Toyota Supra (2020 year). Manual in english - part 2

70

3-1. CONTROLS

Supra Owner's Manual

CarPlay allows certain func-
tions of a compatible Apple
iPhone to be used via Siri voice
operation and Toyota Supra
Command.

• Compatible iPhone.

iPhone 5 or later with iOS 7.1 or
later.

• Corresponding mobile wire-

less contract.

• Bluetooth, WiFi, and Siri voice

operation are activated on the
iPhone.

• Booking the Toyota Supra

Connect service: Apple Car-
Play preparation.

Via Toyota Supra Command:

1

"My Vehicle"

2

"System settings"

3

"Mobile devices"

4

"Settings"

5

Select the following settings:

• "Bluetooth®"
• "Apple CarPlay"

Pair iPhone via Bluetooth with

the vehicle, refer to page 67.
Select CarPlay as the function:

 "Apple CarPlay"

The iPhone is connected to the
vehicle and displayed in the
device list, refer to page 71.

For more information, refer to
the Owner's Manual for naviga-
tion, entertainment, communica-
tion.

All requirements are met and all
required steps were completed
in the specified order. Despite
that, the mobile device does not
function as expected.
In this case, the following expla-
nations can help:
The iPhone has already been
paired with Apple CarPlay.
When a new connection is
established, CarPlay can no lon-
ger be selected.
• Delete the iPhone concerned

from the device list.

• On the iPhone, delete the

vehicle concerned from the
list of stored vehicles under
Bluetooth and under WiFi.

• Pair the iPhone as a new

device.

If the steps listed have been car-
ried out and the required func-
tion is still not available: contact

Apple CarPlay preparation

Concept

Functional requirements

Switching on Bluetooth and
CarPlay

Pairing iPhone with CarPlay

Operation

Frequently asked questions

71

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

the Toyota dealer.

Screen Mirroring enables mirror-
ing (outputting) of the smart-
phone display on the Control
Display.

• Compatible smartphone with

Screen Mirroring interface.

• Screen Mirroring is switched

on on the smartphone.

• WiFi is switched on in the

vehicle.

Via Toyota Supra Command:

1

"My Vehicle"

2

"System settings"

3

"Mobile devices"

4

"Settings"

5

"Vehicle Wi-Fi®"

Via Toyota Supra Command:

1

"My Vehicle"

2

"System settings"

3

"Mobile devices"

4

"Connect new device"

5

 "Screen Mirroring"

The WiFi name of the vehicle is dis-

played on the Control Display.

6

Search for WiFi devices in
the surroundings of the
smartphone.

The WiFi name of the vehicle

appears on the device display.

Select the WiFi name of the vehi-

cle.

7

Confirm the connection via
Toyota Supra Command.

The device is connected and
displayed in the device list, refer
to page 71.

• After one-time pairing, the

devices are automatically rec-
ognized and reconnected
when standby state is
switched on.

• The data stored on the SIM

card or in the mobile phone
are transferred to the vehicle
after recognition.

• For some devices, certain set-

tings are necessary, for
instance authorization; see
the owner's manual of the
device.

All devices paired with or con-
nected to the vehicle are dis-
played in the device list.
Via Toyota Supra Command:

Screen Mirroring

General information

Functional requirements

Activating WiFi

Pairing a smartphone with
Screen Mirroring

Managing mobile devices

General information

Displaying the device list

72

3-1. CONTROLS

Supra Owner's Manual

1

"My Vehicle"

2

"System settings"

3

"Mobile devices"

A symbol indicates, for which
function a device is used.

Functions can be activated or
deactivated for paired and con-
nected devices.
Via Toyota Supra Command:

1

"My Vehicle"

2

"System settings"

3

"Mobile devices"

4

Select the desired device.

5

Select the desired setting.

If a function is assigned to a
device, the function will be deac-
tivated where appropriate for a
device that is already connected
and the device will be discon-
nected.

Via Toyota Supra Command:

1

"My Vehicle"

2

"System settings"

3

"Mobile devices"

4

Select a device.

5

"Disconnect device"

The device remains paired and
can be connected again, refer to
page 72.

A disconnected device can be
reconnected.
Via Toyota Supra Command:

1

"My Vehicle"

2

"System settings"

3

"Mobile devices"

4

Select device.

5

"Connect device"

The functions that were
assigned to the device before
disconnecting are assigned to
the device when it is recon-
nected. If the device is already
connected, these functions are
deactivated.

Via Toyota Supra Command:

1

"My Vehicle"

2

"System settings"

3

"Mobile devices"

4

Select device.

5

"Delete device"

Symbol

Function

"Telephone"

"Additional telephone"

"Bluetooth® audio"

"Apps"

"Apple CarPlay"

"Screen Mirroring"

Configuring the device

Disconnecting the device

Connecting the device

Deleting the device

73

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

The device is disconnected and
removed from the device list.

If two mobile phones are con-
nected to the vehicle, the func-
tions of the phone and additional
phone can be switched.
Via Toyota Supra Command:

1

"My Vehicle"

2

"System settings"

3

"Mobile devices"

4

"Settings"

5

"Swap telephone/additional
tel."

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The vehicle is supplied with two
remote controls with integrated
key.
Each remote control contains a
replaceable battery. Replacing
the battery, refer to page 77.
You may set the button func-
tions, depending on the vehicle
equipment and country version.
Settings, refer to page 88.
A driver profile, refer to page 85,
with personal settings can be
assigned to a remote control.
To prevent possible locking in of
the remote control, take the

Swapping the telephone and
additional phone

Opening and closing

Vehicle features and
options

Remote control

General information

74

3-1. CONTROLS

Supra Owner's Manual

remote control with you when
exiting the vehicle.

1

Unlocking

2

Locking

3

Unlocking the trunk lid

4

Press and hold or press three
times in quick succession:
panic mode
Press briefly: headlight cour-
tesy delay feature

The behavior of the vehicle
when unlocking with the remote
control depends on the following
settings, refer to page 88, for
unlocking and locking:
• If only the driver's door and

the fuel filler flap or all access
to the vehicle will be
unlocked.

• If the unlocking of vehicle is

confirmed with a light signal

Safety information

WARNING

People or animals in the vehicle

can lock the doors from the inside

and lock themselves in. In this

case, the vehicle cannot be

opened from the outside. There is

a risk of injury. Take the remote

control with you so that the vehi-

cle can be opened from the out-

side.

WARNING

For some country versions,

unlocking from the inside is only

possible with special knowledge.

Persons who spend a lengthy

time in the vehicle while being

exposed to extreme tempera-

tures are at risk of injury or death.

Do not lock the vehicle from the

outside when there are people in

it.

WARNING

Unattended children or animals

can cause the vehicle to move

and endanger themselves and

traffic, for instance due to the fol-

lowing actions:

• Pressing the Start/Stop button.

• Releasing the parking brake.

• Opening and closing the doors

or windows.

• Engaging selector lever position

N.

• Using vehicle equipment.

There is a risk of accidents or inju-

ries. Do not leave children or ani-

mals unattended in the vehicle.

Take the remote control with you

when exiting and lock the vehicle.

Overview

Unlocking

General information

75

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

or a sound signal.

• If the welcome light, refer to

page 153, is switched on
when the vehicle is being
unlocked.

• If the exterior mirrors are

automatically folded out and
in when the vehicle is
unlocked and locked.

If, due to the settings, only the
driver's door and fuel filler flap
were unlocked, press the button
on the remote control again to
unlock the other vehicle access
points.
In addition, the following func-
tions are executed:
• If a driver profile, refer to page

85, was assigned to the
remote control, this driver pro-
file will be activated and the
settings that are stored in it
will be applied.

• The interior lights are

switched on, unless they were
manually switched off. Switch
the interior lights on/off manu-
ally, refer to page 156.

• With alarm system: The alarm

system, refer to page , will be
switched off.P.90

After opening one of the front
doors, the vehicle is ready for
operation, refer to page 43.

The light functions may depend
on the ambient brightness.

The windows are opened, as
long as the button on the remote
control is pressed.

The behavior of the vehicle
during locking with the remote
control depends on the following
settings, refer to page 88:
• If the locking of the vehicle is

confirmed with a light signal
or a sound signal.

• If the exterior mirrors are

automatically folded in and
out when the vehicle is locked
and unlocked.

• If the headlight courtesy delay

feature, refer to page 153, is
activated during locking.

1

Close the driver's door.

2

 Press the button on the

remote control.

The following functions are exe-
cuted:

Unlocking the vehicle

Press the button on the
remote control.

Convenient opening

Opening

Press and hold the button
on the remote control.

Locking

General information

Locking the vehicle

76

3-1. CONTROLS

Supra Owner's Manual

• All doors, the trunk lid, and

the fuel filler flap are locked.

• With alarm system: The alarm

system, refer to page 90, will
be switched on.

If the drive-ready state is still
switched on when you lock the
vehicle, the vehicle horn honks
twice. In this case, the
drive-ready state must be
switched off by means of the
Start/Stop button.

The windows are closed in the
area close to the vehicle, as
long as the button on the remote
control is pressed.

The function is not available for
the first 10 seconds after lock-
ing.
• The interior lights are

switched on, unless they were
manually switched off. Switch
the interior lights on/off manu-
ally, refer to page 156.

• Depending on the settings,

the exterior lighting, refer to
page 153, will be switched on.

The light functions may depend
on the ambient brightness.

To avoid locking it in the vehicle,
do not place the remote control
in the cargo area.
You can set up if the doors will
be unlocked when the trunk lid
is opened with the remote con-
trol. Settings, refer to page 88.

With Smart Key System:
convenient closing

Safety information

WARNING

With convenient closing, body

parts can be jammed. There is a

risk of injury. Make sure that the

area of movement of the doors is

clear during convenient closing.

Closing

Press and hold the button
on the remote control after
locking.

Switching on the interior
and exterior lights

Press the button on the
remote control with the
vehicle locked.

Trunk lid

General information

Safety information

WARNING

Body parts can be jammed when

operating the trunk lid. There is a

risk of injury. Make sure that the

area of movement of the trunk lid

is clear during opening and clos-

ing.

77

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

You can trigger the alarm sys-
tem if you find yourself in a dan-
gerous situation.

To switch off the alarm: press
any button.

Set the duration, refer to page
153.

1

Remove the integrated key
from the remote control, refer
to page 80.

2

Place the integrated key
underneath the battery com-
partment cover, arrow

1

, and

lift the cover with a lever
movement of the integrated
key, arrow

2

.

3

Push battery in the direction
of the arrow using a pointed
object and lift it out.

4

Insert a type CR 2032 battery
with the positive side facing
up.

5

Press the cover closed.

NOTICE

During opening, the trunk lid piv-

ots back and up. There is a risk of

damage to property. Make sure

that the area of movement of the

trunk lid is clear during opening

and closing.

Unlocking

Press and hold the button
on the remote control for
approx. 1 second.

Panic mode

• Press the button on the

remote control and hold
for at least 3 seconds.

• Briefly press the button

on the remote control
three times in succes-
sion.

Switching on the headlight
courtesy delay feature

Press and hold the button
on the remote control for
approx. 1 second.

Replacing the battery

Have old batteries dis-
posed of by your Toyota
dealer or take them to a
collection point.

78

3-1. CONTROLS

Supra Owner's Manual

Additional remote controls are
available from your Toyota
dealer.

A lost remote control can be
blocked and replaced by your
Toyota dealer.
If the lost remote control has an
assigned driver profile, refer to
page 85, the connection to this
remote control must be deleted.
A new remote control can then
be assigned to the driver profile.

A vehicle message, refer to
page 131, is displayed.
Remote control detection by the
vehicle may malfunction under
the following circumstances:
• The battery of the remote

control is discharged. Replac-
ing the battery, refer to page
77.

• Interference of the radio con-

nection from transmission
towers or other equipment
with high transmitting power.

• Shielding of the remote con-

trol due to metal objects.

Do not transport the remote control
together with metal objects.

• Interference of the radio con-

nection from mobile phones
or other electronic devices in
direct proximity to the remote
control.

Do not transport the remote control
together with electronic devices.

• Interference of radio transmis-

sion by a charging process of
mobile devices, for instance
charging of a mobile phone.

• The remote control is in direct

proximity of the wireless
charging tray.

Place the remote control down at a
different location.

In the case of interference, the
vehicle can be unlocked and
locked from the outside with the
integrated key, refer to page 79.

It is not possible to switch on the
drive-ready state if the remote
control has not been detected.

Additional remote controls

Loss of the remote con-
trols

Malfunction

General information

Switching the drive-ready
state on via emergency
detection of the remote con-
trol

79

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

Proceed as follows in this case:

1

Hold the remote control with
its back against the marked
area on the steering column.
Pay attention to the display in
the instrument cluster.

2

If the remote control is
detected: Switch on
drive-ready state within 10
seconds.

If the remote control is not
detected, slightly change the
position of the remote control
and repeat the procedure.

What precautions can be taken
to be able to open a vehicle with
an accidentally locked in remote
control?
• The options provided by the

Remote Services of the Toy-
ota Supra Connect app
include the ability to lock and
unlock a vehicle.

This requires an active Toyota
Supra Connect contract and the
Toyota Supra Connect app must be
installed on a smartphone.

• Unlocking the vehicle can be

requested via the Concierge.

An active Toyota Supra Connect
contract is required.

The driver's door can be locked
and unlocked without remote
control using the integrated key.
The integrated key also fits the
glove compartment.

Frequently asked ques-
tions

Integrated key

General information

Safety information

WARNING

For some country versions,

unlocking from the inside is only

possible with special knowledge.

Persons who spend a lengthy

time in the vehicle while being

exposed to extreme tempera-

tures are at risk of injury or death.

Do not lock the vehicle from the

outside when there are people in

it.

NOTICE

The door lock is permanently

joined with the door. The door

handle can be moved. When pull-

ing the door handle with the inte-

grated key inserted, paint or the

integrated key can be damaged.

There is a risk of damage to prop-

erty. Remove the integrated key

before pulling the outside door

handle.

80

3-1. CONTROLS

Supra Owner's Manual

Press the button, arrow

1

, and

pull out the integrated key, arrow

2

.

1

Pull and hold the door handle
outward with one hand.

2

Guide one finger of your
other hand from the back
under the cover and push the
cover out.

Use the thumb for counter support

to prevent the cover from falling out

of the door handle.

3

Remove the cover.

4

Unlock or lock the door lock
using the integrated key.

The other doors must be
unlocked or locked from the
inside.

The alarm system is not
switched on if the vehicle is
locked with the integrated key.
The alarm system is triggered
when the door is opened, if the
vehicle has been unlocked via
the door lock.
In order to stop the alarm,
unlock the vehicle with the
remote control, if necessary
through emergency detection of
the remote control, refer to page

Removing

Locking/unlocking via the
door lock

Alarm system

81

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

78.

In the event of a severe acci-
dent, the vehicle is automatically
unlocked. The hazard warning
system and interior lights come
on.

Buttons for the central locking
system.

• The fuel filler flap remains

unlocked.

• The vehicle is not secured

against theft when locking.

•

 Press the button to

unlock all the doors.

Pull the door opener above the
armrest.

• Pull the door handle on the

door to open the door. The
other doors remain locked.

The vehicle can be accessed
without activating the remote
control.
All you need to do is to have the
remote control with you, such as
in your pants pocket.
The vehicle automatically
detects the remote control when
it is in close proximity or in the
car's interior.

Comfort entry supports the fol-
lowing functions:
• Unlocking and locking the

vehicle from the door handle.

• To lock the vehicle, the

remote control must be
located outside of the vehicle
near the doors.

• The next unlocking and lock-

Buttons for the central
locking system

General information

Overview

Locking

Press the button with the
front doors closed.

Unlocking

Press the button.

Opening

Smart Key System

Concept

General information

Functional requirements

82

3-1. CONTROLS

Supra Owner's Manual

ing cycle is not possible until
after approx. 2 seconds.



The driver should always
carry the remote control on
their person and take it with
them when they leave the
vehicle.



Depending on the location of
the vehicle or the surround-
ing radio wave conditions, the
remote control may not oper-
ate normally. Make sure not to
carry the remote control with
an electronic device, such as
a mobile phone or computer.



Make sure to always take the
remote control with you when
you leave the vehicle, in case
the battery of the remote con-
trol is depleted or the remote
control is malfunctioning.

Important points

Safety notes

WARNING

The vehicle transmits radio waves

whenever the Smart Key System

is used to lock or unlock the

doors, open the trunk lid, or when

the engine switch is operated.

Therefore, this system may affect

the operation of implantable car-

diac pacemakers and implantable

cardioverter defibrillators.

Persons with implantable cardiac

pacemakers or implantable car-

dioverter defibrillators should stay

22 cm or more away from the

vehicle when opening or closing a

door. Also, they should refrain

from leaning on the vehicle or

looking through the windows from

outside when a door is opened or

closed.

Users of any electrical medical

device other than implantable car-

diac pacemakers, cardiac resyn-

chronization therapy-pacemakers

or implantable cardioverter

defibrillators should consult their

doctor or the manufacturer of the

device for information about its

operation under the influence of

radio waves.

83

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

Near the front of the center console
Near the rear of the center console
In the luggage compartment and near the rear bumper
Near each door and door handle

The behavior of the vehicle
during unlocking via the Smart
Key System depends on the fol-
lowing settings, refer to page 88:
• If the unlocking of vehicle is

confirmed with a light signal
or a sound signal.

• If the welcome light, refer to

page 153, is switched on
when the vehicle is being

unlocked.

• If the exterior mirrors are

automatically folded out and
in when the vehicle is
unlocked and locked.

Effective range (areas within which Smart Key System radio
waves are transmitted)

A

B

C

D

Unlocking

General information

84

3-1. CONTROLS

Supra Owner's Manual

Grasp the handle of a vehicle
door completely.

The behavior of the vehicle
during locking via the Smart Key
System depends on the follow-
ing settings, refer to page 88:
• If the locking of the vehicle is

confirmed with a light signal
or a sound signal.

• If the exterior mirrors are

automatically folded out and
in when the vehicle is
unlocked and locked.

• If the headlight courtesy delay

feature, refer to page 153, is
activated during locking.

Close the driver's door.

Touch the grooved surface on
the handle of a closed vehicle
door with your finger for approx.
1 second without grasping the
door handle.

To avoid locking it in the vehicle,
do not place the remote control
in the cargo area.
Depending on the vehicle equip-
ment and country version, it is
also possible to have the doors
unlocked. Adjusting the settings,
refer to page 88.

Unlocking the vehicle

Locking

General information

Locking the vehicle

Trunk lid

General information

Safety information

WARNING

Body parts can be jammed when

operating the trunk lid. There is a

risk of injury. Make sure that the

area of movement of the trunk lid

is clear during opening and clos-

ing.

85

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

Depending on the setting, the
doors may also be unlocked.
Opening with the remote con-
trol, refer to page 76.

Grasp the recess grips and pull
the trunk lid down.

Pull the handle inside the cargo
area.
The trunk lid unlocks.

In the driver profiles, individual
settings for several drivers can
be stored and called up again
when required.

There are three driver profiles
with which personal vehicle set-
tings can be stored. Every
remote control has one of these
driver profiles assigned.
If the vehicle is unlocked using a
remote control, the assigned
personal driver profile will be
activated. All settings stored in
the driver profile are automati-
cally applied.
If several drivers use their own
remote control, the vehicle will
adjust the personal settings

NOTICE

During opening, the trunk lid piv-

ots back and up. There is a risk of

damage to property. Make sure

that the area of movement of the

trunk lid is clear during opening

and closing.

Opening and Closing

Opening from the outside

Press and hold the button
on the remote control for
approx. 1 second.

Opening from the inside

Press the button in the
storage compartment of
the driver's door.

Closing

Trunk emergency unlocking

Driver profile

Concept

General information

86

3-1. CONTROLS

Supra Owner's Manual

during unlocking. These settings
are also restored, if the vehicle
has been used in the meantime
by a person with a different
remote control.
Changes to the settings are
automatically stored in the driver
profile currently activated. If
another driver profile is selected
via Toyota Supra Command, the
settings stored in it will be
applied automatically.
The new driver profile is
assigned to the remote control
currently used.
There is an additional guest pro-
file available that is not assigned
to any remote control. It can be
used to apply settings in the
vehicle without changing the
personal driver profiles.

For the system to be able to
identify the driver profile associ-
ated to a particular driver, the
detected remote control must be
clearly allocated to the driver.
This is the case when:
• The driver is only carrying his

or her own remote control.

• The driver unlocks the vehi-

cle.

• The driver gets into the vehi-

cle through the driver's door.

After switching on the Control
Display, the name of the active
driver profile is displayed.
Select driver profile, refer to
page 87.
As soon as the engine is started
or any key is pressed, the last
selected display is shown on the
Control Display.
To exit the welcome screen via
Toyota Supra Command: "OK"

The settings for the following
systems and functions are
stored in the active driver profile.
The scope of storable settings
depends on country and equip-
ment.
• Unlocking and locking.
• Lights.
• Climate control.
• Radio.
• Instrument cluster.
• Programmable memory but-

tons.

• Volumes, tone.
• Control Display.
• Navigation.
• Parking Sensors.
• Rearview camera.
• Head-up Display.
• Sport mode switch.
• Seat position, exterior mirror

position.

Functional requirements

Active driver profile

Settings

87

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

Both the positions saved via the
seat memory and the last position
set are saved.

• Toyota Supra Safety.

Regardless of the remote con-
trol in use, a different driver pro-
file may be activated. This
allows you to call up personal
vehicle settings, even if you did
not unlock the vehicle with your
own remote control.
Via Toyota Supra Command:

1

"My Vehicle"

2

"Driver profiles"

3

Select driver profile.

4

"OK"

• All settings stored in the

called-up driver profile are
automatically applied.

• The called-up driver profile is

assigned to the remote con-
trol being used at the time.

• If the driver profile is already

assigned to a different remote
control, this driver profile will
apply to both remote controls.

The guest profile is for individual
settings that are stored in none
of the three personal driver pro-
files.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Driver profiles"

3

"Drive off (guest)"

4

"OK"

The guest profile cannot be
renamed. It is not assigned to
the current remote control.

A personal name can be
assigned to the active driver
profile to avoid confusion
between the driver profiles.
Via Toyota Supra Command:

1

"My Vehicle"

2

"Driver profiles"

3

Select driver profile.

 The driver profile marked with

this symbol can be renamed.

4

"Change driver profile name"

5

Enter profile name.

6

 Select the symbol.

The settings of the active driver
profile are reset to their factory
settings.
Via Toyota Supra Command:

1

"My Vehicle"

2

"Driver profiles"

3

Select driver profile.

 The driver profile marked with

Profile management

Selecting a driver profile

Guest profile

Renaming a driver profile

Resetting a driver profile

88

3-1. CONTROLS

Supra Owner's Manual

this symbol can be reset.

4

"Reset driver profile"

5

"OK"

Most settings of the active driver
profile can be exported.
Exporting is helpful when storing
and retrieving personal set-
tings, for instance before deliv-
ering the vehicle to a workshop.
The stored driver profiles can be
taken into another vehicle.
Via Toyota Supra Command:

1

"My Vehicle"

2

"Driver profiles"

3

Select driver profile.

 The driver profile marked with

this symbol can be exported.

4

"Export driver profile"

5

Select a storage device for
exporting the driver profile.

• "USB device"

Select USB storage device, as
needed, refer to page 68.

The existing settings of the
active driver profile are overwrit-
ten with the settings of the
imported driver profile.
Via Toyota Supra Command:

1

"My Vehicle"

2

"Driver profiles"

3

Select the driver profile to be
overwritten.

 The driver profile marked with

this symbol can be overwritten.

4

"Import driver profile"

5

Select a storage device for
importing the driver profile.

• USB storage device: "USB

device"

Select USB storage device as
needed.

6

Select the driver profile to be
imported.

A clear assignment between the
remote control and driver may
not be possible in the following
cases, for example.
• The passenger unlocks the

vehicle with his or her own
remote control, but another
person is driving.

• The driver unlocks the vehicle

via Smart Key System and
has multiple remote controls
with him or her.

• The driver changes, but the

vehicle is not locked and
unlocked.

• Multiple remote controls are

located outside of the vehicle.

Depending on the package and

Exporting driver profiles

Importing driver profiles

System limits

Settings

General information

89

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

country version, various settings
are available for the remote con-
trol functions.
These settings are stored for the
driver profile currently used.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

 "Driver's door" or   "All

doors"

5

Select desired setting:

• "Driver's door only"

Only the driver's door and the fuel
filler flap are unlocked. Pressing
again unlocks the entire vehicle.

• "All doors"

The entire vehicle is unlocked.

Depending on the vehicle equip-
ment and country version, this
setting may not be offered.
Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

 "Tailgate" or

 "Tail-

gate and door(s)"

5

Select desired setting:

• "Tailgate"

The trunk lid is opened.

• "Tailgate and door(s)"

The trunk lid is opened and the
doors are unlocked.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Driver profiles"

3

Select driver profile.

 The setting can be made for the

driver profile marked with this sym-

bol.

4

"Last seat position automatic"

When the vehicle is unlocked,
the driver's seat and exterior
mirrors resume their last set
positions.
The most recent position is inde-
pendent of the positions saved
via the seat memory.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

Deactivate or activate the
desired confirmation signals:

• "Flash for lock/unlock"

Unlocking is signaled by two
flashes, locking by one.

Unlocking

Doors

Trunk lid

Adjusting the last seat and
mirror position

Confirmation signals from
the vehicle

90

3-1. CONTROLS

Supra Owner's Manual

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

Select desired setting:

• "Lock automatically"

The vehicle locks automatically
after a short period of time if no
door is opened after unlocking.

• "Lock after starting to drive"

The vehicle locks automatically
after you drive off.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

"Unlock at end of trip"

After drive-ready state is switched

off by pressing the Start/Stop but-

ton, the locked vehicle is automati-

cally unlocked.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

"Fold mirrors in when locked"

Locking the vehicle folds in the

exterior mirrors automatically.

Unlocking the vehicle automatically

folds out the exterior mirrors.

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Doors/Key"

4

"Turn off after door opening"

Opening the front doors establishes

the idlestate, refer to page 42.

When the vehicle is locked, the
vehicle alarm system reacts to
the following changes:
• Opening a door, the hood or

the trunk lid.

• Movements in the car's inte-

rior.

• Changes in the vehicle tilt, e.

g., during attempts at stealing
a wheel or when towing the
vehicle.

• Disconnected battery voltage.
• Improper use of the socket for

OBD Onboard Diagnosis.

The alarm system signals the
following changes visually and
acoustically:
• Acoustic alarm: Depending on

local regulations, the acoustic
alarm may be suppressed.

• Visual alarm: By flashing the

exterior lighting.

Automatic locking

Automatic unlocking

Folding mirrors automati-
cally

Establishing idle state
after opening the front
doors

Alarm system

General information

91

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

When you unlock and lock the
vehicle, either with the remote
control or with Comfort entry, the
alarm system is switched off and
on at the same time.

The alarm system is triggered
when a door is opened if the
door was unlocked using the
integrated key in the door lock.
Switching off the alarm, refer to
page 92.

The trunk lid can be opened
even when the alarm system is
switched on.
After the trunk lid is closed, it is
locked and monitored again pro-
vided the doors are locked. The
hazard warning system flashes
once.

You can trigger the alarm sys-
tem if you find yourself in a dan-
gerous situation.

To switch off the alarm: press
any button.

• The indicator light flashes

briefly every 2 seconds: The
alarm system is switched on.

• Indicator light flashes for

approx. 10 seconds, then it
flashes briefly every 2 sec-
onds: Interior motion sensor
and tilt alarm sensor are not
active, as doors, hood, or
trunk lid are not correctly
closed. Correctly closed
access points are secured.

When the still open access points
are closed, interior motion sensor
and tilt alarm sensor will be
switched on.

• The indicator light goes out

after unlocking: The vehicle
has not been tampered with.

Switching on/off

Opening the doors with
the alarm system switched
on

Opening the trunk lid with
the alarm system switched
on

Panic mode

• Press the button on the

remote control and hold
for at least 3 seconds.

• Briefly press the button

on the remote control
three times in succes-
sion.

Indicator light on the inte-
rior mirror

92

3-1. CONTROLS

Supra Owner's Manual

• The indicator light flashes

after unlocking until
drive-ready state is switched
on, but no longer than approx.
5 minutes: An alarm has been
triggered.

The tilt of the vehicle is moni-
tored.
The alarm system responds in
situations such as attempts to
steal a wheel or when the vehi-
cle is towed.

The car's interior is monitored to
the height of the seats. The
alarm system is switched on
together with the interior motion
sensor even when the window is
open. Falling objects such as
leaves can trigger the alarm
unintentionally.

The tilt alarm sensor and interior
motion sensor can trigger an
alarm, although no unauthorized
action occurred.
Possible situations for an
unwanted alarm:
• In automatic vehicle washes.
• In duplex garages.

• During transport on trains car-

rying vehicles, at sea or on a
trailer.

• With animals in the vehicle.
• When the vehicle is locked

after start of fueling.

The tilt alarm sensor and the
interior motion sensor can be
switched off in such situations.

The indicator light lights up for
approx. 2 seconds and then
continues to flash.
The tilt alarm sensor and interior
motion sensor are switched off
until the vehicle is locked again.

• Unlock the vehicle using the

remote control, if needed,
through emergency detection
of the remote control, refer to
page 78.

• With Smart Key System: if

you are carrying the remote
control on your person, grasp
the driver side or front pas-
senger side door handle com-
pletely.

Tilt alarm sensor

Interior motion sensor

Avoiding unintentional
alarms

General information

Switching off the tilt alarm
sensor and interior motion
sensor

Press the button on the
remote control within 10
seconds as soon as the
vehicle is locked.

Switching off the alarm

93

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

The windows can be operated
under the following conditions.
• Standby state is established.
• Drive-ready state is estab-

lished.

• The remote control is in the

car's interior.

•

 Press the switch to the

resistance point.

The window opens while the switch
is being held.

•

 Press the switch

beyond the resistance point.

The window opens automatically.
Pressing the switch again stops the
motion.

•

 Pull the switch to the

resistance point.

The window closes while the switch
is being held.

•

 Pull the switch beyond

the resistance point.

The window closes automatically if
the door is closed. Pulling again
stops the motion.

If closing force exceeds a spe-
cific threshold as a window
closes, closing is interrupted.
The window opens slightly.

Power windows

Safety information

WARNING

When operating the windows,

body parts and objects can be

jammed. There is a risk of injury

or risk of damage to property.

Make sure that the area of move-

ment of the windows is clear

during opening and closing.

Overview

Power windows

Functional requirements

Opening

Closing

Jam protection system

General information

Safety information

WARNING

Accessories on the windows such

as antennas can impact jam pro-

tection. There is a risk of injury.

Do not install accessories in the

area of movement of the win-

dows.

94

3-1. CONTROLS

Supra Owner's Manual

In case of danger from the out-
side or if ice might prevent nor-
mal closing, proceed as follows:

1

 Pull the switch past the

resistance point and hold it
there.

The window closes with limited jam

protection. If the closing force

exceeds a specific threshold, clos-

ing is interrupted.

2

 Pull the switch past the

resistance point again within
approx. 4 seconds and hold it
there.

The window closes without jam pro-

tection.

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

An ideal seating position that
meets the needs of the occu-
pants can make a vital contribu-
tion to relaxed, fatigue-free
driving.
In the event of an accident, the
correct seating position plays an
important role. Follow the infor-
mation in the following chapters:
• Seats, refer to page 95.
• Safety belts, refer to page 98.
• Head restraints, refer to page

102.

• Airbags, refer to page 158.

Closing without the jam pro-
tection system

Seats, mirrors, and

steering wheel

Vehicle features and
options

Sitting safely

95

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

1

Backrest angle

2

Height

3

Backrest width

4

Lumbar support

5

Forward/back

6

Seat angle

Pull the lever and apply your
weight to or lift your weight off
the backrest as required.

Seats

Safety information

WARNING

Seat adjustments while driving

can lead to unexpected move-

ments of the seat. Vehicle control

could be lost. There is a risk of an

accident. Only adjust the seat on

the driver's side when the vehicle

is stationary.

WARNING

With a backrest inclined too far to

the rear, the efficacy of the safety

belt can no longer be ensured.

There is a risk of sliding under the

safety belt in an accident. There is

a risk of injuries or danger to life.

Adjust the seat prior to starting the

trip. Adjust the backrest so that it

is in the most upright position as

possible and do not adjust again

while driving.

WARNING

There is a risk of jamming when

moving the seats. There is a risk

of injury or risk of damage to prop-

erty. Make sure that the area of

movement of the seat is clear

prior to any adjustment.

Manually adjustable seats

Overview

Backrest angle

6

5

4 3

2

1

96

3-1. CONTROLS

Supra Owner's Manual

Pull the lever up or press the
lever down repeatedly until the
seat reaches the desired height.

Pull the lever and slide the seat
in the desired direction.
After releasing the lever, move
the seat gently forward or back
to make sure it engages prop-
erly.

Pull the lever up or press the
lever down repeatedly until the
seat reaches the desired angle.

The seat adjustment for the
driver's seat is stored for the
driver profile, refer to page 85,
currently used. When a driver
profile is selected, the stored
position is called up automati-
cally.
The current seat position can be
stored using the memory func-
tion, refer to page 105.

Height

Forward/back

Seat angle

Electrically adjustable
seats

General information

97

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

1

Forward/backward, height,
seat tilt

2

Driver's seat memory

3

Backrest tilt

4

Backrest width

5

Lumbar support

Push switch forward or back-
ward.

Push switch up or down.

Move switch up or down.

Move switch forward or back-
ward.

Overview

Forward/backward

Height

Seat tilt

Backrest tilt

98

3-1. CONTROLS

Supra Owner's Manual

The curvature of the seat back-
rest can be adjusted in a way
that it supports the lumbar
region of the spine. The lower
back and the spine are sup-
ported for upright posture.

Adjusting the backrest width
may improve lateral support
when taking corners.

You can change the backrest
width by adjusting the side
wings of the backrest.

The vehicle is fitted with two
safety belts to ensure occupant
safety. However, they can only
offer protection when adjusted
correctly.

Always make sure that safety
belts are being worn by the
occupants before driving off.
The airbags supplement the
safety belts as an additional
safety device. The airbags are
not a substitute for safety belts.
The upper shoulder strap's
anchorage point will be correct
for adult seat occupants of every
build if the seat is correctly
adjusted.

Lumbar support

Concept

Settings

• Press the front/rear sec-

tion of the button: The
curvature is increased/
decreased.

• Press the upper/lower

section of the button:
The curvature is shifted
up/ down.

Backrest width

Concept

General information

Settings

• Press the front section

of the button: The back-
rest width decreases.

• Press the rear section of

the button: The back-
rest width increases.

Safety belts

Number of safety belts and
safety belt buckles

General information

99

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

• Wear the safety belt twist-free

and tight to your body over
your lap and shoulders.

• Wear the safety belt deep on

your hips over your lap. The
safety belt may not press on
your stomach.

• Do not rub the safety belt

against sharp edges, or guide
it or jam it in across hard or
fragile objects.

• Avoid thick clothing.
• Re-tighten the safety belt fre-

quently upward around your
upper body.

Having a correct driving posture
is essential for safe driving.
Maintaining a correct driving

Safety information

WARNING

Use of a safety belt to buckle

more than one person will poten-

tially defeat the ability of the

safety belt to serve its protective

function. There is a risk of injuries

or danger to life. Do not allow

more than one person to wear a

single safety belt. Infants and chil-

dren are not allowed on an occu-

pant's lap, but must be

transported and secured in desig-

nated child restraint systems.

WARNING

The efficacy of safety gear, includ-

ing safety belts, can be limited or

lost when safety belts are fas-

tened incorrectly. An incorrectly

fastened safety belt can cause

additional injuries, for instance in

the event of an accident or during

braking and evasive maneuvers.

There is a risk of injuries or dan-

ger to life. Make sure that all

occupants are wearing safety

belts correctly.

WARNING

The efficacy of safety gear, includ-

ing safety belts, may not be fully

functional or fail in the following

situations:

• The safety belts or safety belt

buckles are damaged, soiled, or

changed in any other way.

• Belt tensioners or belt retractors

were modified.

Safety belts can be imperceptibly

damaged in the event of an acci-

dent. There is a risk of injuries or

danger to life. Do not modify

safety belts, safety belt buckles,

belt tensioners, belt retractors or

belt anchors and keep them

clean. Have the safety belts

checked after an accident at the

your Toyota dealer.

Correct use of safety belts

Correct driving posture

100

3-1. CONTROLS

Supra Owner's Manual

posture not only helps reduce
fatigue while driving, but helps
ensure that the occupant protec-
tion devices, such as the seat
belts and airbags, will operate
correctly in a collision, reducing
the impact to the occupants.

The most basic occupant pro-

tection device is the seat belt.
The airbags are designed to
supplement the seat belts, not
be used in place of them. Wear-
ing the seat belt correctly
ensures that the occupants are
securely held in the seats and
helps prevent them from con-
tacting interior parts or being
thrown from the vehicle in a col-
lision. Therefore, it is necessary
for all occupants to wear their
seat belt. If a seat belt is worn
improperly, its effectiveness as
an occupant protection device
will be severely reduced. Pay
attention to the following to
ensure the correct driving pos-
ture and use of the seat belts.

Position the head restraint so that the center of it is at the same

Correct use of the seat
belts

Correct driving posture and use of the seat belts

A

101

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

height as the top of your ears
Make sure that the seat belt is not twisted
Adjust the seat so that your arms bend slightly at the elbow when
gripping the upper part of the steering wheel
Make sure that the seat belt is snug and not loose at any point
Position the lap belt as low as possible over the hips
Sit well back in the seat with the seatback upright
Sit so your entire back is in contact with the seatback
Position the shoulder belt so that it does not contact your neck or
slide off your shoulder

B

C

D

E

F

G

H

WARNING

Do not recline the seatback

excessively while driving.

To reduce the risk of sliding under

the lap belt during a collision, do

not recline the seat more than

necessary. If the seat is too

reclined, the lap belt may slide

past the hips and apply restraint

forces directly to the abdomen, or

your neck may contact the shoul-

der belt, increasing the risk of

death or serious injury in the

event of an accident. Adjustments

should not be made while driving

as the seat may unexpectedly

move and cause the driver to lose

control of the vehicle.

WARNING

Make sure that all passengers

wear their seat belt correctly.

Use of seat belts may be manda-

tory under local laws and regula-

tions. If a seat belt is not worn

properly, an occupant may con-

tact interior parts or be thrown

from the vehicle in the case of

sudden braking or a collision, pos-

sibly resulting in death or serious

injury. Also, if an occupant has an

incorrect riding posture, the air-

bags will be ineffectual as occu-

pant protection devices and may

actually cause injuries when they

deploy.

102

3-1. CONTROLS

Supra Owner's Manual

1

Guide the safety belt slowly
over shoulder and hip to put it
on.

2

Insert the tongue plate into
the safety belt buckle. The
safety belt buckle must
engage audibly.

1

Hold the safety belt firmly.

2

Press the red button in the
safety belt buckle.

3

Guide the safety belt back
into its roll-up mechanism.

WARNING

Correct use of the seat belts when

pregnant:

Pregnant women must wear a

seat belt. Consult your physician

for advice on correct way to wear

a seat belt. Position the lap belt as

low as possible over the hips and

the shoulder belt completely over

the shoulder, passing the center

of the chest, so that the seat belt

does not apply any pressure to

the abdomen.

Buckling the safety belt

Unbuckling the safety belt

Safety belt reminder for
driver's seat and front pas-
senger seat

Display in the instrument
cluster

The indicator light lights up
and a signal sounds.
Make sure that the safety
belts are positioned cor-
rectly. The safety belt
reminder can also be acti-
vated if objects are placed
on the front passenger
seat.

Front head restraints

Safety information

WARNING

Objects on the head restraint

reduce the protective effect in the

head and neck area. There is a

risk of injury.

• Do not use seat or head

restraint covers.

• Do not hang objects, for

instance clothes hangers,

directly on the head restraint.

103

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

The height of the head restraints
cannot be adjusted.

The spacing is adjusted to the
back of the head using the
incline of the backrest.
Adjust the distance so that the
head restraint is as close as
possible to the back of the head.

The head restraints cannot be
removed.

The mirror on the front passen-
ger side is more curved than the
driver's side mirror.
The mirror setting is stored for
the driver profile, refer to page
85, currently in use. When a
driver profile is selected, the
stored position is called up auto-
matically.

The current exterior mirror posi-
tion can be stored using the
memory function, refer to page
105.

1

Settings

2

Selecting a mirror, Automatic
Curb Monitor

3

Folding in and out

 Press the button.

The selected mirror moves
along with the button move-
ment.

WARNING

• Only use accessories that have

been determined to be safe for

attachment to a head restraint.

• Do not use any accessories, for

instance pillows, while driving.

Adjusting the height

Adjusting the distance

Removing

Exterior mirrors

General information

Safety information

WARNING

Objects reflected in the mirror are

closer than they appear. The dis-

tance to the traffic behind could

be incorrectly estimated, for

instance while changing lanes.

There is a risk of an accident.

Estimate the distance to the traffic

behind by looking over your

shoulder.

Overview

Adjusting electrically

104

3-1. CONTROLS

Supra Owner's Manual

 To change over to the

other mirror: Slide the switch.

In case of an electrical malfunc-
tion, adjust the mirror by press-
ing the edges of the mirror
glass.

 Press the button.

Folding is only possible up to a
speed of approx. 15 mph/20
km/h.
Folding the mirrors in and out is
helpful in the following situa-
tions:
• In vehicle washes.
• On narrow roads.
Mirrors that were folded in are
folded out automatically at a
speed of approx. 25 mph/40
km/h.

Both exterior mirrors are auto-
matically heated as needed and

when the drive-ready state is
switched on.

The exterior mirror on the
driver's side is automatically
dimmed. Photocells in the car's
interior mirror, refer to page 105,
are used to control this.

If reverse gear is engaged, the
mirror glass on the front passen-
ger side is tilted downward. This
improves your view of the curb
and other low-lying obstacles
when parking, for instance.

1

 Slide the switch to the

driver's side mirror position.

2

Engage selector lever posi-
tion R.

 Slide the switch to the

passenger's side mirror position.

Selecting a mirror

Malfunction

Folding in and out

NOTICE

Depending on the vehicle width,

the vehicle can be damaged in

vehicle washes. There is a risk of

damage to property. Before wash-

ing, fold in the mirrors by hand or

with the button.

Automatic heating

Automatic dimming fea-
ture

Automatic Curb Monitor,
exterior mirror

Concept

Activating

Deactivating

105

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

The interior mirror is dimmed
automatically.
Photocells are used for control:
• In the mirror glass.
• On the back of the mirror.

• Keep the photocells clean.
• Do not cover the area

between the interior mirror
and the windshield.

1

Fold the lever down.

2

Move the steering wheel to
the preferred height and
angle to suit your seating
position.

3

Fold the lever back up.

The following settings can be
stored and, if necessary,
retrieved using the memory
function:
• Seat position.

Interior mirror, automatic
dimming feature

General information

Overview

Functional requirements

Steering wheel

Safety information

WARNING

Steering wheel adjustments while

driving can lead to unexpected

steering wheel movements. Vehi-

cle control could be lost. There is

a risk of an accident. Adjust the

steering wheel while the vehicle is

stationary only.

Manual steering wheel
adjustment

Memory function

Concept

106

3-1. CONTROLS

Supra Owner's Manual

• Exterior mirror position.
• Height of the Head-up Dis-

play.

Two memory locations with dif-
ferent settings can be set for
each driver profile, refer to page
85.
The following settings are not
stored:
• Backrest width.
• Lumbar support.

The memory buttons are located
on the driver's seat.

1

Set the desired position.

2

 Press the button. The

writing on the button lights
up.

3

Press desired button 1 or 2
while the LED is lit. A signal
sounds.

Press selected button 1 or 2.
The stored position is called up.
The procedure stops when a
switch for setting the seat is
pressed or one of the memory
buttons is pressed again.
While driving, the seat position
adjustment on the driver's side
is interrupted after a short time.

General information

Safety information

WARNING

Using the memory function while

driving can lead to unexpected

seat movements. Vehicle control

could be lost. There is a risk of an

accident. Only retrieve the mem-

ory function when the vehicle is

stationary.

WARNING

There is a risk of jamming when

moving the seats. There is a risk

of injury or risk of damage to prop-

erty. Make sure that the area of

movement of the seat is clear

prior to any adjustment.

Overview

Storing

Calling up settings

107

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

 Press the button

once for each temperature level.
The maximum temperature is
reached when three LEDs are
lit.

 Press and hold

the button until the LEDs go out.

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Seat heating

Overview

Seat heating

Switching on

Switching off

Transporting children

safely

Vehicle features and
options

When children are in the
vehicle

WARNING

■

When a child is riding

Observe the following precau-

tions.Failure to do so may result

in death or serious injury.

For effective protection in automo-

bile accidents and sudden stops,

a child must be properly

restrained, using a seat belt or

child restraint system which is

correctly installed. For installation-

details, refer to the operation

manual enclosed with the child

restraint system. General installa-

tion instruction is provided in this

manual.

108

3-1. CONTROLS

Supra Owner's Manual

WARNING

Do not allow occupants to ride

with a child in their arms or on

their lap. In the case of sudden

braking or a collision, the child

may hit their head on the instru-

ment panel or windshield, or may

even be thrown from the vehicle.

The seat belts are designed to

protect persons of average adult

height and weight. A child which

is 150 cm or shorter should be sat

in an appropriately sized child

restraint system, such as a Toyota

genuine child restraint system. Do

not allow a child to be unre-

strained in the vehicle while it is

moving, as doing so is extremely

dangerous.

WARNING

■

When children are in the vehi-

cle

Never leave children unattended

in the vehicle, and never allow

children to have or use the

key.Children may be able to start

the vehicle or shift the vehicle into

neutral. There is also a danger

that children may injure them-

selves by playing with the win-

dows or other features of the

vehicle. In addition, heat build-up

or extremely cold temperatures

inside the vehicle can be fatal to

children.

●

When the vehicle is parked

under direct sunlight, the tem-

perature inside the vehicle can

increase to over 122°F, even in

winter. In this situation, occu-

pants may suffer from dehydra-

tion or heatstroke.

●

If a switch is operated acciden-

tally, it may lead to unexpected

injuries.

●

Do not allow a child to open and

close the doors. When closing a

door, be careful so that the

child’s hands and feet to not get

caught in the door.

●

Do not allow a child to put their

head or limbs out of the door

window and be sure that they

are clear of the window before

operating the power window

switch.

The right place for chil-
dren

Safety information

WARNING

Unattended children or animals

can cause the vehicle to move

and endanger themselves and

traffic, for instance due to the fol-

lowing actions:

109

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

Before using a child restraint
system on the front passenger
seat, ensure that the front, knee,
and side airbags on the front
passenger side are deacti-
vated. Automatic deactivation of
front-seat passenger airbags,
refer to page 168.

Pay attention to the specifica-
tions and the operating and
safety information of the child
restraint system manufacturer
when selecting, installing, and
using child restraint systems.

WARNING

●

Pressing the Start/Stop button.

●

Releasing the parking brake.

●

Opening and closing the doors

or windows.

●

Engaging selector lever position

N.

●

Using vehicle equipment.

There is a risk of accidents or inju-

ries. Do not leave children or ani-

mals unattended in the vehicle.

Take the remote control with you

when exiting and lock the vehicle.

The safety belt cannot be fas-

tened correctly on children shorter

than 5 ft, 150 cm without suitable

additional child restraint systems.

The efficacy of safety gear, includ-

ing safety belts, can be limited or

lost when safety belts are fas-

tened incorrectly. An incorrectly

fastened safety belt can cause

additional injuries, for instance in

the event of an accident or during

braking and evasive maneuvers.

There is a risk of injuries or dan-

ger to life. Secure children shorter

than 5 ft, 150 cm using suitable

child restraint systems.

Children on the front pas-
senger seat

General information

Safety information

WARNING

Active front-seat passenger air-

bags can injure a child in a child

restraint system when the airbags

are activated. There is a risk of

injury. Make sure that the

front-seat passenger airbags are

deactivated and that the PAS-

SENGER AIRBAG OFF indicator

light lights up.

The safety belt cannot be fas-

tened correctly on children shorter

than 5 ft, 150 cm without suitable

additional child restraint systems.

The efficacy of safety gear, includ-

ing safety belts, can be limited or

lost when safety belts are fas-

tened incorrectly. An incorrectly

fastened safety belt can cause

additional injuries, for instance in

the event of an accident or during

braking and evasive maneuvers.

There is a risk of injuries or dan-

ger to life. Secure children shorter

than 5 ft, 150 cm using suitable

child restraint systems.

Installing child restraint
systems

General information

110

3-1. CONTROLS

Supra Owner's Manual

After installing a child restraint
system in the front passenger
seat, make sure that the front,
knee and side airbags on the
front passenger side are deacti-
vated.
Deactivate the front-seat pas-
senger airbags automatically,
refer to page 168.

Before installing a child restraint
system, move the front passen-
ger seat as far back as it will go
and, if possible, bring it up to
medium height. This seat posi-
tion and height ensures the best
possible position for the belt and
offers optimal protection in the
event of an accident.
If the upper anchor of the safety
belt is located in front of the belt
guide of the child seat, move the
front passenger seat carefully

Safety information

WARNING

The protective effect of damaged

child restraint systems or of child

restraint systems exposed to an

accident and their fastening sys-

tems can be limited or lost. A child

can e.g.,not sufficiently

restrained, for instance in the

event of an accident or braking

and evasive maneuvers. There is

a risk of injuries or danger to life.

Have damaged child restraint sys-

tems or of child restraint systems

exposed to an accident and their

fastening systems checked and

possibly replaced by your Toyota

dealer.

WARNING

The stability of the child restraint

system is limited or compromised

with incorrect seat adjustment or

improper installation of the child

seat. There is a risk of injuries or

danger to life. Make sure that the

child restraint system fits securely

against the backrest. If possible,

adjust the backrest tilt for all

affected backrests and correctly

adjust the seats. Make sure that

seats and backrests are securely

engaged or locked.

On the front passenger
seat

Deactivating airbags

WARNING

Active front-seat passenger air-

bags can injure a child in a child

restraint system when the airbags

are activated. There is a risk of

injury. Make sure that the

front-seat passenger airbags are

deactivated and that the PAS-

SENGER AIRBAG OFF indicator

light lights up.

Seat position and height

111

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

forward until the best possible
belt guide position is reached.

Adjustable backrest width:
before installing a child restraint
system in the front passenger
seat, open the backrest width
completely. Do not change the
backrest width again and do not
call up a memory position.

The safety belt on the passen-
ger's side can be locked to fas-
ten child restraint systems.

1

Pull out the belt strap com-
pletely.

2

Secure the child restraint
system with the safety belt.

3

Allow the belt strap to be
pulled in and pull it tight
against the child restraint
system. The safety belt is
locked.

1

Unbuckle the safety belt
buckle.

2

Remove the child restraint
system.

3

Allow the belt strap to be
pulled in completely.

Backrest width

Child seat security

Locking the safety belt

Unlocking the safety belt

Child restraint systems
with tether strap

Safety information

WARNING

If the upper retaining strap is

incorrectly used for the child

restraint system, the protective

effect can be reduced. There is a

risk of injury. Make sure that the

upper retaining strap is not guided

across sharp edges and without

twisting to the upper retaining

strap.

NOTICE

The anchors for the upper retain-

ing straps of child restraint sys-

tems are only provided for these

retaining straps. When other

objects are mounted, the anchors

can be damaged. There is a risk

of damage to property. Only

mount child restraint systems to

the upper retaining straps.

112

3-1. CONTROLS

Supra Owner's Manual

1

Direction of travel

2

Head restraint

3

Hook for the upper retaining
strap

4

Mounting point/eyelet

5

Vehicle floor

6

Seat

7

Upper retaining strap

1

Open the anchor cover.

2

Guide the upper retaining
strap over the head restraint
to the anchor.

3

Attach the hook of the retain-
ing strap to the anchor.

4

Tighten the retaining strap.

Anchors

Symbol

Meaning

The respective sym-
bol shows the anchor
for the upper retaining
strap. Seats with an
upper top tether are
marked with this sym-
bol. It can be found on
the rear seat backrest
or the rear window
shelf.

Routing the retaining strap

Attaching the upper retain-
ing strap to the anchor

113

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The drive-ready state is
switched on when you depress
the brake pedal while pressing
the Start/Stop button.
Pressing the Start/Stop button
again switches drive-ready state
back off and standby state, refer
to page 42, is switched back on.

The Auto Start/Stop function
helps save fuel. The system
switches off the engine during a
stop, for instance in traffic con-
gestion or at traffic lights.
Drive-ready state remains
switched on. The engine starts
automatically for driving off.

After each engine start using the
Start/Stop button, the Auto
Start/Stop function is ready. The
function is activated from
speeds of approx. 3 mph/5
km/h.
Depending on the selected driv-
ing mode, refer to page 128, the
system is automatically acti-
vated or deactivated.

The engine is switched off auto-
matically during a stop under the
following conditions:



The selector lever is in selec-
tor lever position D.



The brake pedal remains
pressed while the vehicle is
stationary.

Driving

Vehicle features and
options

Start/Stop button

Concept

Pressing the Start/Stop
button switches
drive-ready state on or
off, refer to page 42.

Auto Start/Stop function

Concept

General information

Engine stop

Functional requirements

114

3-1. CONTROLS

Supra Owner's Manual



The driver's safety belt is
buckled or the driver's door is
closed.

If the engine was not switched
off automatically when the vehi-
cle stopped, the engine can be
switched off manually:



Press the brake pedal force-
fully again from the current
pedal position.



Engage selector lever posi-
tion P.

If all functional preconditions are
fulfilled, the engine switches off.

The air flow from the air condi-
tioner is reduced when the
engine is switched off.

■

General information

The engine is not switched off
automatically in the following sit-
uations:



In case of a steep downhill
grade.



Brake not engaged strongly
enough.



The external temperature is
high and automatic climate
control is running.



The car's interior has not yet
been heated or cooled to the
required level.



Where there is a risk of win-
dow condensation when the
automatic climate control is
switched on.



Engine or other parts not at
operating temperature.



Engine cooling is required.



The wheels are at a sharp
angle or the steering wheel is
being turned.



Vehicle battery is heavily dis-
charged.



At higher elevations.



The hood is unlocked.



The parking assistant is acti-
vated.



Stop-and-go traffic.



Selector lever position in N or
R.



After driving in reverse.

Manual engine stop

Air conditioner when the
engine is switched off

Displays in the instrument
cluster

The display in the
tachometer indicates
that the Auto Start/Stop
function is ready for an
Automatic engine start.
The display indicates
that the conditions for
an automatic engine
stop have not been
met.

Functional limitations

115

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS



Use of fuel with high ethanol
content.

The engine starts automatically
under the following precondi-
tions:



By releasing the brake pedal.

After the engine starts, acceler-
ate as usual.

After the engine switches off
automatically, it will not start
again automatically if any one of
the following conditions are met:



The driver's safety belt is
unbuckled and the driver's
door is open.



The hood was unlocked.

Some indicator lights light up for
a varied length of time.
The engine can only be started
via the Start/Stop button.

Even if driving off was not
intended, the deactivated
engine starts up automatically in
the following situations:



Excessive warming of the

car's interior when the air con-
ditioning is switched on.



Excessive cooling of the car's
interior when the heating is
switched on.



Where there is a risk of win-
dow condensation when the
automatic climate control is
switched on.



The steering wheel is turned.



Change from selector lever
position D to N or R.



Change from selector lever
position P to N, D, or R.



Vehicle battery is heavily dis-
charged.



Start of an oil level measure-
ment.

The engine is not automatically
switched off.
The engine is started during an
automatic engine stop.

Starting the engine

Functional requirements

Driving off

Safety mode

System limits

Activating/deactivating the
system manually

Concept

116

3-1. CONTROLS

Supra Owner's Manual

 Press the button.

The Auto Start/Stop function is
also deactivated in selector
lever position M.

The Auto Start/Stop function is
also deactivated in SPORT driv-
ing mode of the Sport mode
switch.

■

General information

During an automatic engine
stop, the vehicle can be
switched off permanently, for
instance when leaving it.

1

Press the Start/Stop button.



Drive-ready state is switched
off.



Standby state is switched on.



Selector lever position P is
engaged automatically.

2

Set the parking brake.

In certain situations, the Auto
Start/Stop function is deacti-
vated automatically for safety
reasons, for instance if no driver
is detected.

The Auto Start/Stop function no
longer switches off the engine
automatically. A vehicle mes-
sage is displayed. It is possible
to continue driving. Have the
system checked by your Toyota
dealer.

The parking brake is used to
prevent the vehicle from rolling
when it is parked.

Using the button

Via selector lever position

Via the Sport mode switch

Switching off the vehicle
during an automatic engine
stop

Automatic deactivation

General information

Malfunction

Parking brake

Concept

117

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

■

General information

To use as emergency brake
while driving.
Pull the switch and hold it. The
vehicle brakes hard while the
switch is being pulled.
A vehicle message is displayed.
The parking brake is engaged

Safety information

WARNING

An unsecured vehicle can begin

to move and possibly roll away.

There is a risk of an accident.

Before exiting, secure the vehicle

against rolling.
In order to ensure that the vehicle

is secured against rolling away,

follow the following:

●

Set the parking brake.

●

On uphill grades or on a down-

hill slope, turn the front wheels

in the direction of the curb.

●

On uphill grades or on a down-

hill slope, also secure the vehi-

cle, for instance with a wheel

chock.

WARNING

Unattended children or animals

can cause the vehicle to move

and endanger themselves and

traffic, for instance due to the fol-

lowing actions:

●

Pressing the Start/Stop button.

●

Releasing the parking brake.

●

Opening and closing the doors

or windows.

●

Engaging selector lever position

N.

●

Using vehicle equipment.

There is a risk of accidents or inju-

ries. Do not leave children or ani-

mals unattended in the vehicle.

Take the remote control with you

when exiting and lock the vehicle.

Overview

Parking brake

Setting

With a stationary vehicle

Pull the switch.
The LED lights up.
The indicator light in the
instrument cluster illumi-
nates red. The parking
brake is set.

While driving

The indicator light in the
instrument cluster illumi-
nates red, a signal
sounds, and the brake
lights illuminate.

118

3-1. CONTROLS

Supra Owner's Manual

when the vehicle is stationary.

1

Switch on drive-ready state.

2

 Press the switch while

the brake is pressed or selec-
tor lever position P is set.

The LED and indicator light go out.
The parking brake is released.

The parking brake is released
automatically when you drive
away.
The LED and indicator light go
out.

In the event of a failure or mal-
function of the parking brake:
Secure the vehicle against roll-
ing away, for instance with a
wheel chock, after existing the
vehicle.

To reestablish parking brake
functionality after a power fail-
ure:

1

Switch on standby state.

2

 Pull the switch while

stepping on the brake pedal

or selector lever position P is
set and then push.

This process may take a few
seconds. Any sounds associ-
ated with this are normal.

When driving and during opera-
tion of the turn signals or hazard
warning system, do not fold in
the exterior mirrors, so that the
signal lights on the exterior mir-
ror are easy to see.

Press the lever past the resis-
tance point.

Releasing

Releasing manually

Automatic release

Malfunction

After a power failure

The indicator light is no
longer illuminated as
soon as the parking
brake is ready for oper-
ation again.

Turn signal

Turn signal in exterior mir-
ror

Using turn signals

119

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

Lightly tap the lever up or down.
The triple turn signal duration
can be adjusted.
Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Exterior lighting"

4

"One-touch turn signal"

5

Select the desired setting.

The setting is stored for the
driver profile currently used.

Press the lever to the resistance
point and hold it there for as
long as you want the turn signal
to flash.

Push the lever forward or pull it
backward.

1

High beams on, arrow

1

.

The high beams light up when the

low beams are switched on.

2

High beams off/headlight
flasher, arrow

2

.

Do not use the wipers if the
windshield is dry, as this may
damage the wiper blades or
cause them to become worn
more quickly.

Triple turn signal activa-
tion

Signaling briefly

High beams, headlight
flasher

Washer/wiper system

General information

Safety information

WARNING

If the wipers start moving in the

folded away state, body parts can

be jammed or damage may occur

to parts of the vehicle. There is a

risk of injury or risk of damage to

property. Make sure that the vehi-

cle is switched off when the wip-

ers are in the folded away state

and the wipers are folded in when

switching on.

NOTICE

If the wipers are frozen to the

windshield, the wiper blades can

be torn off and the wiper motor

can overheat when switching on.

There is a risk of damage to prop-

erty. Defrost the windshield prior

to switching the wipers on.

120

3-1. CONTROLS

Supra Owner's Manual

Press the lever up until the
desired position is reached.



Resting position of the wipers,
position

0

.



Rain sensor, position

1

.



Normal wiper speed, position

2

.



Fast wiper speed, position

3

.

When travel is interrupted with
the wiper system switched on:
when travel continues, the wip-
ers resume at their previous
speed.

Press the lever down.



Switching off: press the lever
down until it reaches its stan-

dard position.



Brief wipe: press the lever
down from the standard posi-
tion.

The lever automatically returns to
its initial position when released.

The rain sensor automatically
controls the time between wipes
depending on the intensity of the
rainfall.

The sensor is located on the
windshield, directly in front of
the interior mirror.

Switching on

Switching off and brief
wipe

Rain sensor

Concept

General information

Safety information

NOTICE

If the rain sensor is activated, the

wipers can accidentally start mov-

ing in vehicle washes. There is a

risk of damage to property. Deac-

tivate the rain sensor in vehicle

washes.

121

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

Press the lever up once from its
standard position, arrow

1

.

Wiping is started.
The LED in the wiper lever is
illuminated.
If wipers are frozen to wind-
shield, wiper operation is deacti-
vated.

Press the lever back into the
standard position.

Turn the thumbwheel to adjust
the sensitivity of the rain sensor.
Upward: high rain sensor sensi-

tivity.
Downward: low rains sensor
sensitivity.

Pull the lever.
The system sprays washer fluid
on the windshield and activates
the wipers briefly.

Activating

Deactivating

Adjusting the rain sensor
sensitivity

Windshield washer system

Safety information

WARNING

The washer fluid can freeze onto

the window at low temperatures

and obstruct the view. There is a

risk of an accident. Only use the

washer systems, if the washer

fluid cannot freeze. Use washer

fluid with antifreeze, if needed.

NOTICE

When the washer fluid reservoir is

empty, the wash pump cannot

work as intended. There is a risk

of damage to property. Do not use

the washer system when the

washer fluid reservoir is empty.

Cleaning the windshield

122

3-1. CONTROLS

Supra Owner's Manual

The windshield washer nozzles
are automatically heated while
standby state is switched on.

The fold-out position enables
the wipers to be folded away
from the windshield.

Important, for instance when
changing the wiper blades or
when folding out under frosty
conditions.

1

Switch on standby state.

2

Press and hold the wiper
level down, until the wipers
stop in a close to vertical
position.

3

Fold the wipers all the way
away from the windshield.

After the wipers are folded back
down, the wiper system must be
reactivated.

Windshield washer nozzles

Fold-away position of the
wipers

Concept

General information

Safety information

WARNING

If the wipers start moving in the

folded away state, body parts can

be jammed or damage may occur

to parts of the vehicle. There is a

risk of injury or risk of damage to

property. Make sure that the vehi-

cle is switched off when the wip-

ers are in the folded away state

and the wipers are folded in when

switching on.

NOTICE

If the wipers are frozen to the

windshield, the wiper blades can

be torn off and the wiper motor

can overheat when switching on.

There is a risk of damage to prop-

erty. Defrost the windshield prior

to switching the wipers on.

Folding away the wipers

Folding down the wipers

123

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

1

Fold the wipers back down
onto the windshield.

2

Switch on standby state and
press and hold the wiper
lever down again.

3

Wipers return to their resting
position and are ready again
for operation.

The Automatic transmission
combines the functions of man-
ual shifting, if needed.

Selector lever position for nor-
mal vehicle operation. All gears
for forward travel are activated
automatically.

Engage selector lever position R
only when the vehicle is station-

ary.

The vehicle may be pushed or
roll without power, for instance
in vehicle washes, refer to page
125, in selector lever position N.

Selector lever position, for
instance for parking the vehicle.
The transmission blocks the
drive wheels in selector lever
position P.
Engage selector lever position P
only when the vehicle is station-
ary.

■

P is engaged automatically

Selector lever position P is
engaged automatically in situa-
tions such as the following:



After the drive-ready state is
switched off and selector
lever position R, D or M is
engaged.



After the standby state has
been switched off when selec-
tor lever position N is
engaged.



If the driver's safety belt is
unbuckled, the driver's door is
opened, and the brake pedal
is not pressed while the vehi-
cle is stationary and selector
lever position D, M or R is
engaged.

Automatic transmission

Concept

Safety information

WARNING

An unsecured vehicle can begin

to move and possibly roll away.

There is a risk of an accident.

Before exiting, secure the vehicle

against rolling, for instance with

the parking brake.

Selector lever positions

Drive mode D

Reverse R

Neutral N

Parking position P

124

3-1. CONTROLS

Supra Owner's Manual

To prevent the vehicle from
creeping after you select a drive
mode, maintain pressure on the
brake pedal until you are ready
to start.

Only when the drive-ready state
is switched on and the brake
pedal is depressed is it possible
to change from selector lever
position P to another selector
lever position.
The selection lever position P
cannot be changed until all tech-
nical requirements are met.

A selector lever lock prevents
the following faulty operation:



Unintentional shifting into
selector lever position R.



Unintentional shifting from
selector lever position P into
another selector lever posi-
tion.

1

Fasten driver's safety belt.

2

Press and hold the button to
release the selector lever
lock.

3

Push the selector lever in the
desired direction, past a
resistance point, if needed.
The selector lever automati-
cally returns to the center
position when released.

Press button P.

Engaging selector lever
positions

General information

Functional requirements

Engaging selector lever
position D, N, R

Engaging selector lever
position P

125

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

In some situations, the vehicle is
to roll without its own power for
a short distance, for instance in
a vehicle wash, or be pushed.

1

Switch on drive-ready state
while pressing on the brake
pedal.

2

If necessary, release the
parking brake.

3

Depress the brake pedal.

4

Touch the selector lever lock
and engage selector lever
position N.

5

Switch off drive-ready state.

In this way, standby state remains

switched on, and a vehicle mes-

sage is displayed.
The vehicle may roll.

Irrespective of standby state, the
selector lever position P is auto-
matically engaged after approx.
35 minutes.
If there is a malfunction, you

may not be able to change the
selector lever position.
Electronically unlock the trans-
mission lock, if needed, refer to
page 127.

Kickdown is used to achieve
maximum driving performance.
Step on the accelerator pedal
beyond the resistance point at
the full throttle position.

Manual gear-shifting is possible
in manual mode.

Press the selector lever to the
left out of selector lever position
D.
The engaged gear is displayed
in the instrument cluster, for
instance 1M.

Rolling or pushing the
vehicle

General information

Engaging selector lever
position N

NOTICE

Selector lever position P is auto-

matically engaged when standby

state is switched off. There is a

risk of damage to property. Do not

switch standby state off in vehicle

washes.

Kickdown

Manual mode

Concept

Activating manual mode

126

3-1. CONTROLS

Supra Owner's Manual



To shift down: press the
selector lever forward.



To shift up: pull the selector
lever rearwards.

Push the selector lever to the
right.
D is displayed in the instrument
cluster.

The shift paddles on the steer-
ing wheel allow you to shift
gears quickly while keeping both
hands on the steering wheel.

■

Shifting

The vehicle only shifts at suit-
able engine and road speeds.

■

Short-term manual mode

In selector lever position D,
actuating a shift paddle switches
into manual mode temporarily.
After conservative driving in
manual mode without accelera-
tion or shifting via the shift pad-
dles for a certain amount of
time, the transmission switches
back to automatic mode.

It is possible to switch into auto-
matic mode as follows:



Pull and hold right shift pad-
dle.



In addition to the briefly pulled
right shift paddle, briefly pull
the left shift paddle.

■

Continuous manual mode

In selector lever position M,
actuating a shift paddle switches
into manual mode permanently.



To shift up: briefly pull right
shift paddle.



To shift down: briefly pull left
shift paddle.



The lowest possible gear can
be selected by pulling and
holding the left shift paddle.

The selected gear is briefly dis-
played in the instrument cluster,
followed by the current gear.

Shifting

Ending the manual mode

Shift paddles

Concept

General information

Shifting

127

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

Electronically unlock the trans-
mission lock to maneuver vehi-
cle from a danger area.
Unlocking is possible, if the
starter can spin the engine.
Before unlocking the transmis-
sion lock, set the parking brake
to prevent the vehicle from roll-
ing away.

1

Press and hold down brake
pedal.

2

Press the Start/Stop button.
The starter must audibly
start. Hold the Start/Stop but-
ton pressed.

3

With your free hand, press
the button on the selector
lever, arrow

1

, and press the

selector lever into selector
lever position N and hold,
arrow N, until selector lever

position N is displayed in the
instrument cluster.

A vehicle message is displayed.

4

Release Start/Stop button
and selector lever.

5

Release brake, as soon as
the starter stops.

6

Maneuver the vehicle from
the danger area and secure it
against moving on its own.

For additional information, see
the chapter on tow-starting and
towing, refer to page 311.

Launch Control enables opti-
mum acceleration on surfaces
with good traction under dry sur-
rounding conditions.

The use of Launch Control
causes premature component
wear since this function rep-
resents a very heavy load for
the vehicle.

Displays in the instrument
cluster

The selector lever posi-
tion is displayed, for
example P.

Electronic unlocking of
the transmission lock

General information

Engaging selector lever
position N

Launch Control

Concept

General information

1

R

N

128

3-1. CONTROLS

Supra Owner's Manual

Do not use Launch Control
during the break-in, refer to
page 246, period.
Do not steer the steering wheel
when driving off with Launch
Control.

Launch Control is available
when the engine is at operating
temperature. The engine is at
operating temperature after an
uninterrupted trip of at least 6
miles/10 km.

1

Switch on drive-ready state.

2

Press the sport button.

SPORT will be displayed on the

instrument cluster, indicating sport

mode has been selected.

3

 Press the button.

TRACTION will be displayed on the

instrument cluster and the VSC

OFF indicator lamp will illuminate.

4

Select the D selector lever
position.

5

Firmly depress the brake
pedal with your left foot.

6

Fully depress and hold the
accelerator pedal at the kick-
down position.

A flag symbol will be shown in the

instrument cluster.

7

The engine speed will be
adjusted for launching.

Release the brake pedal
within 3 seconds.

After Launch Control has been
used, the transmission must
cool down for approx. 5 minutes
before Launch Control can be
used again. Launch Control
adjusts to the surrounding con-
ditions, when used again.

To increase vehicle stability,
activate VSC Vehicle Stability
Control System again as soon
as possible.

An experienced driver may be
able to achieve better accelera-
tion values in VSC OFF mode.

The Sport mode button influ-
ences the driving dynamics
properties of the vehicle.

The following systems are
affected, for instance:



Engine characteristics.



Automatic transmission.

Functional requirements

Start with launch control

Repeated use during a trip

After using Launch Control

System limits

Sport mode button

Concept

General information

129

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS



Adaptive variable suspension.



Steering.



Display in the instrument clus-
ter.



Cruise control.

When drive-ready state is
switched on, the NORMAL driv-
ing mode is selected automati-

cally.

■

Concept

Balanced tuning between
dynamic and efficient driving.

■

Concept

Dynamic tuning for higher agility
with an optimized chassis and
suspension.

■

Switching on

■

Concept

Customize settings can be
adjusted in the customize driv-
ing mode.

■

Configuration

Via Toyota Supra Command:

1

"My Vehicle"

2

"Vehicle settings"

3

"Configure SPORT INDIVID-
UAL"

4

Select the desired setting.

The setting is stored for the
driver profile currently used.
Reset Customize to the stan-

Overview

Displays in the instrument
cluster

The selected driving
mode is displayed in
the instrument cluster.

Driving modes

Button in the vehicle

Button

Driving

mode

Configu-

ration

SPORT

SPORT

Custom-

ize

Driving modes in detail

NORMAL

SPORT

Press the button.

Customize

130

3-1. CONTROLS

Supra Owner's Manual

dard settings:
"Reset to SPORT STANDARD".

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The instrument cluster is a vari-
able display. When the sport
mode switch is used to change
the driving mode, the instrument
cluster displays change to
match the driving mode.

The display change in the instru-
ment cluster can be deactivated
via Toyota Supra Command.
Some of the displays in the
instrument cluster may differ
from the illustrations in this
Owner's Manual.

Displays

Vehicle features and
options

Instrument cluster

Concept

General information

131

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

1

Fuel gauge P.136

2

Speedometer

3

Tachometer P.137
Status, Sport mode switch
P.128

4

Time P.61

5

Variable displays P.131

6

External temperature P.138

7

Engine coolant temperature
P.138

8

Vehicle messages P.131
Range P.138

9

Transmission display P.123

10

Variable displays P.131

Speed Limit Info P.140

In some areas of the instrument
cluster, various assistance sys-
tems, for example the cruise
control, can be displayed. The
displays may vary depending on
the equipment version and
country variant.

The display can be changed for
sport mode.

The driving mode will change to
sport mode.

The vehicle messages system
monitors functions in the vehicle
and notifies you of malfunctions
in the monitored systems.

A vehicle messages message is
displayed as a combination of
indicator or warning lights and
SMS text messages in the
instrument cluster and, if appli-
cable, in the Head-up Display.
In addition, an acoustic signal
may sound and an SMS text
message may appear on the
Control Display.

Overview

Variable displays

Sport mode display

Concept

Changing the display

Push the sport mode
switch until SPORT is
displayed.

Vehicle messages

Concept

General information

132

3-1. CONTROLS

Supra Owner's Manual

Press and hold the button on the
turn signal lever.

Some vehicle messages are
displayed continuously and are
not cleared until the malfunction
is eliminated. If several malfunc-
tions occur at once, the mes-
sages are displayed
consecutively.
The messages can be hidden
for approx. 8 seconds. After this
time, they are displayed again
automatically.

Some vehicle messages are
hidden automatically after
approx. 20 seconds. The vehicle
messages are stored and can
be displayed again later.

Via Toyota Supra Command:

1

"My vehicle"

2

"Vehicle status"

3

"vehicle messages"

4

Select the SMS text mes-
sage.

SMS text messages in combina-
tion with a symbol in the instru-
ment cluster explain a vehicle
message and the meaning of
the indicator/warning lights.

Additional information, such as
the reason for an error or mal-
function or the required action,
can be called up via vehicle
messages.
With urgent messages the
added text will be automatically
displayed on the Control Dis-
play.
Depending on the vehicle mes-
sage, further help can be
selected.
Via Toyota Supra Command:

1

"My vehicle"

Hiding vehicle messages

Continuous display

Temporary display

Displaying stored vehicle
messages

Display

Vehicle messages

At least one vehicle
messages message is
displayed or is stored.

SMS text messages

Supplementary SMS text
messages

133

3-1. CONTROLS

Supra Owner's Manual

3

CON

T

ROLS

2

"Vehicle status"

3

"Vehicle messages"

4

Select the desired text mes-
sage.

5

Select desired setting

Special messages displayed
while driving are displayed
again after drive-ready state is
switched off.

Indicator/warning lights in the
instrument cluster display the
status of some functions in the
vehicle and indicate when a
malfunction is present in the
monitored systems.

The indicator/warning lights can
light up in a variety of combina-
tions and colors.
Several of the lights are
checked for proper functioning
and light up temporarily when
drive-ready state is switched on.

Messages after trip comple-
tion

Indicator/warning lights

Concept

General information

Red lights

Safety belt reminder

Indicator light flashes or
is illuminated: safety
belt on the driver or
passenger side is not
buckled. The safety belt
reminder can also be
activated if objects are
placed on the front pas-
senger seat.
Make sure that the
safety belts are posi-
tioned correctly.

Airbag system

Airbag system and belt
tensioner are not work-
ing.
Have the vehicle
checked immediately
by your Toyota dealer.

Parking brake

The parking brake is
set.
Release the parking
brake, refer to page
118.
