208

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Using this system, a desired
speed and a distance to a vehi-
cle ahead can be adjusted using
the buttons on the steering
wheel.
The system maintains the
desired speed on clear roads.
For this purpose, the vehicle
accelerates or brakes automati-
cally.
If a vehicle is driving ahead of
you, the system adjusts the
speed of your vehicle so that the
set distance to the vehicle
ahead is maintained. The speed
is adjusted as far as the given
situation allows.

A radar sensor is located in the
front bumper and a camera on
the interior mirror to detect vehi-
cles driving ahead of you.
Depending on the vehicle set-
tings, the characteristics of the
Cruise Control may change.
The distance can be adjusted in
several steps. For safety rea-
sons, it depends on the respec-
tive speed.
If the vehicle ahead of you

brakes to a halt, and then pro-
ceeds to drive again within a
brief period, the system is able
to detect this within the given
system limits.

Dynamic radar cruise
control with full-speed
range

Concept

General information

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment in assessing the traffic

conditions. Based on the limits of

the system, it cannot inde-

pendently react to all traffic situa-

tions. There is a risk of accident.

Adjust driving style to traffic condi-

tions. Watch traffic closely and

actively intervene where apaprk-

ing sensorspropriate.

WARNING

An unsecured vehicle can begin

to move and possibly roll away.

There is a risk of an accident.

Before exiting, secure the vehicle

against rolling.
In order to ensure that the vehicle

is secured against rolling away,

follow the following:

●

Set the parking brake.

●

On uphill grades or on a down-

hill slope, turn the front wheels

in the direction of the curb.

●

On uphill grades or on a down-

hill slope, also secure the vehi-

cle, for instance with a wheel

chock.

209

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

The radar sensor is located in
the front bumper.
Always keep radar sensor clean
and unobstructed.

WARNING

The desired speed can be incor-

rectly adjusted or called up by

mistake. There is a risk of an acci-

dent. Adjust the desired speed to

the traffic conditions. Watch traf-

fic closely and actively intervene

where appropriate.

WARNING

Risk of accident due to too high

speed differences to other vehi-

cles, for instance in the following

situations:

●

When fast approaching a slowly

moving vehicle.

There is a risk of injuries or dan-

ger to life. Watch traffic closely

and actively intervene where

appropriate.

●

Vehicle suddenly swerving into

own lane.

●

When fast approaching stand-

ing vehicles.

Overview

Buttons on the steering
wheel

Button

Function

Cruise control on/off,
refer to page 210.

Store current speed.

When active, press the
button: Pause cruise
control, refer to page
210.
Press the button with
the system interrupted:
Continue cruise control
with the last setting,
refer to page 212.

Increase distance, refer
to page 212.
Switch distance control
on/off.

Reduce distance, refer
to page 212.
Switch distance control
on/off.

Rocker switch:
Set speed, refer to
page 211.

Radar sensor

Button

Function

210

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

The camera is installed near the
interior mirror.
Keep the windshield in front of
the interior mirror clean and
clear.

The system is best used on
well-constructed roads.
The system is functional at
speeds beginning at approx. 20
mph/30 km/h.
The maximum speed that can
be set is limited and, e.g.,
depends on the vehicle and the
vehicle equipment version.
The system can also be acti-
vated when stationary.

The indicator will come on.

Cruise control is active. The cur-
rent speed is maintained and
stored as desired speed.
VSC Vehicle Stability Control
System is switched on, if neces-
sary.

To switch off the system while
standing, step on brake pedal at
the same time.
Press the following button on
the steering wheel again:

The displays go out. The stored
desired speed is deleted.

When active, press the following
button on the steering wheel:

If interrupting the system while
stationary, press on the brake
pedal at the same time.

The system is automatically
interrupted in the following situa-
tions:



When the driver applies the
brakes.



When selector lever position
D is disengaged.

Camera

Area of application

Switching on/off and inter-
rupting cruise control

Switching on

Press the button on the
steering wheel.

Switching off

Button on the steering
wheel.

Interrupting manually

Button on the steering
wheel.

Interrupting automatically

211

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS



Traction mode is activated or
VSC Vehicle Stability Control
System is deactivated.



If VSC Vehicle Stability Con-
trol System intervenes.



If the safety belt is unbuckled
and the driver's door is
opened while the vehicle is
standing still.



If the system has not detected
objects for an extended
period, for instance on a road
with very little traffic without
curb or shoulder markings.



If the detection range of the
radar is impaired, for instance
by dirt or heavy fog.



After a longer stationary
period when the vehicle has
been braked to a stop by the
system.

Press the rocker switch up or
down once while the system is
interrupted. The system will be

activated.
The current speed is maintained
and stored as desired speed.
The stored speed is displayed
on the speedometer.
VSC Vehicle Stability Control
System is switched on, if neces-
sary.
The speed can also be stored
by pressing a button.

Press the rocker switch up or
down repeatedly until the
desired speed is set.
If active, the displayed speed is
stored and the vehicle reaches
the stored speed when the road
is clear.



Each time the rocker switch is
pressed to the resistance
point, the desired speed
increases or decreases by 1
mph/1 km/h.



Each time the rocker switch is
pressed past the resistance
point, the desired speed

Setting the speed

Maintaining and storing the
speed

Press the button.

Changing the speed

212

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

changes by a maximum of 5
mph/10 km/h.

Hold the rocker switch in posi-
tion to repeat the action.

Instrument cluster will display
selected distance, refer to page
212.

Instrument cluster will display
selected distance, refer to page
212.

An interrupted cruise control can
be continued by calling up the
stored speed.
Make sure that the difference
between current speed and
stored speed is not too large
before calling up the stored
speed. Otherwise, unintentional
braking or accelerating may
occur.

Cruise control is continued with
the stored values.
In the following cases, the
stored speed value is deleted
and cannot be called up again:



When the system is switched
off.



When drive-ready state is
switched off.

Selected distance to the vehicle
ahead of you is shown.

Adjusting distance

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment. Due to the system lim-

its, braking can be late. There is a

risk of accidents or risk of damage

to property. Be aware to the traffic

situation at all times. Adjust the

distance to the traffic and weather

conditions and maintain the pre-

scribed safety distance, possibly

by braking.

Reduce distance

Press the button repeat-
edly until the desired dis-
tance is set.

Increase distance

Press the button repeat-
edly until the desired dis-
tance is set.

Continuing cruise control

Press the button to
resume system operation
when it is canceled.

Displays in the instrument
cluster

Status display

The selected desired
speed will be displayed.

Distance to vehicle ahead of
you

SET

110

213

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

As soon as the detected vehicle
drives off, the vehicle symbol in
the distance indicator will move
away.
To accelerate, activate ACC, for
instance by briefly stepping on
the accelerator pedal or press-
ing the rocker switch.

Symbol

Description

Distance 1

Distance 2

Distance 3

Distance 4
This value is set
automatically after
the system is
switched on.

System interrupted.

No distance control
display, as the accel-
erator pedal is being
pressed.

Detected vehicle

Symbol

Description

Green symbol:
A vehicle has been
detected ahead of
you. The system
maintains the set dis-
tance to the vehicle
in front.

214

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Some system information can
also be displayed in the
Head-up Display.

The distance information is
active in the following situations:



Dynamic radar cruise control
switched off.



Display in the Head-up Dis-
play selected, refer to page
154.



Distance too short.



Speed greater than approx.
40 mph/70 km/h.

The detection capacity of the
system and the automatic brak-
ing capacity are limited.
Two-wheeled vehicles for
instance might not be detected.

Indicator/warning lights

Symbol

Description

Indicator light green:
system is active.
No indicator light:
system is switched
off.

Vehicle symbol
flashes:
The conditions are
not adequate for the
system to work.
The system was
deactivated but
applies the brakes
until you actively
resume control by
pressing on the
brake pedal or accel-
erator pedal.

The vehicle symbol
and distance bars
flash red and an
acoustic signal
sounds:
Brake and make an
evasive maneuver, if
necessary.

Displays in the Head-up
Display

Desired speed

The symbol is displayed
when the set desired
speed is reached.

Distance information

The symbol is displayed
when the distance from
the vehicle traveling
ahead is too short.

System limits

Detection range

215

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

The system does not decelerate
in the following situations:



For pedestrians or similarly
slow-moving road users.



For red traffic lights.



For cross traffic.



For oncoming traffic.

A vehicle driving in front of you
is not detected until it is com-
pletely within the same lane as
your vehicle.
If a vehicle driving ahead of you
suddenly swerves into your
lane, the system may not be
able to automatically restore the
selected distance. It may not be
possible to restore the selected
distance in certain situations,
including if you are driving sig-
nificantly faster than vehicles
driving ahead of you, for
instance when rapidly approach-
ing a truck. When a vehicle driv-
ing ahead of you is reliably
detected, the system requests

that the driver intervene by brak-
ing and carrying out evasive
maneuvers, if needed.

When the desired speed is too
high for a curve, the speed is
reduced slightly. Because
curves may not be anticipated in
advance, drive into a curve at an
appropriate speed.
The system has a limited detec-
tion range. Situations can arise
in tight curves where a vehicle
driving ahead will not be
detected or will be detected very
late.

When you approach a curve the
system may briefly report vehi-
cles in the next lane due to the
bend of the curve. If the system
decelerates you may compen-

Deceleration

Swerving vehicles

Cornering

216

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

sate it by briefly accelerating.
After releasing the accelerator
pedal the system is reactivated
and controls speed inde-
pendently.

In some situations, the vehicle
cannot drive off automatically;
for example:



On steep uphill grades.



From bumps in the road.

In these cases, step on the
accelerator pedal.

The following restrictions can
occur under unfavorable
weather or light conditions:



Poorer vehicle recognition.



Short-term interruptions for
vehicles that are already rec-
ognized.

Examples of unfavorable
weather or light conditions:



Wet conditions.



Snowfall.



Slush.



Fog.



Glare.

Drive attentively, and react to
the current traffic situation. If
necessary, intervene actively,
for instance by braking, steering
or evading.

The desired speed is also main-
tained downhill. The speed may
not be maintained on uphill
grades if the engine power is
insufficient.

The system cannot be activated
if the radar sensor is not aligned
correctly. This may be caused
by damage incurred, for
instance during parking.
A vehicle message is displayed
if the system fails.
Have the system checked by
your Toyota dealer.
The system may be impaired
when the detection range of the
radar sensor is partially covered
such as by the license plate
holder.

The function for detecting and
responding when approaching
stationary vehicles may be lim-
ited in the following situations:



During calibration of the cam-
era immediately after vehicle
delivery.



If the camera is malfunction-
ing or dirty. A vehicle mes-
sage is displayed.

Driving off

Weather

Engine power

Malfunction

Radar sensor

Camera

217

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

When the systems in the vehicle
e.g., Speed Limit Info, detect a
change of the speed limit along
the route, this new speed value
ca be applied for the following
systems:



Manual Speed Limiter.



Cruise Control.



Dynamic radar cruise control
with full-speed range.

The speed value is suggested
as the new desired speed to be
applied. To apply the speed
value, the corresponding system
must be activated.

Via Toyota Supra Command:

1

"My vehicle"

2

"Vehicle settings"

3

"Speed Assistant"

4

"Notes on speed limits"

Select the desired setting:



"adjust manually": detected
speed limit can be applied
manually.



"Show current limit": detected
speed limits are displayed in
the instrument cluster without
being applied.



"Off": Speed Limit Assist will
be switched off.

Speed Limit Assist

Concept

Safety information

WARNING

The system cannot serve as a

substitute for the driver's personal

judgment in assessing the traffic

situation. Based on the limits of

the system, it cannot inde-

pendently react to all traffic situa-

tions. There is a risk of an

accident. Adjust driving style to

traffic conditions. Watch traffic

closely and actively intervene

where appropriate.

WARNING

The desired speed can be incor-

rectly adjusted or called up by

mistake. There is a risk of an acci-

dent. Adjust the desired speed to

the traffic conditions. Watch traf-

fic closely and actively intervene

where appropriate.

Overview

Buttons on the steering
wheel

Button

Function

Apply suggested speed
manually.

Switching on/off and
adjusting

218

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

A message is indicated in the
instrument cluster when the sys-
tem and cruise control are acti-
vated.

Speed Limit Assist is based on
the Speed Limit Info system.

Thus, also observe the system
limits of the Speed Limit Info
system, refer to page 146.

Parking Sensor is a support
when parking. Objects that you
are approaching slowly in front
of or behind the vehicle are indi-
cated by signal tones and a dis-
play on the Control Display.
Depending on the equipment
version: Obstacles at the side of
the vehicle that are detected by
the side ultrasonic sensors may
also be reported by the side pro-
tection, refer to page 222, func-
tion.

The ultrasound sensors for dis-
tance measurements are
located in the bumpers and pos-
sibly on the sides of the vehicle.
The range, depending on the
obstacle and environmental
conditions, is approx. 6 ft/2 m.
An acoustic warning sounds in
case of an impending collision at
a distance to the object of
approx. 27 in/70 cm.
For objects behind the vehicle,
the acoustic warning is already
issued at a distance to the
object of approx. 5 ft/1.50 m.

Displays in the instrument
cluster

Symbol

Function

Indicator light illumi-
nates green, together
with the symbol for a
cruise control system:
Speed Limit Assist is
active and detected
speed limits can be
applied manually for
the displayed system.

Detected change of a
speed limit with imme-
diate effect.

Indicator light illumi-
nates green: the
detected speed limit
can be applied with the
SET button.
As soon as the speed
limit has been applied,
a green checkmark is
displayed.

Taking over the sug-
gested speed

As soon as the SET icon
lights up, press the button.

System limits

Parking Sensors

Concept

General information

219

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Ensure full functionality:



Do not cover sensors, for
instance with stickers, bicycle
racks.



Keep the sensors clean and
unobstructed.

The system switches on auto-
matically in the following situa-
tions:



If selector lever position R is
engaged when the engine is
running.



Depending on the equipment
version: while approaching
detected obstacles if the
speed is slower than approx.
2.5 mph/4 km/h. The activa-
tion distance depends on the
situation in question.

You may switch automatic acti-
vation when obstacles are
detected on and off.
Via Toyota Supra Command:

1

"My vehicle"

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment in assessing the traffic

conditions. Based on the limits of

the system, it cannot inde-

pendently react to all traffic situa-

tions. There is a risk of accident.

Adjust driving style to traffic condi-

tions. Watch traffic closely and

actively intervene where appropri-

ate.

WARNING

Due to high speeds when Parking

Sensors is activated, the warning

can be delayed due to physical

circumstances. There is a risk of

injury or risk of damage to prop-

erty. Avoid approaching an object

too fast. Avoid driving off fast

while Parking Sensors is not yet

active.

Overview

Button in the vehicle

Park assistance button

Ultrasound sensors

Ultrasound sensors of
the Parking Sensor, for
instance in the bum-
pers.

Functional requirements

Switching on/off

Switching on automatically

220

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

2

"Vehicle settings"

3

"Parking"

4

Where applicable: "Automatic
Parking Sens. activation"

5

"Automatic Parking Sensors
activ."

The setting is stored for the
driver profile currently used.
Depending on equipment, an
additional camera view is also
switched on.

The system switches off when a
certain driving distance or speed
is exceeded.
Switch the system back on, if
needed.



On: the LED lights up.



Off: the LED goes out.

The rearview camera image is
displayed if the reverse gear is
engaged when pressing the
park assistance button.
Depending on the equipment
version, the system cannot be
switched off manually if the
reverse gear is engaged.

■

General information

An intermittent tone indicates
when the vehicle is approaching
an object. For instance, if an
object is detected to the left rear
of the vehicle, a signal tone
sounds from the left rear
speaker.
The shorter the distance to the
object, the shorter the intervals.
If the distance to a detected
object is less than approx. 8
in/20 cm, a continuous tone is
sounded.
If there are objects in front of
and behind the vehicle at the
same time, with a distance
smaller than approx. 8 in/20 cm,
an alternating constant tone will
sound.
The intermittent tone and con-
stant tone are switched off if the
selector lever position P is
engaged.
The intermittent tone is switched
off after a short time when the
vehicle is stationary.

■

Volume

The Parking Sensor signal tone
volume can be adjusted.
Via Toyota Supra Command:

1

"My vehicle"

2

"System settings"

Automatic deactivation
during forward travel

Switching on/off manually

Press the park assistance
button.

WARNING

Signal tones

221

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

3

"Tone"

4

"Volume settings"

5

"Parking Sens."

6

Set the desired value.

The setting is stored for the
driver profile currently used.

The approach of the vehicle to
an object is shown on the Con-
trol Display. Objects that are far-
ther away are already displayed
on the Control Display before a
signal sounds.
The display appears as soon as
Parking Sensor is activated.
The range of the sensors is rep-
resented in the colors green,
yellow and red when obstacles
are detected.
Pathway lines are faded in for
better estimation of the required
space.
When the image of the rearview
camera is displayed, the switch
can be made to Parking Sensor
or to a different view with obsta-
cle markings as needed:

1

Press the Controller to the
left, if needed.

2

E. g. "Park. sensors only"

RCTA (Rear cross traffic alert)
function, refer to page 228:
depending on the equipment, it
is warned in the Parking Sensor
display against vehicles
approaching in the front or rear
from the side.

The emergency braking function
of Parking Sensor initiates an
emergency braking in case of
acute risk of collision.

Due to system limits, a collision
cannot be prevented under all
circumstances.
The function is available from
walking speed while backing up
or rolling backward.
A press of the accelerator pedal
interrupts the braking interven-
tion.
After emergency braking to a
stop, further creeping toward an
obstacle is possible. To creep
toward the obstacle, lightly

Visual warning

Depending on the equip-
ment version: emergency
brake function, Parking
Sensors with emergency
braking function

Concept

General information

222

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

press the accelerator pedal and
release it again.
If the accelerator pedal is heav-
ily depressed, the vehicle drives
off as usual. Manual braking is
possible at any time.
The system uses the ultrasound
sensors of Parking Sensor and
parking assistant.

Via Toyota Supra Command:

1

"My vehicle"

2

"Vehicle settings"

3

"Parking"

4

"Park. Sens. w. em. braking
funct."

5

"Park. Sens. w. em. braking
funct."

The setting is stored for the
driver profile currently used.

The system warns of obstacles
on the side of the vehicle.

The system uses the ultrasound
sensors of Parking Sensor and
parking assistant.

To protect the sides of the vehi-
cle, obstacle markings are dis-
played on the sides of the
vehicle.



Color markings: warning
against detected obstacles.



Gray markings, hatched area:
no obstacles were detected.



No markings, black area: the
area next to the vehicle was
not yet captured.

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment in assessing the traffic

conditions. There is a risk of acci-

dent. Adjust driving style to traffic

conditions. Watch traffic and vehi-

cle surroundings closely and

actively intervene where appropri-

ate.

Activating/deactivating the
system

Depending on the equip-
ment version: side parking
aid

Concept

General information

Display

223

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

The system only displays sta-
tionary obstacles that were pre-
viously detected by sensors
while passing them.
The system does not detect
whether an obstacle moves later
on. If the vehicle is stationary,
the markings are shown in black
after a certain time. The area
next to the vehicle must be
newly captured.

Ultrasonic measurements might
not function in the following situ-
ations:



For small children and ani-
mals.



For persons with certain cloth-
ing, for instance coats.



With external interference of
the ultrasound, for instance
from passing vehicles or loud
machines.



When sensors are dirty, iced
over, damaged or out of posi-
tion.



Under certain weather condi-
tions such as high relative
humidity, wet conditions,
snowfall, extreme heat, or
strong wind.



With tow bars and trailer cou-
plings of other vehicles.



With thin or wedge-shaped
objects.



With moving objects.



With elevated, protruding
objects such as ledges.



With objects with corners,
edges, and smooth surfaces.



With objects with a fine sur-
face structure such as fences.



For objects with porous sur-
faces.



With small and low objects,
for instance boxes.



With obstacles and persons at
the edge of the lane.



With soft obstacles or obsta-
cles covered in foam material.



With plants and bushes.



Low objects already dis-
played, for instance curbs,
can move into the blind area
of the sensors before or after

Limits of side parking aid

System limits

Safety information

WARNING

The system is designed to oper-

ate in certain conditions and cir-

cumstances. Due to conditions or

other factors, the system may not

respond. There may be a risk of

accident or risk of damage to

property. Actively intervene as

needed. Refer to the information

in this Owner’s Manual regarding

the scope of the system’s opera-

tion and limitations.

Limits of ultrasonic measure-
ment

224

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

a continuous tone sounds.



Cargo that extends beyond
the perimeter of the vehicle is
not taken into account by the
system.

The system may issue a warn-
ing under the following condi-
tions even though there is no
obstacle within the detection
range:



In heavy rain.



When sensors are very dirty
or covered with ice.



When sensors are covered in
snow.



On rough road surfaces.



On uneven surfaces, such as
speed bumps.



In large buildings with right
angles and smooth walls, for
instance in underground
garages.



In automatic vehicle washes.



Due to heavy exhaust.



Due to other ultrasound
sources, for instance sweep-
ing machines, high pressure
steam cleaners or neon lights.

To prevent false alarms, switch
off Automatic Park Sensors
activ. on obstacle detection,
refer to page 225, for instance in
automatic vehicle washes.

A vehicle message is displayed.

Parking Sensor has failed. Have
the system checked by your
Toyota dealer.

The rearview camera provides
assistance in parking and
maneuvering backwards. The
area behind the vehicle is
shown on the Control Display.
Additionally, assistance func-
tions can be shown in the dis-
play, e.g., help lines.

False warnings

Malfunction

White symbol is displayed,
and the range of the sen-
sors is dimmed on the
Control Display.

Rearview camera

Concept

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment in assessing the traffic

conditions. There is a risk of acci-

dent. Adjust driving style to traffic

conditions. Watch traffic and vehi-

cle surroundings closely and

actively intervene where appropri-

ate.

225

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

The camera lens is near the
license plate light.
The image quality may be
impaired by dirt. If necessary,
clean the camera lens.

The system is switched on auto-
matically if selector lever posi-

tion R is engaged when the
engine is running.

The system switches off when a
certain driving distance or speed
is exceeded.
Switch the system back on, if
needed.



On: the LED lights up.



Off: the LED goes out.

The parking assistance func-
tions are shown on the Control
Display.

If the rearview camera view is
not displayed, change the view
via Toyota Supra Command:

1

If necessary, tilt the controller
to the side.

2

 "Rear view camera"

The rearview camera image is
displayed.



The rearview camera is

Overview

Depending on the vehicle
equipment: button in the
vehicle

Park assistance button

Camera

Switching on/off

Switching on automatically

Automatic deactivation
during forward travel

Depending on the vehicle
equipment: switching on/off
manually

Press the park assistance
button.

Switching the view via Toy-
ota Supra Command

Functional requirements

226

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

switched on.



Keep the recording range of
the camera clear. Protruding
cargo or roof rack systems
can limit the detection range
of the camera.

More than one assistance func-
tion can be active at the same
time.
The assistance functions can be
manually activated.

1

Move the Controller to the
right, if needed.

2

With corresponding equip-
ment:

3

With corresponding equip-
ment:

 "Camera image"



 "Parking aid lines".

Pathway lines and turning radius
lines are displayed, refer to page

226

.



 "Obstacle marking".

Depending on the vehicle equip-
ment, the obstacles detected by
Parking Sensors are displayed,
refer to page

227

, by markings.

■

Pathway lines

Pathway lines help you to esti-
mate the space required when
parking and maneuvering on
level roads.
Pathway lines depend on the
steering angle and are continu-
ously adjusted to the steering
wheel movements.

■

Turning radius lines

Turning radius lines can only be
superimposed on the camera
image together with pathway
lines.
Turning radius lines show the
course of the smallest possible
turning radius on a level road.
Only one turning radius line is
displayed after the steering

Display on the Control Dis-
play

General information

Parking aid lines

227

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

wheel is turned past a certain
angle.

■

Parking using pathway and
turning radius lines

1

Position the vehicle so that
the red turning radius line
leads to within the limits of
the parking space.

2

Turn the steering wheel to
the point where the green
pathway line covers the cor-
responding turning radius
line.

Depending on the vehicle equip-
ment, obstacles behind the vehi-
cle are detected by the Parking
Sensors.
Obstacle markings can be faded
into the image of the rearview
camera.
The colored thresholds of the
obstacle markings match the
markings of the Parking Sen-
sors.

With the rearview camera
switched on:

1

Move the Controller to the
left, if needed.

2

"Camera image"

3



"Brightness"



"Contrast"

4

Set the desired value.

If the camera is deactivated, for
instance if the trunk lid is open,
the camera image is displayed
hatched in gray.

Very low obstacles as well as
high, protruding objects such as
ledges may not be detected by
the system.
Depending on the vehicle equip-
ment, some assistance func-
tions also consider data from the
Parking Sensors.
Follow the notes in the Parking
Sensors chapter.
The objects displayed on the
Control Display may be closer

Obstacle marking

Setting brightness and
contrast via Toyota Supra
Command

System limits

Deactivated camera

Detection of objects

228

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

than they appear. Do not esti-
mate the distance from the
objects on the display.

At blind driveways or when driv-
ing out of diagonal parking
spaces, approaching cross traf-
fic is detected sooner by the
system than is possible from the
driver's seat.

Two radar sensors in the rear
bumper monitor the area behind
the vehicle.
The system indicates approach-
ing traffic.

The radar sensors are located in
the rear bumper.
Always keep the bumper in the

RCTA (Rear cross traffic
alert) function

Concept

General information

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment in assessing visibility

and traffic situation. There is a risk

of an accident. Adjust driving style

to traffic conditions. Watch traffic

closely and actively intervene

where appropriate.

Overview

Button in the vehicle

Park assistance button

Radar sensors

229

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

area of the radar sensors clean
and unobstructed.

1

 Press park assistance

button.

2

Move the Controller to the
left.

3

 "Settings"

4

"Cross traffic alert"

5

"Cross traffic alert"

Or via Toyota Supra Command:

1

"My vehicle"

2

"Vehicle settings"

3

"Parking"

4

"Cross traffic alert"

5

"Cross traffic alert"

If the system was activated on
the Control Display, it is auto-
matically switched on as soon
as Parking Sensors or Pan-
orama View is active and a gear
is engaged.
If reverse gear is engaged, the
rear system is switched on.

The system is automatically

switched off in the following situ-
ations:



When the speed exceeds
walking speed.



When a certain driving dis-
tance is exceeded.



With an active parking opera-
tion of the parking assistant.

The respective display is called
up on the Control Display. A sig-
nal tone may sound and the light
in the exterior mirror may flash.

The light in the exterior mirror
flashes if vehicles are detected
by the rear sensors and your
own vehicle is moving back-
wards.

Switching on/off

Activating/deactivating the
system

Switching on automatically

Switching off automatically

WARNING

General information

Light in the exterior mirror

230

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

In the Parking Sensors view, the
respective boundary area
flashes red, if vehicles are
detected by the sensors.

In addition to the optical indica-
tor, a warning signal sounds if
your own vehicle moves into the
respective direction.

The system may not be fully
functional in the following situa-
tions:



If the speed of the approach-
ing vehicle is very high.



In heavy fog, wet conditions,
or snowfall.



In tight curves.



If the bumper is dirty, iced up,
or covered, for instance by
stickers.



If the field of view of the sen-
sors is covered, e.g., by
garage walls, hedges or snow

hills.



If cargo protrudes.



If crossing objects move at a
very slow speed.



If other objects are in the cap-
ture range of the sensors, that
hide cross traffic.

Display in the Parking Sen-
sors view

Acoustic warning

System limits

231

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The chassis components are
optimized for the vehicle and its
scope of application and thereby
ensure the best possible Driving
Dynamics.

The Adaptive variable suspen-
sion is a controllable sport chas-
sis/suspension. This system
reduces undesirable vehicle
motion when using a dynamic
driving style or traveling on
uneven road surfaces.

This enhances the driving
dynamics and driving comfort
depending on the road surface
condition and driving style.

The system offers different
shock absorber settings rang-
ing from comfortable travel to
dynamic driving.
The damping settings are
assigned to the different driving
modes of the Sport mode
switch, refer to page 135.

Driving comfort

Vehicle features and
options

Chassis components

Adaptive variable suspen-
sion

Concept

General information

232

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The air quality in the vehicle is
improved by the following com-
ponents:



Emission tested car's interior.



Microfilter.



Air conditioning system to
control the temperature, air
flow and recirculated-air
mode.



Automatic recirculated-air
control AUC.



Parked-car ventilation.



A label regarding the refriger-
ant of the air conditioning sys-
tem is attached to the hood at
the location shown in the fol-
lowing illustration.



The meaning of each symbol
on the label are as follows:

Climate control

Vehicle features and
options

Interior air quality

Safety notes

WARNING

When using the air conditioning

system, seat heaters, etc. for a

long period of time, make sure

that no body parts are kept near

the air outlets or in direct contact

with the seat, as doing so may

lead to minor burns or chill burns.

If you feel unusual while using the

air conditioning system or seat

heaters, stop use or change the

setting immediately.

Air conditioning system
refrigerant

Caution

Air conditioning sys-
tem

Air conditioning sys-
tem lubricant type

233

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Requires registered
technician to service
air conditioning sys-
tem

Flammable refrigerant

NOTICE

■

When repairing/replacing

parts of the air conditioning

system

Have repair/replacement per-

formed by your Toyota dealer.

When a part of the air conditioning

system, such as the evaporator, is

to be replaced, it must be

replaced with a new one.

Automatic air condition-
ing

Overview

Buttons in the vehicle

Climate control functions

Button

Function

Temperature, refer to
page 234.

Air-conditioning mode,
see page 234.

Maximum cooling, refer
to page 235.

AUTO program, refer to
page 235.

Recirculated-air mode,
refer to page 236.

Switch off, refer to page
234.

Air distribution, man-
ual, refer to page 237.

Defrost and defog the
windshield, refer to
page 237.

Rear window defroster,
refer to page 237.

234

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Press any button except for the
following:



Switching off.



Rear window defroster.



Seat heating.

Complete system:

The automatic air conditioning
achieves the set temperature as
quickly as possible, if needed,
by using the maximum cooling
or heating capacity, and then
keeps it constant.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Climate functions"

4

"Temperature adjustment,
upper body"

5

Set the desired temperature.

Do not rapidly switch between
different temperature settings.
Otherwise, the automatic air
conditioning will not have suffi-
cient time to adjust the set tem-
perature.

The air in the car's interior will
be cooled and dehumidified
and, depending on the tempera-
ture setting, warmed again.
The car's interior can only be
cooled with the drive-ready state
switched on.

Seat heating, refer to
page 109.

Air flow, manual, refer
to page 236.

Switching on/off

Switching on

Switching off

Press and hold the but-
ton.

Temperature

Concept

Button

Function

Adjusting

Turn the dial clockwise
to increase the tempera-
ture and counterclock-
wise to decrease the
temperature.

Air conditioning

Concept

235

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Air conditioning is switched on
with the engine running.
Depending on the weather, the
windshield and side windows
may fog up briefly when
drive-ready state is switched on.
The air conditioning is switched
on automatically with the AUTO
program.
When using the automatic air
conditioning, condensation
water develops and collects
underneath the vehicle.

The system is set to the lowest
temperature, optimum air flow
and recirculated-air mode with
the drive-ready state switched
on.

The function is available with
external temperatures above
approx. 32 °F/0 °C and with the
drive-ready state switched on.

The LED is illuminated with the
system switched on.
Air flows out of the vents to the
upper body region. The vents
need to be open for this.
The air flow can be adjusted
with the program active.

The AUTO program cools, venti-
lates or heats the car's interior
automatically.
The air flow, air distribution and
temperature will be controlled
automatically depending on the
interior temperature and the set-
ting for the desired temperature.

The LED is illuminated with the
AUTO program switched on.
Depending on the selected tem-
perature and outside influ-
ences, the air is directed to the
windshield, side windows, upper

Switching on/off

Press the button.

Maximum cooling

Concept

General information

Switching on/off

Press the button.

AUTO program

Concept

Switching on/off

Press the button.

236

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

body, and into the floor area.
The air conditioning, refer to
page 234, is switched on auto-
matically with the AUTO pro-
gram.
The AUTO program is switched
off automatically, when manual
air distribution is set.

You may react to unpleasant
odors or pollutants in the imme-
diate environment by temporar-
ily suspending the supply of
outside air. The system then
recirculates the air flow within
the vehicle.

The LED is illuminated when the
recirculated-air mode is
switched on.
When the left LED is illuminated:
Automatic recirculated air mode

If the pollution sensor detects pol-
lutants in the outside air, the air
mode is automatically changed
from outside air mode to recircu-
lated air mode.

When the right LED is illumi-
nated: Recirculated air mode

The air in the cabin is continuously

recirculated.

To prevent window fogging,
recirculated-air mode switches
off automatically after a certain
amount of time, depending on
the environmental conditions.
With constant recirculated-air
mode, the air quality in the car's
interior deteriorates and the fog-
ging of the windows increases.
If there is window condensation,
switch off recirculated-air mode
or defog the windows, refer to
page 237.

The air flow for climate control
can be adjusted manually.

To manually adjust air flow
switch off AUTO program first.

The selected air flow is shown
on the climate control display.
The air flow may be reduced
automatically to save battery
power.

Recirculated-air mode

Concept

Operation

Press the button repeat-
edly to select an operat-
ing mode.

Controlling the air flow
manually

Concept

General information

Operation

Press the left or right
side of the button:
decrease or increase air
flow.

237

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

The air distribution for climate
control can be adjusted manu-
ally.



Windows, upper body region,
and floor area.



Upper body region and floor
area.



Floor area.



Windows and floor area.



Windows.



Windows and upper body.



Upper body region.

The selected air distribution is
shown on the climate control
display.
If there is window condensation,
defog the windows, refer to
page P.237.

Ice and condensation are

quickly removed from the wind-
shield and the front side win-
dows.

The LED is illuminated with the
system switched on.
The air flow can be adjusted
manually with the system
switched on.

The function is available with the
engine running.
The rear window defroster
switches off automatically after a
certain period of time.

The microfilter removes dust
and pollen from the incoming air.
Have this filter changed during
vehicle maintenance, refer to
page 307.

Controlling the air distri-
bution manually

Concept

Operation

Press the button repeat-
edly to select a program:

Defrost windshield and
remove condensation

Concept

Switching on/off

Press the button.

If there is any window
condensation, press the
button on the driver's
side or switch on the air
conditioning. Make sure
that air can flow to the
windshield.

Rear window defroster

Press the button. The
LED lights up.

Microfilter

238

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

The air flow directions can be
individually adjusted.

The air flow directions can be
adjusted for direct or indirect
ventilation.
Open the vents and position
them to ensure effective climate
control.

The air flow is directed towards
the passengers. The air flow
heats or cools noticeably,
depending on the adjusted tem-
perature.

The air flow is not directed
towards the passengers. The
car's interior is warmed or
cooled indirectly, depending on
the set temperature.



Lever for changing the air flow
direction, arrow

1

.



Thumbwheel for variable
opening and closing of the
vents, arrow

2

.

The car's interior can be cooled
or heated before driving off with
the parked-car ventilation.
Depending on set temperature
and ambient temperature, the
car's interior is ventilated or pos-
sibly heated using the residual
engine heat.

The system can be switched on
and off directly or via a preset
departure time.
The activation time is deter-
mined based on the external
temperature. The system
promptly switches on before the
selected departure time.

Ventilation

Concept

Adjusting the ventilation

General information

Direct ventilation

Indirect ventilation

Front ventilation

Parked-car ventilation

Concept

General information

239

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS



The vehicle is in idle state or
standby state and not in
drive-ready state.



Battery is sufficiently charged.

If parked-car ventilation is switched
on, the vehicle battery will be dis-
charged. Thus, limit the maximum
activation time to save the vehicle
battery. The system will be avail-
able again after the engine is
started or after a short trip.



Make sure that the vehicle's
date and time are set cor-
rectly.



Open the vents to allow air to
flow out.

There are different ways to
switch the system on or off.
The system switches off auto-
matically after a certain period of
time. The system continues to
run for some time after being
switched off.

■

General information

When the vehicle is in standby
state, the parked-car ventilation
can be switched on or off via the
automatic air conditioning but-
tons.

■

Switching on

Press any button except:



Rear window defroster.



Lower air flow button side.



Seat heating.



Menu.

■

Switching off

The system switches off after
leaving and locking the vehicle.

 Press and hold the bot-

tom button.

1

"My Vehicle"

2

"Vehicle settings"

3

"Climate functions"

4

"Comfort ventilation"

5

"Activate now"

Functional requirements

Switching on/off directly

General information

Using the button

Via Toyota Supra Command

Display

Symbol

Description

Symbol on the auto-
matic air conditioning
indicates the system is
switched on.
REST is displayed on
the automatic air condi-
tioning. The residual
engine heat is used.

240

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Different departure times can be
adjusted to ensure a comfort-
able interior temperature in the
vehicle at the time of departure.



One-time departure time: the
time can be set.

The system is switched on once.



Departure time with week-
day: time and day of the week
can be set.

On the desired weekdays, the sys-
tem will be switched on promptly
before the set departure time.

The departure time is prese-
lected in two steps:



Set departure times.



Activate departure times.

A minimum of 10 minutes
should pass between set-
ting/activating the departure
time and the planned departure
time to allow a sufficient period
of time for the climate control.

■

Via Toyota Supra Command

1

"My Vehicle"

2

"Vehicle settings"

3

"Climate functions"

4

"Comfort ventilation"

5

Select the desired departure
time.

6

Set the departure time.

7

Select day of the week, if
needed.

■

Functional requirement

If a departure time is to influ-
ence the switching on of
parked-car ventilation, the
respective departure time must
be activated first.

■

Via Toyota Supra Command

1

"My Vehicle"

2

"Vehicle settings"

3

"Climate functions"

4

"Comfort ventilation"

5

"For departure time"

6

Activate the desired depar-
ture time.

 The symbol on the automatic

air conditioning signals an acti-
vated departure time.

Departure time

Concept

Setting the departure time

Activating the departure time

Display

241

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The integrated Universal
Remote Control in the interior
mirror can operate up to 3 func-
tions of remote-controlled sys-
tems such as garage door
drives, barriers, or lighting sys-
tems.

The Integrated Universal
Remote Control replaces up to 3
different hand-held transmitters.
To operate the remote control,
the buttons on the interior mirror
must be programmed with the

desired functions. The
hand-held transmitter for the
particular system is required in
order to program the remote
control.
Before selling the vehicle, delete
the stored functions for the sake
of security.
If possible, do not install the
antenna of the remote-con-
trolled system, e.g. the garage
door drive, near metal objects to
ensure the best possible opera-
tion.

Interior equipment

Vehicle features and
options

Integrated Universal
Remote Control

Concept

General information

Safety information

WARNING

The operation of remote-con-

trolled systems with the integrated

universal remote control, such as

the garage door, may result in

injury, for example, body parts

becoming jammed in a garage

door. There is a risk of injury or

risk of damage to property. Make

sure that the area of movement of

the respective system is clear

during programming and opera-

tion. Also follow the safety infor-

mation of the hand-held

transmitter.

Compatibility

If this symbol is printed
on the packaging or in
the owner's manual of
the system to be con-
trolled, the system is
generally compatible
with the integrated Uni-
versal Remote Control.

242

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Additional questions are
answered by:



Your Toyota dealer.



www.homelink.com on the
Internet.

HomeLink is a registered trade-
mark of Gentex Corporation.



Buttons, arrow

1

.



LED, arrow

2

.



The hand-held transmitter,
arrow

3

, is required for pro-

gramming.

The battery of the hand-held
transmitter must be fully
charged at the time of program-
ming to ensure an optimal range
of the integrated universal
remote control.

1

Switch on standby state.

2

Initial setup: Press and hold
the two outer buttons on the

interior mirror simultaneously
for approximately 10 seconds
until the LED flashes green
rapidly. This erases all pro-
gramming of the buttons on
the interior mirror.

3

Press the interior mirror but-
ton to be programmed. The
LED on the interior mirror will
slowly begin flashing orange.

4

Hold the hand-held transmit-
ter for the system to be used
approx. 1 to 12 in/2.5 to 30
cm away from the buttons on
the interior mirror. The
required distance depends
on the hand-held transmitter.

5

Press and hold the button of
the desired function on the
hand-held transmitter.

Canada: if programming with the

hand-held transmitter was inter-

rupted, hold down the interior mirror

button and repeatedly press and

release the hand-held transmitter

button for 2 seconds.

6



The LED lights up green: pro-
gramming completed.

Release the button.



The LED flashes fast: pro-
gramming is not complete.

Press the button on the interior mir-
ror for 2 seconds and release. Per-
form this procedure three times to
complete the programming proce-
dure.
If the integrated universal remote
control remains nonoperational,
continue with the special features

Control elements on the
interior mirror

Programming

General information

243

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

for change code wireless systems.



LED does not flash green
after 60 seconds: program-
ming not completed.

Repeat steps

3

 to

6

.

To program other functions on
other buttons, repeat steps

3

 to

5

.

If you are unable to operate the
remote-controlled system after
repeated programming, please
check if the system to be con-
trolled features a rolling code
radio system.
Refer to the owner's manual for
the system.
For systems with a rolling code
radio system, the integrated
Universal Remote Control and
the system also have to be syn-
chronized.
Please read the owner's manual
to find out how to synchronize
the system.
Synchronizing is easier with the
aid of a second person.
Synchronizing the universal
remote control with the system:

1

Park the vehicle within range
of the remote-controlled sys-
tem.

2

Program the relevant button
on the interior mirror as
described.

3

Locate and press the syn-
chronizing button on the sys-
tem being programmed, e.g.
at the garage gate. You have
approx. 30 seconds for the
next step.

4

Hold down the programmed
button on the interior mirror
for approximately 3 seconds
and then release it. If neces-
sary, repeat this step up to
three times in order to finish
synchronization. Once syn-
chronization is complete, the
programmed function will be
carried out.

1

Switch on standby state.

2

Press and hold the interior
mirror button to be pro-
grammed.

3

As soon as the LED on the
interior mirror flashes orange
after approx. 20 seconds,
release the button.

4

Hold the hand-held transmit-
ter for the system to be used
approx. 1 to 12 in/2.5 to 30
cm away from the buttons on
the interior mirror. The
required distance depends
on the hand-held transmitter.

5

Press and hold the button of
the desired function on the
hand-held transmitter.

Canada: if programming with the

Special feature of the rolling
code wireless system

Reprogramming individ-
ual buttons

244

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

hand-held transmitter was inter-

rupted, hold down the interior mirror

button and repeatedly press and

release the hand-held transmitter

button for 2 seconds.

6

The LED can light up in dif-
ferent ways.



The LED lights up green: the
programming procedure is
completed.

Release the button.



The LED flashes fast: the
hand-held transmitter was
detected but programming is
not complete.

Press the button on the interior mir-
ror for 2 seconds and release. Per-
form this procedure three times to
complete the programming proce-
dure.
If the universal remote control
remains nonoperational, continue
with the special features for change
code wireless systems.



LED does not flash green
after 60 seconds: program-
ming not completed.

Repeat steps

3

 to

6

.

If the programming procedure is
not completed, the previous pro-
gramming will remain
unchanged.

The system, such as the garage
door, can be operated using the
button on the interior mirror
while the drive-ready or standby
state is switched on. To do this,
hold down the button within
receiving range of the system
until the function is activated.
The interior mirror LED stays lit
while the wireless signal is being
transmitted.

All stored functions will be
deleted. The functions cannot
be deleted individually.
Press and hold the two outer
buttons on the interior mirror
simultaneously for approxi-
mately 10 seconds until the LED
on the interior mirror flashes
green rapidly.

Operation

WARNING

The operation of remote-con-

trolled systems with the integrated

universal remote control, such as

the garage door, may result in

injury, for example, body parts

becoming jammed in a garage

door. There is a risk of injury or

risk of damage to property. Make

sure that the area of movement of

the respective system is clear

during programming and opera-

tion. Also follow the safety infor-

mation of the hand-held

transmitter.

Deleting stored functions

245

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Fold the sun visor down or up.

A vanity mirror is located in the
sun visor behind a cover. When
the cover is opened, the mirror
lighting switches on.

The lighter socket can be used
as a socket for electrical equip-
ment when standby and
drive-ready state are switched
on.

The total load of all sockets
must not exceed 140 watts at 12
volts.
Do not damage the socket by
using non-compatible connec-
tors.

Pull off the cover.

Sun visor

Glare shield

Vanity mirror

Sockets

Concept

General information

Safety information

WARNING

Devices and cables in the unfold-

ing area of the airbags, such as

portable navigation devices, can

hinder the unfolding of the airbag

or be thrown around in the car's

interior during unfolding. There is

a risk of injury. Make sure that

devices and cables are not in the

airbag's area of unfolding.

NOTICE

Battery chargers for the vehicle

battery can work with high volt-

ages and currents, which means

that the 12 volt on-board network

can be overloaded or damaged.

There is a risk of damage to prop-

erty. Only connect battery char-

gers for the vehicle battery to the

starting aid terminals in the

engine compartment.

NOTICE

If metal objects fall into the

socket, they can cause a short cir-

cuit. There is a risk of damage to

property. Replace the socket

cover again after using the

socket.

Center console

246

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Open the cover.

Follow the information regarding
the connection of mobile
devices to the USB port in the
section on USB connections,
refer to page 70.

The USB port is located on the
center console.
Properties:



USB port Type A.



For charging external
devices.



Charging current:

max. 1.5 A (vehicles without wire-
less charger)
max. 2.1 A (vehicles with wireless
charger)



For data transfer.

The wireless charging tray
enables the following functions
to be performed without cables:



Charging the rechargeable
battery of a mobile phone with
Qi capability and of other
mobile devices, which support
the Qi standard.



Connect the mobile phone to
the external antenna.

Depending on the country, this pro-
vides for better network reception
and a consistent reproduction qual-
ity.

When inserting the mobile
phone, make sure there are no
objects between it and the wire-
less charging tray.
During charging, the surface of
the tray and the mobile phone
may become warm. Higher tem-
peratures may lead to a reduc-
tion in the charge current
through the mobile phone, and
in isolated cases the charging

Cargo area

USB port

General information

In the center console

Wireless charging tray

Concept

General information

247

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

process is paused temporarily.
Follow the relevant instructions
in the mobile phone owner's
manual.

 If the vehicle is equipped

with a charge indicator, the Con-
trol Display shows whether a
mobile phone with Qi capability
is being charged.

This device has been tested for

human exposure limits and found

compliant at a minimum distance of

4 in/10 cm during operation.
Therefore, a distance of 4 in/10 cm

must be maintained in every direc-

tion when operating the device.

Mounting position of the product.



The mobile phone must com-
patibly support the required Qi
standard.

If the mobile phone does not sup-
port the Qi standard, the mobile
phone can be charged using a spe-
cial Qi-compatible charging case.



Standby state is switched on.



Observe the maximum
dimensions of the mobile
phone.

Safety information

WARNING

When charging a device that

meets the Qi standard in the wire-

less charging tray, any metal

objects located between the

device and the tray can become

very hot. Placing storage devices

or electronic cards, such as chip

cards, cards with magnetic strips

or cards for signal transmission,

between the device and the tray

may impair the card function.

There is a risk of injury and risk of

damage to property. When

charging mobile devices, make

sure there are no objects between

the device and the tray.

NOTICE

The tray is intended for mobile

phones up to a particular size.

Forceful inserting of the mobile

phone into the tray can damage

the tray or the mobile phone.

There is a risk of damage to prop-

erty. Observe the maximum

dimensions for mobile phones. Do

not force the mobile phone into

the tray.

Functional requirements

248

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)



Use only protective jackets
and covers up to a maximum
thickness of 0.07 in/2 mm.
Otherwise, the charging func-
tion may be impaired.



The mobile phone to be
charged is located in the cen-
ter of the tray.

1

LED

2

Storage area

Place the mobile phone cen-
tered in the storage tray with the
display facing up.

The mobile phone must not exceed
the maximum size of approximately
6.0 x 3.1 x 0.7 in/154.5 x 80 x 18
mm.

If the vehicle is equipped with
the forgotten warning function, a
warning can be output if a
mobile phone with Qi capability
was forgotten in the wireless
charging tray when leaving the
vehicle.
The forgotten warning is dis-
played in the instrument cluster.

Operation

Overview

Inserting the mobile phone

LED displays

Color

Meaning

Blue

The mobile phone is
charging.
Depending on the model
and the vehicle, the blue
LED is no longer illumi-
nated once the inserted
mobile phone with Qi
capability is fully charged.

Orange

The mobile phone is not
charging.
Temperature on the
mobile phone possibly
too high or foreign object
in the charging tray.

Red

The mobile phone is not
charging.
Contact a dealer’s ser-
vice center or another
qualified service center or
repair shop.

Forgotten warning

General information

249

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Via Toyota Supra Command:

1

“My Vehicle”

2

“System settings”

3

“Wireless charging tray”

4

“Forgotten mobile device
alert”

At high temperatures on the
mobile phone or in the vehicle,
the charging functions of the
mobile phone may be limited
and some functions may no lon-
ger work.

Your car is equipped with a wire-
less charging tray (WCA) to
charge your mobile phone and
connect it to the mobile network.
To ensure the best possible con-
nection a signal booster
(LTE-Compensator) is used in
conjunction with the WCA. The
following paragraphs refer to
this booster:
This is a CONSUMER device.
BEFORE USE, you MUST
REGISTER THIS DEVICE with
your wireless provider and have
your provider's consent. Most
wireless providers consent to
the use of Compensators. Some
providers may not consent to

the use of this device on their
network. If you are unsure, con-
tact your provider. You MUST
operate this device with
approved antennas and cables
as specified by the manufac-
turer. Antennas MUST be
installed at least 20 cm (8
inches) from any person. You
MUST cease operating this
device immediately if requested
by the FCC or a licensed wire-
less service provider. Warning
E911 location information may
not be provided or may be inac-
curate for calls served by using
this device.
Please observe additionally the
following information



Sprint Nextel will allow con-
sumers to register their signal
boosters by calling their
toll-free number.



T-Mobile online registration
link:
(www.T-Mobile.com/Booster-
Registration);
(https://saqat.t-mobile.com/sit
es/SignalBooster#).



Verizon’s online registration
link: (http://www.verizonwire-
less.com/wcms/con-
sumer/register-signal-booster.
html).



AT&T online registration link
(https://secu-
rec45.securewebses-
sion.com/attsignal-booster.co
m/).

Activating

System limits

LTE-Compensator - Infor-
mation and User Manual

250

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)



U.S.Cellular online registra-
tion link (http://www.uscellu-
lar.com/uscellular/support/fcc-
booster-registration.jsp).

Before use you must register
your booster device with your
wireless provider.
If you should be requested by
the FCC to cease operating your
booster you are not allowed to
insert your mobile phone in the
charging tray anymore unless
the booster is permanently
deactivated by your Toyota
dealer.
You must not remove the
booster from the car nor use it
with any other than the prein-
stalled coupling device or
antenna. Any modification of the
existing antenna or coupling
device as well as the use of
other antennas or coupling
devices will cause the cease of
the booster’s operating license.
The booster device fulfills the
network protections tandards as
required by the FCC, such as
intermodulation limits, oscillation
detection and gainlimits.
Booster Manufacturer: Kathrein
Automotive
Model Number: LTECOMPB0
Part Number: 6803145-01
FCC-ID: 2ACC7LTECOMPB0

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Storage compart-

ments

Vehicle features and
options

Safety information

WARNING

Loose objects or devices with a

cable connection to the vehicle,

for instance mobile phones, can

be thrown into the car’s interior

while driving, for instance in the

event of an accident or during

braking and evasive maneuvers.

There is a risk of injury. Secure

loose objects or devices with a

cable connection to the vehicle in

the car’s interior.

NOTICE

Anti-slip pads such as anti-slip

mats can damage the dashboard.

There is a risk of damage to prop-

erty. Do not use anti-slip pads.

251

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

The vehicle interior contains
multiple storage compartments
for stowing objects.

Pull the handle.
The light in the glove compart-
ment switches on.

Fold cover closed.

The glove compartment can be
locked with an integrated key,
refer to page 84. This prevents
access to the glove compart-
ment.
After the glove compartment is
locked, the remote control can
be handed over without the inte-
grated key, for instance when
the vehicle is parked by valet
parking.

There are storage compart-
ments in the doors.

Storage compartments

Glove compartment

Safety information

WARNING

Folded open, the glove compart-

ment protrudes in the car's inte-

rior. Objects in the glove

compartment can be thrown into

the car's interior while driving, for

instance in the event of an acci-

dent or during braking and eva-

sive maneuvers. There is a risk of

injury. Always close the glove

compartment immediately after

using it.

Opening

Closing

Locking

Compartments in the
doors

General information

Safety information

WARNING

Breakable objects, such as glass

bottles or glasses, can break in

the event of an accident or a brak-

ing or evasive maneuver. Broken

glass can be scattered in the car's

interior. There is a risk of injury or

risk of damage to property. Do not

use any breakable objects while

driving. Only stow breakable

objects in closed storage com-

partments.

252

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Cup holders

Safety information

WARNING

Unsuitable containers in the cup

holders may damage the cup

holders or be thrown about the

car’s interior in the event of an

accident, an evasive maneuver,

or forceful braking. Spilled liquids

can distract from the traffic condi-

tions and lead to an accident. Hot

drinks can damage the cup holder

or lead to scalding. There is a risk

of injury or risk of damage to prop-

erty. Do not force objects into the

cup holder. Use lightweight, shat-

terproof, and sealable containers.

Do not transport hot beverages.

Cargo area

Vehicle features and
options

Loading

Safety information

WARNING

High gross weight can overheat

the tires, damage them internally

and cause a sudden drop in tire

inflation pressure. Driving charac-

teristics may be negatively

impacted, reducing lane stability,

lengthening the braking distances

and changing the steering

response. There is a risk of an

accident. Pay attention to the per-

mitted load capacity of the tires

and never exceed the permitted

gross weight.

253

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

1

Locate the statement “The
combined weight of occu-
pants and cargo should
never exceed XXX kg or XXX
lbs” on your vehicle’s plac-
ard.

2

Determine the combined
weight of the driver and pas-
sengers that will be riding in
your vehicle.

3

Subtract the combined
weight of the driver and pas-
sengers from XXX kg or XXX
lbs.

4

The resulting figure equals
the available amount of cargo
and luggage load capacity.
For example, if the “XXX”
amount equals 1,400 lbs and
there will be five 150 lbs pas-
sengers in your vehicle, the
amount of available cargo
and luggage load capacity is
650 lbs (1,400–750 (5 x 150)
= 650 lbs).

5

Determine the combined
weight of luggage and cargo
being loaded on the vehicle.
That weight may not safely
exceed the available cargo
and luggage load capacity
calculated in Step

4

.

6

If your vehicle will be towing
a trailer, load from your trailer
will be transferred to your
vehicle. Consult this manual
to determine how this
reduces the available cargo
and luggage load capacity of
your vehicle.

WARNING

Loose object or devices with a

cable connection to the vehicle,

for instance mobile phones, can

be thrown about the car’s interior

while driving, for instance in the

event of an accident or during

braking and evasive maneuvers.

There is a risk of injury. Secure

loose objects or devices with a

cable connection to the vehicle in

the car’s interior.

WARNING

Improperly stowed objects can

shift and be thrown into the car’s

interior, for instance in the event

of an accident or during braking

and evasive maneuver. Vehicle

occupants can be hit and injured.

There is a risk of injury. Stow and

secure objects and cargo prop-

erly.

NOTICE

Fluids in the cargo area can

cause damage. There is a risk of

damage to property. Make sure

that no fluids leak in the cargo

area.

Steps for Determining Cor-
rect Load Limit

254

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

The maximum load is the sum of
the weight of the occupants and
the cargo.
The greater the weight of the
occupants, the less cargo that
can be transported.



Cover sharp edges and cor-
ners on the cargo.



Heavy cargo: stow as far for-
ward and as low as possible,
ideally directly behind the
cargo partition.



Smaller and lighter cargo:
secure with ratchet straps or
with a cargo net or draw
straps.



Larger and heavy cargo:
secure with cargo straps.

Attach load securing aids, such
as lashing straps, tensioning
straps, draw straps or cargo
nets, to the lashing eyes in the
cargo area.

There are four lashing eyes in
the cargo area for securing
cargo.

A multi-function hook is located
on the left and right side in the
cargo area.

Load

Stowing and securing
cargo

Lashing eyes in the cargo
area

General information

Lashing eyes

Multi-function hook

General information

255

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

A tensioning strap is available
on the right side trim for fasten-
ing small objects.

Small objects can be stowed in
the net on the left side. To trans-
port larger objects, slide the net
down. Grab the top of the net as
close as possible to the edge
next to the holder. At first, a
resistance must be overcome.

A storage compartment is avail-
able on the right side of the
cargo area.

Unlock the cover of the right
side panel, arrow

1

, and fold up,

arrow

2

.

The cover can be removed for
stowing bulky items.

1

Unhook the retaining straps
on the tailgate.

Safety information

WARNING

Improper use of the multi-function

hooks can lead to a risk of objects

flying about during braking and

evasive maneuvers, for example.

There is a risk of injury and risk of

damage to property. Only hang

lightweight objects, such as shop-

ping bags, from the multi-function

hooks. Only transport heavy lug-

gage in the cargo area if it has

been appropriately secured.

Tensioning strap

Net

Storage compartment on
the right side

General information

Opening

Luggage cover

Removing

256

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

2

Slightly lift the cover, arrow

1

,

and pull backward from the
holders, arrows

2

.

To insert, proceed in reverse
order. Make sure that the lug-
gage cover is positioned cor-
rectly in the brackets.

Inserting

257

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

5

5

DR
IVING TIPS

DRIVING TIPS

.

5-1. DRIVING TIPS

Things to remember when

driving........................

258

Saving fuel ..................

263

258

5-1. DRIVING TIPS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

5-1.DRIVING TIPS

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Moving parts need to begin
working together smoothly.
The following instructions will
help you to achieve a long vehi-
cle life and good efficiency.
During break-in, do not use the
Launch Control, refer to page
134.

Do not exceed the maximum
engine and road speed:



For gasoline engine 4,500
rpm and 100 mph/160 km/h.

Avoid full load or kickdown
under all circumstances.

The engine and vehicle speed
can gradually be increased.

Tire traction is not optimal due to
manufacturing circumstances
when tires are brand-new; they
achieve their full traction poten-
tial after a break-in time.
Drive conservatively for the first
200 miles/300 km.

Things to remember

when driving

Vehicle features and
options

Breaking-in period

General information

Safety information

WARNING

Due to new parts and compo-

nents, safety and driver assis-

tance systems can react with a

delay. There is a risk of an acci-

dent. After installing new parts or

with a new vehicle, drive conser-

vatively and intervene early if nec-

essary. Observe the break-in

procedures of the respective parts

and components.

Engine, transmission, and
axle drive

Up to 1,200 miles/2,000 km

From 1,200 miles/2,000 km

Tires

259

5-1. DRIVING TIPS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

5

DR
IVING TIPS

Brake discs and brake pads only
reach their full effectiveness
after approx. 300 miles/500 km.
Drive moderately during this
break-in period.

Observe the break-in proce-
dures again, if components
mentioned above are replaced.

Brake system

Following part replace-
ment

General driving notes

Closing the trunk lid

Safety information

WARNING

An open trunk lid protrudes from

the vehicle and can endanger

occupants and other traffic partici-

pants or damage the vehicle in

the event of an accident, braking

or evasive maneuvers. In addi-

tion, exhaust fumes may enter the

car's interior. There is a risk of

injury or risk of damage to prop-

erty. Do not drive with the trunk lid

open.

Ice on window glass

NOTICE

The window will be lowered

slightly when pulling on the door

handle. In the event of frost, the

window may freeze up and not be

lowered. There is a risk of dam-

age to property. When pulling on

the door handle, make sure that

the window is lowered. If neces-

sary, remove snow and ice from

the window. Do not open the door

with force.

Hot exhaust gas system

WARNING

High temperatures can occur

underneath the body, for instance

caused by the exhaust gas sys-

tem, while driving. Contact with

the exhaust gas system can

cause burns. There is a risk of

injury. Do not touch the hot

exhaust gas system, including the

exhaust pipe.

WARNING

If combustible materials, such as

leaves or grass, come in contact

with hot parts of the exhaust gas

system, these materials can

ignite. There is a risk of fire and

injuries. Do not remove the heat

shields installed and never apply

undercoating to them. Make sure

that no combustible materials can

come in contact with hot vehicle

parts in driving operation, idle or

during parking.

260

5-1. DRIVING TIPS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

When visibility is poor due to
fog, even if it is daytime, turn the
low beam headlights on to make
your vehicle more visible to
other vehicles, etc. Drive with
caution at a low speed, using
the centerline, guardrails, tail-
lights of a preceding vehicle,
etc., as guide.

When the vehicle is being blown
by crosswinds, drive at a lower
speed and grip the steering
wheel stronger than normal.
The vehicle is especially sus-
ceptible to crosswinds when
exiting a tunnel or underpass,
when driving on a bridge or
embankment, or when passing
or being passed by a truck or
other large vehicle.



During a rain storm or when
the road surface is wet, the
road surface may be slippery
and visibility may be reduced.
In this case, turn the low
beam headlights on to make
your vehicle more visible to

Mobile communication
devices in the vehicle

WARNING

Vehicle electronics and mobile

phones can influence one

another. There is radiation due to

the transmission operations of

mobile phones. There is a risk of

injury or risk of damage to prop-

erty. If possible, in the car's inte-

rior use only mobile phones with

direct connections to an exterior

antenna in order to exclude

mutual interference and deflect

the radiation from the car's inte-

rior.

Driving in inclement
weather

When visibility is poor due to
fog

During strong wind

When it is raining

261

5-1. DRIVING TIPS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

5

DR
IVING TIPS

other vehicles, etc. Increase
the distance between your
vehicle and preceding vehi-
cles and drive safely at a
lower speed than normal,
avoiding sudden accelera-
tion, braking or steering oper-
ations.



Use the rear defroster and air
conditioning system to pre-
vent the windows from fog-
ging up.



Hydroplaning is more likely to
occur when driving on ruts or
through large puddles.

On wet or slushy roads, a
wedge of water can form
between the tires and road sur-
face.
This phenomenon is referred to
as hydroplaning. It is character-
ized by a partial or complete
loss of contact between the tires
and the road surface, ultimately
undermining your ability to steer
and brake the vehicle.

When driving through water, fol-
low the following:



Deactivate Auto Start/Stop
function.



Drive through calm water

only.



Drive through water only if it is
not deeper than maximum 9.8
inches/25 cm.



Drive through water no faster
than walking speed, up to 3
mph/5 km/h.

The vehicle is equipped with an
Antilock Braking System ABS as
a standard feature.
Perform an emergency stop in
situations that require such.
Steering is still responsive. You
can still avoid any obstacles with
a minimum of steering effort.
Pulsation of the brake pedal and
sounds from the hydraulic cir-
cuits indicate that the Antilock
Braking System ABS is in its
active mode.
In certain braking situations, the

Hydroplaning

Driving through water

General information

Safety information

NOTICE

When driving too quickly through

too deep water, water can enter

into the engine compartment, the

electrical system or the transmis-

sion. There is a risk of damage to

property. When driving through

water, do not exceed the maxi-

mum indicated water level and the

maximum speed for driving

through water.

Braking safely

General information

262

5-1. DRIVING TIPS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

perforated brake discs can emit
functional noises. However,
functional noises have no effect
on the performance and opera-
tional reliability of the brake.

When roads are wet, salted, or
in heavy rain, gently press the
brake pedal every few miles.
Ensure that this action does not
endanger other traffic.
The heat generated during brak-
ing dries brake discs and brake
pads and protects them against
corrosion.
In this way braking efficiency will
be available when you need it.

■

General information

Drive long or steep downhill gra-
dients in the gear that requires
least braking effort. Otherwise,
the brakes may overheat and
reduce brake efficiency.
You can increase the engine's
braking effect by shifting down,
going all the way to first gear, if
needed.

■

Safety information

Corrosion on the brake discs
and contamination on the brake
pads are increased by the fol-
lowing circumstances:



Low mileage.



Extended periods when the
vehicle is not used at all.

Objects in the area around
the pedals

WARNING

Objects in the driver's floor area

can limit the pedal distance or

block a depressed pedal. There is

a risk of an accident. Stow objects

in the vehicle such that they are

secured and cannot enter into the

driver's floor area. Use floor mats

that are suitable for the vehicle

and can be safely attached to the

floor. Do not use loose floor mats

and do not layer several floor

mats. Make sure that there is suf-

ficient clearance for the pedals.

Ensure that the floor mats are

securely fastened again after they

were removed, for instance for

cleaning.

Driving in wet conditions

Hills

WARNING

Light but consistent brake pres-

sure can lead to high tempera-

tures, brakes wearing out and

possibly even brake failure. There

is a risk of an accident. Avoid

placing excessive stress on the

brake system.

WARNING

In idle state or with the engine

switched off, safety functions, for

instance engine braking effect,

braking assistance and steering

assistance, may not be available.

There is a risk of accident. Do not

attempt to drive in idle state or

with the engine switched off.

Brake disc corrosion

263

5-1. DRIVING TIPS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

5

DR
IVING TIPS



Infrequent use of the brakes.



Aggressive, acidic, or alka-
line cleaning agents.

Corrosion buildup on the brake
discs will cause a pulsating
effect on the brakes in their
response - generally this cannot
be corrected.

When using the automatic air
conditioning, condensation
water develops and collects
underneath the vehicle.

Higher mechanical and thermal
loads during racetrack operation
lead to increased wear. This
wear is not covered by the war-
ranty. The vehicle is not
designed for use in motor sports
competition.
Have vehicle checked by your
Toyota dealer before and after
driving on a racetrack.

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The vehicle contains advanced
technologies for the reduction of
consumption and emission val-
ues.
Fuel consumption depends on a
number of different factors.
Carrying out certain measures,
such as a moderate driving style
and regular maintenance, can
influence fuel consumption and
the environmental impact.

Condensation water under
the parked vehicle

Driving on racetracks

Saving fuel

Vehicle features and
options

Reducing fuel consump-
tion

General information

264

5-1. DRIVING TIPS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Additional weight increases fuel
consumption.

Attached parts on the vehicle
impair the aerodynamics and
increase the fuel consumption.

Open windows increase air
resistance and therefore lead to
greater fuel consumption.

Tires can affect consumption in
various ways, for instance tire
size may influence consump-
tion.

Check and, if needed, correct
the tire inflation pressure at least
twice a month and before start-
ing on a long trip.
Low tire inflation pressure
increases rolling resistance and
thus raises fuel consumption
and tire wear.

Do not wait for the engine to
warm-up while the vehicle
remains stationary. Start driving
right away, but at moderate
engine speeds.
This is the quickest way of
warming the cold engine up to
operating temperature.

Driving smoothly and proactively
reduces fuel consumption.
Avoid unnecessary acceleration
and braking.
By maintaining a suitable dis-
tance to the vehicle driving
ahead of you.

Driving at low engine speeds
lowers fuel consumption and
reduces wear.
If necessary, observe the vehi-
cle's gear shift indicator, refer to
page 146.

When approaching a red light,
take your foot off the accelerator
and let the vehicle coast to a
halt.
For going downhill take your foot
off the accelerator and let the

Remove unnecessary
cargo

Remove attached parts fol-
lowing use

Closing the windows

Tires

General information

Check the tire inflation pres-
sure regularly

Drive away without delay

Look well ahead when
driving

Avoid high engine speeds

Use coasting conditions

265

5-1. DRIVING TIPS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

5

DR
IVING TIPS

vehicle roll.
The flow of fuel is interrupted
while coasting.

Switch off the engine during lon-
ger stops, for instance at traffic
lights, railroad crossings or in
traffic congestion.

The Auto Start/Stop function of
the vehicle automatically
switches off the engine during a
stop.
If the engine is switched off and
then restarted rather than leav-
ing the engine running con-
stantly, fuel consumption and
emissions are reduced. Sav-
ings can begin within a few sec-
onds of switching off the engine.
In addition, fuel consumption is
also determined by other fac-
tors, such as driving style, road
conditions, maintenance or envi-
ronmental factors.

Functions such as seat heating
and the rear window defroster

require a lot of energy and
increase fuel consumption,
especially in city and
stop-and-go traffic.
Switch off these functions if they
are not needed.

Have the vehicle maintained
regularly to achieve optimal
vehicle efficiency and service
life. Toyota recommends that
maintenance work be performed
by Toyota.
For information on the Mainte-
nance System, refer to page
307.

Switch off the engine
during longer stops

Switching off the engine

Auto Start/Stop function

Switch off any functions
that are not currently
needed

Have maintenance carried
out

266

5-1. DRIVING TIPS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

267

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

6

6

MOBILITY

MOBILITY

.

6-1. MOBILITY

Refueling.....................

268

Fuel .............................

270

Wheels and tires .........

272

Engine compartment...

298

Engine oil ....................

301

Coolant........................

305

Maintenance ...............

307

Replacing components

..................................

309

Breakdown assistance

..................................

319

Care ............................

328

268

6-1. MOBILITY

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

6-1.MOBILITY

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Follow the fuel recommenda-
tion, refer to page 270, prior to
refueling.
When refueling, insert the filler
nozzle completely into the filler
pipe. Lifting up the fuel pump
nozzle during refueling causes:



Premature switching off.



Reduced return of the fuel
vapors.

The fuel tank is full when the
filler nozzle clicks off the first
time.
Make sure that the fuel cap is

closed properly after refueling,
otherwise the emissions warn-
ing light may light up.
Follow safety regulations posted
at the gas station.

1

Briefly press the rear edge of
the fuel filler flap.

Refueling

Vehicle features and
options

Follow the following when
refueling

General information

Safety information

NOTICE

With a driving range of less than

30 miles/50 km the engine may

no longer have sufficient fuel.

Engine functions are not ensured

anymore. There is a risk of dam-

age to property. Refuel promptly.

NOTICE

Fuels are toxic and aggressive.

Overfilling of the fuel tank can

damage the fuel system. Painted

surfaces may be damaged by

contact with fuel. Escaping fuel

can harm the environment. There

is a risk of damage to property.

Avoid overfilling.

Fuel cap

Opening

269

6-1. MOBILITY

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

6

MOBILITY

2

Turn the fuel cap counter-
clockwise.

3

Place the fuel cap in the
bracket attached to the fuel
filler flap.

1

Fit the cap and turn it clock-
wise until you clearly hear a
click.

2

Press on the fuel filler flap
until it engages.

It may be necessary in certain
situations to unlock the fuel filler
flap manually, e.g. with an elec-
trical fault.
Have fuel filler flap unlocked by
your Toyota dealer.

Closing

WARNING

The retaining strap of the fuel cap

can be jammed and crushed

during closing. The cap cannot be

correctly closed. Fuel or fuel

vapors can escape. There is a

risk of injury or risk of damage to

property. Pay attention that the

retaining strap is not jammed or

crushed when closing the cap.

Manually unlocking fuel
filler flap

270

6-1. MOBILITY

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures that are not necessarily
available in your vehicle, for
instance, due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Depending on the region, many
gas stations sell fuel that has
been customized to winter or
summer conditions. Fuel that is
available in winter,for instance
helps make a cold start easier.

For the best fuel efficiency, the
gasoline should be sulfur-free or
very low in sulfur content.
Fuels that are marked on the
gas pump as containing metal

must not be used.
Fuels with a maximum ethanol
content of 25 %, i. e. E10 or
E25, may be used for refueling.
Ethanol should meet the follow-
ing quality standards:
US: ASTM 4806–xx
CAN: CGSB-3.511–xx
xx: comply with the current stan-
dard in each case.

Fuel

Vehicle features andop-
tions

Fuel recommendation

General information

Gasoline

General information

Safety information

WARNING

The use of poor-quality fuels may

result in harmful engine deposits

or damage. Additionally, problems

relating to drivability, starting and

stalling, especially under certain

environmental conditions such as

high ambient temperature and

high altitude, may occur.
If drivability problems are encoun-

tered, we recommend switching

to a high quality gasoline brand

and a higher octane grade - AKI

number - for a few tank fills. To

avoid harmful engine deposits, it

is highly recommended to pur-

chase gasoline from Top Tier

retailers.
Failure to comply with these rec-

ommendations may result in the

need for unscheduled mainte-

nance.

271

6-1. MOBILITY

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

6

MOBILITY



SZ-R models

Toyota recommends AKI 91.



RZ models

Toyota recommends AKI 93.
Refuel with this gasoline to

achieve the rated performance
and consumption values.

Toyota recommends AKI 89.
If you use gasoline with this min-
imum AKI Rating, the engine
may produce knocking sounds
when starting at high external
temperatures. This has no effect
on the engine life.

NOTICE

Even small quantities of the

wrong fuel or wrong fuel additives

can damage the fuel system and

engine. Furthermore, the catalytic

converter is permanently dam-

aged. There is a risk of damage to

property. Do not refuel or add the

following in the case of gasoline

engines:

• Leaded gasoline.

• Metallic additives, for instance

manganese or iron.

Do not press the Start/Stop button

after refueling with the wrong fuel.

Contact your Toyota dealer.

NOTICE

Incorrect fuels can damage the

fuel system and the engine. There

is a risk of damage to property. Do

not use fuels with a higher per-

centage of ethanol than recom-

mended. Do not refuel with fuels

containing methanol, e.g. M5 to

M100.

NOTICE

Fuel that does not comply with the

minimum quality can compromise

engine function or cause engine

damage. There is a risk of dam-

age to property. Do not fill with

fuel that does not comply with the

minimum quality.

Recommended fuel grade

Minimum fuel grade
