Toyota Mirai (2022 year). Manual in english

163

5-1. Before driving

ing

WARNING

■

When starting the vehicle

Always keep your foot on the

brake pedal while stopped with

the “READY” indicator is illumi-

nated. This prevents the vehicle

from creeping.

■

When driving the vehicle

●

Do not drive if you are unfamil-

iar with the location of the brake

and accelerator pedals to avoid

depressing the wrong pedal.

• Accidentally depressing the

accelerator pedal instead of the

brake pedal will result in sudden

acceleration that may lead to an

accident.

• When backing up, you may twist

your body around, leading to dif-

ficulty in operating the pedals.

Make sure to operate the pedals

properly.

• Make sure to keep a correct

driving posture even when mov-

ing the vehicle only slightly. This

allows you to depress the brake

and accelerator pedals properly.

• Depress the brake pedal using

your right foot. Depressing the

brake pedal using your left foot

may delay response in an emer-

gency, resulting in an accident.

●

The driver should pay extra

attention to pedestrians as this

vehicle is powered only by an

electric motor (traction motor).

As there is no engine noise, the

pedestrians may misjudge the

vehicle’s movement. Even with

the acoustic vehicle alerting

system activate, drive with care

as pedestrians in the vicinity

may still not notice the vehicle if

the surrounding area is noisy.

●

During normal driving, do not

turn off the fuel cell system.

Turning the fuel cell system off

while driving will not cause loss

of steering or braking control,

however, power assist to the

steering will be lost. This will

make it more difficult to steer

smoothly, so you should pull

over and stop the vehicle as

soon as it is safe to do so.

In the event of an emergency,

such as if it becomes impossible

to stop the vehicle in the normal

way:



P.432

●

Using the brakes continuously

may cause the brakes to over-

heat and lose effectiveness

when driving down a steep hill.

●

Do not adjust the positions of

the steering wheel, the seat, or

the inside or outside rear view

mirrors while driving.

Doing so may result in a loss of

vehicle control.

●

Always check that all passen-

gers’ arms, heads or other parts

of their body are not outside the

vehicle.

●

Do not drive in excess of the

speed limit. Even if the legal

speed limit permits it, do not

drive over 85 mph (140 km/h)

unless your vehicle has high-

speed capability tires. Driving

over 85 mph (140 km/h) may

result in tire failure, loss of con-

trol and possible injury. Be sure

to consult a tire dealer to deter-

mine whether the tires on your

vehicle are high-speed capabil-

ity tires or not before driving at

such speeds.

■

When driving on slippery

road surfaces

●

Sudden braking, acceleration

and steering may cause tire

slippage and reduce your ability

to control the vehicle.

164

5-1. Before driving

WARNING

●

Sudden acceleration or regen-

erative braking due to shifting

could cause the vehicle to skid.

●

After driving through a puddle,

lightly depress the brake pedal

to make sure that the brakes

are functioning properly. Wet

brake pads may prevent the

brakes from functioning prop-

erly. If the brakes on only one

side are wet and not functioning

properly, steering control may

be affected.

■

When shifting the shift posi-

tion

●

Do not let the vehicle roll back-

ward while a forward driving

position is selected, or roll for-

ward while the shift position is in

Doing so may result in an acci-

dent or damage to the vehicle.

●

Do not shift the shift position to

P while the vehicle is moving.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Do not shift the shift position to

R while the vehicle is moving

forward.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Do not shift the shift position to

a driving position while the vehi-

cle is moving backward.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Changing the shift position to N

while the vehicle is moving will

disengage the fuel cell system.

Regenerative braking is not

available with the fuel cell sys-

tem disengaged.

●

Be careful not to change the

shift position with the accelera-

tor pedal depressed. Changing

the shift position to any posi-

tions other than P or N may lead

to unexpected rapid accelera-

tion of the vehicle that may

cause an accident and result in

death or serious injury.

After changing the shift position,

make sure to confirm the cur-

rent shift position displayed on

the shift position indicator inside

the meter.

■

If you hear a squealing or

scraping noise (brake pad

wear limit indicators)

Have the brake pads checked and

replaced by your Toyota dealer as

soon as possible.

Rotor damage may result if the

pads are not replaced when

needed.

It is dangerous to drive the vehicle

when the wear limits of the brake

pads and/or those of the brake

discs are exceeded.

■

When the vehicle is stopped

●

Do not depress the accelerator

pedal unnecessarily.

If the shift position is in any

position other than P or N, the

vehicle may accelerate sud-

denly and unexpectedly, caus-

ing an accident.

●

In order to prevent accidents

due to the vehicle rolling away,

always keep depressing the

brake pedal while stopped with

the “READY” indicator is illumi-

nated, and apply the parking

brake as necessary.

165

5-1. Before driving

ing

WARNING

●

If the vehicle is stopped on an

incline, in order to prevent acci-

dents caused by the vehicle roll-

ing forward or backward, always

depress the brake pedal and

securely apply the parking

brake as needed.

■

When the vehicle is parked

●

Do not leave glasses, cigarette

lighters, spray cans, or soft

drink cans in the vehicle when it

is in the sun.

Doing so may result in the fol-

lowing:

• Gas may leak from a cigarette

lighter or spray can, and may

lead to a fire.

• The temperature inside the

vehicle may cause the plastic

lenses and plastic material of

glasses to deform or crack.

• Soft drink cans may fracture,

causing the contents to spray

over the interior of the vehicle,

and may also cause a short cir-

cuit in the vehicle’s electrical

components.

●

Do not leave cigarette lighters in

the vehicle. If a cigarette lighter

is in a place such as the glove

box or on the floor, it may be lit

accidentally when luggage is

loaded or the seat is adjusted,

causing a fire.

●

Do not attach adhesive discs to

the windshield or windows. Do

not place containers such as air

fresheners on the instrument

panel or dashboard. Adhesive

discs or containers may act as

lenses, causing a fire in the

vehicle.

●

Do not leave a door or window

open if the curved glass is

coated with a metallized film

such as a silver-colored one.

Reflected sunlight may cause

the glass to act as a lens, caus-

ing a fire.

●

Always apply the parking brake,

shift the shift position to P, stop

the fuel cell system and lock the

vehicle.

Do not leave the vehicle unat-

tended while the “READY” indi-

cator is illuminated.

If the vehicle is parked with the

shift position in P but the park-

ing brake is not set, the vehicle

may start to move, possibly

leading to an accident.

■

When taking a nap in the vehi-

cle

Always turn the fuel cell system

off. Otherwise, if you accidentally

move the shift lever or depress

the accelerator pedal, causing the

vehicle to unintentionally move,

which can lead to an accident,

resulting in death or serious injury.

■

When braking

●

When the brakes are wet, drive

more cautiously.

Braking distance increases

when the brakes are wet, and

this may cause one side of the

vehicle to brake differently than

the other side. Also, the parking

brake may not securely hold the

vehicle.

●

If the electronically controlled

brake system does not operate,

do not follow other vehicles

closely and avoid hills or sharp

turns that require braking.

In this case, braking is still pos-

sible, but the brake pedal

should be depressed more

firmly than usual. Also, the brak-

ing distance will increase. Have

your brakes fixed immediately.

166

5-1. Before driving

WARNING

●

The brake system consists of 2

or more individual hydraulic sys-

tems; if one of the systems fails,

the other(s) will still operate. In

this case, the brake pedal

should be depressed more

firmly than usual and the brak-

ing distance will increase. Have

your brakes fixed immediately.

NOTICE

■

When driving the vehicle

●

Do not depress the accelerator

and brake pedals at the same

time during driving, as this may

restrain the fuel cell system out-

put.

●

Do not use the accelerator

pedal or depress the accelera-

tor and brake pedals at the

same time to hold the vehicle on

a hill.

■

When parking the vehicle

Always set the parking brake, and

shift the shift position to P. Failure

to do so may cause the vehicle to

move or the vehicle may acceler-

ate suddenly if the accelerator

pedal is accidentally depressed.

■

Avoiding damage to vehicle

parts

●

Do not turn the steering wheel

fully in either direction and hold

it there for an extended period

of time.

Doing so may damage the

power steering motor.

●

When driving over bumps in the

road, drive as slowly as possible

to avoid damaging the wheels,

underside of the vehicle, etc.

■

If you get a flat tire while driv-

ing

A flat or damaged tire may cause

the following situations. Hold the

steering wheel firmly and gradu-

ally depress the brake pedal to

slow down the vehicle.

●

It may be difficult to control your

vehicle.

●

The vehicle will make abnormal

sounds or vibrations.

●

The vehicle will lean abnor-

mally.

Information on what to do in case

of a flat tire (



P.455)

■

When encountering flooded

roads

Do not drive on a road that has

flooded after heavy rain, etc.

Doing so may cause the following

serious damage to the vehicle:

●

Fuel cell system stalling

●

Short in electrical components

●

Fuel cell system damage

caused by water immersion

In the event that you drive on a

flooded road and the vehicle is

flooded, be sure to have your Toy-

ota dealer check the following:

●

Fuel cell system

●

Brake function

●

Changes in quantity and quality

of transmission fluid, etc.

●

Lubricant condition for the bear-

ings and suspension joints

(where possible), and the func-

tion of all joints, bearings, etc.

167

5-1. Before driving

ing

When the following unusual
operation is performed with the
accelerator pedal depressed,
the fuel cell system output may
be restrained.
• When the shift position is

shifted to R

• When the shift position is

shifted from P or R to forward
drive shift position such as D

When the system operates, a mes-
sage appears on the multi-informa-
tion display. Read the message and
follow the instruction.

: Depending on the situation, the

shift position may not be
changed.

■

Drive-Start Control (DSC)

●

When the TRAC is turned off

(



P.316), sudden start restraint

control also does not operate. If

your vehicle have trouble escap-

ing from the mud or fresh snow

due to sudden start restraint con-

trol operation, deactivate TRAC

(



P.316) so that the vehicle may

become able to escape from the

mud or fresh snow.

Cargo capacity depends on the
total weight of the occupants.
(Cargo capacity) = (Total load
capacity) — (Total weight of
occupants)
Steps for Determining Correct
Load Limit —
(1) Locate the statement “The
combined weight of occupants
and cargo should never exceed
XXX kg or XXX lbs.” on your
vehicle’s placard.
(2) Determine the combined
weight of the driver and passen-
gers that will be riding in your
vehicle.
(3) Subtract the combined
weight of the driver and passen-
gers from XXX kg or XXX lbs.
(4) The resulting figure equals
the available amount of cargo
and luggage load capacity.
For example, if the “XXX”
amount equals 1400 lbs. and
there will be five 150 lb passen-
gers in your vehicle, the amount
of available cargo and luggage
load capacity is 650 lbs. (1400 −

NOTICE

If the shift control system is dam-

aged by flooding, it may not be

possible to shift the shift position

to P, or from P to other positions.

In this case, contact your Toyota

dealer.

Sudden start restraint
control (Drive-Start Con-
trol [DSC])

Cargo and luggage

Take notice of the following
information about storage
precautions, cargo capacity
and load:

Capacity and distribution

168

5-1. Before driving

750 (5



150) = 650 lbs.)

(5) Determine the combined
weight of luggage and cargo
being loaded on the vehicle.
That weight may not safely
exceed the available cargo and
luggage load capacity calcu-
lated in Step 4.
(6) If your vehicle will be towing
a trailer, load from your trailer
will be transferred to your vehi-
cle. Consult this manual to
determine how this reduces the
available cargo and luggage
load capacity of your vehicle.
(



P.170)

Toyota does not recommend towing
a trailer with your vehicle. Your
vehicle is not designed for trailer
towing.

Cargo capacity

Total load capacity (vehicle
capacity weight) (



P.482)

When 2 people with the com-
bined weight of A lb. (kg) are rid-
ing in your vehicle, which has a

total load capacity (vehicle
capacity weight) of B lb. (kg),
the available amount of cargo
and luggage load capacity will
be C lb. (kg) as follows:

lb. (kg) - A

lb. (kg) = C

lb.

(kg)

:A =Weight of people

:B =Total load capacity

:C =Available cargo and luggage

load

In this condition, if 3 more passen-
gers with the combined weight of D
lb. (kg) get on, the available cargo
and luggage load will be reduced E
lb. (kg) as follows:

C lb. (kg) - D

lb. (kg) = E

lb.

(kg)

:D =Additional weight of people

:E =Available cargo and luggage

load

As shown in the example above,
if the number of occupants
increases, the cargo and lug-
gage load will be reduced by an
amount that equals the
increased weight due to the
additional occupants. In other
words, if an increase in the num-
ber of occupants causes an
excess of the total load capacity
(combined weight of occupants
plus cargo and luggage load),
you must reduce the cargo and
luggage on your vehicle.

Calculation formula for
your vehicle

169

5-1. Before driving

ing

WARNING

■

Things that must not be car-

ried in the trunk

The following things may cause a

fire if loaded in the trunk:

●

Receptacles containing gaso-

line

●

Aerosol cans

■

Storage precautions

Observe the following precau-

tions.

Failure to do so may prevent the

pedals from being depressed

properly, may block the driver’s

vision, or may result in items hit-

ting the driver or passengers, pos-

sibly causing an accident.

●

Stow cargo and luggage in the

trunk whenever possible.

●

Do not place cargo or luggage

in or on the following locations.

• At the feet of the driver

• On the front passenger or rear

seats (when stacking items)

• On the package tray

• On the instrument panel

• On the dashboard

●

Secure all items in the occupant

compartment.

■

Capacity and distribution

●

Do not exceed the maximum

axle weight rating or the total

vehicle weight rating.

●

Even if the total load of occu-

pant’s weight and the cargo

load is less than the total load

capacity, do not apply the load

unevenly. Improper loading may

cause deterioration of steering

or braking control which may

cause death or serious injury.

NOTICE

■

Roof film (vehicles with elec-

tronic sunshade)

Do not attach a roof carrier on the

roof film. It may damage the film

surface.

170

5-1. Before driving

■

Total load capacity and seating

capacity

These details are also described on

the tire and loading information

label. (



P.415)

Vehicle load limits

Vehicle load limits include
total load capacity, seating
capacity, towing capacity
and cargo capacity.



Total load capacity (vehicle
capacity weight):



P.482

Total load capacity means the
combined weight of occu-
pants, cargo and luggage.



Seating capacity:



P.482

Seating capacity means the
maximum number of occu-
pants whose estimated aver-
age weight is 150 lb. (68 kg)
per person.



TWR (Trailer Weight Rat-
ing)

Toyota does not recommend
towing a trailer with your vehi-
cle.



Cargo capacity

Cargo capacity may increase
or decrease depending on the
weight and the number of
occupants.

WARNING

■

Overloading the vehicle

Do not overload the vehicle.

It may not only cause damage to

the tires, but also degrade steer-

ing and braking ability, resulting in

an accident.

172

5-2. Driving procedures

5-2.Driving procedures

Pull the parking brake switch
to check that the parking
brake is set. (



P.183)

The parking brake indicator will

come on.

Firmly depress the brake
pedal.

and a message will be dis-

played on the multi-information dis-

play.

If it is not displayed, the fuel cell

system cannot be started.
When the shift position is N, the

fuel cell system cannot start. Shift

the shift position to P when starting

the fuel cell system. (



P.178)

Press the power switch
shortly and firmly.

When operating the power switch,

one short, firm press is enough. It is

not necessary to press and hold the

switch.
If the “READY” indicator turns on,

the fuel cell system will operate nor-

mally.
Continue depressing the brake

pedal until the “READY” indicator is

illuminated.
The fuel cell system can be started

from any power switch mode.

Check that the “READY” indi-
cator is illuminated.

The vehicle cannot be driven if the

“READY” indicator is off.

■

Starting the fuel cell system in

cold temperatures

●

When the fuel cell system is

started during cold temperatures,

the fuel cell stack quickly warms

up using waste heat during power

generation. Operation noises will

be louder than usually, but this is

not a malfunction. Depending on

the situation, the operation noises

may also continue for a fixed

period of time after the “READY”

indicator is turned on. (



P.75)

●

When the temperatures are cold,

it may take more time than usual

until the “READY” indicator turns

on. In those cases, the progress

state is displayed in the multi-

information display.

“FCV System is Warmed Up
Waiting...”

●

When starting the fuel cell system

during cold weather, “FCV System

Power switch

Performing the following
operations when carrying
the electronic key on your
person starts the fuel cell
system or changes power
switch modes.

Starting the fuel cell sys-
tem

173

5-2. Driving procedures

ing

Shutdown Due to Freezing Stop in

a Safe Place See Owner’s Man-

ual” may be displayed in the multi-

information display.

The fuel cell system is frozen and
cannot be started. Contact your Toy-
ota dealer.

●

The power output will be tempo-

rarily limited until the fuel cell sys-

tem reaches full operating

temperature.

●

When the traction battery is

extremely cold (below approxi-

mately -22˚F [-30˚C]) under the

influence of outside temperature,

it may not be possible to start the

fuel cell system. In this case, try to

start the fuel cell system again

after the temperature of the trac-

tion battery increases due to the

outside temperature increase etc.

■

If the fuel cell system does not

start

●

The immobilizer system may not

have been deactivated. (



P.69)

Contact your Toyota dealer.

●

If a message related to start-up is

shown on the multi-information

display, read the message and fol-

low the instructions.

●

Check that the fuel door is closed.

When the fuel door is open, the

fuel cell system cannot be started.

Close the fuel door before starting

the system. (



P.205)

■

Sounds and vibrations specific

to a fuel cell vehicle



P.75

■

If the 12-volt battery is dis-

charged

The fuel cell system cannot be

started using the smart key system.

Refer to P.471to restart the fuel cell

system.

■

Electronic key battery depletion



P.118

■

Conditions affecting operation



P.132

■

Notes for the entry function



P.132

■

If “Smart Key System Malfunc-

tion See Owner’s Manual” is

displayed on the multi-informa-

tion display

The system may be malfunctioning.

Have the vehicle inspected by your

Toyota dealer immediately.

■

Steering lock function

●

After turning the power switch off

and opening and closing the

doors, the steering wheel will be

locked due to the steering lock

function. Operating the power

switch again automatically can-

cels the steering lock.

●

When the steering lock cannot be

released, “Push Power Switch

while Turning Steering Wheel in

Either Direction” will be displayed

on the multi-information display.

Press the power switch shortly

and firmly while turning the steer-

ing wheel left and right.

●

To prevent the steering lock motor

from overheating, the motor may

be suspended if the fuel cell sys-

tem is turned on and off repeat-

edly in a short period of time. In

this case, refrain from operating

the power switch. After about 10

seconds, the steering lock motor

will resume functioning.

■

If the “READY” indicator does

not come on

In the event that the “READY” indi-

cator does not come on even after

174

5-2. Driving procedures

performing the proper procedures

for starting the vehicle, contact your

Toyota dealer immediately.

■

If the fuel cell system is mal-

functioning



P.451

■

Electronic key battery



P.423

■

Operation of the power switch

●

If the switch is not pressed shortly

and firmly, the power switch mode

may not change or the fuel cell

system may not start.

●

If attempting to restart the fuel cell

system immediately after turning

the power switch off, the fuel cell

system may not start in some

cases. After turning the power

switch off, please wait a few sec-

onds before restarting the fuel cell

system.

■

Customization

If the smart key system has been

deactivated in a customized setting,

refer to P.468.

Stop the vehicle completely.

Set the parking brake.
(



P.183)

Press the P position switch.
(



P.178)

Check that the shift position indica-

tor shows P and the parking brake

indicator is illuminated.

Press the power switch.

The fuel cell system will stop, and

the meter display will be extin-

guished (the shift position indicator

will be extinguished a few seconds

after the meter display).

Release the brake pedal and
check that “ACCESSORY” or
“IGNITION ON” is not shown
on the meter.

■

Stopping the fuel cell system in

cold temperatures

●

When the power switch is pressed

and the fuel cell system is stopped

WARNING

■

When starting the fuel cell

system

Always start the fuel cell system

while sitting in the driver’s seat.

Do not depress the accelerator

pedal while starting the fuel cell

system under any circumstances.

Doing so may cause an accident

resulting in death or serious injury.

■

Caution while driving

If fuel cell system failure occurs

while the vehicle is moving, do not

lock or open the doors until the

vehicle reaches a safe and com-

plete stop. The steering lock func-

tion will activate and this may lead

to an accident, resulting in death

or serious injury.

NOTICE

■

When starting the fuel cell

system

If the fuel cell system becomes

difficult to start, have your vehicle

checked by your Toyota dealer

immediately.

■

Symptoms indicating a mal-

function with the power

switch

If the power switch seems to be

operating somewhat differently

than usual, such as the switch

sticking slightly, there may be a

malfunction. Contact your Toyota

dealer immediately.

Stopping the fuel cell sys-
tem

175

5-2. Driving procedures

ing

during cold temperatures, the time

for water purge from the tailpipe

may be longer than usual to pre-

vent liquid in the fuel cell stack

from freezing.

●

If the “FCV System Purge in Prog-

ress Purge will Stop Automati-

cally” is displayed in the multi-

information display, however it is

no problem to exit the vehicle.

●

The water purge time may also be

long if the system is stopped

before fuel cell system warm-up is

completed.

●

It is normal to hear hissing and

other sounds during purge.

(



P.75)

●

It is not a problem to do refueling

operations while the system is

purging.

The purging process is carried out

automatically after several min-

utes and a white mist may be

emitted, however this is not a mal-

function.

■

Parking the vehicle during cold

weather

●

Water may automatically purge

from the tailpipe, even when the

fuel cell system is off, in order to

prevent liquid in the fuel cell stack,

hydrogen pipelines, etc., from

freezing. Also, water vapor may

be purged, but this is not malfunc-

tion.

●

It is normal to hear hissing and

other sounds during purge.

(



P.75)

■

Automatic fuel cell system shut

off feature

●

The vehicle is equipped with a

feature that automatically shuts off

the fuel cell system when the shift

position is in P with the fuel cell

system operating for an extended

period.

●

The fuel cell system will automati-

cally shut off after approximately 1

hour if it has been left running

while the shift position is in P.

●

The timer for the automatic fuel

cell system shut off feature will

reset if the brake pedal is

depressed or if the shift position is

in a position other than P.

●

After the vehicle is parked, if the

door is locked with the door lock

switch (



P.124) from the inside or

the mechanical key from the out-

side, the automatic fuel cell sys-

tem shut off feature will be

disabled. The timer for the auto-

matic fuel cell system shut off fea-

ture will be re-enabled if the

driver’s door is opened.

■

When the shift control system

malfunctions

When attempting to turn the power

switch off while there is a malfunc-

tion in the shift control system, the

power switch mode may change to

ACC. In this case, ACC may be

turned off by applying the parking

brake and pressing the power

switch again.
If there is a malfunction in the sys-

tem, have the vehicle inspected by

your Toyota dealer immediately.

■

Automatic P position selection

function



P.180

■

Water release (H

O switch)



P.189

176

5-2. Driving procedures

Modes can be changed by
pressing the power switch with
the brake pedal released. (The
mode changes each time the
switch is pressed.)

“ACCESSORY”

“IGNITION ON”

OFF

The emergency flashers can be
used.

ACC

Some electrical components such
as the audio system can be used.
“ACCESSORY” will be displayed
on the meter.

All electrical components can be
used.
“IGNITION ON” will be displayed on
the meter.

■

Auto power off function

If the vehicle is left in ACC for more

than 20 minutes or ON (with fuel cell

system not operating) for more than

an hour with the shift position in P,

the power switch will automatically

turn off. However, this function can-

not entirely prevent the 12-volt bat-

tery discharge. Do not leave the

vehicle with the power switch in

ACC or ON for long periods of time

when the fuel cell system is not

operating.

WARNING

■

Stopping the fuel cell system

in an emergency

●

If you want to stop the fuel cell

system in an emergency while

driving the vehicle, press and

hold the power switch for more

than 2 seconds, or press it

briefly 3 times or more in suc-

cession. (



P.432)

However, do not touch the

power switch while driving

except in an emergency. Turn-

ing the fuel cell system off while

driving will not cause loss of

steering or braking control, how-

ever, power assist to the steer-

ing will be lost. This will make it

more difficult to steer smoothly,

so you should pull over and stop

the vehicle as soon as it is safe

to do so.

●

If the power switch is operated

while the vehicle is running, a

warning message will be shown

on the multi-information display

and a buzzer sounds.

●

When restarting the fuel cell

system after an emergency

shutdown, press the power

switch.

Changing power switch
modes

177

5-2. Driving procedures

ing

Br mode is not a shift position.
(



P.182)

■

If a message about a shift oper-

ation is shown

To prevent the shift position from

being selected incorrectly or the

vehicle from moving unexpectedly,

the shift position may be changed

automatically or operating the shift

lever may be required. In this case,

change the shift position following

the messages on the multi-informa-

tion display.

NOTICE

■

To prevent 12-volt battery dis-

charge

●

Do not leave the power switch

in ACC or ON for long periods of

time without the fuel cell system

on.

●

If “ACCESSORY” or “IGNITION

ON” is displayed on the meter,

the power switch is not off. Exit

the vehicle after turning the

power switch off.

Shift position

Select the shift position
depending on your pur-
pose and situation.

Shift position purpose
and functions

Shift posi-

tion

Objective or function

Parking the vehi-

cle/starting the fuel cell

system

Reversing

Neutral

Normal driving

178

5-2. Driving procedures

Shift lever

Operate the shift lever gently and

securely in the direction of the
arrow on the shift position indicator.
To shift to N, slide the shift lever in
the direction of the arrow and hold
it.
Release the shift lever after each
shifting operation to allow it to

return to its regular position (

Shifting to Br mode is only possible
when the shift position is in D.
When shifting from P to N, D or R,
from N, D, Br mode or R to P, from
D or Br mode to R, or from R to D,
ensure that the brake pedal is being
depressed and the vehicle is sta-
tionary.

Shift position indicator

Meter display:
The current shift position is high-
lighted.
When any shift position other than
D position or Br mode is selected,
the Br mode indicator are displayed
in gray.

P position switch

Fully stop the vehicle and set the
parking brake, and then press the P
position switch.
When the shift position is changed
to P, the switch illuminates.
Check that the shift position indica-
tor shows P.

■

Changing the shift position in

each power switch mode

●

The shift position cannot be

changed when the power switch is

in ACC or off.

●

When the power switch is in ON, if

the READY indicator is not illumi-

nated, the shift position can only

be changed to N.

NOTICE

■

Situations where shift control

system malfunctions are pos-

sible

If any of the following situations

occurs, shift control system mal-

functions are possible.

Immediately stop the vehicle in a

safe place on level ground, apply

the parking brake, and then con-

tact your Toyota dealer.

●

When the warning message

indicating the shift control sys-

tem appears on the multi-infor-

mation display. (



P.451)

●

The display indicates that no

shift position is selected for

more than a few seconds.

Shift position display and
how to change the shift
position

Toyota Mirai (2022 year). Manual in english - page 10
