80

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

folded out.

If the exterior mirrors were folded in
via the button in the car’s interior,
they will not be folded out when
unlocking.

• With alarm system: The alarm

system, refer to page , will be
switched off.

After opening one of the front
doors, the vehicle is ready for
operation, refer to page 41.
The light functions may depend
on the ambient brightness.

The windows are opened, as
long as the button on the remote
control is pressed.

The behavior of the vehicle
during locking with the remote
control depends on the following
settings, refer to page 91:
• If the locking of the vehicle is

confirmed with a light signal
or a sound signal.

• If the exterior mirrors are

automatically folded in when
the vehicle is locked. The
exterior mirrors are not folded

in when the hazard warning
flashers are switched on.

• If the headlight courtesy delay

feature is activated during
locking.

1

Close the driver's door.

2

 Press the button on the

remote control.

The following functions are exe-
cuted:
• All doors, the trunk lid, and

the fuel filler flap are locked.

• With alarm system: The alarm

system will be switched on.

If the drive-ready state is still
switched on when you lock the
vehicle, the vehicle horn honks
twice. In this case, the
drive-ready state must be
switched off by means of the
Start/Stop button.

Convenient opening

Opening

Press and hold the button
on the remote control.

Locking

General information

Locking the vehicle

With Smart Key System:
convenient closing

Safety information

WARNING

With convenient closing, body

parts can be jammed. There is a

risk of injury. Make sure that the

area of movement of the doors is

clear during convenient closing.

81

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

The windows are closed in the
area close to the vehicle, as
long as the button on the remote
control is pressed.

The function is not available for
the first 10 seconds after lock-
ing.
• The interior lights are

switched on, unless they were
manually switched off. For
switching the interior lights
on/off manually, refer to page
162.

• Depending on the settings,

the exterior lighting, refer to
page 159, will be switched on.

The light functions may depend
on the ambient brightness.

To avoid locking the vehicle key
in the vehicle, do not place the
vehicle key in the cargo area.
You can set up if the doors will

be unlocked when the trunk lid
is opened with the remote con-
trol. Settings, refer to page 91.

You can trigger the alarm sys-
tem if you find yourself in a dan-
gerous situation.

To switch off the alarm: press
any button.

Closing

Press and hold the button
on the remote control after
locking.

Switching on the interior
and exterior lights

Press the button on the
remote control with the
vehicle locked.

Trunk lid

General information

Safety information

WARNING

Body parts can be jammed when

operating the trunk lid. There is a

risk of injury. Make sure that the

area of movement of the trunk lid

is clear during opening and clos-

ing.

NOTICE

During opening, the trunk lid piv-

ots back and up. There is a risk of

damage to property. Make sure

that the area of movement of the

trunk lid is clear during opening

and closing.

Unlocking

Press and hold the button
on the remote control for
approx. 1 second.

Panic mode

• Press the button on the

remote control and hold
for at least 3 seconds.

• Briefly press the button

on the remote control
three times in succes-
sion.

82

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Set the duration, refer to page
159.

1

Remove the integrated key
from the remote control, refer
to page 84.

2

Place the integrated key
underneath the battery com-
partment cover, arrow

1

, and

lift the cover with a lever
movement of the integrated
key, arrow

2

.

3

Push battery in the direction
of the arrow using a pointed
object and lift it out.

4

Insert a type CR 2032 battery
with the positive side facing
up.

5

Press the cover closed.

6

Push the integrated key into
the vehicle key until the inte-
grated key engages.

Additional remote controls are
available from your Toyota
dealer.

A lost remote control can be
blocked and replaced by your
Toyota dealer.
If the lost remote control has an
assigned driver profile, refer to
page 63, the connection to this
remote control must be deleted.
A new remote control can then
be assigned to the driver profile.

A vehicle message, refer to
page 137, is displayed.
Remote control detection by the
vehicle may malfunction under

Switching on the headlight
courtesy delay feature

Press and hold the button
on the remote control for
approx. 1 second.

Replacing the battery

Have old batteries dis-
posed of by your Toyota
dealer or take them to a
collection point.

Additional remote controls

Loss of the remote con-
trols

Malfunction

General information

83

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

the following circumstances:
• The battery of the vehicle key

is discharged. For replacing
the battery, refer to page 82.

• Interference of the radio con-

nection from transmission
towers or other equipment
with high transmitting power.

• Shielding of the remote con-

trol due to metal objects.

Do not transport the remote control
together with metal objects.

• Interference of the radio con-

nection from mobile phones
or other electronic devices in
direct proximity to the remote
control.

Do not transport the remote control
together with electronic devices.

• Interference of radio transmis-

sion by a charging process of
mobile devices, for instance
charging of a mobile phone.

• The remote control is in direct

proximity of the wireless
charging tray.

Place the remote control down at a
different location.

In the case of interference, the
vehicle can be unlocked and
locked from the outside with the
integrated key, refer to page 84.

It is not possible to switch on the
drive-ready state if the remote
control has not been detected.
Proceed as follows in this case:

1

Hold the remote control with
its back against the marked
area on the steering column.
Pay attention to the display in
the instrument cluster.

2

If the remote control is
detected: Switch on
drive-ready state within 10
seconds.

If the remote control is not
detected, slightly change the
position of the remote control
and repeat the procedure.

What precautions can be taken
to be able to open a vehicle with
an accidentally locked in remote
control?
• The options provided by the

Switching the drive-ready
state on via emergency
detection of the remote con-
trol

Frequently asked ques-
tions

84

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Remote Services of the Toy-
ota Supra Connect app
include the ability to lock and
unlock a vehicle.

This requires an active Toyota
Supra Connect contract and the
Toyota Supra Connect app must be
installed on a smartphone.

• Unlocking the vehicle can be

requested via the Concierge.

An active Toyota Supra Connect
contract is required.

The driver's door can be locked
and unlocked without remote
control using the integrated key.
The integrated key also fits the
glove compartment.

Press the button, arrow

1

, and

pull out the integrated key, arrow

2

.

1

Pull and hold the door handle
outward with one hand.

2

Guide one finger of your
other hand from the back

Integrated key

General information

Safety information

WARNING

For some country versions,

unlocking from the inside is only

possible with special knowledge.

Persons who spend a lengthy

time in the vehicle while being

exposed to extreme tempera-

tures are at risk of injury or death.

Do not lock the vehicle from the

outside when there are people in

it.

NOTICE

The door lock is permanently

joined with the door. The door

handle can be moved. When pull-

ing the door handle with the inte-

grated key inserted, paint or the

integrated key can be damaged.

There is a risk of damage to prop-

erty. Remove the integrated key

before pulling the outside door

handle.

Removing

Locking/unlocking via the
door lock

85

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

under the cover and push the
cover out.

Use the thumb for counter support

to prevent the cover from falling out

of the door handle.

3

Remove the cover.

4

Unlock or lock the door lock
using the integrated key.

The other doors must be
unlocked or locked from the
inside.

The activated alarm system is
triggered when the door is
opened, if the vehicle has been
unlocked via the door lock.
The alarm system is not
switched on if the vehicle is
locked with the integrated key.

In the event of a severe acci-
dent, the vehicle is automatically
unlocked. The hazard warning
system and interior lights come
on.

Buttons for the central locking
system.

• The fuel filler flap remains

unlocked.

• The vehicle is not secured

against theft when locking.

Alarm system

Buttons for the central
locking system

General information

Overview

Locking

Press the button with the
front doors closed.

Unlocking

Press the button.

86

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

•

 Press the button to

unlock all the doors.

Pull the door opener above the
armrest.

• Pull the door handle on the

door to open the door. The
other doors remain locked.

The vehicle can be accessed
without operating the vehicle
key.
Carrying the vehicle key with
you, e.g., in your pants pocket,
is sufficient.
The vehicle automatically
detects the remote control when
it is in close proximity or in the
car's interior.

Comfort entry supports the fol-
lowing functions:
• Unlocking and locking the

vehicle from the door handle.

• To lock the vehicle, the

remote control must be
located outside of the vehicle
near the doors.

• The next unlocking and lock-

ing cycle is not possible until
after approx. 2 seconds.



The driver should always
carry the remote control on
their person and take it with
them when they leave the
vehicle.



Depending on the location of
the vehicle or the surround-
ing radio wave conditions, the
remote control may not oper-
ate normally. Make sure not to
carry the remote control with
an electronic device, such as
a mobile phone or computer.



Make sure to always take the
remote control with you when
you leave the vehicle, in case
the battery of the remote con-
trol is depleted or the remote
control is malfunctioning.

Opening

Smart Key System

Concept

General information

Functional requirements

Important points

87

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Safety notes

WARNING

The vehicle transmits radio waves

whenever the Smart Key System

is used to lock or unlock the

doors, open the trunk lid, or when

the engine switch is operated.

Therefore, this system may affect

the operation of implantable car-

diac pacemakers and implantable

cardioverter defibrillators.

Persons with implantable cardiac

pacemakers or implantable car-

dioverter defibrillators should stay

22 cm or more away from the

vehicle when opening or closing a

door. Also, they should refrain

from leaning on the vehicle or

looking through the windows from

outside when a door is opened or

closed.

Users of any electrical medical

device other than implantable car-

diac pacemakers, cardiac resyn-

chronization therapy-pacemakers

or implantable cardioverter

defibrillators should consult their

doctor or the manufacturer of the

device for information about its

operation under the influence of

radio waves.

88

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Near the front of the center console
Near the rear of the center console
In the luggage compartment and near the rear bumper
Near each door and door handle

The behavior of the vehicle
during unlocking via the Smart
Key System depends on the fol-
lowing settings, refer to page 91:
• If the unlocking of vehicle is

confirmed with a light signal
or a sound signal.

• If the welcome light, refer to

page 159, is switched on
when the vehicle is being

unlocked.

• If the exterior mirrors are

automatically folded out and
in when the vehicle is
unlocked and locked.

Effective range (areas within which Smart Key System radio
waves are transmitted)

A

B

C

D

Unlocking

General information

89

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Grasp the handle of a vehicle
door completely.
In addition, the following func-
tions are executed:
• If a driver profile was

assigned to the vehicle key,
this driver profile will be acti-
vated and the settings that
are stored in it will be applied.

• The interior lights are

switched on, unless they were
manually switched off.

• Folded in exterior mirrors are

folded out.

If the exterior mirrors were folded in
via the button in the car’s interior,
they will not be folded out when
unlocking.

• With alarm system: The alarm

system will be switched off.

The behavior of the vehicle
during locking via the Smart Key
System depends on the follow-
ing settings, refer to page 91:

• If the locking of the vehicle is

confirmed with a light signal
or a sound signal.

• If the exterior mirrors are

automatically folded in when
the vehicle is locked. The
exterior mirrors are not folded
in when the hazard warning
flashers are switched on.

• If the headlight courtesy delay

feature is activated during
locking.

Close the driver's door.

Touch the grooved surface on
the handle of a closed vehicle
door with your finger for approx.
1 second without grasping the
door handle.
The following functions are exe-
cuted:
• All doors, the trunk lid, and

the fuel filler flap are locked.

• With alarm system: The alarm

system will be switched on.

Unlocking the vehicle

Locking

General information

Locking the vehicle

90

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

To avoid locking the vehicle key
in the vehicle, do not place the
vehicle key in the cargo area.
Depending on the vehicle equip-
ment and country version, it is
also possible to have the doors
unlocked. To perform settings,
refer to page 91.

When unlocking with the vehicle
key, refer to page 81, the doors
may also be unlocked.

Trunk lid

General information

Safety information

WARNING

Body parts can be jammed when

operating the trunk lid. There is a

risk of injury. Make sure that the

area of movement of the trunk lid

is clear during opening and clos-

ing.

NOTICE

During opening, the trunk lid piv-

ots back and up. There is a risk of

damage to property. Make sure

that the area of movement of the

trunk lid is clear during opening

and closing.

NOTICE

When closing the trunk lid, make

sure that the straps of the luggage

cover are not caught.
If a strap is caught on the luggage

cover, when the trunk lid is

closed, the strap hanger on the

trunk lid may be damaged.

Opening and closing

Opening from the outside

Press and hold the button
on the remote control for
approx. 1 second.

Opening from the inside

Press the button in the
storage compartment of
the driver's door.

91

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Grasp the recess grips and pull
the trunk lid down.

Pull the handle inside the cargo
area.
The trunk lid unlocks.

Depending on the package and
country version, various settings
are available for the remote con-
trol functions.
These settings are stored for the
driver profile currently used.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

 "Driver's door" or   "All

doors"

5

Select the desired setting:

• "Driver's door only"

Only the driver's door and the fuel
filler flap are unlocked. Pressing
again unlocks the entire vehicle.

• "All doors"

The entire vehicle is unlocked.

Depending on the vehicle equip-
ment and country version, this
setting may not be offered.
Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

 "Tailgate" or

 "Tail-

gate and door(s)"

5

Select the desired setting:

• "Tailgate"

The trunk lid is opened.

• "Tailgate and door(s)"

The trunk lid is opened and the
doors are unlocked.

Closing

Trunk emergency unlocking

Settings

General information

Unlocking

Doors

Trunk lid

92

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Via Toyota Supra Command:

1

"My Vehicle"

2

"Driver profiles"

3

Select driver profile.

 The setting can be made for the

driver profile marked with this sym-

bol.

4

"Last seat position automatic"

When the vehicle is unlocked,
the driver's seat and exterior
mirrors resume their last set
positions.
The most recent position is inde-
pendent of the positions saved
via the seat memory.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

Deactivate or activate the
desired confirmation signals:

• "Flash for lock/unlock"

Unlocking is signaled by two
flashes, locking by one.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

Select desired setting:

• "Lock automatically"

The vehicle locks automatically
after a short period of time if no
door is opened after unlocking.

• "Lock after starting to drive"

The vehicle locks automatically
after you drive off.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

"Unlock at end of trip"

After drive-ready state is switched

off by pressing the Start/Stop but-

ton, the locked vehicle is automati-

cally unlocked.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

"Fold mirrors in when locked"

The exterior mirrors are automati-

cally folded in during locking.

Via Toyota Supra Command:

1

"My Vehicle"

Adjusting the last seat and
mirror position

Confirmation signals from
the vehicle

Automatic locking

Automatic unlocking

Folding mirrors automati-
cally

Establishing idle state
after opening the front
doors

93

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

2

"Vehicle settings"

3

"Doors/Key"

4

"Turn off after door opening"

Opening the front doors establishes

the idle state, refer to page 40.

When the vehicle is locked, the
vehicle alarm system reacts to
the following changes:
• Opening a door, the hood or

the trunk lid.

• Movements in the car's inte-

rior.

• Changes in the vehicle tilt, e.

g., during attempts at stealing
a wheel or when towing the
vehicle.

• Disconnected battery voltage.
• Improper use of the socket for

OBD Onboard Diagnosis.

• Locking the vehicle while a

device is connected to the
socket for the OBD Onboard-
Diagnosis. For socket for the
OBD Onboard Diagnosis,
refer to page 308

The alarm system signals the
following changes visually and
acoustically:
• Acoustic alarm: Depending on

local regulations, the acoustic
alarm may be suppressed.

• Visual alarm: By flashing of

the hazard warning system
and headlights, where

required.

Do not modify the system to
ensure function of the alarm
system.

When you unlock and lock the
vehicle, either with the remote
control or with Comfort entry, the
alarm system is switched off and
on at the same time.

The alarm system is triggered
when a door is opened if the
door was unlocked using the
integrated key in the door lock.
Switching off the alarm, refer to
page 95.

The trunk lid can be opened
even when the alarm system is
switched on.
After the trunk lid is closed, it is
locked and monitored again pro-
vided the doors are locked. The
hazard warning system flashes
once.

You can trigger the alarm sys-

Alarm system

General information

Switching on/off

Opening the doors with
the alarm system switched
on

Opening the trunk lid with
the alarm system switched
on

Panic mode

94

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

tem if you find yourself in a dan-
gerous situation.

To switch off the alarm: press
any button.

• The indicator light flashes

briefly every 2 seconds: The
alarm system is switched on.

• Indicator light flashes for

approx. 10 seconds, then it
flashes briefly every 2 sec-
onds: Interior motion sensor
and tilt alarm sensor are not
active, as doors, hood, or
trunk lid are not correctly
closed. Correctly closed
access points are secured.

When the still open access points
are closed, interior motion sensor
and tilt alarm sensor will be
switched on.

• The indicator light goes out

after unlocking: The vehicle
has not been tampered with.

• The indicator light flashes

after unlocking until
drive-ready state is switched
on, but no longer than approx.
5 minutes: An alarm has been
triggered.

The tilt of the vehicle is moni-
tored.
The alarm system responds in
situations such as attempts to
steal a wheel or when the vehi-
cle is towed.

The car's interior is monitored to
the height of the seats. The
alarm system is switched on
together with the interior motion
sensor even when the window is
open. Falling objects such as
leaves can trigger the alarm
unintentionally.

The tilt alarm sensor and interior
motion sensor can trigger an
alarm, although no unauthorized
action occurred.
Possible situations for an
unwanted alarm:

• Press the button on the

remote control and hold
for at least 3 seconds.

• Briefly press the button

on the remote control
three times in succes-
sion.

Indicator light on the inte-
rior mirror

Tilt alarm sensor

Interior motion sensor

Avoiding unintentional
alarms

General information

95

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

• In automatic vehicle washes.
• In duplex garages.
• During transport on trains car-

rying vehicles, at sea or on a
trailer.

• With animals in the vehicle.
• When the vehicle is locked

after start of fueling.

The tilt alarm sensor and the
interior motion sensor can be
switched off in such situations.

The indicator light lights up for
approx. 2 seconds and then
continues to flash.
The tilt alarm sensor and interior
motion sensor are switched off
until the vehicle is locked again.

• Unlock the vehicle with the

remote control.

• Unlock the vehicle with the

integrated key and activate
the drive-ready state via
emergency detection of the
vehicle key, refer to page 82.

• With Smart Key System:

when carrying the vehicle key,
grasp the driver’s door or front
passenger door handle com-

pletely.

The windows can be opened
with the vehicle key from the
outside as well as closed with
Smart Key System.
Additional information: Vehicle
key, refer to page 78.

The windows can be operated
under the following conditions.

Switching off the tilt alarm
sensor and interior motion
sensor

Press the button on the
remote control within 10
seconds as soon as the
vehicle is locked.

Switching off the alarm

Power windows

General information

Safety information

WARNING

When operating the windows,

body parts and objects can be

jammed. There is a risk of injury

or risk of damage to property.

Make sure that the area of move-

ment of the windows is clear

during opening and closing.

Overview

Power windows

Functional requirements

96

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

• Standby state is established.
• Drive-ready state is activated.
The remote control must be in
the car’s interior.

•

 Press the switch to the

resistance point.

The window opens while the switch
is being held.

•

 Press the switch

beyond the resistance point.

The window opens automatically.
Pressing the switch again stops the
motion.

•

 Pull the switch to the

resistance point.

The window closes while the switch
is being held.

•

 Pull the switch beyond

the resistance point.

The window closes automatically if
the door is closed. Pulling again
stops the motion.

The jam protection prevents
objects or body parts becoming
jammed between the door frame
and window while a window is
being closed.

If resistance or a blockage is
detected while a window is
being closed, the closing action
is interrupted and the window
opens slightly.

In case of danger from the out-
side or if ice might prevent nor-
mal closing, proceed as follows:

1

 Pull the switch past the

resistance point and hold it
there.

The window closes with limited jam

protection. If the closing force

exceeds a specific threshold, clos-

ing is interrupted.

2

 Pull the switch past the

resistance point again within
approx. 4 seconds and hold it
there.

The window closes without jam pro-

tection.

Opening

Closing

Jam protection system

Concept

General information

Safety information

WARNING

Accessories on the windows such

as antennas can impact jam pro-

tection. There is a risk of injury.

Do not install accessories in the

area of movement of the win-

dows.

Closing without the jam pro-
tection system

97

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

An ideal seating position that
meets the needs of the occu-
pants can make a vital contribu-
tion to relaxed, fatigue-free
driving.
In the event of an accident, the
correct seating position plays an
important role. Follow the infor-
mation in the following chapters:
• Seats, refer to page 97.
• Safety belts, refer to page

101.

• Head restraints, refer to page

105.

• Airbags, refer to page 164.

Seats, mirrors, and

steering wheel

Vehicle features and
options

Sitting safely

Seats

Safety information

WARNING

Seat adjustments while driving

can lead to unexpected move-

ments of the seat. Vehicle control

could be lost. There is a risk of an

accident. Only adjust the seat on

the driver's side when the vehicle

is stationary.

WARNING

With a backrest inclined too far to

the rear, the efficacy of the safety

belt can no longer be ensured.

There is a risk of sliding under the

safety belt in an accident. There is

a risk of injuries or danger to life.

Adjust the seat prior to starting the

trip. Adjust the backrest so that it

is in the most upright position as

possible and do not adjust again

while driving.

WARNING

There is a risk of jamming when

moving the seats. There is a risk

of injury or risk of damage to prop-

erty. Make sure that the area of

movement of the seat is clear

prior to any adjustment.

98

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

1

Backrest angle

2

Height

3

Backrest width

4

Lumbar support

5

Forward/back

6

Seat angle

Pull the lever and apply your
weight to or lift your weight off
the backrest as required.

Pull the lever up or press the
lever down repeatedly until the
seat reaches the desired height.

Pull the lever and slide the seat
in the desired direction.
After releasing the lever, move
the seat gently forward or back
to make sure it engages prop-
erly.

Manually adjustable seats

Overview

Backrest angle

6

5

4 3

2

1

Height

Forward/back

99

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Pull the lever up or press the
lever down repeatedly until the
seat reaches the desired angle.

The seat adjustment for the
driver’s seat is stored for the
driver profile currently used.
When the vehicle is unlocked
via the vehicle key, the position
is automatically retrieved if the
function, refer to page 63, is
activated for this purpose.
The current seat position can be
stored using the memory func-
tion, refer to page 108.

1

Forward/backward, height,
seat tilt

2

Driver's seat memory

3

Backrest tilt

4

Backrest width

5

Lumbar support

Push switch forward or back-
ward.

Seat angle

Electrically adjustable
seats

General information

Overview

Forward/backward

100

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Push switch up or down.

Move switch up or down.

Move switch forward or back-
ward.

The curvature of the seat back-
rest can be adjusted in a way
that it supports the lumbar
region of the spine. The lower
back and the spine are sup-
ported for upright posture.

Adjusting the backrest width
may improve lateral support
when taking corners.

You can change the backrest
width by adjusting the side
wings of the backrest.

Height

Seat tilt

Backrest tilt

Lumbar support

Concept

Adjusting

• Press the front/rear sec-

tion of the button: The
curvature is increased/
decreased.

• Press the upper/lower

section of the button:
The curvature is shifted
up/ down.

Backrest width

Concept

General information

101

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

The vehicle is fitted with two
safety belts to ensure occupant
safety. However, they can only
offer protection when adjusted
correctly.

Always make sure that safety
belts are being worn by the
occupants before driving off.
The airbags supplement the
safety belts as an additional
safety device. The airbags are
not a substitute for safety belts.
The upper shoulder strap's
anchorage point will be correct
for adult seat occupants of every
build if the seat is correctly
adjusted.

Adjusting

• Press the front section

of the button: The back-
rest width decreases.

• Press the rear section of

the button: The back-
rest width increases.

Safety belts

Number of safety belts and
safety belt buckles

General information

Safety information

WARNING

Use of a safety belt to buckle

more than one person will poten-

tially defeat the ability of the

safety belt to serve its protective

function. There is a risk of injuries

or danger to life. Do not allow

more than one person to wear a

single safety belt. Infants and chil-

dren are not allowed on an occu-

pant's lap, but must be

transported and secured in desig-

nated child restraint systems.

WARNING

The efficacy of safety gear, includ-

ing safety belts, can be limited or

lost when safety belts are fas-

tened incorrectly. An incorrectly

fastened safety belt can cause

additional injuries, for instance in

the event of an accident or during

braking and evasive maneuvers.

There is a risk of injuries or dan-

ger to life. Make sure that all

occupants are wearing safety

belts correctly.

WARNING

The efficacy of safety gear, includ-

ing safety belts, may not be fully

functional or fail in the following

situations:

• The safety belts or safety belt

buckles are damaged, soiled, or

changed in any other way.

• Belt tensioners or belt retractors

were modified.

102

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

• Wear the safety belt twist-free

and tight to your body over
your lap and shoulders.

• Wear the safety belt deep on

your hips over your lap. The
safety belt may not press on
your stomach.

• Do not rub the safety belt

against sharp edges, or guide
it or jam it in across hard or
fragile objects.

• Avoid thick clothing.
• Re-tighten the safety belt fre-

quently upward around your
upper body.

Having a correct driving posture
is essential for safe driving.

Maintaining a correct driving
posture not only helps reduce
fatigue while driving, but helps
ensure that the occupant protec-
tion devices, such as the seat
belts and airbags, will operate
correctly in a collision, reducing
the impact to the occupants.

The most basic occupant pro-
tection device is the seat belt.
The airbags are designed to
supplement the seat belts, not
be used in place of them. Wear-
ing the seat belt correctly
ensures that the occupants are
securely held in the seats and
helps prevent them from con-
tacting interior parts or being
thrown from the vehicle in a col-
lision. Therefore, it is necessary
for all occupants to wear their
seat belt. If a seat belt is worn
improperly, its effectiveness as
an occupant protection device
will be severely reduced. Pay
attention to the following to
ensure the correct driving pos-
ture and use of the seat belts.

WARNING

Safety belts can be imperceptibly

damaged in the event of an acci-

dent. There is a risk of injuries or

danger to life. Do not modify

safety belts, safety belt buckles,

belt tensioners, belt retractors or

belt anchors and keep them

clean. Have the safety belts

checked after an accident at the

your Toyota dealer.

Correct use of safety belts

Correct driving posture

Correct use of the seat
belts

103

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Position the head restraint so that the center of it is at the same
height as the top of your ears
Make sure that the seat belt is not twisted
Adjust the seat so that your arms bend slightly at the elbow when
gripping the upper part of the steering wheel
Make sure that the seat belt is snug and not loose at any point
Position the lap belt as low as possible over the hips
Sit well back in the seat with the seatback upright
Sit so your entire back is in contact with the seatback
Position the shoulder belt so that it does not contact your neck or
slide off your shoulder

Correct driving posture and use of the seat belts

A

B

C

D

E

F

G

H

WARNING

Do not recline the seatback

excessively while driving.

104

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

1

Guide the safety belt slowly
over shoulder and hip to put it
on.

2

Insert the tongue plate into
the safety belt buckle. The

WARNING

To reduce the risk of sliding under

the lap belt during a collision, do

not recline the seat more than

necessary. If the seat is too

reclined, the lap belt may slide

past the hips and apply restraint

forces directly to the abdomen, or

your neck may contact the shoul-

der belt, increasing the risk of

death or serious injury in the

event of an accident. Adjustments

should not be made while driving

as the seat may unexpectedly

move and cause the driver to lose

control of the vehicle.

WARNING

Make sure that all passengers

wear their seat belt correctly.

Use of seat belts may be manda-

tory under local laws and regula-

tions. If a seat belt is not worn

properly, an occupant may con-

tact interior parts or be thrown

from the vehicle in the case of

sudden braking or a collision, pos-

sibly resulting in death or serious

injury. Also, if an occupant has an

incorrect riding posture, the air-

bags will be ineffectual as occu-

pant protection devices and may

actually cause injuries when they

deploy.

WARNING

Correct use of the seat belts when

pregnant:

Pregnant women must wear a

seat belt. Consult your physician

for advice on correct way to wear

a seat belt. Position the lap belt as

low as possible over the hips and

the shoulder belt completely over

the shoulder, passing the center

of the chest, so that the seat belt

does not apply any pressure to

the abdomen.

Buckling the safety belt

105

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

safety belt buckle must
engage audibly.

1

Hold the safety belt firmly.

2

Press the red button in the
safety belt buckle.

3

Guide the safety belt back
into its roll-up mechanism.

The height of the head restraints
cannot be adjusted.

The distance to the back of the
head is adjusted via the back-
rest tilt.
Adjust the distance so that the
head restraint is as close as
possible to the back of the head.

The head restraints cannot be
removed.

Unbuckling the safety belt

Safety belt reminder for
driver's seat and front pas-
senger seat

Display in the instrument
cluster

The indicator light lights up
and a signal sounds.
Make sure that the safety
belts are positioned cor-
rectly. The safety belt
reminder can also be acti-
vated if objects are placed
on the front passenger
seat.

Front head restraints

Safety information

WARNING

Objects on the head restraint

reduce the protective effect in the

head and neck area. There is a

risk of injury.

• Do not use seat or head

restraint covers.

• Do not hang objects, for

instance clothes hangers,

directly on the head restraint.

• Only use accessories that have

been determined to be safe for

attachment to a head restraint.

• Do not use any accessories, for

instance pillows, while driving.

Adjusting the height

Adjusting the distance

Removing

106

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

The mirror on the front passen-
ger side is more curved than the
driver's side mirror.
The mirror setting is stored for
the driver profile currently in
use. When the vehicle is
unlocked via the vehicle key, the
position is automatically
retrieved if the function, refer to
page 63, is activated for this
purpose.
The current exterior mirror posi-
tion can be stored using the
memory function, refer to page
108.

1

Adjusting

2

Selecting a mirror, Automatic
Curb Monitor

3

Folding in and out

 Press the button.

The selected mirror moves
along with the button move-
ment.

 To change over to the

other mirror: Slide the switch.

In case of an electrical malfunc-
tion, adjust the mirror by press-
ing the edges of the mirror
glass.

Exterior mirrors

General information

Safety information

WARNING

Objects reflected in the mirror are

closer than they appear. The dis-

tance to the traffic behind could

be incorrectly estimated, for

instance while changing lanes.

There is a risk of an accident.

Estimate the distance to the traffic

behind by looking over your

shoulder.

Overview

Adjusting electrically

Selecting a mirror

Malfunction

107

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

 Press the button.

Folding is only possible up to a
speed of approx. 15 mph/20
km/h.
Folding the mirrors in and out is
helpful in the following situa-
tions:
• In vehicle washes.
• On narrow roads.
Mirrors that were folded in are
folded out automatically at a
speed of approx. 25 mph/40
km/h.

Both exterior mirrors are auto-
matically heated as needed and
when the drive-ready state is
switched on.

The exterior mirror on the
driver's side is automatically
dimmed. Photocells in the car's
interior mirror, refer to page 107,
are used to control this.

If reverse gear is engaged, the
mirror glass on the front passen-
ger side is tilted downward. This
improves your view of the curb
and other low-lying obstacles
when parking, for instance.

1

 Slide the switch to the

driver's side mirror position.

2

Engage selector lever posi-
tion R.

Slide the switch to the passen-
ger's side mirror position.

The interior mirror is dimmed
automatically.
Photocells are used for control:
• In the mirror glass.
• On the back of the mirror.

Folding in and out

NOTICE

Depending on the vehicle width,

the vehicle can be damaged in

vehicle washes. There is a risk of

damage to property. Before wash-

ing, fold in the mirrors by hand or

with the button.

Automatic heating

Automatic dimming fea-
ture

Automatic Curb Monitor,
exterior mirror

Concept

Activating

Deactivating

Interior mirror, automatic
dimming feature

General information

108

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

• Keep the photocells clean.
• Do not cover the area

between the interior mirror
and the windshield.

1

Fold the lever down.

2

Move the steering wheel to
the preferred height and
angle to suit your seating
position.

3

Fold the lever back up.

The following settings can be
stored and, if necessary,
retrieved using the memory
function:
• Seat position.
• Exterior mirror position.
• Height of the Head-up Dis-

play.

Two memory locations with dif-
ferent settings can be set for
each driver profile, refer to page
63.
The following settings are not
stored:

Overview

Functional requirements

Steering wheel

Safety information

WARNING

Steering wheel adjustments while

driving can lead to unexpected

steering wheel movements. Vehi-

cle control could be lost. There is

a risk of an accident. Adjust the

steering wheel while the vehicle is

stationary only.

Manual steering wheel
adjustment

Memory function

Concept

General information

109

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

• Backrest width.
• Lumbar support.

The memory buttons are located
on the driver's seat.

1

Set the desired position.

2

 Press the button. The

writing on the button lights
up.

3

Press desired button 1 or 2
while the LED is lit. A signal
sounds.

The stored position is called up
automatically.
Press the desired button 1 or 2.
The stored position is called up.
The procedure stops when a
switch for setting the seat is
pressed or one of the memory
buttons is pressed again.
While driving, the seat position
adjustment on the driver's side
is interrupted after a short time.

 Press the button

Safety information

WARNING

Using the memory function while

driving can lead to unexpected

seat movements. Vehicle control

could be lost. There is a risk of an

accident. Only retrieve the mem-

ory function when the vehicle is

stationary.

WARNING

There is a risk of jamming when

moving the seats. There is a risk

of injury or risk of damage to prop-

erty. Make sure that the area of

movement of the seat is clear

prior to any adjustment.

Overview

Storing

Calling up settings

Seat heating

Overview

Seat heating

Switching on

110

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

once for each temperature level.
The maximum temperature is
reached when three LEDs are
lit.

 Press and hold

the button until the LEDs go out.

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Switching off

Transporting children

safely

Vehicle features and
options

When children are in the
vehicle

WARNING

■

When a child is riding

Observe the following precau-

tions. Failure to do so may result

in death or serious injury.

For effective protection in automo-

bile accidents and sudden stops,

a child must be properly

restrained, using a seat belt or

child restraint system which is

correctly installed. For installation

details, refer to the operation

manual enclosed with the child

restraint system. General installa-

tion instruction is provided in this

manual.

111

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

WARNING

Do not allow occupants to ride

with a child in their arms or on

their lap. In the case of sudden

braking or a collision, the child

may hit their head on the instru-

ment panel or windshield, or may

even be thrown from the vehicle.

The seat belts are designed to

protect persons of average adult

height and weight. A child which

is 150 cm or shorter should be sat

in an appropriately sized child

restraint system, such as a Toyota

genuine child restraint system. Do

not allow a child to be unre-

strained in the vehicle while it is

moving, as doing so is extremely

dangerous.

WARNING

■

When children are in the vehi-

cle

Never leave children unattended

in the vehicle, and never allow

children to have or use the

key.Children may be able to start

the vehicle or shift the vehicle into

neutral. There is also a danger

that children may injure them-

selves by playing with the win-

dows or other features of the

vehicle. In addition, heat build-up

or extremely cold temperatures

inside the vehicle can be fatal to

children.

●

When the vehicle is parked

under direct sunlight, the tem-

perature inside the vehicle can

increase to over 122°F, even in

winter. In this situation, occu-

pants may suffer from dehydra-

tion or heatstroke.

●

If a switch is operated acciden-

tally, it may lead to unexpected

injuries.

●

Do not allow a child to open and

close the doors. When closing a

door, be careful so that the

child’s hands and feet to not get

caught in the door.

●

Do not allow a child to put their

head or limbs out of the door

window and be sure that they

are clear of the window before

operating the power window

switch.

112

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Before using a child restraint
system on the front passenger
seat, ensure that the front, knee,
and side airbags on the front
passenger side are deacti-
vated. For automatic deactiva-
tion of frontseat passenger
airbags, refer to page 174.

The right place for chil-
dren

Safety information

WARNING

Unattended children or animals in

the vehicle can cause the vehicle

to move and endanger them-

selves and traffic, for instance due

to the following actions:

●

Pressing the Start/Stop button.

●

Releasing the parking brake.

●

Opening and closing the doors

or windows.

●

Engaging selector lever position

N.

●

Using vehicle equipment.

There is a risk of accidents or inju-

ries. Do not leave children or ani-

mals unattended in the vehicle.

Take the remote control with you

when exiting and lock the vehicle.

WARNING

A heated vehicle may result in

death to persons, especially chil-

dren and animals. There is a risk

of injuries or danger to life. Do not

leave persons, especially chil-

dren and animals unattended in

the vehicle.

WARNING

Exposure to intense sunlight can

cause child restraint systems and

their components to become very

hot. Persons may sustain burn

injuries when touching the hot

components. There is a risk of

injury. Do not expose the child

restraint system to direct sunlight

or cover where necessary. If nec-

essary, let the child restraint sys-

tem cool down before transporting

a child. Do not leave children

unattended in the vehicle.

Children on the front pas-
senger seat

General information

Safety information

WARNING

Active front-seat passenger air-

bags can injure a child in a child

restraint system when the airbags

are activated. There is a risk of

injury. Make sure that the

front-seat passenger airbags are

deactivated and that the PAS-

SENGER AIRBAG OFF indicator

light lights up.

113

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Pay attention to the specifica-
tions and the operating and
safety information of the child
restraint system manufacturer
when selecting, installing, and
using child restraint systems.

WARNING

The safety belt cannot be fas-

tened correctly on children shorter

than 5 ft, 150 cm without suitable

additional child restraint systems.

The efficacy of safety gear, includ-

ing safety belts, can be limited or

lost when safety belts are fas-

tened incorrectly. An incorrectly

fastened safety belt can cause

additional injuries, for instance in

the event of an accident or during

braking and evasive maneuvers.

There is a risk of injuries or dan-

ger to life. Secure children shorter

than 5 ft, 150 cm using suitable

child restraint systems.

Installing child restraint
systems

General information

Safety information

WARNING

The protective effect of child

restraint systems and their fasten-

ing systems which have been

damaged or exposed to an acci-

dent can be limited or lost. A child

cannot be properly restrained in

the event of an accident or brak-

ing and evasive maneuvers.

There is a risk of injuries or dan-

ger to life. Do not use child

restraint systems which have

been damaged or exposed to an

accident. If a child restraint sys-

tem and its fastening system has

been damaged or exposed to an

accident, have these systems

checked and replaced by your

Toyota dealer.

WARNING

The stability of the child restraint

system is limited or compromised

with incorrect seat adjustment or

improper installation of the child

seat. There is a risk of injuries or

danger to life. Make sure that the

child restraint system fits securely

against the backrest. If possible,

adjust the backrest tilt for all

affected backrests and correctly

adjust the seats. Make sure that

seats and backrests are securely

engaged or locked. If possible,

adjust the height of the head

restraints or remove them.

114

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Before installing a child restraint
system in the front passenger
seat, make sure that the front,
knee and side airbags on the
front passenger side are deacti-
vated.
Deactivate the front-seat pas-
senger airbags automatically,
refer to page 174.

Before installing a child restraint
system, move the front passen-
ger seat as far back as it will go
and, if possible, bring it up to
medium height. This seat posi-
tion and height ensure the best
possible position for the belt and
offers optimal protection in the
event of an accident.
If the upper anchor of the safety
belt is located in front of the belt
guide of the child seat, move the
front passenger seat carefully

forward until the best possible
belt guide position is reached.

Adjustable backrest width:
before installing a child restraint
system in the front passenger
seat, open the backrest width
completely. Do not change the
backrest width again and do not
call up a memory position.

The safety belt on the passen-
ger's side can be locked to fas-
ten child restraint systems.

1

Pull out the belt strap com-
pletely.

2

Secure the child restraint
system with the safety belt.

3

Allow the belt strap to be
pulled in and pull it tight
against the child restraint
system. The safety belt is
locked.

On the front passenger
seat

Deactivating airbags

WARNING

Active front-seat passenger air-

bags can injure a child in a child

restraint system when the airbags

are activated. There is a risk of

injury. Make sure that the

front-seat passenger airbags are

deactivated and that the PAS-

SENGER AIRBAG OFF indicator

light lights up.

Seat position and height

Backrest width

Child seat security

Locking the safety belt

115

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

1

Unbuckle the safety belt
buckle.

2

Remove the child restraint
system.

3

Allow the belt strap to be
pulled in completely.

1

Direction of travel

2

Head restraint

3

Hook for the upper retaining
strap

4

Mounting point/eyelet

5

Vehicle floor

6

Seat

7

Upper retaining strap

1

Open the anchor cover.

Unlocking the safety belt

Child restraint systems
with tether strap

Safety information

WARNING

If the upper retaining strap is

incorrectly used for the child

restraint system, the protective

effect can be reduced. There is a

risk of injury. Make sure that the

upper retaining strap is not guided

across sharp edges and without

twisting to the upper retaining

strap.

NOTICE

The anchors for the upper retain-

ing straps of child restraint sys-

tems are only provided for these

retaining straps. When other

objects are mounted, the anchors

can be damaged. There is a risk

of damage to property. Only

mount child restraint systems to

the upper retaining straps.

Anchors

Symbol

Meaning

The respective sym-
bol shows the anchor
for the upper retaining
strap. Seats with an
upper top tether are
marked with this sym-
bol. It can be found on
the rear seat backrest
or the rear window
shelf.

Routing the retaining strap

Attaching the upper retain-
ing strap to the anchor

116

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

2

Guide the upper retaining
strap over the head restraint
to the anchor.

3

Attach the hook of the retain-
ing strap to the anchor.

4

Tighten the retaining strap.

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The drive-ready state is
switched on when you depress
the brake pedal while pressing
the Start/Stop button.
Pressing the Start/Stop button
again switches drive-ready state
back off and standby state, refer
to page 40, is switched back on.

1

Switch on drive-ready state.

Driving

Vehicle features and
options

Start/Stop button

Concept

Pressing the Start/Stop
button switches
drive-ready state on or
off, refer to page 40.

Driving away

117

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

2

Apply drive mode.

3

Release the parking brake.

4

Drive away.

1

Depress the brake pedal.

2

Press the Start/Stop button.

The ignition is activated auto-
matically for a brief time and is
stopped as soon as the engine
starts.
Most of the indicator/warning
lights in the instrument cluster
light up for a varied length of
time.

Depending on the engine condi-
tion, the full drive power may not
be available for approximately
30 seconds after starting the
engine. In this case, the vehicle
will not accelerate as usual.

When drive-ready state is
switched on, the tachometer
shows the current engine

Drive-ready state

Safety information

WARNING

If the exhaust pipe is blocked or

ventilation is insufficient, harmful

exhaust gases can enter into the

vehicle. The exhaust gases con-

tain pollutants which are colorless

and odorless. In enclosed areas,

exhaust gases can also accumu-

lateout side of the vehicle. There

is danger to life. Keep the exhaust

pipe free and ensure sufficient

ventilation.

WARNING

An unsecured vehicle can begin

to move and possibly roll away.

There is a risk of an accident.

Before exiting, secure the vehicle

against rolling.

In order to ensure that the vehicle

is secured against rolling away,

follow the following:

• Set the parking brake.

• On uphill grades or on a down-

hill slope, turn the front wheels

in the direction of the curb.

• On uphill grades or on a down-

hill slope, also secure the vehi-

cle, for instance with a wheel

chock.

NOTICE

In the case of repeated starting

attempts or repeated starting in

quick succession, the fuel is not

burned or is inadequately burned.

The catalytic converter can over-

heat. There is a risk of damage to

property. Avoid repeated starting

in quick succession.

Switching on drive-ready
state

Automatic transmission

Gasoline engine

Display in the instrument
cluster

118

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

speed.

1

Engage selector lever posi-
tion P with the vehicle
stopped.

2

Press the Start/Stop button.

The engine is switched off.

3

Set the parking brake.

The Auto Start/Stop function
helps save fuel. The system
switches off the engine during a
stop, for instance in traffic con-
gestion or at traffic lights.
Drive-ready state remains
switched on. The engine starts
automatically for driving off.

After each engine start using the
Start/Stop button, the Auto
Start/Stop function is ready. The
function is activated from
speeds of approx. 3 mph/5
km/h.
Depending on the selected driv-
ing mode, refer to page 135, the
system is automatically acti-
vated or deactivated.

The engine is switched off auto-
matically during a stop under the
following conditions:



The selector lever is in selec-
tor lever position D.



The brake pedal remains
pressed while the vehicle is
stationary.



The driver's safety belt is
buckled or the driver's door is
closed.

If the engine was not switched
off automatically when the vehi-
cle stopped, the engine can be
switched off manually:



Press the brake pedal force-
fully again from the current
pedal position.



Engage selector lever posi-
tion P.

If all functional preconditions are
fulfilled, the engine switches off.

The air flow from the air condi-
tioner is reduced when the
engine is switched off.

Switching off drive-ready
state

Automatic transmission

Auto Start/Stop function

Concept

General information

Engine stop

Functional requirements

Manual engine stop

Air conditioner when the
engine is switched off

119

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

■

General information

The engine is not switched off
automatically in the following sit-
uations:



In case of a steep downhill
grade.



Brake not engaged strongly
enough.



The external temperature is
high and automatic air condi-
tioning is running.



The car's interior has not yet
been heated or cooled to the
required level.



Where there is a risk of win-
dow condensation when the
automatic air conditioning is
switched on.



Engine or other parts not at
operating temperature.



Engine cooling is required.



The wheels are at a sharp
angle or the steering wheel is

being turned.



Vehicle battery is heavily dis-
charged.



At higher elevations.



The hood is unlocked.



The parking assistant is acti-
vated.



Stop-and-go traffic.



Selector lever position in N or
R.



After driving in reverse.



Use of fuel with high ethanol
content.

The engine starts automatically
under the following precondi-
tions:



By releasing the brake pedal.

After the engine starts, acceler-
ate as usual.

After the engine switches off
automatically, it will not start
again automatically if any one of
the following conditions are met:



The driver's safety belt is
unbuckled and the driver's
door is open.

Displays in the instrument
cluster

The display in the
tachometer indicates
that the Auto Start/Stop
function is ready for an
Automatic engine start.
The display indicates
that the conditions for
an automatic engine
stop have not been
met.

Functional limitations

Starting the engine

Functional requirements

Driving off

Safety mode

120

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)



The hood was unlocked.

Some indicator lights light up for
a varied length of time.
The engine can only be started
via the Start/Stop button.

Even if driving off was not
intended, the deactivated
engine starts up automatically in
the following situations:



Excessive warming of the
car's interior when the air con-
ditioning is switched on.



Excessive cooling of the car's
interior when the heating is
switched on.



Where there is a risk of win-
dow condensation when the
automatic air conditioning is
switched on.



The steering wheel is turned.



Change from selector lever
position D to N or R.



Change from selector lever
position P to N, D, or R.



Vehicle battery is heavily dis-
charged.



Start of an oil level measure-
ment.

Depending on the vehicle equip-
ment and country-specific ver-

sion, the vehicle features a
variety of sensors for assessing
the traffic situation. The Auto
Start/Stop function uses this
information to adapt to various
traffic situations in a proactive
manner.
For instance, this applies to the
following situations:



If a situation is detected in
which the stopping time is
expected to be very short, the
engine is not switched off
automatically. A message
appears on the Control Dis-
play, depending on the situa-
tion.



If a situation is detected in
which the vehicle needs to
drive off immediately, the
engine is started automati-
cally.

The function may be restricted if
the navigation data is invalid,
outdated or not available, for
example.

The engine is not automatically
switched off.
The engine is started during an
automatic engine stop.

System limits

Additional functions Auto
Start/Stop

Activating/deactivating the
system manually

Concept

121

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

 Press the button.

The Auto Start/Stop function is
also deactivated in selector
lever position M.

The Auto Start/Stop function is
also deactivated in SPORT driv-
ing mode of the Sport mode
switch.

■

General information

During an automatic engine
stop, the vehicle can be
switched off permanently, for
instance when leaving it.

1

Press the Start/Stop button.



Drive-ready state is switched
off.



Standby state is switched on.



Selector lever position P is
engaged automatically.

2

Set the parking brake.

In certain situations, the Auto
Start/Stop function is deacti-
vated automatically for safety
reasons, for instance if no driver
is detected.

The Auto Start/Stop function no
longer switches off the engine
automatically. A vehicle mes-
sage is displayed. It is possible
to continue driving. Have the
system checked by your Toyota
dealer.

The parking brake is used to
prevent the vehicle from rolling
when it is parked.

Using the button

Via selector lever position

Via the Sport mode switch

Switching off the vehicle
during an automatic engine
stop

Automatic deactivation

General information

Malfunction

Parking brake

Concept

122

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

■

General information

To use as emergency brake
while driving:
Pull the switch and hold it. The
vehicle brakes hard while the
switch is being pulled.
A vehicle message is displayed.
If the vehicle is slowed down to

Safety information

WARNING

An unsecured vehicle can begin

to move and possibly roll away.

There is a risk of an accident.

Before exiting, secure the vehicle

against rolling.
In order to ensure that the vehicle

is secured against rolling away,

follow the following:

●

Set the parking brake.

●

On uphill grades or on a down-

hill slope, turn the front wheels

in the direction of the curb.

●

On uphill grades or on a down-

hill slope, also secure the vehi-

cle, for instance with a wheel

chock.

WARNING

Unattended children or animals in

the vehicle can cause the vehicle

to move and endanger them-

selves and traffic, for instance due

to the following actions:

●

Pressing the Start/Stop button.

●

Releasing the parking brake.

●

Opening and closing the doors

or windows.

●

Engaging selector lever position

N.

●

Using vehicle equipment.

There is a risk of accidents or inju-

ries. Do not leave children or ani-

mals unattended in the vehicle.

Take the remote control with you

when exiting and lock the vehicle.

Overview

Parking brake

Setting

With a stationary vehicle

Pull the switch.
The LED lights up.
The indicator light in the
instrument cluster illumi-
nates red. The parking
brake is set.

While driving

The indicator light in the
instrument cluster illumi-
nates red, a signal
sounds, and the brake
lights illuminate.

123

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

a speed of approx. 2 mph/3
km/h the parking brake is set.

1

Switch on drive-ready state.

2

 Press the switch while

the brake is pressed or selec-
tor lever position P is set.

The LED and indicator light go out.
The parking brake is released.

The parking brake is released
automatically when you drive
away.
The LED and indicator light go
out.

In the event of a failure or mal-
function of the parking brake:
Secure the vehicle against roll-
ing away, for instance with a
wheel chock, after existing the
vehicle.

To reestablish parking brake
functionality after a power fail-
ure:

1

Switch on standby state.

2

 Pull the switch while

stepping on the brake pedal
or selector lever position P is
set and then push.

This process may take a few
seconds. Any sounds associ-
ated with this are normal.

When driving and during opera-
tion of the turn signals or hazard
warning system, do not fold in
the exterior mirrors, so that the
signal lights on the exterior mir-
ror are easy to see.

Press the lever past the resis-

Releasing

Releasing manually

Automatic release

Malfunction

After a power failure

The indicator light is no
longer illuminated as
soon as the parking
brake is ready for oper-
ation again.

Turn signal, high beams,
headlight flasher

Turn signal

Turn signal in exterior mirror

Using turn signals

124

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

tance point.

Lightly tap the lever up or down.
The triple turn signal duration
can be adjusted.
Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Exterior lighting"

4

"One-touch turn signal"

5

Select the desired setting.

The setting is stored for the
driver profile currently used.

Press the lever to the resistance
point and hold it there for as
long as you want the turn signal
to flash.

Push the lever forward or pull it
backward.

1

High beams on, arrow

1

.

The high beams light up when the

low beams are switched on.

2

High beams off/headlight
flasher, arrow

2

.

Do not use the wipers if the
windshield is dry, as this may
damage the wiper blades or
cause them to become worn
more quickly.

Triple turn signal activation

Signaling briefly

High beams, headlight
flasher

Washer/wiper system

General information

Safety information

WARNING

If the wipers start moving in the

folded away state, body parts can

be jammed or damage may occur

to parts of the vehicle. There is a

risk of injury or risk of damage to

property. Make sure that the vehi-

cle is switched off when the wip-

ers are in the folded away state

and the wipers are folded in when

switching on.

NOTICE

If the wipers are frozen to the

windshield, the wiper blades can

be torn off and the wiper motor

can overheat when switching on.

There is a risk of damage to prop-

erty. Defrost the windshield prior

to switching the wipers on.

125

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Press the lever up until the
desired position is reached.



Resting position of the wipers,
position

0

.



Rain sensor, position

1

.



Normal wiper speed, position

2

.



Fast wiper speed, position

3

.

When travel is interrupted with
the wiper system switched on:
when travel continues, the wip-
ers resume at their previous
speed.

Press the lever down.



Switching off: press the lever
down until it reaches its stan-

dard position.



Brief wipe: press the lever
down from the standard posi-
tion.

The lever automatically returns to
its initial position when released.

The rain sensor automatically
controls the time between wipes
depending on the intensity of the
rainfall.

The sensor is located on the
windshield, directly in front of
the interior mirror.

Switching on

Switching off and brief
wipe

Rain sensor

Concept

General information

Safety information

NOTICE

If the rain sensor is activated, the

wipers can accidentally start mov-

ing in vehicle washes. There is a

risk of damage to property. Deac-

tivate the rain sensor in vehicle

washes.

126

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Press the lever up once from its
standard position, arrow

1

.

Wiping is started.
The LED in the wiper lever is
illuminated.
In frosty conditions, wiper oper-
ation may not start.

Press the lever back into the
standard position.

Turn the thumbwheel to adjust
the sensitivity of the rain sensor.
Upward: high rain sensor sensi-
tivity.

Downward: low rains sensor
sensitivity.

Pull the lever.
The system sprays washer fluid
on the windshield and activates
the wipers briefly.

Activating

Deactivating

Adjusting the rain sensor
sensitivity

Windshield washer system

Safety information

WARNING

The washer fluid can freeze onto

the window at low temperatures

and obstruct the view. There is a

risk of an accident. Only use the

washer systems, if the washer

fluid cannot freeze. Use washer

fluid with antifreeze, if needed.

NOTICE

When the washer fluid reservoir is

empty, the wash pump cannot

work as intended. There is a risk

of damage to property. Do not use

the washer system when the

washer fluid reservoir is empty.

Cleaning the windshield

127

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

The windshield washer nozzles
are automatically heated while
standby state is switched on.

The fold-out position enables
the wipers to be folded away
from the windshield.

Important, for instance when
changing the wiper blades or
when folding out under frosty
conditions.

1

Switch on standby state.

2

Press and hold the wiper
level down, until the wipers
stop in a close to vertical
position.

3

Fold the wipers all the way
away from the windshield.

After the wipers are folded back
down, the wiper system must be
reactivated.

Windshield washer nozzles

Fold-away position of the
wipers

Concept

General information

Safety information

WARNING

If the wipers start moving in the

folded away state, body parts can

be jammed or damage may occur

to parts of the vehicle. There is a

risk of injury or risk of damage to

property. Make sure that the vehi-

cle is switched off when the wip-

ers are in the folded away state

and the wipers are folded in when

switching on.

NOTICE

If the wipers are frozen to the

windshield, the wiper blades can

be torn off and the wiper motor

can overheat when switching on.

There is a risk of damage to prop-

erty. Defrost the windshield prior

to switching the wipers on.

Folding away the wipers

Folding down the wipers

128

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

1

Fold the wipers back down
onto the windshield.

2

Switch on standby state and
press and hold the wiper
lever down again.

3

Wipers return to their resting
position and are ready again
for operation.

All washer nozzles are supplied
from one reservoir.
Use a mixture of tap water and
windshield washer concentrate.
If desired, a windshield washer
concentrate containing anti-
freeze can be used.
Recommended minimum fill
quantity:0.2 US gal/1 liter.

Washer fluid

General information

Safety information

WARNING

Some antifreeze agents can con-

tain harmful substances and are

flammable. There is a risk of fire

and a risk of injury. Follow the

instructions on the containers.

Keep antifreeze away from igni-

tion sources. Do not refill operat-

ing materials into different bottles.

Store operating materials out of

reach of children.
United States: the washer fluid

mixture ratio is regulated by the

U.S. EPA and many individual

states; do not exceed the allow-

able washer fluid dilution ratio lim-

its that apply. Follow the usage

instructions on the washer fluid

container.

WARNING

Washer fluid can ignite and catch

fire on contact with hot engine

parts. There is a risk of injury or

risk of damage to property. Only

add washer fluid when the engine

is cooled down. Next, fully close

the lid of the washer fluid reser-

voir.

NOTICE

Silicon-containing additives in the

washer fluid for the water-repel-

ling effect on the windows can

lead to damage to the washing

system. There is a risk of damage

to property. Do not add sili-

con-containing additives to the

washer fluid.

129

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

The washer fluid reservoir is
located in the engine compart-
ment.

The use of undiluted windshield
washer concentrate or alco-
hol-based antifreeze can lead to
incorrect readings at tempera-
tures below +5°F/-15°C.

The Automatic transmission
combines the functions of man-
ual shifting, if needed.

Selector lever position for nor-
mal vehicle operation. All gears
for forward travel are activated
automatically.

Engage selector lever position R
only when the vehicle is station-
ary.

The vehicle may be pushed or
roll without power, for instance
in vehicle washes, refer to page
131, in selector lever position N.

NOTICE

Mixing different windshield

washer concentrates or antifreeze

can damage the washing system.

There is a risk of damage to prop-

erty. Do not mix different wind-

shield washer concentrates or

antifreeze. Follow the information

and mixing ratios provided on the

containers.

Overview

Malfunction

Automatic transmission

Concept

Safety information

WARNING

An unsecured vehicle can begin

to move and possibly roll away.

There is a risk of an accident.

Before exiting, secure the vehicle

against rolling.

In order to ensure that the vehicle

is secured against rolling away,

follow the following:

●

Set the parking brake.

●

On uphill grades or on a down-

hill slope, turn the front wheels

in the direction of the curb.

●

On uphill grades or on a down-

hill slope, also secure the vehi-

cle, for instance with a wheel

chock.

Selector lever positions

Drive mode D

Reverse R

Neutral N

130

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Selector lever position, for
instance for parking the vehicle.
The transmission blocks the
drive wheels in selector lever
position P.
Engage selector lever position P
only when the vehicle is station-
ary.

■

P is engaged automatically

Selector lever position P is
engaged automatically in situa-
tions such as the following:



After the drive-ready state is
switched off and selector
lever position R, D or M is
engaged.



After the standby state has
been switched off when selec-
tor lever position N is
engaged.



If the driver's safety belt is
unbuckled, the driver's door is
opened, and the brake pedal
is not pressed while the vehi-
cle is stationary and selector
lever position D, M or R is
engaged.

To prevent the vehicle from
creeping after you select a drive
mode, maintain pressure on the

brake pedal until you are ready
to start.

Only when the drive-ready state
is switched on and the brake
pedal is depressed is it possible
to change from selector lever
position P to another selector
lever position.
The selection lever position P
cannot be changed until all tech-
nical requirements are met.

A selector lever lock prevents
the following faulty operation:



Unintentional shifting into
selector lever position R.



Unintentional shifting from
selector lever position P into
another selector lever posi-
tion.

1

Fasten driver's safety belt.

2

Press and hold the button to
release the selector lever
lock.

Parking position P

Engaging selector lever
positions

General information

Functional requirements

Engaging selector lever
position D, N, R

131

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

3

Push the selector lever in the
desired direction, past a
resistance point, if needed.
The selector lever automati-
cally returns to the center
position when released.

Press button P.

In some situations, the vehicle is
to roll without its own power for
a short distance, for instance in
a vehicle wash, or be pushed.

1

Switch on drive-ready state
while pressing on the brake
pedal.

2

If necessary, release the
parking brake.

3

Depress the brake pedal.

4

Touch the selector lever lock
and engage selector lever
position N.

5

Switch off drive-ready state.

In this way, standby state remains

switched on, and a vehicle mes-

sage is displayed.
The vehicle can roll.

Irrespective of standby state, the
selector lever position P is auto-
matically engaged after approx.
35 minutes.
If there is a malfunction, you
may not be able to change the
selector lever position.
Electronically unlock the trans-
mission lock, if needed, refer to
page 133.

Kickdown is used to achieve
maximum driving performance.

Engaging selector lever
position P

Rolling or pushing the
vehicle

General information

Engaging selector lever
position N

NOTICE

Selector lever position P is auto-

matically engaged when standby

state is switched off. There is a

risk of damage to property. Do not

switch standby state off in vehicle

washes.

Kickdown

132

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Step on the accelerator pedal
beyond the resistance point at
the full throttle position.

Manual gear-shifting is possible
in manual mode.

Press the selector lever to the
left from selector lever position
D.
The engaged gear is displayed
in the instrument cluster, for
instance 1M.



To shift down: press the
selector lever forward.



To shift up: pull the selector
lever rearwards.

Push the selector lever to the
right.

D is displayed in the instrument
cluster.

The shift paddles on the steer-
ing wheel allow you to shift
gears quickly while keeping both
hands on the steering wheel.

■

Shifting

The vehicle only shifts at suit-
able engine and road speeds.

■

Short-term manual mode

In selector lever position D,
actuating a shift paddle switches
into manual mode temporarily.
After conservative driving in
manual mode without accelera-
tion or shifting via the shift pad-
dles for a certain amount of
time, the transmission switches
back to automatic mode.
It is possible to switch into auto-
matic mode as follows:



Pull and hold right shift pad-
dle.



In addition to the briefly pulled
right shift paddle, briefly pull
the left shift paddle.

■

Continuous manual mode

In selector lever position M,
actuating a shift paddle switches

Manual mode

Concept

Activating manual mode

Shifting

Ending the manual mode

Shift paddles

Concept

General information

133

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

into manual mode permanently.



Shifting up: pull the right shift
paddle.



Shifting down: pull left shift
paddle.



Downshifting to the lowest
possible gear: keep the left
shift paddle pulled.

The selected gear is briefly dis-
played in the instrument cluster,
followed by the current gear.

Electronically unlock the trans-
mission lock to maneuver vehi-

cle from a danger area.
Unlocking is possible, if the
starter can spin the engine.
Before unlocking the transmis-
sion lock, set the parking brake
to prevent the vehicle from roll-
ing away.

1

Press and hold down brake
pedal.

2

Press the Start/Stop button.
The starter must audibly
start. Hold the Start/Stop but-
ton pressed.

3

With your free hand, press
the button on the selector
lever, arrow

1

, and press the

selector lever into selector
lever position N and hold,
arrow N, until selector lever
position N is displayed in the
instrument cluster.

A vehicle message is displayed.

4

Release Start/Stop button
and selector lever.

5

Release brake, as soon as
the starter stops.

Shifting

Displays in the instrument
cluster

The selector lever posi-
tion is displayed, for
example P.

Electronic unlocking of
the transmission lock

General information

Engaging selector lever
position N

1

R

N

134

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

6

Maneuver the vehicle from
the danger area and secure it
against moving on its own.

For additional information, see
the chapter on tow-starting and
towing, refer to page 325.

Launch Control enables opti-
mum acceleration on surfaces
with good traction under dry sur-
rounding conditions.

The use of Launch Control
causes premature component
wear since this function rep-
resents a very heavy load for
the vehicle.
Do not use Launch Control
during the break-in, refer to
page 258, period.
Do not steer the steering wheel
when driving off with Launch
Control.

Launch Control is available
when the engine is at operating
temperature. The engine is at
operating temperature after an
uninterrupted trip of at least 6
miles/10 km.

1

Switch on drive-ready state.

2

Press the sport button.

SPORT will be displayed on the

instrument cluster, indicating sport

mode has been selected.

3

 Press the button.

TRACTION will be displayed on the

instrument cluster and the VSC

OFF indicator lamp will illuminate.

4

Select the D selector lever
position.

5

Firmly depress the brake
pedal with your left foot.

6

Fully depress and hold the
accelerator pedal at the kick-
down position.

A flag symbol will be shown in the

instrument cluster.

7

The engine speed will be
adjusted for launching.
Release the brake pedal
within 3 seconds.

After Launch Control has been
used, the transmission must
cool down for approx. 5 minutes
before Launch Control can be
used again. Launch Control
adjusts to the surrounding con-
ditions, when used again.

To increase vehicle stability,
activate VSC Vehicle Stability

Launch Control

Concept

General information

Functional requirements

Start with launch control

Repeated use during a trip

After using Launch Control

135

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Control System again as soon
as possible.

An experienced driver may be
able to achieve better accelera-
tion values in VSC OFF mode.

The Sport mode button influ-
ences the driving dynamics
properties of the vehicle.

The following systems are
affected, for instance:



Engine characteristics.



Automatic transmission.



Adaptive variable suspension.



Steering.



Display in the instrument clus-
ter.



Cruise control.

When drive-ready state is
switched on, the NORMAL driv-
ing mode is selected automati-
cally.

System limits

Sport mode button

Concept

General information

Overview

Displays in the instrument
cluster

The selected driving
mode is displayed in
the instrument cluster.

Driving modes

Button in the vehicle

Button

Driving

mode

Configu-

ration

SPORT

SPORT

Custom-

ize

136

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

■

Concept

Balanced tuning between
dynamic and efficient driving.

■

Concept

Dynamic tuning for higher agility
with an optimized chassis and
suspension.

■

Switching on

■

Concept

Customize settings can be
adjusted in the customize driv-
ing mode.

■

Configuration

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Configure SPORT INDIVID-
UAL"

4

Select the desired setting.

The setting is stored for the
driver profile currently used.
Reset Customize to the stan-
dard settings:
"Reset to SPORT STANDARD".

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The instrument cluster is a vari-
able display. When the sport
mode switch is used to change
the driving mode, the instrument
cluster displays change to
match the driving mode.

The display change in the instru-
ment cluster can be deactivated
via Toyota Supra Command.
Some of the displays in the
instrument cluster may differ
from the illustrations in this
Owner's Manual.

Driving modes in detail

NORMAL

SPORT

Press the button.

Customize

Displays

Vehicle features and
options

Instrument cluster

Concept

General information

137

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

1

Fuel gauge P.142

2

Speedometer

3

Tachometer P.143
Status, Sport mode switch
P.135

4

Time P.58

5

Variable displays P.137

6

External temperature P.144

7

Engine coolant temperature
P.144

8

Vehicle messages P.137
Range P.144

9

Transmission display P.129

10

Variable displays P.137

Speed Limit Info P.146

In some areas of the instrument
cluster, various assistance sys-
tems, for example the cruise
control, can be displayed. The
displays may vary depending on
the equipment version and
country variant.

The display can be changed for
sport mode.

The driving mode will change to
sport mode.

The vehicle messages system
monitors functions in the vehicle
and notifies you of malfunctions
in the monitored systems.

A vehicle messages message is
displayed as a combination of
indicator or warning lights and
SMS text messages in the
instrument cluster and, if appli-
cable, in the Head-up Display.
In addition, an acoustic signal
may sound and an SMS text
message may appear on the
Control Display.

Overview

Variable displays

Sport mode display

Concept

Changing the display

Push the sport mode
switch until SPORT is
displayed.

Vehicle messages

Concept

General information

138

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Press and hold the button on the
turn signal lever.

Some vehicle messages are
displayed continuously and are
not cleared until the malfunction
is eliminated. If several malfunc-
tions occur at once, the mes-
sages are displayed
consecutively.
The messages can be hidden
for approx. 8 seconds. After this
time, they are displayed again
automatically.

Some vehicle messages are
hidden automatically after
approx. 20 seconds. The vehicle
messages are stored and can
be displayed again later.

Via Toyota Supra Command:

1

"My vehicle"

2

"Vehicle status"

3

"Vehicle messages"

4

Select the SMS text mes-
sage.

SMS text messages in combina-
tion with a symbol in the instru-
ment cluster explain a vehicle
message and the meaning of
the indicator/warning lights.

Additional information, such as
the reason for an error or mal-
function or the required action,
can be called up via vehicle
messages.
With urgent messages the
added text will be automatically
displayed on the Control Dis-
play.
Depending on the vehicle mes-
sage, further help can be
selected.
Via Toyota Supra Command:

1

"My vehicle"

Hiding vehicle messages

Continuous display

Temporary display

Displaying stored vehicle
messages

Display

Vehicle messages

At least one vehicle
messages message is
displayed or is stored.

SMS text messages

Supplementary SMS text
messages

139

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

2

"Vehicle status"

3

"Vehicle messages"

4

Select the desired text mes-
sage.

5

Select desired setting

Certain messages displayed
while driving are displayed
again after drive-ready state is
switched off.

Indicator/warning lights in the
instrument cluster display the
status of some functions in the
vehicle and indicate when a
malfunction is present in the
monitored systems.

The indicator/warning lights can
light up in a variety of combina-
tions and colors.
Several of the lights are
checked for proper functioning
and light up temporarily when
drive-ready state is switched on.

Messages after trip comple-
tion

Indicator/warning lights

Concept

General information

Red lights

Safety belt reminder

Indicator light flashes or
is illuminated: safety
belt on the driver or
passenger side is not
buckled. The safety belt
reminder can also be
activated if objects are
placed on the front pas-
senger seat.
Make sure that the
safety belts are posi-
tioned correctly.

Airbag system

Airbag system and belt
tensioner are not work-
ing.
Have the vehicle
checked immediately
by your Toyota dealer.

Parking brake

The parking brake is
set.
For releasing the park-
ing brake, refer to page
123.

140

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

Brake system

Braking system
impaired. Continue to
drive moderately.
Have the vehicle
checked immediately
by your Toyota dealer.

Yellow lights

Anti-lock Braking System
ABS

Braking force boost
may not be working.
Avoid abrupt braking.
Take the longer brak-
ing distance into
account.
Have the system imme-
diately checked by your
Toyota dealer.

VSC Vehicle Stability Con-
trol System

The indicator light
flashes: VSC controls
the drive and braking
forces. The vehicle is
stabilized. Reduce
speed and modify your
driving style to the driv-
ing circumstances.
The indicator light lights
up: VSC has malfunc-
tioned.
Have the system imme-
diately checked by a
dealer’s service center
or another qualified ser-
vice center or repair
shop.
VSC, refer to page 200.

VSC Vehicle Stability Con-
trol System is deactivated or
Traction mode is activated

VSC is deactivated or
Traction mode is acti-
vated.
VSC, refer to page 200,
and Traction mode,
refer to page 202.

141

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Tire Pressure Monitor TPM

The indicator light lights
up: the Tire Pressure
Monitor reports a low
tire inflation pressure or
a flat tire. Follow the
information in the vehi-
cle message.
The indicator light
flashes and then con-
tinuously lights up: no
flat tire or loss of tire
inflation pressure can
be detected.



Interference caused
by systems or
devices with the
same radio fre-
quency: after leaving
the area of the inter-
ference, the system
automatically
becomes active
again.



A wheel without TPM
wheel electronics is
mounted: have it
checked by your Toy-
ota dealer as needed.



Malfunction: have the
system checked by
your Toyota dealer.

Tire Pressure Monitor,
refer to page 288.

Steering system

Steering system may
not be working.
Have the system
checked by your Toyota
dealer.

Emissions



The warning light
lights up:

Emissions are deterio-
rating. Have the vehi-
cle checked as soon
as possible.



The warning light
flashes under certain
circumstances:

This indicates that
there is excessive mis-
firing in the engine.
Reduce the vehicle
speed and have the
system checked imme-
diately; otherwise, seri-
ous engine misfiring
within a brief period
can seriously damage
emission control com-
ponents, in particular
the catalytic converter.
Socket for Onboard
Diagnosis, refer to page
308.

142

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

The current fill level of the fuel
tank is displayed.

Vehicle tilt position may cause
the display to vary.
Information on refueling, refer to
page 268.

Green lights

Turn signal

Turn signal switched
on.
Unusually rapid flash-
ing of the indicator light
indicates that a turn sig-
nal bulb has failed.
Turn signal, refer to
page 123.

Parking lights

Parking lights are
switched on.
Parking lights/low
beams, refer to page
157.

Low beams

Low beams are
switched on.
Parking lights/low
beams, refer to page
157.

Lane departure warning

The indicator light lights
up: the system is acti-
vated. A lane marking
was detected on at
least one side of the
vehicle and warnings
can be issued.
Lane departure warn-
ing, refer to page 188.

Automatic high-beam

Automatic high-beam is
switched on.
High beams are
switched on and off
automatically depend-
ing on the traffic situa-
tion.
Automatic high-beam,
refer to page 160.

Blue lights

High beams

High beams are
switched on.
High beams, refer to
page 124.

Fuel gauge

Concept

General information

143

4-1. CONTROLS

Supra Owner’s Manual_U (from Mar. ’20

Prod.)

4

CON

T

ROLS

Always avoid engine speeds in
the red warning field. In this
range, the fuel supply is reduced
to protect the engine.

Depending on the vehicle equip-
ment, the shift position indica-
tors on the tachometer indicate
the maximum shift point at
which the best possible acceler-
ation can be achieved.

When the selected driving mode
is sport mode, a shift light will be
displayed.

1

Select SPORT using the
sport mode switch.

2

Activate manual mode of the
transmission.

• Successive orange illumi-

nated fields indicate the
upcoming shift moment.

• The field lights up red. Do not

wait any further to shift.

When the maximum speed is
reached, the entire display
flashes red and the supply of
fuel is interrupted in order to
protect the engine.

Display

An arrow beside the
fuel pump symbol
shows which side of the
vehicle the fuel filler
flap is on.

Indicator light in the
instrument cluster

The yellow indicator
light illuminates, once
the fuel reserve is
reached.

Tachometer

Shift lights

Concept

Functional requirement

Switching on shift lights

Display

Standby state and
drive-ready state

The letters OFF in the
tachometer indicate
that drive-ready state is
switched off and
standby state is
switched on.
