Maximum Load Rating

This number indicates the maximum load in kilograms and pounds
that can be carried by the tire.

■

Maximum Permissible Inflation Pressure

This number is the greatest amount of air pressure that should ever
be put in the tire under normal driving conditions.

■

Tread Wear, Traction and Temperature Grades

●

Tread wear: The tread wear grade is a comparative rating based
on the wear rate of the tire when tested under controlled condi-
tions on a specified government test course. For example, a tire
graded 150 would wear one and one-half (1 1/2) times as well on
the government course as a tire graded 100.

●

Traction: The traction grades, from highest to lowest are AA, A,
B, and C. The grades represent the tire’s ability to stop on wet
pavement as measured under controlled conditions on specified
government test surfaces of asphalt and concrete. A tire marked
C may have poor traction performance.

●

Temperature: The temperature grades are A (the highest), B and
C, representing the tire’s resistance to the generation of heat and
its ability to dissipate heat when tested under controlled condi-
tions on a specified indoor laboratory test wheel.

■

Snow Tires

In some heavy snow areas, local governments may require true
snow tires, those with very deeply cut tread. These tires should only
be used in pairs or placed on all four wheels. Make sure you pur-
chase snow tires that are the same size and construction type as
the other tires on your vehicle.

■

SAFETY WARNING

The following safety warning appears on the tire’s sidewall. SERI-
OUS INJURY MAY RESULT FROM:

• EXPLOSION OF TIRE/RIM ASSEMBLY DUE TO IMPROPER

MOUNTING-MATCH TIRE DIAMETER TO RIM DIAMETER;
NEVER EXCEED 40 psi (275 kPa) TO SEAT BEADS-ONLY
SPECIALLY TRAINED PERSONS SHOULD MOUNT TIRES.

• TIRE FAILURE DUE TO UNDER-INFLATION/OVERLOADING/

DAMAGE-FOLLOW OWNER’S MANUAL AND PLACARD IN
VEHICLE-FREQUENTLY CHECK INFLATION PRESSURE AND
INSPECT FOR DAMAGE.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

526

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Please refer to the sample below.

Temporary tires
Nominal width of tire in millime-
ters
Ratio of height to width (aspect
ratio)
Diagonal
Rim diameter code
Load index & speed symbol

T115/70D16 90M is an example of a tire size and load index rating.
Here is an explanation of the various components of that tire size and
load index rating. Note that the tire size and load index rating may be
different from the example.

●

T
Indicates a tire that may be installed on cars, SUVs, minivans and
light trucks as designated by the Tire and Rim Association (T&RA).

●

115
“115” is the nominal width of the tire in millimeters. This three-digit
number gives the width in millimeters of the tire from sidewall edge
to sidewall edge. In general, the larger the number, the wider the
tire.

●

70
“70” is the aspect ratio. This two-digit number indicates the tire’s
ratio of height to width.

●

D
“D” is the tire construction symbol. D indicates “diagonal ply con-
struction”.

●

16
“16” is the wheel rim diameter in inches.

Information on Temporary Tires

1
2

4
5
6

-------------------------------------------------------------------------------------------------------------------------------------------------------------

528

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Location of the Tire Label (Placard)

You will find the tire label containing tire inflation pressure by tire size
and other important information on the driver’s side B-pillar or on the
edge of the driver’s door frame.
SAMPLE

On the tire label you will find the recommended tire inflation pressure
in both kPa and psi for the tires installed as original equipment on the
vehicle. It is very important that the inflation pressure of the tires on
your vehicle is maintained at the recommended pressure. You should
check the tire pressure regularly to insure that the proper inflation
pressure is maintained. Refer to Tires on P. 553.

Tire pressures listed on the vehicle placard or tire information label indi-

cate the recommended cold tire inflation pressure, measured when the

tires are cold, after the vehicle has been parked for at least 3 hours. As

you drive, the temperature in the tire warms up, increasing the tire pres-

sure.

Recommended Tire Inflation Pressure

-------------------------------------------------------------------------------------------------------------------------------------------------------------

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

529

Customer In

When  you  check  the  air  pressure,  make  sure  the  tires  are  cold  -
meaning they are not hot from driving even a mile.
Remove the cap from the valve on one tire.
Firmly press a tire gauge onto the valve.
Add air to achieve recommended air pressure.
If you overfill the tire, release air by pushing on the metal stem in
the  center  of  the  valve. Then  recheck  the  pressure  with  your  tire
gauge.
Replace the valve cap.
Repeat with each tire, including the spare.
Visually inspect the tires to make sure there are no nails or other
objects embedded that could poke a hole in the tire and cause an
air leak.
Check  the  sidewalls  to  make  sure  there  are  no  gouges,  cuts,
bulges, cracks or other irregularities.

Some spare tires require higher inflation pressure.

WARNING

■

Always check the tire inflation pressures on a regular basis accord-

ing to the recommended tire inflation pressure on the tire label and

in conjunction with the information in this owner’s manual

Driving your vehicle with under-inflated tires is dangerous.
Under-inflation is the most common cause of failures in any kind of tire

and may result in severe cracking, tread separation or “blowout”, with

unexpected loss of vehicle control and increased risk of injury. Under-

inflation increases sidewall flexing and rolling resistance, resulting in

heat buildup and internal damage to the tire. It results in unnecessary

tire stress, irregular wear, loss of control and accidents. A tire can lose

up to half of its air pressure and not appear to be flat!
It is impossible to determine whether or not tires are properly inflated

just by looking at them.

Checking Tire Pressure

-------------------------------------------------------------------------------------------------------------------------------------------------------------

530

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

●

Tire Placard: A label indicating the OE tire sizes, recommended
inflation pressure, and the maximum weight the vehicle can carry.

●

Tire Identification Number (TIN): A number on the sidewall of each
tire providing information about the tire brand and manufacturing
plant, tire size, and date of manufacture.

●

Inflation Pressure: A measure of the amount of air in a tire.

●

kPa: Kilopascal, the metric unit for air pressure.

●

psi: Pounds per square inch, the English unit for air pressure.

●

B-pillar: The structural member at the side of the vehicle behind the
front door.

●

Original Equipment (OE): Describes components originally
equipped on the vehicle.

●

Vehicle Load Limit: The maximum value of the combination weight
of occupants and cargo.

●

Bead Area of the Tire: Area of the tire next to the rim.

●

Sidewall Area of the Tire: Area between the bead area and the
tread.

●

Tread Area of the Tire: Area on the perimeter of the tire that con-
tacts the road when it’s mounted on the vehicle.

●

Seating capacity means the total allowable number of vehicle occu-
pants. Seating capacity is described on the tire label.

●

Production options weight is the combination weight of installed
regular production options weighing over 2.3 kilograms in excess of
the standard items which they replace, and not previously consid-
ered in the curb weight or accessory weight, including heavy duty
brakes, ride levelers, roof rack, heavy duty battery, and special trim.

●

Rim is the metal support (wheel) for a tire or a tire and tube assem-
bly upon which the tire beads are seated.

Glossary of Terms

-------------------------------------------------------------------------------------------------------------------------------------------------------------

531

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Customer In

Tire Maintenance

Improper or inadequate vehicle maintenance can cause tires to wear
abnormally. Here are some important maintenance points:

Inspect all tire pressure monthly (including the spare) when the tires
are cold. Maintain recommended pressures for the best ride, top han-
dling, and minimum tire wear. Use the pressures specified on the
vehicle tire information placard or tire label for optimum service.

To  equalize  tire  wear  and  extend
tire  life,  Toyota  recommends  that
tire  rotation  is  carried  out  at  the
same interval as tire inspection.

Inspect the tires for uneven wear and damage. Abnormal wear is usu-
ally caused by one or a combination of the following:

• Incorrect tire pressure
• Improper wheel alignment
• Out-of-balance wheel
• Severe braking

After rotation, inflate all tire pressures to specification (

P. 553) and

inspect the lug nuts for tightness.

Tire Inflation Pressure

Tire Rotation

Forward

Do not include
(TEMPORARY USE ONLY)
spare tire in rotation.

NOTICE

Rotate unidirectional tires and radial tires that have an asymmetrical

tread pattern or studs only from front to rear, not from side to side. Tire

performance will be weakened if rotated from side to side.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

532

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

If a tire wears evenly, a wear indicator will appear as a solid band
across the tread. Replace the tire when this happens.
You should replace the tire before the band crosses the entire tread.

New tread
Worn tread
Tread wear indicator

Tires degrade over time, even when they are not being used on the road.

It is recommended that tires generally be replaced when they are 6 years

or older. Heat caused by hot climates or frequent high loading conditions

can accelerate the aging process. You should replace the spare tire when

you replace the other road tires due to the aging of the spare tire. The

period in which the tire was manufactured (both week and year) is indi-

cated by a 4-digit number.

Refer to Tire Labeling on P. 522.

The way you drive has a great deal to do with your tire mileage and
safety. So cultivate good driving habits for your own benefit.

• Observe posted speed limits and drive at speeds that are safe for

the existing weather conditions

• Avoid fast starts, stops and turns
• Avoid potholes and objects on the road
• Do not run over curbs or hit the tire against the curb when parking

Replacing a Tire

1
2
3

WARNING

■

Always use tires that are in good condition

Driving with worn tires is dangerous. Reduced braking, steering, and

traction could result in an accident.

Safety Practices

-------------------------------------------------------------------------------------------------------------------------------------------------------------

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

533

Customer In

NOTICE

If you feel a sudden vibration or ride disturbance while driving or you

suspect your tire or vehicle has been damaged, immediately reduce

your speed. Drive with caution until you can safely pull off the road. Stop

and inspect the tire for damage. If the tire is under-inflated or damaged,

deflate it, remove the tire and rim and replace it with your spare tire. If

you cannot detect a cause, have the vehicle towed to the nearest vehi-

cle or tire dealer to have the vehicle inspected.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

534

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Vehicle Loading

This  section  will  guide  you  in  the  proper  loading  of  your  vehicle,  to
keep  your  loaded  vehicle  weight  within  its  design  rating  capability.
Properly loading your vehicle will provide maximum return of vehicle
design performance. Before loading your vehicle, familiarize yourself
with the following terms for determining your vehicle’s weight ratings,
from the vehicle’s Safety Certification Label and Tire and Load Infor-
mation Label:
Base Curb Weight is the weight of the vehicle including a full tank of
fuel  and  all  standard  equipment.  It  does  not  include  passengers,
cargo, or optional equipment.
Vehicle  Curb  Weight  is  the  weight  of  your  new  vehicle  when  you
picked it up from your dealer plus any aftermarket equipment.

Payload is the combination weight of cargo and passengers that the
vehicle is designed to carry. The  maximum payload for your vehicle
can be found on the Tire and Load Information label on the driver’s
door frame or door pillar. Look for “THE COMBINATION WEIGHT OF
OCCUPANTS AND  CARGO  SHOULD  NEVER  EXCEED  XXX  kg  or
XXX  lb.”  for  your  maximum  payload.  The  payload  listed  on  the  tire
label is the maximum payload for the vehicle as built by the assembly
plant.  If  any  aftermarket  or  dealer  installed  equipment  has  been
installed  on  the  vehicle,  the  weight  of  the  equipment  must  be  sub-
tracted from the payload listed on the tire label in order to be accurate.

PAYLOAD

-------------------------------------------------------------------------------------------------------------------------------------------------------------

536

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Examples: Based on a single occupant weight of 150 lb. (68 kg), and
a value of 849 lb. (385 kg) for the “combination weight of occupants
and cargo should never exceed”:
The cargo weight limit with one occupant is 849 lb. (385 kg) - 150 lb.
(68 kg) = 699 lb. (317 kg)
The cargo weight limit with two occupants is 849 lb. (385 kg) - (150 x
2) lb. ((68 x 2) kg) = 549 lb. (249 kg)
If  the  weight  of  the  occupant  increases,  the  cargo  weight  limit
decreases by that much.
GAW  (Gross Axle  Weight)  is  the  total  weight  placed  on  each  axle
(front and rear) - including vehicle curb weight and all payload.
GAWR (Gross Axle Weight Rating) is the maximum allowable weight
that can be carried by a single axle (front or rear). These numbers are
shown  on  the  Safety  Compliance  Certification  Label  located  on  the
driver’s  door  frame  or  door  pillar. The  total  load  on  each  axle  must
never exceed its GAWR.

GVW  (Gross  Vehicle  Weight)  is  the  Vehicle  Curb  Weight  +  cargo  +
passengers.
GVWR  (Gross  Vehicle  Weight  Rating)  is  the  maximum  allowable
weight  of  the  fully  loaded  vehicle  (including  all  options,  equipment,
passengers and cargo). The GVWR is shown on the Safety Compli-
ance Certification Label located on the driver’s door frame or door pil-
lar. The GVW must never exceed the GVWR.

GVW

-------------------------------------------------------------------------------------------------------------------------------------------------------------

538

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

GCWR (Gross Combination Weight Rating) is the maximum allowable
weight of the vehicle - including all cargo and passengers - that the
vehicle can handle without risking damage. The GCW must never
exceed the GCWR.

WARNING

■

Do not tow a trailer with this vehicle

Towing a trailer with this vehicle is dangerous because it has not been

designed to tow a trailer and doing so will affect the drive system which

could result in vehicle damage.

■

Overloaded Vehicle

Overloading a vehicle is dangerous. The results of overloading can

have serious consequences in terms of passenger safety. Too much

weight on a vehicle’s suspension system can cause spring or shock

absorber failure, brake failure, handling or steering problems, irregular

tire wear, tire failure or other damage.
Overloading makes a vehicle harder to drive and control. It also

increases the distance required for stopping. In cases of serious over-

loading, brakes can fail completely, particularly on steep grades. The

load a tire will carry safely is a combination of the size of the tire, its load

range, and corresponding inflation pressure.
Never overload the vehicle and always observe the vehicle’s weight rat-

ings from the vehicle’s Safety Certification and Tire and Load Informa-

tion labels.

■

Never Exceed Axle Weight Rating Limits

Exceeding the Safety Certification Label axle weight rating limits is dan-

gerous and could result in death or serious injury as a result of substan-

dard vehicle handling, performance, engine, transmission and/or

structural damage, serious damage to the vehicle, or loss of control.
Always keep the vehicle within the axle weight rating limits.

■

Never Exceed GVWR or GAWR Specifications

Exceeding the GVWR or the GAWR specified on the certification label is

dangerous. Exceeding any vehicle rating limitation could result in a seri-

ous accident, injury, or damage to the vehicle.
Do not use replacement tires with lower load carrying capacities than

the originals because they may lower the vehicle’s GVWR and GAWR

limitations. Replacement tires with a higher limit than the originals do

not increase the GVWR and GAWR limitations. Never exceed the

GVWR or the GAWR specified on the certification label.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

539

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Customer In

Steps for Determining the Correct Load

Limit

Steps for Determining Correct Load Limit-

(1) Locate the statement “The combined weight of occupants and

cargo should never exceed XXX kg or XXX lbs.” on your vehicle’s
placard.

(2) Determine the combined weight of the driver and passengers that

will be riding in your vehicle.

(3) Subtract the combined weight of the driver and passengers from

XXX kg or XXX lbs.

(4) The resulting figure equals the available amount of cargo and lug-

gage load capacity. For example, if the “XXX” amount equals 1400
lbs. and there will be five 150 lb passengers in your vehicle, the
amount of available cargo and luggage load capacity is 650 lbs.
(1400 - 750 (5 x 150) = 650 lbs.)

(5) Determine the combined weight of luggage and cargo being loaded

on the vehicle. That weight may not safely exceed the available
cargo and luggage load capacity calculated in Step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will be

transferred to your vehicle. Consult this manual to determine how
this reduces the available cargo and luggage load capacity of your
vehicle.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

548

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Specifications

: The spark plugs provide the engine its optimum performance. Consult your

Toyota dealer for details.

Engine

Item

Specification

Type

DOHC-16V in-line, 4-cylinder

Bore



Stroke

2.93



3.38 in. (74.5



85.8 mm)

Displacement

1,496.1 ml (1,496.1 cc)

Compression ratio

12.0

Electrical System

Item

Classification

Battery

12V-60Ah/20HR

Spark-plug number

spark plug required

P51R-18-110

NOTICE

When cleaning the iridium plugs, do not use a wire brush. The fine particu-
late coating on the iridium alloy and platinum tips could be damaged.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

549

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Specifica

Refer to Recommended Oil on P. 395.

Refer to Introduction on P. 386 for owner’s responsibility in protecting your
investment.

Approximate Quantities:

Check oil and fluid levels with dipsticks or reservoir gauges.

Lubricant Quality

Item

Classification

Engine oil

Coolant

FL-22 type

Manual transaxle oil

API Service

GL-4

SAE

75W-80

Automatic transaxle fluid

ATF required

Brake/Clutch fluid

SAE J1703 or FMVSS116 DOT-3

Capacities

Item

Capacity

Engine oil

With oil filter replacement

4.4 qt. (4.2 L, 3.7 Imp.qt.)

Without oil filter replace-
ment

4.1 qt. (3.9 L, 3.4 Imp.qt.)

Coolant

Manual transaxle

5.6 qt. (5.3 L, 4.7 Imp.qt.)

Automatic transaxle

5.8 qt. (5.5 L, 4.8 Imp.qt.)

Manual transaxle oil

1.68 qt. (1.59 L, 1.40 Imp.qt.)

Automatic transaxle fluid

7.6 qt. (7.2 L, 6.3 Imp.qt.)

Fuel tank

11.6 gal. (44.0 L, 9.68 Imp.gal.)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

550

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)



4-Door



5-Door

: The overall height is categorized according to the antenna type as follows:

Dimensions

Item

Vehicle specification

Overall length

171.9 in. (4,365 mm)

Overall width

66.7 in. (1,695 mm)

Overall height

58.3 in. (1,480 mm)

Front tread

58.8 in. (1,493 mm)

Rear tread

58.4 in. (1,483 mm)

Wheelbase

101.2 in. (2,571 mm)

Item

Vehicle specification

Overall length

159.8 in. (4,060 mm)

Overall width

66.7 in. (1,695 mm)

Overall height

Type A

59.7 in. (1,515 mm)

Type B

58.9 in. (1,495 mm)

Front tread

58.8 in. (1,493 mm)

Rear tread

58.4 in. (1,483 mm)

Wheelbase

101.2 in. (2,571 mm)

Type A:

Type B:

Antenna

-------------------------------------------------------------------------------------------------------------------------------------------------------------

551

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Specifica



4-Door



5-Door

The type of refrigerant used is indicated on a label attached to the
inside of the engine compartment. Check the label before recharging
the refrigerant. Refer to Climate Control System on P. 256.

Weights

Item

Weight

Manual transaxle

Automatic transaxle

GVWR (Gross Vehicle Weight
Rating)

3,344 lb. (1,517 kg) 3,393 lb. (1,539 kg)

GAWR (Gross Axle
Weight Rating)

Front

1,753 lb. (795 kg)

1,795 lb. (814 kg)

Rear

1,638 lb. (743 kg)

1,627 lb. (738 kg)

Item

Weight

Manual transaxle

Automatic transaxle

GVWR (Gross Vehicle Weight
Rating)

3,314 lb. (1,503 kg) 3,360 lb. (1,524 kg)

GAWR (Gross Axle
Weight Rating)

Front

1,733 lb. (786 kg)

1,786 lb. (810 kg)

Rear

1,585 lb. (719 kg)

1,581 lb. (717 kg)

Air Conditioner

Item

Specification

Refrigerant Type

HFC134a (R-134a)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

552

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

■

Exterior light

: UN-R stands for United Nations Regulation.

LED is the abbreviation for Light Emitting Diode.

: Double-filament light bulb, however, only 60 W filament bulb is used in the

daytime running lights.

Light Bulbs

Light bulb

Category

Wattage

UN-R

Trunk light (4-Door)



Luggage compartment light (5-Door)



Overhead lights/Map lights



Tires

Tire size

Inflation pressure

Front

Rear

P185/65R15 86H

255 kPa (37 psi)

230 kPa (33 psi)

P185/60R16 86H

250 kPa (36 psi)

230 kPa (33 psi)

Tire size

Inflation pressure

T125/70D15 95M

420 kPa (60 psi)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

554

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

■

Lug nut tightening torque

When installing a tire, tighten the lug nut to the following torque.
80-108 ft

•

lbf (108-147 N

•

m, 12-14 kgf

•

The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Toyota recommends that you replace tires of the

same type originally fitted to your vehicle. For details, contact your Toyota

dealer.

Refer to Fuses on P. 435.

Fuses

-------------------------------------------------------------------------------------------------------------------------------------------------------------

555

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Specifica

Customizable Features

The following customizable features can be set or changed by your
Toyota dealer. Consult your Toyota dealer for details.
Additionally, some of the customizable features can be changed by
the customer depending on the feature.
Customizable features which can be changed differ depending on the
market and specification.

Settings can be changed by operating the center display screen.
A: Refer to Settings on P. 300.
B: Refer to Fuel Economy Monitor on P. 221.
Settings can be changed by operating the vehicle switches.
C: Refer to Stopping The Low Speed Pre-Collision System Opera-

tion on P. 233.

D: Refer to Auto Lock/Unlock Function on P. 108.
E: Refer to Smart Key on P. 93.
F: Refer to Locking, Unlocking with Request Switch (With the

advanced keyless function) on P. 103.

Settings can be changed by your Toyota dealer.

■

Safety

●

Low Speed Pre-Collision System (



P. 228)

: Though these systems can be turned Off, doing so will defeat the purpose

of the system and Toyota recommends that these systems remain On.

Settings Change Method

Feature

Factory

Setting

Available

Settings

Settings Change

Method

The  system  can  be
changed  so  that  Low
Speed  Pre-Collision  Sys-
tem does not operate.

–

Off

-------------------------------------------------------------------------------------------------------------------------------------------------------------

556

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

■

Vehicle

●

Power Door locks (



P. 108)

●

Keyless entry system (

P. 92)

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Changes  the  auto  lock/
unlock function setting for
all  the  doors  according  to
the  vehicle  speed,  the
vehicle power supply con-
dition,  and  the  selector
lever position.

Lock: When

Driving/

Unlock: IGN

Off

Lock: Out of

Park/Unlock:

In Park



Lock: Shift-

ing Out of

Park

Lock: When

Driving/

Unlock: In

Park

Lock: When

Driving/

Unlock: IGN

Off

Lock: When

Driving

Off

Feature

Factory

Setting

Available

Settings

Settings Change

Method

The method for unlocking
the doors using the smart
key can be changed.

Driver’s:

Once/All

Doors:

Twice

All Doors:

Once



Driver’s:

Once/All

Doors:

Twice

The  time  required  for  the
doors  to  relock  automati-
cally  after  unlocking  with
the  smart  key  can  be
changed.

60 seconds

90 seconds

–



60 seconds

30 seconds

-------------------------------------------------------------------------------------------------------------------------------------------------------------

557

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Specifica

●

Advanced keyless entry system (

P. 99)

●

Illuminated entry system (

P. 377)

Feature

Factory

Setting

Available

Settings

Settings Change

Method

The  method  for  unlocking
the  doors  using  the
request  switch/transmitter
can be changed.

Driver’s:

Once/

All Doors:

Twice

All Doors:

Once

E/F



Driver’s:

Once/

All Doors:

Twice

The

volume

the

answer-back  beep  during
advanced  keyless  entry
system  operation  can  be
changed.

Medium

High



Medium

Low

Off

The  function  to  automati-
cally  lock  the  doors  when
leaving  the  vehicle  while
carrying  the  key  can  be
changed.

Off

–



Off

The  time  required  for  the
doors  to  relock  automati-
cally  after  unlocking  with
the  request  switch/trans-
mitter can be changed.

60 seconds

90 seconds

–



60 seconds

30 seconds

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Time until interior lights
turn off after closing door

15 seconds

60 seconds

–



30 seconds

15 seconds

7.5 seconds

Time until interior lights
turn

off

automatically

when any door is not
closed completely

30 minutes

60 minutes

–



30 minutes

10 minutes

-------------------------------------------------------------------------------------------------------------------------------------------------------------

558

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

●

Auto-wiper control (

P. 201)

: If the auto-wiper control is set to Off, the wiper lever

position is set to

intermittent operation.

●

Daytime running lights (

P. 197)

●

Auto-light control (



P. 192)

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Operational/
non-operational

–



Off

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Operational/non-opera-
tional

–



Off

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Timing by which lights turn
on

Medium

High

–



Med.High

Medium

Med.Low

Low

-------------------------------------------------------------------------------------------------------------------------------------------------------------

559

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Specifica

●

Auto headlight off (



P. 192)

: When set to Off, the lights-on reminder is operable.

●

Lights-on reminder

(

P. 502)

: The setting of the lights-on reminder can be changed with the time set-

ting of auto headlight off function set to Off. Refer to Lights-On Reminder
on P. 502.

●

Turn indicator (

P. 199)

●

Three-flash turn signal (

P. 200)

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Time until headlights turn
off

30 seconds

120 seconds

–



90 seconds

60 seconds

30 seconds

Off

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Warning beep volume

High

–



Low

Off

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Beep volume

High

–



Low

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Operational/non-opera-
tional

–



Off

-------------------------------------------------------------------------------------------------------------------------------------------------------------

560

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

■

System

●

Language

: Available only in display from the center display.

●

Temperature unit

●

Distance unit

■

Fuel Economy Monitor (

P. 221)

●

Ending display

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Language indicated in dis-
play

US English

Depends on

market

–



Feature

Factory

Setting

Available

Settings

Settings Change

Method

Temperature unit indi-
cated in display

°F or °C

°F

–



°C

Feature

Factory

Setting

Available

Settings

Settings Change

Method

Distance unit indicated in
display

miles or km

miles

–



Feature

Factory

Setting

Available

Settings

Settings Change

Method

On/off

Off

–



Off

-------------------------------------------------------------------------------------------------------------------------------------------------------------

561

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)

Specifica
