Toyota Mirai (2022 year). Manual in english - page 21

339

6-1. Using the air conditioning system and defogger

Interior

featur

Press the switch to turn the sys-
tem on/off.

The indicator comes on when the
system is on.
The windshield wiper de-icer will
automatically turn off after approxi-
mately 15 minutes.

Air conditioner operation
screen select switch

Rear air conditioning control
screen select switch

Select the air conditioner opera-
tion screen with the Toyota
multi-operation touch, and then
select the rear air conditioner
operation screen.

If you do not operate for more than
20 seconds after switching to the
rear air conditioner operation
screen, it will return to the front air
conditioner operation screen.

Adjust the rear seat tempera-
ture setting

Adjust the rear seat airflow
mode setting

: Air flows to the upper body

: Air flows to the upper body and

feet

: Air flows to the feet

■

Location of air outlets

The air outlets and air volume
change according to the
selected air flow mode.

WARNING

■

To prevent burns

Do not touch the glass at lower

part of the windshield or to the

side of the front pillars when the

windshield wiper deicer is on.

Rear air conditioning con-
trol screen (Vehicles with
3-ZONE climate control)

Air outlet layout and oper-
ations

340

6-1. Using the air conditioning system and defogger

■

Adjusting the air flow direc-
tion and opening/closing
the air outlets



Front

Direct air flow to the left or
right, up or down

Open the vent

Close the vent



Rear

Direct air flow to the left or
right, up or down

Open the vent

Close the vent

WARNING

■

To not interrupt the wind-

shield defogger from operat-

ing

Do not place anything on the

instrument panel which may cover

the air outlets. Otherwise, air flow

may be obstructed, preventing the

windshield defoggers from defog-

ging.

341

6-1. Using the air conditioning system and defogger

Interior

featur

: If equipped

■

Rear control panel

The rear A/C can be operated
by turning the rear control panel
ON using the ON/OFF switch.
When the front seat A/C is OFF,
the rear A/C cannot be turned
ON independently.

Rear control panel ON/OFF
switch.

Rear seat Airflow mode con-
trol switch

Rear seat temperature con-
trol switch

The temperature setting of the
rear seats can be adjusted using
the following methods:



When the “3-ZONE” indicator
is off: Adjust the driver’s seat
temperature.



Adjust the temperature setting
of rear seat using the Toyota
multi-operation touch (rear air
conditioning control screen)
or rear control panel.

■

Location of air outlets

The air outlets and air volume
changes according to the
selected air flow mode.

: Air flows to the upper body

and feet

: Air flows to the feet

Rear automatic air

conditioning system

The air outlets and fan
speed are automatically
adjusted according to the
temperature setting.

Rear air conditioning con-
trol

Adjusting the temperature
setting of the rear seats

Air outlet layout and oper-
ations

342

6-1. Using the air conditioning system and defogger

■

Adjusting the position of
and opening and closing
the air outlets



Rear

Direct air flow to the left or
right, up or down

Open the vent

Close the vent

: If equipped

NOTICE

■

To prevent 12-volt battery dis-

charge

Do not leave the air conditioning

system on longer than necessary

when the fuel cell system is off.

Heated steering

wheel

/seat heat-

ers

/seat ventilators



Heated steering wheel

Warms up the grip of the
steering wheel



Front seat heaters/Rear
seat heaters

Warm up the seat upholstery



Front seat ventilators/Rear
seat ventilators

Maintain good ventilation by
pulling air through the seat
upholstery

It can be operated using the
front air conditioner
switches and the Toyota
multi-operation touch, as
well as the rear control
panel (if equipped).

WARNING

■

To prevent minor burn inju-

ries

Care should be taken if anyone in

the following categories comes in

contact with the steering wheel or

seats when the heater is on:

●

Babies, small children, the

elderly, the sick and the physi-

cally challenged

●

Persons with sensitive skin

●

Persons who are fatigued

343

6-1. Using the air conditioning system and defogger

Interior

featur

■

Front (air conditioning con-
trol panel: vehicle with a
12.3-inch display)

Adjust the front seat heater
temperature level

The seat heater can be adjusted in
3 levels. (Low, Mid or Hi)

Seat heater/seat ventilator
auto mode Indicator

Adjust the front seat ventila-
tor fan speed level

The seat ventilator can be adjusted
in 3 levels. (Low, Mid or Hi)

■

Toyota multi-operation
touch (Vehicle with a 12.3-
inch display)

Select the

displayed on the

Toyota multi-operation touch
and the Seat/Steering Climate
screen is displayed.

Adjust the seat heater tem-
perature level

The seat heater can be adjusted in
3 levels. (Low, Mid or Hi)

Adjust the heated steering
wheel temperature level

The heated steering wheel can be
adjusted in 2 levels. (Low or Hi)

Adjust the seat ventilator fan
speed level

The seat ventilator can be adjusted
in 3 levels. (Low, Mid or Hi)

ALL AUTO control switch

When the ALL AUTO control is on,
the indicator illuminates on the
screen. (



P.324)

WARNING

●

Persons who have taken alco-

hol or drugs that induce sleep

(sleeping drugs, cold remedies,

etc.)

NOTICE

■

To prevent damage to the

seat heaters and seat ventila-

tors

Do not put heavy objects that

have an uneven surface on the

seat and do not stick sharp

objects (needles, nails, etc.) into

the seat.

■

To prevent 12-volt battery dis-

charge

Do not use the functions when the

fuel cell system is off.

Operating instructions

344

6-1. Using the air conditioning system and defogger

■

Rear control panel (if
equipped)

Adjust the rear seat heater
temperature level

The seat heater can be adjusted in
3 levels. (Low, Mid or Hi)

Adjust the rear right side seat
ventilator fan speed level

The seat ventilator can be adjusted
in 3 levels. (Low, Mid or Hi)

Indicators

■

The heated steering wheel, seat

heaters and seat ventilators can

be used when

The power switch is in ON.

■

Air conditioning system-linked

control mode

When the seat ventilator fan speed

level is Hi, the seat ventilator fan

speed becomes higher according to

the fan speed of the air conditioning

system.

■

When the air conditioning sys-

tem is operating in S-FLOW

mode

If a passenger is not detected in the

passenger seat, the seat ventilator

and seat heater of the passenger’s

seat will be turned off if on.

(



P.338)

■

Change settings for the rear

control panel

The following settings can be

changed.
• Reaction time after touching the

button.

• Turn button operation sounds

ON/OFF

Stop the vehicle in a safe place

and stop the fuel cell system.

Press the power switch 1 time

with brake pedal released and

switch the mode to ACC.

The setting cannot be changed

when the power switch is ON.

Press

for 10 seconds or

more while pressing the

but-

ton.

Release the button after the

buzzer sounds.

Select customizable item

Change the reaction time for button

operations:

When

is pressed it becomes

faster, when

is pressed it

becomes slower.
Change the button operation

sounds ON/OFF

When

is pressed it turns ON,

when

is pressed it turns OFF.

When changes are complete, the

indicators for the seat

heater/seat ventilator turns on as

shown in the following table.

345

6-1. Using the air conditioning system and defogger

Interior

featur

Settings are complete with any of

the following.

• Operate the

button and turn

OFF the rear control panel.

• Press the power switch.
• Do not operate the power switch

for approximately 10 seconds.

■

Customization

Some functions can be customized.

(



P.508)

Function

Settings

Indicator

Reaction
Time

Fast

A little fast

Normal

A little
slow

Slow

Operation
sounds

OFF

WARNING

■

To prevent overheating and

minor burn injuries

Observe the following precautions

when using the seat heaters.

●

Do not cover the seat with a

blanket or cushion when using

the seat heater.

●

Do not use seat heater more

than necessary.

346

6-2. Using the interior lights

6-2.Using the interior lights

Door trim ornament lights (



P.347) (if equipped)

Rear personal lights (



P.347)

Inside door handle lights (



P.347) (if equipped)

Front personal lights (



P.347)

Shift lever lights (if equipped)

Interior lights (



P.347)

Outer foot lights (if equipped)

Front footwell lights (if equipped)

Instrument panel ornament lights (



P.347) (if equipped)

Cup holder lights (



P.347)

Rear footwell lights (if equipped)

Door courtesy lights

Interior lights list

Location of the interior lights

347

6-2. Using the interior lights

Interior

featur

■

Turning the door position
on

Press the door-linked interior
light switch

The lights are turned on and off
according to whether the doors are
opened/closed.

■

Turning the lights on/off

Touch the light

The rear personal lights turn on/off
along with the interior lights.

■

Turning the lights on/off

Touch the light

■

Turning the lights on/off

Press the switch

The rear personal lights turn on/off
along with the interior lights.

Using the Toyota multi-operation
touch (



P.353), one of 8 colors

of following lights can be
selected. However, it cannot be
changed individually.



Inside door handle lights



Door trim ornament lights



Cup holder lights



Instrument panel ornament
lights

Operating the interior
lights

Operating the front per-
sonal lights

Operating the rear per-
sonal lights

Changing the illumina-
tion color (if equipped)

348

6-2. Using the interior lights

Select

Select “Illumination Color”.

Select the desired color.

■

Illuminated entry system

The lights automatically turn on/off

according to the power switch

mode, the presence of the elec-

tronic key, whether the doors are

locked/unlocked, and whether the

doors are open/closed.

■

To prevent the 12-volt battery

from being discharged

If the interior lights remain on when

the power switch is turned off, the

lights will go off automatically after

20 minutes.

■

When the interior lights or front

personal lights do not respond

as normal

●

When water, dirt, etc., have

adhered to the lens surface

●

When operated with a wet hand

●

When wearing gloves, etc.

■

The interior lights may turn on

automatically when

If any of the SRS airbags deploy

(inflate) or in the event of a strong

rear impact, the interior lights will

turn on automatically.
The interior lights will turn off auto-

matically after approximately 20min-

utes.
The interior lights can be turned off

manually. However, in order to help

prevent further collisions, it is rec-

ommended that they be left on until

safety can be ensured.
(The interior lights may not turn on

automatically depending on the

force of the impact and conditions of

the collision.)

■

Customization

Some functions can be customized.

(



P.498)

NOTICE

■

To prevent 12-volt battery dis-

charge

Do not leave the lights on longer

than necessary when the fuel cell

system is off.

■

Removing light lenses

Never remove the lens for the

interior lights and front personal

lights. Otherwise, the lights will be

damaged. If a lens needs to be

removed, contact your Toyota

dealer.

349

6-3. Using the storage features

Interior

featur

6-3.Using the storage features

Auxiliary boxes

(



P.351)

Cup holders (



P.350)

Console box (



P.351)

Glove box (



P.349)

: If equipped

Pull up the lever to open.

List of storage features

Location of the storage features

WARNING

■

Items that should not be left

in the storage spaces

Do not leave glasses, lighters or

spray cans in the storage spaces,

as this may cause the following

when cabin temperature becomes

high:

●

Glasses may be deformed by

heat or cracked if they come

into contact with other stored

items.

●

Lighters or spray cans may

explode. If they come into con-

tact with other stored items, the

lighter may catch fire or the

spray can may release gas,

causing a fire hazard.

Glove box

350

6-3. Using the storage features

Unlock with the mechanical
key

Lock with the mechanical key

■

Glove box light

The glove box light turns on when

the tail lights are on.

■

Trunk opener main switch

The trunk opener main switch is

located in the glove box. (



P.129)



Front



Rear (vehicles without rear
seat heater)

Press in and release the button.



Rear (vehicles with rear seat
heater)

Press in and release the button.

WARNING

■

Caution while driving

Keep the glove box closed. In the

event of sudden braking or sud-

den swerving, an accident may

occur due to an occupant being

struck by the open glove box or

the items stored inside.

Cup holders

WARNING

■

Items unsuitable for the cup

holder

Do not place anything other than

cups or beverage cans in the cup

holders.

Inappropriate items must not be

stored in the cup holders even if

the lid is closed.

Other items may be thrown out of

the holders in the event of an

accident or sudden braking and

cause injury. If possible, cover hot

drinks to prevent burns.

■

When not in use

Keep the cup holders closed.

Injuries may result in the event of

an accident or sudden braking.

351

6-3. Using the storage features

Interior

featur

Press a button to open the con-
sole box.



Overhead (vehicles without
electronic sunshade)

Push in and release the auxiliary
box.

This box is useful for temporarily
storing the small items.



Rear seat (vehicles with rear
seat heater)

Pull the armrest down then push
the knob and lift the lid to open

it.

Console box

WARNING

■

Caution while driving

Keep the console box closed.

Injuries may result in the event of

an accident or sudden braking.

Auxiliary boxes

WARNING

■

Caution while driving

Do not leave the auxiliary box

open while driving.

Items may fall out and cause

death or serious injury in case of

an accident or sudden stop.

■

Items unsuitable for storing

(overhead)

Do not store items heavier than

0.4 lb. (0.2 kg).

Doing so may cause the auxiliary

box to open and the items inside

may fall out, resulting in an acci-

dent.

352

6-3. Using the storage features



Side covers

Lift the side covers and remove
it.



Luggage mat

Pull the strap upwards and lift
up the luggage mat.

Lift the luggage mat until it
engages with the hook.

The warning reflector can be
stowed underneath the luggage
mat.

Trunk features

Luggage mats

NOTICE

■

To prevent damage to the

hook for the luggage mat

Do not hang a grocery bag or any

other object from the hook.

Warning reflector

353

6-4. Using the other interior features

Interior

featur

6-4.Using the other interior features

The following functions can be
displayed and operated on the
side display.

Operate a button to change the dis-
played function screen.
The displayed function can be
changed by performing an up or
down flick operation on the side dis-
play.

Select to display the air con-
ditioning control screen.
(



P.332)

Select to display the seat
heater/ventilation control
screen, etc.

(



P.343)

Select to display the audio
control screen.

Select to display the energy
monitor/fuel consumption
screen, etc. (



P.113)

Select to display the settings
screen and software informa-
tion. (



P.354)

:If equipped

:Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

Toyota multi-opera-

tion touch (vehicle

with the 12.3-inch dis-

play)

The Toyota multi-operation
touch allows screens, such
as the air conditioning con-
trol screen and the naviga-
tion screen, to be displayed
and operated simultane-
ously.

For details about the opera-
tion of the Toyota multi-
operation touch, refer to
“NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S
MANUAL”.

Toyota multi-operation
touch overview

354

6-4. Using the other interior features

■

Moving screens on the Toy-
ota multi-operation touch

Selecting

to change its

displayed position of the side
display to the left or right side of
the screen.
The screen position can also be
changed by perform a left or
right flick operation on a screen.

■

Displaying a screen in full
screen

Selecting

on the

energy monitor/consumption
screen or vehicle information
screen will display that screen in
full screen.
Select

to return to the

split-screen display.

Select

on the side display to

display the setting screen.

Select to change the interior

illumination light color.

(



P.347)

Select to turn flick operation
on the side display on/off.

Display the software informa-
tion.

: If equipped

■

Software license

Toyota multi-operation
touch operation

Settings and software
information

Content .. 19 20 21 22 ..
