the electronic key to
enable this function.

Grip the driver’s door handle
to unlock the door. Holding
the driver’s door handle for
approximately 2 seconds
unlocks all the doors. Grip
the front passenger’s door
handle to unlock all the
doors.

Make sure to touch the sensor on
the back of the handle.
The doors cannot be unlocked for 3
seconds after the doors are locked.

: The door unlock settings can be

changed. (



P.117, 528)

Touch the lock sensor (the
indentation on the side of the
front door handle) to lock all
the doors.

Check that the door is securely
locked.

■

Wireless remote control

Locks all the doors

Check that the door is securely
locked.

Unlocks all the doors

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
Press and hold to open the win-
dows.

: This setting must be customized

at your Toyota dealer.

■

Switching the door unlock func-

tion

It is possible to set which doors the

entry function unlocks using the

wireless remote control.

Turn the power switch off.

When the indicator light on the

key surface is not on, press and
hold

for

approximately 5 seconds while
pressing and holding

The setting changes each time an

operation is performed, as shown

below. (When changing the setting

continuously, release the buttons,

wait for at least 5 seconds, and

repeat step

Doors

Unlocking and locking the
doors from the outside

118

3-2. Opening, closing and locking the doors

To prevent unintended triggering of

the alarm, unlock the doors using

the wireless remote control and

open and close a door once after

the settings have been changed. (If

a door is not opened within 60 sec-
onds after

is pressed, the doors

will be locked again and the alarm

will automatically be set.)

In case that the alarm is triggered,

immediately stop the alarm. (



P.89)

■

Operation signals

A buzzer sounds and the emer-

gency flashers flash to indicate that

the doors have been

locked/unlocked using the entry

function or wireless remote control.

(Locked: Once; Unlocked: Twice)
A buzzer sounds to indicate that the

windows are operating.

■

Security feature

If a door is not opened within

approximately 60 seconds after the

vehicle is unlocked using the entry

function or wireless remote control,

the security feature automatically

locks the vehicle again.

■

When the door cannot be

locked by the lock sensor on

the surface of the front door

handle

If the doors cannot be locked by

touching the lock sensor with a fin-

ger, touch the lock sensor with the

palm of your hand.
If you are wearing gloves, remove

them.

■

Door lock buzzer

If an attempt to lock the doors using

the entry function or wireless remote

control is made when a door is not

fully closed, a buzzer will sound

continuously for 5 seconds. Fully

close the door to stop the buzzer,

and lock the doors again.

■

Alarm

Locking the doors will set the alarm

system. (



P.89)

■

Conditions affecting the opera-

tion of the smart key system or

wireless remote control



P.125

■

If the smart key system or the

wireless remote control does

not operate properly

Use the mechanical key to lock and

unlock the doors. (

Replace the key battery with a new

one if it is depleted. (

P.443)

■

If the 12-volt battery is dis-

charged

The doors cannot be locked and

unlocked using the smart key sys-

Multi-informa-

tion display/Beep

Unlocking func-

tion

Exterior: Beeps 3

times

Interior: Pings

once

Holding the
driver’s door
handle unlocks
only the driver’s
door.

Holding the front
passenger’s
door handle
unlocks all the
doors.

Exterior: Beeps

twice

Interior: Pings

once

Holding either
front door handle
unlocks all the
doors.

119

3-2. Opening, closing and locking the doors

Before driv

ing

tem or wireless remote control. Lock

or unlock the doors using the

mechanical key. (



■

Customization

Some functions can be customized.

(

■

Door lock switches (to
lock/unlock)

Locks all the doors

Unlocks all the doors

■

Inside lock buttons

Locks the door

Unlocks the door

WARNING

■

To prevent an accident

Observe the following precautions

while driving the vehicle.

Failure to do so may result in a

door opening and an occupant

being thrown out of the vehicle,

resulting in death or serious injury.

●

Ensure that all doors are prop-

erly closed and locked.

●

Do not pull the inside door han-

dle while driving.

Be especially careful of the front

doors, as the doors may be

opened even if the inside lock

buttons are in the locked posi-

tion.

●

Set the rear door child-protector

locks when children are seated

in the rear seats.

■

When opening or closing a

door

Check the surroundings of the

vehicle such as whether the vehi-

cle is on an incline, whether there

is enough space for a door to

open and whether a strong wind

is blowing. When opening or clos-

ing the door, hold the door handle

tightly to prepare for any unpre-

dictable movement.

■

When using the wireless

remote control and operating

the power windows

Operate the power windows after

checking to make sure that there

is no possibility of any passenger

having any of their body parts

caught in the windows. Also, do

not allow children to operate the

wireless remote control. It is pos-

sible for children and other pas-

sengers to get caught in the

power windows.

Unlocking and locking the
doors from the inside

120

3-2. Opening, closing and locking the doors

The front doors can be opened by
pulling the inside handle even if the
lock buttons are in the lock position.

■

Locking the front doors from

the outside without a key

Move the inside lock button to

the lock position.

Close the door.

The door cannot be locked if the

power switch is in ACC or ON, or

the electronic key is left inside the

vehicle.
The key may not be detected cor-

rectly and the door may be locked.

■

Open door warning buzzer

If a door or the trunk is not fully

closed, a buzzer will sound when

the vehicle speed reaches 3 mph (5

km/h).
The open door(s) or trunk is indi-

cated on the multi-information dis-

play.

The door cannot be opened
from inside the vehicle when
lock is set.

Unlock

Lock

These locks can be set to prevent
children from opening the rear
doors. Push down on each rear

door switch to lock both rear doors.

The following functions can be
set or canceled:

For instructions on customizing,
refer to P.528.

Rear door child-protector
lock

Automatic door locking
and unlocking systems

Function

Operation

Speed linked
door locking
function

All doors are auto-
matically locked
when vehicle
speed is approxi-
mately 12 mph (20
km/h) or higher.

Shift position
linked door
locking func-
tion

All doors are auto-
matically locked
when shifting the
shift lever out of P.

Shift position
linked door
unlocking
function

All doors are auto-
matically unlocked
when shifting the
shift lever to P.

Driver’s door
linked door
unlocking
function

All doors are auto-
matically unlocked
when driver’s door
is opened.

121

3-2. Opening, closing and locking the doors

Before driv

ing

Trunk

The trunk can be opened
using the trunk opener,
entry function or wireless
remote control.

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Before driving

●

Make sure that the trunk lid is

fully closed. If the trunk lid is not

fully closed, it may open unex-

pectedly while driving and hit

near-by objects or luggage in

the trunk may be thrown out,

causing an accident.

●

Do not allow children to play in

the trunk.

If a child is accidentally locked

in the trunk, they could suffer

from heat exhaustion, suffoca-

tion or other injuries.

●

Do not allow a child to open or

close the trunk lid.

Doing so may cause the trunk

lid to open unexpectedly, or

cause the child’s hands, head,

or neck to be caught by the

closing trunk lid.

■

Important points while driving

Never let anyone sit in the trunk.

In the event of sudden braking or

a collision, they are susceptible to

death or serious injury.

■

Using the trunk

Observe the following precau-

tions.

Failure to do so may cause parts

of the body to be caught, resulting

in serious injury.

●

Remove any heavy loads, such

as snow and ice, from the trunk

lid before opening it. Failure to

do so may cause the trunk lid to

suddenly shut again after it is

opened.

●

When opening or closing the

trunk lid, thoroughly check to

make sure the surrounding area

is safe.

●

If anyone is in the vicinity, make

sure they are safe and let them

know that the trunk is about to

open or close.

●

Use caution when opening or

closing the trunk lid in windy

weather as it may move

abruptly in strong wind.

●

The trunk lid may suddenly shut

if it is not opened fully. It is more

difficult to open or close the

trunk lid on an incline than on a

level surface, so beware of the

trunk lid unexpectedly opening

or closing by itself. Make sure

that the trunk lid is fully open

and secure before using the

trunk.

●

When closing the trunk lid, take

extra care to prevent your fin-

gers etc. from being caught.

122

3-2. Opening, closing and locking the doors

■

Trunk opener

Pull the lever upward to release
the trunk lid.

■

Trunk release button

While carrying the electronic
key, press the button on the
trunk lid.
When all the doors are unlocked
using one of the following meth-
ods, the trunk can be opened
without the electronic key:



Entry function



Wireless remote control



Door lock switches



Automatic door unlocking sys-
tem



Mechanical key

■

Wireless remote control

Press and hold the switch.

A buzzer sounds.

■

Trunk light

●

The trunk light turns on when the

trunk is opened.

●

If the trunk light is left on when the

power switch is turned off, the light

will go off automatically after 20

minutes.

■

Function to prevent the trunk

being locked with the electronic

key inside

●

When all doors are locked, closing

the trunk lid with the electronic key

left inside the trunk will sound an

alarm.

In this case, the trunk lid can be

opened pressing the trunk release

button on the trunk lid.

●

If the spare electronic key is put in

the trunk with all the doors locked,

the key confinement prevention

function is activated so the trunk

can be opened. In order to pre-

vent theft, take all electronic keys

WARNING

●

When closing the trunk lid,

make sure to press it lightly on

its outer surface.

●

Do not attach any accessories

other than genuine Toyota parts

to the trunk lid. Such additional

weight on the trunk lid may

cause the lid to suddenly shut

again after it is opened.

Opening the trunk

123

3-2. Opening, closing and locking the doors

Before driv

ing

with you when leaving the vehicle.

●

If the electronic key is put in the

trunk with all the doors locked, the

key may not be detected depend-

ing on the location of the key and

the surrounding radio wave condi-

tions. In this case, the key con-

finement prevention function

cannot be activated, causing the

doors to lock when the trunk is

closed. Make sure to check where

the key is before closing the trunk.

●

The key confinement prevention

function cannot be activated if any

one of the doors is unlocked. In

this case, open the trunk using the

trunk opener.

■

Internal trunk release lever

The trunk lid can be opened by pull-

ing up the glow-in-the-dark lever

located on the inside of the trunk lid.
The lever will continue to glow for

some time after the trunk lid is

closed.

■

If the smart key system or the

wireless remote control does

not operate properly

Replace the key battery with a new

one if it is depleted. (



P.443)

■

Open door warning buzzer

P.120

■

Customization

Some functions can be customized.

(

■

Antenna location

Antennas outside the cabin
Antennas inside the cabin
Antenna inside the trunk
Antenna outside the trunk

Smart key system

The following operations
can be performed simply by
carrying the electronic key
on your person, for example
in your pocket. The driver
should always carry the
electronic key.



Locks and unlocks the
doors (



Opens the trunk (

P.122)



Starts the hybrid system
(

P.153)

124

3-2. Opening, closing and locking the doors

■

Effective range (areas within

which the electronic key is

detected)

When locking or unlocking the
doors

The system can be operated when
the electronic key is within about 2.3
ft. (0.7 m) of either of the front out-
side door handles. (Only the doors
detecting the key can be operated.)

When starting the hybrid system
or changing power switch
modes

The system can be operated when
the electronic key is inside the vehi-
cle.

When opening the trunk

The system can be operated when
the electronic key is within about 2.3
ft. (0.7 m) of the trunk release but-
ton.

■

Alarms and warning messages

A combination of exterior and inte-

rior buzzers as well as warning mes-

sages shown on the

multi-information display are used to

prevent theft of the vehicle and acci-

dents resulting from erroneous

operation. Take appropriate mea-

sures based on the displayed mes-

sage. (

P.471)

When only an alarm sounds, cir-

cumstances and correction proce-

dures are as follows.

●

Exterior buzzer sounds once for 5

seconds

●

Interior buzzer sounds continu-

ously

■

Battery-saving function

The battery-saving function will be

activated in order to prevent the

electronic key battery and the

12-volt battery from being dis-

charged while the vehicle is not

operated for a long time.

●

In the following situations, the

smart key system may take some

time to unlock the doors.

• The electronic key has been left

within approximately 11 ft. (3.5 m)

of the outside of the vehicle for 2

minutes or longer.

• The smart key system has not

Situation

Correction

procedure

An attempt was
made to lock the
vehicle while a door
was open.

Close all of
the doors
and lock the
doors again.

The trunk was closed
while the electronic
key was still inside
the trunk and all the
doors were locked.

Retrieve the
electronic
key from the
trunk and
close the
trunk lid.

Situation

Correction

procedure

The power switch
was turned to ACC
while the driver’s
door was open (or
the driver’s door was
opened while the
power switch was in
ACC).

Turn the
power
switch off
and close
the driver’s
door.

The power switch
was turned to off
while the driver’s
door was open.

Close the
driver’s door

125

3-2. Opening, closing and locking the doors

Before driv

ing

been used for 5 days or longer.

●

If the smart key system has not

been used for 14 days or longer,

the doors cannot be unlocked

from any door except the driver’s

door. In this case, hold the driver’s

door handle, or use the wireless

remote control or mechanical key

to unlock the doors.

■

Electronic key battery-saving

function

When battery-saving mode is set,

battery depletion is minimized by

stopping the electronic key from

receiving radio waves.

Press

twice while pressing and

holding

. Confirm that the elec-

tronic key indicator flashes 4 times.
While the battery-saving mode is

set, the smart key system cannot be

used. To cancel the function, press

any of the electronic key buttons.

■

Conditions affecting operation

The smart key system uses weak

radio waves. In the following situa-

tions, the communication between

the electronic key and the vehicle

may be affected, preventing the

smart key system, wireless remote

control and immobilizer system from

operating properly.

●

When the electronic key battery is

depleted

●

Near a TV tower, electric power

plant, gas station, radio station,

large display, airport or other facil-

ity that generates strong radio

waves or electrical noise

●

When carrying a portable radio,

cellular phone, cordless phone or

other wireless communication

device

●

When the electronic key is in con-

tact with, or is covered by the fol-

lowing metallic objects

• Cards to which aluminum foil is

attached

• Cigarette boxes that have alumi-

num foil inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless keys (that

emit radio waves) are being used

nearby

●

When carrying the electronic key

together with the following devices

that emit radio waves

• Another vehicle’s electronic key or

a wireless key that emits radio

waves

• Personal computers or personal

digital assistants (PDAs)

• Digital audio players

• Portable game systems

●

If window tint with a metallic con-

tent or metallic objects are

attached to the rear window

●

When the electronic key is placed

near a battery charger or elec-

tronic devices

●

When the vehicle is parked in a

pay parking spot where radio

waves are emitted

If the doors cannot be

locked/unlocked using the smart key

system, lock/unlock the doors by

performing any of the following:

●

Bring the electronic key close to

either front door handle and oper-

ate the entry function.

●

Operate the wireless remote con-

trol.

If the doors cannot be

locked/unlocked using the above

methods, use the mechanical key.

(



If the hybrid system cannot be

started using the smart key system,

126

3-2. Opening, closing and locking the doors

refer to P.496.

■

Note for the entry function

●

Even when the electronic key is

within the effective range (detec-

tion areas), the system may not

operate properly in the following

cases:

• The electronic key is too close to

the window or outside door han-

dle, near the ground, or in a high

place when the doors are locked

or unlocked.

• The electronic key is near the

ground or in a high place, or too

close to the center of the rear

bumper when the trunk is opened.

• The electronic key is on the instru-

ment panel, rear package tray or

floor, or in the door pockets or

glove box when the hybrid system

is started or power switch modes

are changed.

●

Do not leave the electronic key on

top of the instrument panel or near

the door pockets when exiting the

vehicle. Depending on the radio

wave reception conditions, it may

be detected by the antenna out-

side the cabin and the door will

become lockable from the outside,

possibly trapping the electronic

key inside the vehicle.

●

As long as the electronic key is

within the effective range, the

doors may be locked or unlocked

by anyone. However, only the

doors detecting the electronic key

can be used to unlock the vehicle.

●

Even if the electronic key is not

inside the vehicle, it may be possi-

ble to start the hybrid system if the

electronic key is near the window.

●

The doors may unlock or lock if a

large amount of water splashes on

the door handle, such as in the

rain or in a car wash when the

electronic key is within the effec-

tive range. (The doors will auto-

matically be locked after

approximately 60 seconds if the

doors are not opened and closed.)

●

If the wireless remote control is

used to lock the doors when the

electronic key is near the vehicle,

there is a possibility that the door

may not be unlocked by the entry

function. (Use the wireless remote

control to unlock the doors.)

●

If the doors have been locked

from outside of the vehicle and are

then not unlocked using the wire-

less remote control or smart key

system, the hybrid system cannot

be started using the smart key

system. (However, if the doors

have been locked from inside the

vehicle, the hybrid system can be

started using the smart key sys-

tem.)

If it is necessary to start the hybrid

system, it can be started using the

procedure in “If the electronic key

dose not operate properly”

(



P.496).

●

Touching the door lock or unlock

sensor while wearing gloves may

prevent lock or unlock operation.

●

When the lock operation is per-

formed using the lock sensor, rec-

ognition signals will be shown up

to two consecutive times. After

this, no recognition signals will be

given.

●

If the door handle becomes wet

while the electronic key is within

the effective range, the door may

lock and unlock repeatedly. In that

case, follow the following correc-

tion procedures to wash the vehi-

cle:

• Place the electronic key in a loca-

tion 6 ft. (2 m) or more away from

the vehicle. (Take care to ensure

that the key is not stolen.)

• Set the electronic key to bat-

tery-saving mode to disable the

smart key system. (



P.125)

●

If the electronic key is inside the

vehicle and a door handle

becomes wet during a car wash, a

message may be shown on the

multi-information display and a

buzzer will sound outside the vehi-

127

3-2. Opening, closing and locking the doors

Before driv

ing

cle. To turn off the alarm, lock all

the doors.

●

The lock sensor may not work

properly if it comes into contact

with ice, snow, mud, etc. Clean

the lock sensor and attempt to

operate it again.

●

A sudden handle operation or a

handle operation immediately

after entering the effective range

may prevent the doors from being

unlocked. Touch the door unlock

sensor and check that the doors

are unlocked before pulling the

door handle again.

●

If there is another electronic key in

the detection area, it may take

slightly longer to unlock the doors

after the door handle is gripped.

■

When the vehicle is not driven

for extended periods

●

To prevent theft of the vehicle, do

not leave the electronic key within

6 ft. (2 m) of the vehicle.

●

The smart key system can be

deactivated in advance. (



●

Setting the electronic key to bat-

tery-saving mode helps to reduce

key battery depletion. (



P.125)

■

To operate the system properly

●

Make sure to carry the electronic

key when operating the system.

Do not get the electronic key too

close to the vehicle when operat-

ing the system from the outside of

the vehicle.

Depending on the position and hold-

ing condition of the electronic key,

the key may not be detected cor-

rectly and the system may not oper-

ate properly. (The alarm may go off

accidentally, or the door lock pre-

vention function may not operate.)

●

Do not leave the electronic key

inside the trunk.

The key confinement prevention

function may not operate, depend-

ing on the location of the key (the

inside edge of the trunk), condi-

tions (inside a metal bag, close to

metallic objects) and the radio

waves in the surrounding area.

(



P.122)

■

If the smart key system does

not operate properly

●

Locking and unlocking the doors:



P.495

●

Starting the hybrid system:



P.496

■

Customization

Some functions can be customized.

(



■

If the smart key system has

been deactivated in a custom-

ized setting

●

Locking and unlocking the doors:

Use the wireless remote control or

mechanical key. (
