Toyota Prius (2020 year). Manual in english - part 7

400

PRIUS_OM_OM47D44U_(U)

4-5. Using the driving support systems

■

When the operation is canceled

The  S-APGS  switch  is  operated  in  an  area  where
there are obstacles to the front, and the vehicle can-
not  move  forward  to  the  starting  point  for  backing
up.



Assist  control  cannot  be  used,  as  there  are
obstacles in front of the vehicle. Use parking
spaces  that  have  no  obstacles  in  front  of
them.

Message

Situation/Handling method

Message

Situation/Handling method

While assist control is operating, the driver changes
the  shift  position  to  P  or  operates  the  S-APGS
switch.

The vehicle speed exceeds 19 mph (30 km/h) when
searching for a parallel parking assist mode space.

Assist control is started in an area with narrow park-
ing spaces.

The  shift  position  is  changed  without  having  used
the turn signal lever to select a departure direction
when using the exit parallel parking assist mode.



Follow the guidance provided by the system.

When assist control starts, the vehicle proceeds in a
direction opposite to the guidance.



Follow  the  guidance  provided  by  the  system
to proceed forward.

PRIUS_OM_OM47D44U_(U)

401

4-5. Using the driving support systems

4

Drivin

g

■

When the operation is canceled

The maximum number of movements for multi-turn
maneuvering is reached during assist control, or the
target  parking  spot  cannot  be  reached  due  to  the
control being used on a road with steep grade.



Follow  the  assist  control  guidance  and  use
the system in a wide space that does not have
a steep grade.

Message

Situation/Handling method

Message

Situation/Handling method

The  driver  holds  the
steering wheel during
assist control.



Stop  the  vehicle  and
rest  your  hands  on  the
steering  wheel  without
applying

any

force.

Then press the S-APGS
switch  to  restart  assist
control.

The  vehicle  speed
exceeds

4

mph

(7 km/h) during assist
control.

The  S-APGS  switch
is

pressed

while

assist  control  is  tem-
porarily  stopped  and
the  steering  wheel  is
firmly held.



Rest your hands on the
steering  wheel  without
applying

any

force.

Then stop the vehicle to
restart assist control.

The  S-APGS  switch
is

pressed

while

assist  control  is  tem-
porarily  stopped  and
the vehicle is moving.

Assist control  is  tem-
porarily

stopped

(able to be restarted)



Stop  the  vehicle  and
rest  your  hands  on  the
steering  wheel  without
applying

any

force.

Then press the S-APGS
switch  to  restart  assist
control.

402

PRIUS_OM_OM47D44U_(U)

4-5. Using the driving support systems

The  vehicle  moved
too close to an obsta-
cle  in  front  of  the
vehicle.



Press

the

S-APGS

switch  after  changing
the shift position to R to
restart assist control.

The  vehicle  moved
too close to an obsta-
cle  to  the  rear  of  the
vehicle.



Press

the

S-APGS

switch  after  changing
the shift position to D to
restart assist control.

Message

Situation/Handling method

PRIUS_OM_OM47D44U_(U)

403

4-5. Using the driving support systems

4

Drivin

g

■

Sensors

Detect the vehicle to help determine the parking spot.

Front side sensors
Rear side sensors

Precautions during use

1

2

●

The sensor detection range when using
back-in parking assist mode

Intended parking spot

●

The sensor detection range when using
parallel parking assist mode

Intended parking spot

1

1

404

PRIUS_OM_OM47D44U_(U)

4-5. Using the driving support systems

●

When there is a parked vehicle behind the target parking spot, it may not be
detected due to the distance. Also, depending on the shape of the vehicle
and  other  conditions,  the  detectable  range  may  shorten  or  detection  may
not be possible.

●

The Simple Advanced Parking Guidance System may not operate if grating,
diamond plates or similar materials are detected on the surface of the park-
ing space.

●

Objects other than parked vehicles, such
as poles and walls, may not be detected.
Also,  even  if  these  objects  can  be
detected,  the  target  parking  spot  may
deviate.

Poles
Wall

●

Also,  the  target  parking  spot  may  devi-
ate when a pedestrian, etc. is detected.

Pedestrian

1

2

1

PRIUS_OM_OM47D44U_(U)

405

4-5. Using the driving support systems

4

D

riv

in

g

WARNING

●

Do not rely solely upon the Simple Advanced Parking Guidance System.
As  with  unequipped  vehicles,  move  forward  and  back  up  carefully  while
directly confirming the safety of your surroundings and the area to the rear
of the vehicle.

●

Do  not  back  up  while  viewing  the  multi-information  display.  Backing  up
while only viewing the monitor screen may cause a collision or lead to an
accident,  as  the  image  displayed  on  the  monitor  screen  may  differ  from
actual conditions. Make sure to visually check the surrounding areas and
the area to the rear of the vehicle with and without the mirror while backing
up.

●

Drive  slowly  while  adjusting  your  speed  by  depressing  the  brake  pedal
when backing up or moving forward.

●

If it seems the vehicle may make contact with a pedestrian, another vehi-
cle or any other obstacles, stop the vehicle by depressing the brake pedal,
and then press the S-APGS switch to turn off the system.

●

Use the system in a parking lot with a flat surface.

●

Observe  the  following  precautions,  as  the  steering  wheel  automatically
turns during use.
• There  is  risk  of  a  necktie,  scarf,  your  arm,  etc.  being  caught  on  the

steering wheel. Please do not allow your upper body to be close to the
steering wheel. Also, do not allow children close to the steering wheel.

• There is a possibility of injury when the steering wheel turns if you have

long fingernails.

• In  case  of  an  emergency,  stop  the  vehicle  by  depressing  the  brake

pedal, and then press the S-APGS switch to turn off the system.

●

Always confirm that there is appropriate space before attempting to park
the vehicle and operate the system.

406

PRIUS_OM_OM47D44U_(U)

4-5. Using the driving support systems

WARNING

●

Do not use the system in the following situations, as the system may be
unable to correctly assist you in reaching the target parking spot and may
lead to an unexpected accident.
• In an area that is not a parking lot
• A parking lot that is not paved and has no parking space lines, such as

a sand or gravel parking lot

• A parking lot that has a slope or undulations in the road
• A frozen, snow-covered or slippery road
• The asphalt is melting due to hot weather
• There is an obstacle between the vehicle and the target parking spot
• Using tire chains or compact spare tire (if equipped)

●

Do not use tire other than that provided by the manufacturer. The system
may  not  operate  properly.  When  replacing  tires,  contact  your  Toyota
dealer.

●

The system may not be able position the vehicle in the set location in the
following situations.
• The tires are extremely worn or the tire pressure is low
• The vehicle is carrying very heavy load
• The vehicle is tilted due to having luggage, etc. located on one side of

the vehicle

• There are road heaters installed in the parking lot to prevent the road

surface from freezing.

In any other situations when the set position and vehicle position greatly
differ, have the vehicle inspected by your Toyota dealer.

●

Make sure to observe the following precautions regarding the exit parallel
parking assist mode.
Exit parallel parking assist mode is a function used when departing from a
parallel parking spot. However, this function may not be usable if obsta-
cles or people are detected in front of the vehicle. Only use this function
when departing from a parallel parking spot. In the event that the steering
control operates, either turn the system off using the S-APGS switch or
operate the steering wheel to stop the control.

●

If exit parallel parking assist mode is mistakenly used in the following situ-
ations, the vehicle may make contact with an obstacle.
The  departure  function  is  operated  in  a  direction  where  an  obstacle  is
present, but the obstacle is not detected by the side sensors (situations
such as when the vehicle is directly beside a pole).

PRIUS_OM_OM47D44U_(U)

407

4-5. Using the driving support systems

4

D

riv

in

g

WARNING

●

Observe  the  following  precautions,  as  the  sensors  may  stop  functioning
properly which may lead to an accident.
• Do not subject the sensor to strong shocks by hitting it, etc. The sen-

sors may not function properly.

• When using a high-pressure washer to wash the vehicle, do not spray

water  directly  on  the  sensors.  Equipment  may  not  function  properly  if
subjected  to  an  impact  from  strong  water  pressure.  If  the  vehicle
bumper strikes something, equipment may not operate properly due to
a sensor malfunction. Have the vehicle inspected at your Toyota dealer.

●

In the following situations, the sensors may not operate normally and may
lead to an accident. Drive carefully.
• Obstacles cannot be detected in the side areas until a scan of the side

areas is completed. (



P. 356)

• Even after the scan of the side areas is completed, obstacles such as

other vehicles, people or animals that approach from the sides cannot
be detected.

• The sensor is frozen (if it thaws, the system returns to normal).

A warning message may display at particularly low temperatures due to
the sensor freezing and it may not detect parked vehicles.

• The sensor is blocked by someone’s hand.
• The vehicle is tilted a large amount.
• The temperature is extremely hot or cold.
• The vehicle is driven on undulating roads, slopes, gravel roads, in areas

with tall grass, etc.

• An  ultrasonic  wave  source  is  nearby,  such  as  the  horn  or  sensors  of

another vehicle, a motorcycle engine or the air brake of a large vehicle.

• Heavy rain or a water strikes the vehicle.
• The  angle  of  the  sensor  may  be  deviated  when  assist  control  starts

even  if  there  is  a  parked  vehicle  in  the  target  parking  spot.  Have  the
vehicle inspected at your Toyota dealer.

• Do not install any accessories within the sensor detection range.

408

PRIUS_OM_OM47D44U_(U)

4-5. Using the driving support systems

Driving assist systems

◆

ECB (Electronically Controlled Brake System)

The electronically controlled system generates braking force corre-
sponding to the brake operation

◆

ABS (Anti-lock Brake System)

Helps to prevent wheel lock when the brakes are applied suddenly,
or if the brakes are applied while driving on a slippery road surface

◆

Brake assist

Generates an increased level of braking force after the brake pedal
is depressed when the system detects a panic stop situation

◆

VSC (Vehicle Stability Control)

Helps  the  driver  to  control  skidding  when  swerving  suddenly  or
turning on slippery road surfaces.

◆

Enhanced VSC (Enhanced Vehicle Stability Control)

Provides cooperative control of the ABS, TRAC, VSC and EPS.
Helps  to  maintain  directional  stability  when  swerving  on  slippery
road surfaces by controlling steering performance.

◆

TRAC (Traction Control)

Helps  to  maintain  drive  power  and  prevent  the  drive  wheels  from
spinning when starting the vehicle or accelerating on slippery roads

◆

Active Cornering Assist (ACA)

Helps to prevent the vehicle from drifting to the outer side by per-
forming  inner  wheel  brake  control  when  attempting  to  accelerate
while turning

To keep driving safety and performance, the following systems
operate automatically in response to various driving situations.
Be aware, however, that these systems are supplementary and
should not be relied upon too heavily when operating the vehi-
cle.

PRIUS_OM_OM47D44U_(U)

409

4-5. Using the driving support systems

4

Drivin

g

◆

Hill-start assist control

Helps to reduce the backward movement of the vehicle when start-
ing on an uphill

◆

EPS (Electric Power Steering)

Employs an electric motor to reduce the amount of effort needed to
turn the steering wheel

◆

E-Four (Electronic On-Demand AWD system) (AWD models)

Automatically  switches  from  front-wheel  drive  to  all-wheel  drive
(AWD)  according  to  the  driving  conditions,  helping  to  ensure  reli-
able handling and stability. Examples of conditions where the sys-
tem will switch to AWD are when cornering, going uphill, starting off
or accelerating, and when the road surface is slippery due to snow,
rain, etc.

The  slip  indicator  light  will  flash
while  the  TRAC/VSC/ABS  sys-
tems are operating.

When the TRAC/VSC/ABS systems are operating

410

PRIUS_OM_OM47D44U_(U)

4-5. Using the driving support systems

If the vehicle gets stuck in mud, dirt or snow, the TRAC system may

reduce power from the hybrid system to the wheels. Pressing

to turn the system off may make it easier for you to rock the vehicle in
order to free it.
To  turn  the  TRAC  system  off,
quickly

press

and

release

.

The  “Traction  Control  Turned  Off”
will be shown on the multi-informa-
tion display.

Press



again to turn the sys-

tem back on.

■

Turning off both TRAC and VSC systems

To turn the TRAC and VSC systems off, press and hold

 for more than

3 seconds while the vehicle is stopped.
The VSC OFF indicator light will come on and the “Traction Control Turned
Off” will be shown on the multi-information display.

*

Press

 again to turn the systems back on.

*

: On  vehicles  with  pre-collision  system, pre-collision  brake assist and  pre-

collision braking will also be disabled. The PCS warning light will come on
and the message will be shown on the multi-information display. (



P. 581)

■

When the message is displayed on the multi-information display show-

ing that TRAC has been disabled even if

 has not been pressed

TRAC is temporary deactivated. If the information continues to show, contact
your Toyota dealer.

■

Operating conditions of hill-start assist control

When  the  following  four  conditions  are  met,  the  hill-start  assist  control  will
operate:

●

The shift position is in a position other than P or N (when starting off forward/
backward on an upward incline)

●

The vehicle is stopped

●

The accelerator pedal is not depressed

●

The parking brake is not engaged

Disabling the TRAC system

PRIUS_OM_OM47D44U_(U)

411

4-5. Using the driving support systems

4

Drivin

g

■

Automatic system cancelation of hill-start assist control

The hill-start assist control will turn off in any of the following situations:

●

Shift the shift position to P or N

●

The accelerator pedal is depressed

●

The parking brake is engaged

●

No more than 2 seconds have elapsed after the brake pedal is released.

■

Sounds and vibrations caused by the ABS, brake assist, VSC, TRAC and
hill-start assist control systems

●

A sound may be heard from the engine compartment when the brake pedal
is depressed repeatedly, when the hybrid system is started or just after the
vehicle begins to move. This sound does not indicate that a malfunction has
occurred in any of these systems.

●

Any  of  the  following  conditions  may  occur  when  the  above  systems  are
operating. None of these indicates that a malfunction has occurred.
• Vibrations may be felt through the vehicle body and steering.
• A motor sound may be heard also after the vehicle comes to a stop.

■

ECB operating sound

ECB  operating  sound  may  be  heard  in  the  following  cases,  but  it  does  not
indicate that a malfunction has occurred.

●

Operating sound heard from the engine compartment when the brake pedal
is operated.

●

Motor  sound  of  the  brake  system  heard  from  the  front  part  of  the  vehicle
when the driver’s door is opened.

●

Operating sound heard from the engine compartment when one or two min-
utes passed after the stop of the hybrid system.

■

Active Cornering Assist operation sounds and vibrations

When  the Active Cornering Assist  is operated,  operation  sounds  and  vibra-
tions may be generated from the brake system, but this is not a malfunction.

■

EPS operation sound

When the steering wheel is operated, a motor sound (whirring sound) may be
heard. This does not indicate a malfunction.

■

Automatic reactivation of TRAC and VSC systems

After turning the TRAC and VSC systems off, the systems will be automati-
cally re-enabled in the following situations:

●

When the power switch is turned off

●

If only the TRAC system is turned off, the TRAC will turn on when vehicle
speed increases
If both the TRAC and VSC systems are turned off, automatic re-enabling
will not occur when vehicle speed increases.

412

PRIUS_OM_OM47D44U_(U)

4-5. Using the driving support systems

■

Operating conditions of Active Cornering Assist

The system operates when the following occurs.

●

TRAC/VSC can operate

●

The driver is attempting to accelerate while turning

●

The system detects that the vehicle is drifting to the outer side

●

The brake pedal is released

■

Reduced effectiveness of the EPS system

The effectiveness of the EPS system is reduced to prevent the system from
overheating when there is frequent steering input over an extended period of
time. The steering wheel may feel heavy as a result. Should this occur, refrain
from excessive steering input or stop the vehicle and turn the hybrid system
off. The EPS system should return to normal within 10 minutes.

■

Electric power steering system warning light (warning buzzer)



P. 581

■

When a message related to AWD system is displayed on the multi-infor-
mation display (AWD models)

Perform the following actions.

Message

Details

Actions

“AWD System Overheated

Switching to 2WD Mode”

AWD system is over-
heating.

Stop  the  vehicle  for  a
certain  amount  of  time
or  drive  the  vehicle  at
approximately  6  mph
(10  km/h)  or  more  to
reduce  the  overload  to
the  system.  Once  the
display message on the
multi-information

dis-

play  turns  off,  there  is
no  problem  continuing
to drive.

“AWD System Overheated

2WD Mode Engaged”

The vehicle switched
from  all-wheel  drive
(AWD) to front wheel
drive  due  to  over-
heating.

“AWD System Malfunction

2WD Mode Engaged

Visit Your Dealer”

A

malfunction

occurred in the AWD
system,  and  the
vehicle  switched  to
front wheel drive.

Have

the

vehicle

inspected  by  your  Toy-
ota dealer immediately.

PRIUS_OM_OM47D44U_(U)

413

4-5. Using the driving support systems

4

D

riv

in

g

WARNING

■

The ABS does not operate effectively when

●

The  limits  of  tire  gripping  performance  have  been  exceeded  (such  as
excessively worn tires on a snow covered road).

●

The vehicle hydroplanes while driving at high speed on wet or slick roads.

■

Stopping distance when the ABS is operating may exceed that of nor-
mal conditions

The ABS is not designed to shorten the vehicle’s stopping distance. Always
maintain a safe distance from the vehicle in front of you, especially in the
following situations:

●

When driving on dirt, gravel or snow-covered roads

●

When driving with tire chains

●

When driving over bumps in the road

●

When driving over roads with potholes or uneven surfaces

■

TRAC/VSC may not operate effectively when

Directional control and power may not be achievable while driving on slip-
pery road surfaces, even if the TRAC/VSC system is operating. Drive the
vehicle carefully in conditions where stability and power may be lost.

■

Active Cornering Assist does not operate effectively when

●

Do not overly rely on Active Cornering Assist. Active Cornering Assist may
not operate effectively when accelerating down slopes or driving on slip-
pery road surfaces.

●

When  Active  Cornering  Assist  frequently  operates,  Active  Cornering
Assist  may  temporarily  stop  operating  to  ensure  proper  operation  of  the
brakes, TRAC and VSC.

■

Hill-start assist control does not operate effectively when

●

Do not overly rely on hill-start assist control. Hill-start assist control may
not operate effectively on steep inclines and roads covered with ice.

●

Unlike the parking brake, hill-start assist control is not intended to hold the
vehicle  stationary for an  extended  period  of time. Do not attempt to  use
hill-start assist control to hold the vehicle on an incline, as doing so may
lead to an accident.

■

When the TRAC/ABS/VSC is activated

The slip indicator light flashes. Always drive carefully. Reckless driving may
cause an accident. Exercise particular care when the indicator light flashes.

414

PRIUS_OM_OM47D44U_(U)

4-5. Using the driving support systems

WARNING

■

When the TRAC/VSC systems are turned off

Be  especially  careful  and  drive  at  a  speed  appropriate  to  the  road  condi-
tions. As these are the systems to help ensure vehicle stability and driving
force, do not turn the TRAC/VSC systems off unless necessary.

■

Replacing tires

Make sure that all tires are of the specified size, brand, tread pattern and
total load capacity. In addition, make sure that the tires are  inflated to the
recommended tire inflation pressure level.
The ABS, TRAC and VSC systems will not function correctly if different tires
are installed on the vehicle.
Contact  your Toyota  dealer  for  further  information  when  replacing  tires  or
wheels.

■

Handling of tires and the suspension

Using tires with any kind of problem or modifying the suspension will affect
the driving assist systems, and may cause a system to malfunction.

415

PRIUS_OM_OM47D44U_(U)

4-6. Driving tips

4

Drivin

g

Hybrid vehicle driving tips

◆

Using Eco drive mode

When using Eco drive mode, the torque corresponding to the accel-
erator pedal depression amount can be generated more smoothly
than it is in normal conditions. In addition, the operation of the air
conditioning system (heating/cooling) will be minimized, improving
the fuel economy. (



P. 336)

◆

Use of Hybrid System Indicator

The Eco-friendly driving is possible by keeping the Hybrid System
Indicator within Eco area. (



P. 127)

◆

Shift position operation

Shift the shift position to D when stopped at a traffic light, or driving
in heavy traffic etc. Shift the shift position to P when parking. When
using the N, there is no positive effect on fuel consumption. In the
N,  the  gasoline  engine  operates  but  electricity  cannot  be  gener-
ated. Also, when using the air conditioning system, etc., the hybrid
battery (traction battery) power is consumed.

◆

Accelerator pedal/brake pedal operation

●

Drive  your  vehicle  smoothly.  Avoid  abrupt  acceleration  and
deceleration.  Gradual  acceleration  and  deceleration  will  make
more effective use of the electric motor (traction motor) without
having to use gasoline engine power.

●

Avoid  repeated  acceleration.  Repeated  acceleration  consumes
hybrid battery (traction battery) power, resulting in poor fuel con-
sumption.  Battery  power  can  be  restored  by  driving  with  the
accelerator pedal slightly released.

For economical and ecological driving, pay attention to the fol-
lowing points:

416

PRIUS_OM_OM47D44U_(U)

4-6. Driving tips

◆

When braking

Make sure to operate the brakes gently and in a timely manner. A
greater amount of electrical energy can be regenerated when slow-
ing down.

◆

Delays

Repeated  acceleration  and  deceleration,  as  well  as  long  waits  at
traffic  lights,  will  lead  to  bad  fuel  economy.  Check  traffic  reports
before leaving and avoid delays as much as possible. When driving
in a traffic jam, gently release the brake pedal to allow the vehicle to
move  forward  slightly  while  avoiding  overuse  of  the  accelerator
pedal. Doing so can help control excessive gasoline consumption.

◆

Highway driving

Control and maintain the vehicle at a constant speed. Before stop-
ping  at  a  toll  booth  or  similar,  allow  plenty  of  time  to  release  the
accelerator and gently apply the brakes. A greater amount of elec-
trical energy can be regenerated when slowing down.

◆

Air conditioning

Use  the  air  conditioning  only when necessary.  Doing  so  can  help
reduce excessive gasoline consumption.
In summer: When the ambient temperature is high, use the recircu-
lated air mode. Doing so will help to reduce the burden on the air
conditioning system and reduce fuel consumption as well.
In winter: Because the gasoline engine will not automatically cut out
until it and the interior of the vehicle are warm, it will consume fuel.
Also, fuel consumption can be improved by avoiding overuse of the
heater.

PRIUS_OM_OM47D44U_(U)

417

4-6. Driving tips

4

Drivin

g

◆

Checking tire inflation pressure

Make sure to check the tire inflation pressure frequently. Improper
tire inflation pressure can cause poor fuel economy.
Also, as snow tires can cause large amounts of friction, their use on
dry roads can lead to poor fuel economy. Use tires that are appro-
priate for the season.

◆

Luggage

Carrying heavy luggage will lead to poor fuel economy. Avoid carry-
ing unnecessary luggage. Installing a large roof rack will also cause
poor fuel economy.

◆

Warming up before driving

Since  the  gasoline  engine  starts  up  and  cuts  out  automatically
when cold, warming up the engine is unnecessary. Moreover, fre-
quently driving short distances will cause the engine to repeatedly
warm up, which can lead to excess fuel consumption.

418

PRIUS_OM_OM47D44U_(U)

4-6. Driving tips

Winter driving tips

●

Use  fluids  that  are  appropriate  to  the  prevailing  outside  tempera-
tures.

• Engine oil
• Engine/power control unit coolant
• Washer fluid

●

Have a service technician inspect the condition of the 12-volt bat-
tery.

●

Have the vehicle fitted with four snow tires or purchase a set of tire
chains for the front tires.

Ensure that all tires are the same size and brand, and that chains match
the size of the tires.

Perform the following according to the driving conditions:

●

Do not try to forcibly open a window or move a wiper that is frozen.
Pour warm water over the frozen area to melt the ice. Wipe away
the water immediately to prevent it from freezing.

●

To  ensure  proper  operation  of  the  climate  control  system  fan,
remove  any  snow  that  has  accumulated  on  the  air  inlet  vents  in
front of the windshield.

●

Check for and remove any excess ice or snow that may have accu-
mulated  on  the  exterior  lights,  vehicle’s  roof,  chassis,  around  the
tires or on the brakes.

●

Remove  any  snow  or  mud  from  the  bottom  of  your  shoes  before
getting in the vehicle.

Carry  out  the  necessary  preparations  and  inspections  before
driving the vehicle in winter. Always drive the vehicle in a man-
ner appropriate to the prevailing weather conditions.

Preparation for winter

Before driving the vehicle

PRIUS_OM_OM47D44U_(U)

419

4-6. Driving tips

4

Drivin

g

Accelerate the vehicle slowly, keep a safe distance between you and
the vehicle ahead, and drive at a reduced speed suitable to road con-
ditions.

Park the vehicle and shift the shift position to P and block the wheel
under the vehicle without setting the parking brake. The parking brake
may  freeze  up,  preventing  it  from  being  released.  If  the  vehicle  is
parked  without  setting  the  parking  brake,  make  sure  to  block  the
wheels.
Failure to do so may be dangerous because it may cause the vehicle
to move unexpectedly, possibly leading to an accident.

Use the correct tire chain size when mounting the tire chains. Chain
size is regulated for each tire size.
Side chain

0.12 in. (3.0 mm)
1.18 in. (30.0 mm)
0.39 in. (10.0 mm)

Cross chain

0.16 in. (4.0 mm)
0.98 in. (25.0 mm)
0.55 in. (14.0 mm)

Regulations regarding the use of tire chains vary depending on loca-
tion and type of road. Always check local regulations before installing
chains.

When driving the vehicle

When parking the vehicle

Selecting tire chains

1

2

3

4

5

6

Regulations on the use of tire chains

420

PRIUS_OM_OM47D44U_(U)

4-6. Driving tips

■

Tire chain installation

Observe the following precautions when installing and removing chains:

●

Install and remove tire chains in a safe location.

●

Install tire chains on the front tires only. Do not install tire chains on the rear
tires.

●

Install tire chains on front tires as tightly as possible. Retighten chains after
driving 1/4 - 1/2 mile (0.5 - 1.0 km).

●

Install tire chains following the instructions provided with the tire chains.

WARNING

■

Driving with snow tires

Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in a loss of vehicle control and cause death or
serious injury.

●

Use tires of the specified size.

●

Maintain the recommended level of air pressure.

●

Do  not  drive  in  excess  of  75  mph  (120  km/h),  regardless  of  the  type  of
snow tires being used.

●

Use snow tires on all, not just some wheels.

■

Driving with tire chains

Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in the vehicle being unable to be driven safely,
and may cause death or serious injury.

●

Do not drive in excess of the speed limit specified for the tire chains being
used, or 30 mph (50 km/h), whichever is lower.

●

Avoid driving on bumpy road surfaces or over potholes.

●

Avoid  sudden  acceleration,  abrupt  steering,  sudden  braking  and  shifting
operations that cause sudden engine braking.

●

Slow down sufficiently before entering a curve to ensure that vehicle con-
trol is maintained.

●

Do not use LDA (Lane Departure Alert with steering control) (if equipped).

■

When parking the vehicle

When parking the vehicle without applying the parking brake, make sure to
chock the wheels.  If you do not  chock the wheels, the vehicle  may  move
unexpectedly, possibly resulting in an accident.

PRIUS_OM_OM47D44U_(U)

421

4-6. Driving tips

4

D

riv

in

g

NOTICE

■

Repairing or replacing snow tires

Request repairs or replacement of snow tires from Toyota dealers or legiti-
mate tire retailers.
This is because the removal and attachment of snow tires affects the opera-
tion of the tire pressure warning valves and transmitters.

■

Fitting tire chains

The tire pressure warning valves and transmitters may not function correctly
when tire chains are fitted.

422

PRIUS_OM_OM47D44U_(U)

4-6. Driving tips

423

PRIUS_OM_OM47D44U_(U)

5

Interior features

5-1. Using the air conditioning

system and defogger

Automatic air conditioning

system (vehicles with
7-inch display)................. 424

Automatic air conditioning

system (vehicles with
11.6-inch display)............ 434

Heated steering wheel/

seat heaters .................... 444

5-2. Using the interior lights

Interior lights list ................ 446

• Front interior light.......... 447
• Front personal lights ..... 447
• Rear interior light .......... 448

5-3. Using the storage

features

List of storage features ..... 449

• Glove box...................... 450
• Console box.................. 450
• Cup holders .................. 451
• Bottle holders/

door pockets ................. 452

• Auxiliary boxes.............. 453
• Seat back pockets ........ 454

Luggage compartment

features........................... 455

5-4. Using the other interior

features

Other interior features ....... 461

• Sun visors ..................... 461
• Vanity mirrors................ 461
• Power outlets ................ 462
• USB charging ports....... 463
• Wireless charger........... 465
• Armrest ......................... 474
• Coat hooks.................... 474
• Assist grips ................... 475

Garage door opener.......... 476

424

PRIUS_OM_OM47D44U_(U)

5-1. Using the air conditioning system and defogger

Automatic air conditioning system

(vehicles with 7-inch display)

■

Adjusting the temperature setting

Move  the  temperature  setting
knob  upwards  to  increase  the
temperature and downwards to
decrease the temperature.

If

 is not pressed, the sys-

tem  will  blow  ambient  tempera-
ture air or heated air.

■

Fan speed setting

Move  the  fan  speed  setting
knob  upwards  to  increase  the
fan  speed  and  downwards  to
decrease the fan speed.

The  fan  speed  is  shown  on  the
display. (7 levels)

Press

 to turn the fan off.

Air outlets and fan speed are automatically adjusted according
to the temperature setting.

Air conditioning controls

Temperature
setting knob

Fan speed
setting knob

PRIUS_OM_OM47D44U_(U)

425

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

■

Change the airflow mode

Move  the  airflow  change  knob
upwards  or  downwards  to
change the airflow mode.

The  air  outlets  used  are
switched  each  time  the  knob  is
operated.

Air flows to the upper body
Air  flows  to  the  upper  body
and feet
Air flows to the feet
Air  flows  to  the  feet  and  the
windshield  defogger  oper-
ates

Airflow change
knob

1

2

3

4

426

5-1. Using the air conditioning system and defogger

PRIUS_OM_OM47D44U_(U)

■

S-FLOW mode

In S-FLOW mode, priority for the airflow is given to the front seats,
reducing the airflow and air conditioning effect on the rear seats.
When  a  passenger  is  not  detected  in  the  front  passenger  seat,
depending on the set temperature and ambient temperature, prior-
ity for the airflow will be given to the driver’s seat only.

However, air will always be blown from the side outlet of the front pas-
senger seat.

The following S-FLOW modes are available:



Automatic S-FLOW mode

The system determines whether or not a rear passenger is in the
vehicle by the opening and closing of a rear door. When a rear pas-
senger  is  determined  to  be  in  the  vehicle,  S-FLOW  mode  will  be
automatically disabled.
To enable S-FLOW mode again, press

 and enter manual

S-FLOW mode. (



P. 430)

The

 indicator will illuminate when S-FLOW mode is enabled.



Manual S-FLOW mode

When

 is pressed, S-FLOW mode will be manually enabled/

disabled. (



P. 430)

The

 indicator will illuminate when S-FLOW mode is enabled.

When the power switch is turned to ON mode, the system is oper-
ated in automatic S-FLOW mode.

■

Other functions

●

Switching between outside air and recirculated air modes
(



P. 427)

●

Defogging the windshield (



P. 428)

●

Defogging the rear window and outside rear view mirrors
(



P. 428)

PRIUS_OM_OM47D44U_(U)

427

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

Press

.

Adjust the temperature setting. (



P. 424)

Press

.

The cooling and dehumidification function switches between on and

off each time

 is pressed.

To stop the operation, press

.

■

Automatic mode indicator

If the fan speed setting or air flow modes are operated, the
indicator  goes  off.  However,  automatic  mode  for  functions  other
than that operated is maintained.

■

Switching between outside air and recirculated air modes

Press

.

The mode switches between outside air mode and recirculated air mode

each time

 is pressed.

The

  indicator  illuminates  when  the  recirculated  air  mode  is

selected.

■

Air conditioning eco mode

The air conditioning system is controlled with low fuel consumption
prioritized such as reducing fan speed, etc.

Press

.

The air conditioning eco mode switches between on and off each time

 is pressed.

“ECO” is displayed in the air conditioning control panel display when the
air conditioning eco mode is on.

Using automatic mode

Other functions

1

2

3

4

428

5-1. Using the air conditioning system and defogger

PRIUS_OM_OM47D44U_(U)

■

Defogging the windshield

Defoggers  are  used  to  defog  the  windshield  and  front  side  win-
dows.

Press

.

Set

 to outside air mode if the recirculated air mode is used. (It

may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.

The

 indicator illuminates when the defoggers are on.

To  return  to  the  previous  mode,  press

  again  when  the  wind-

shield is defogged. Also, turning the power switch off during operation
can return to the previous mode.

■

Defogging the rear window and outside rear view mirrors

Defoggers are used to defog the rear window and to remove rain-
drops, dew and frost from the outside rear view mirrors.

Press

.

Defoggers switch between on and off each time

 is pressed.

The

 indicator illuminates when the defoggers are on.

The defoggers will automatically turn off after approximately 15 minutes.

■

Eco score (A/C score)



P. 129

PRIUS_OM_OM47D44U_(U)

429

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

■

Location of air outlets

The  air  outlets  and  air  volume
change

according

to

the

selected airflow mode.

■

Adjusting the air flow direction

Direct air flow to the left or right,
up or down.

■

Opening and closing the air outlets

Air outlets



Left side outlet/right side outlet



Center outlets

Open the vent
Close the vent

Open the vent
Close the vent

1

2

1

2

430

5-1. Using the air conditioning system and defogger

PRIUS_OM_OM47D44U_(U)

■

Using automatic mode

Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow

immediately after

 is pressed.

■

Setting confirmation screen

■

S-FLOW mode operation

■

Changing from manual S-FLOW mode to automatic S-FLOW mode

Press

 to disable S-FLOW mode.

The

 indicator will go off.

Turn the power switch off.
After 60 minutes have elapsed, change the power switch to ON mode.

■

Changing settings using the multi-information display

The air conditioning system settings can be changed on the

 screen of

the multi-information display. (



P. 145)

■

Fogging up of the windows

●

The  windows  will  easily  fog  up  when  the  humidity  in  the  vehicle  is  high.

Turning

  on  will  dehumidify  the  air  from  the  outlets  and  defog  the

windshield effectively.

●

If you turn

 off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

When  changing  the  settings  of  the  air
conditioning system, the setting confirma-
tion screen is shown as a pop-up on the
multi-information display.
Press

 of the meter control switches to

go back to the previous screen.

When

  is  pressed,  the  S-FLOW

mode  status  is  displayed  on  the  multi-
information display.

1

2

3

PRIUS_OM_OM47D44U_(U)

431

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

■

Windshield fog detection function

When automatic mode is set, the humidity sensor (



P. 433) detects fog on

the windshield and controls the air conditioning system to prevent fog.

■

When driving on dusty roads

Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air intake mode be
set to outside air mode and the fan speed to any setting except off.

■

Outside/recirculated air mode

●

Setting to the recirculated air mode temporarily is recommended in prevent-
ing dirty air from entering the vehicle interior and helping to cool the vehicle
when the outside air temperature is high.

●

Outside/recirculated  air  mode  may  automatically  switch  depending  on  the
temperature setting or the inside temperature.

■

Fresh air intake system while parking

When  parking,  the  system  automatically  switches  to  outside  air  mode  to
encourage  better  air  circulation  throughout  the  vehicle,  helping  to  reduce
odors that occur when starting the vehicle.

■

Operation  of  the  air  conditioning  system  in  the  air  conditioning  eco
mode

●

In the air conditioning eco mode, the air conditioning system is controlled as
follows to prioritize fuel efficiency:
• Engine  speed  and  compressor  operation  controlled  to  restrict  heating/

cooling capacity

• Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations:
• Adjust the fan speed
• Adjust the temperature setting
• Turn off the air conditioning eco mode

●

When the driving mode is set to Eco driving mode, the air conditioning eco
mode will be turned on automatically. Even in this case, the air conditioning

eco mode can be turned off by pressing

. (



P. 336)

■

When the outside temperature falls to nearly 32



F (0



C)

The dehumidification function may not operate even when

 is pressed.

432

5-1. Using the air conditioning system and defogger

PRIUS_OM_OM47D44U_(U)

■

Ventilation and air conditioning odors

●

To let the fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

In  order  to  suppress  odors  that  occur  when  the  air  conditioning  system
starts, fresh air is automatically taken in when parked.

●

To reduce potential odors from occurring, the start timing of the blower may
be delayed for a short period of time immediately after the air conditioning
system is started in automatic mode.

■

Air conditioning filter



P. 536

WARNING

■

To prevent the windshield from fogging up

●

Do not use



 during cool air operation in extremely humid weather.

The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.

■

To prevent burns

Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.

●

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

PRIUS_OM_OM47D44U_(U)

433

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

NOTICE

■

Humidity sensor (if equipped)

●

Do not spray the glass cleaner on the sensor or subject it to strong impacts

●

Do not stick anything on the sensor

■

To prevent 12-volt battery discharge

Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.

■

Air outlets

The air outlets become hot when used for heating. Therefore, use caution
and adjust the air outlets accordingly.

In order to detect fog on the windshield, a
sensor  which  monitors  the  temperature
of the windshield, the surround humidity,
etc. is installed. (



P. 431)

Follow  these  points  to  avoid  damaging
the sensor:

●

Do not disassemble the sensor

434

PRIUS_OM_OM47D44U_(U)

5-1. Using the air conditioning system and defogger

Automatic air conditioning system

(vehicles with 11.6-inch display)

The  following  informations  are  displayed  on  the  navigation  system
screen.

Temperature setting
Fan speed setting
Automatic mode setting
Airflow mode setting
S-FLOW mode setting
Air  conditioning  eco  mode  set-
ting

A/C setting
Outside/recirculated air mode setting

Air outlets and fan speed are automatically adjusted according
to the temperature setting.

Air conditioner information area

1

2

3

4

5

6

7

8

PRIUS_OM_OM47D44U_(U)

435

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

The  air  conditioning  control
screen can be displayed by touch-
ing the air conditioner information
area  on  the  navigation  system
screen.

■

Adjusting the temperature setting

Press “



” on

 to increase the temperature and “



” to decrease

the temperature.

If  the

  indicator  is  turned  off,  the  system  will  blow  ambient

temperature air or heated air.

■

Adjusting the fan speed setting

Select

 on the air conditioning control screen to increase the

fan speed and

 to decrease the fan speed.

The fan speed is shown on the control screen. (7 levels)

Select

 to turn the fan off.

■

Change the airflow mode

To change the air outlets, select any switch on the air conditioning
control screen.

Air flows to the upper body
Air  flows  to  the  upper  body
and feet
Air flows to the feet
Air  flows  to  the  feet  and  the
windshield  defogger  oper-
ates

Air conditioning control screen

Air conditioning controls

1

2

3

4

436

5-1. Using the air conditioning system and defogger

PRIUS_OM_OM47D44U_(U)

■

S-FLOW mode

In S-FLOW mode, priority for the airflow is given to the front seats,
reducing the airflow and air conditioning effect on the rear seats.
When  a  passenger  is  not  detected  in  the  front  passenger  seat,
depending on the set temperature and ambient temperature, prior-
ity for the airflow will be given to the driver’s seat only.

However, air will always be blown from the side outlet of the front pas-
senger seat.

The following S-FLOW modes are available:



Automatic S-FLOW mode

The system determines whether or not a rear passenger is in the
vehicle by the opening and closing of a rear door. When a rear pas-
senger  is  determined  to  be  in  the  vehicle,  S-FLOW  mode  will  be
automatically disabled.
To enable S-FLOW mode again, select

 and enter manual S-

FLOW mode. (



P. 440)

The

 indicator will illuminate when S-FLOW mode is enabled.



Manual S-FLOW mode

When

 is selected, S-FLOW mode will be manually enabled/

disabled. (



P. 440)

The

 indicator will illuminate when S-FLOW mode is enabled.

When the power switch is turned to ON mode, the system is oper-
ated in automatic S-FLOW mode.

■

Other functions

●

Switching between outside air and recirculated air modes
(



P. 437)

●

Defogging the windshield (



P. 438)

●

Defogging the rear window and outside rear view mirrors
(



P. 438)

PRIUS_OM_OM47D44U_(U)

437

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

Select

 on the air conditioning control screen.

Adjust the temperature setting. (



P. 435)

To stop the operation, select

.

■

Automatic mode indicator

If  the  fan  speed  setting  or  air  flow  modes  are  operated,  the

 indicator goes off. However, automatic mode for func-

tions other than that operated is maintained.

■

Switching between outside air and recirculated air modes

Select

 on the air conditioning control screen.

The mode switches between outside air mode and recirculated air mode
each time

 is selected.

The

 indicator illuminates when the recirculated  air mode is

selected.

■

Air conditioning eco mode

The air conditioning system is controlled with low fuel consumption
prioritized such as reducing fan speed, etc.

Select

 on the air conditioning control screen.

The air conditioning eco mode switches between on and off each time

 is selected.

The

  indicator  illuminates  when  the  air  conditioning  eco  mode  is

on.

Using automatic mode

Other functions

1

2

3

438

5-1. Using the air conditioning system and defogger

PRIUS_OM_OM47D44U_(U)

■

Defogging the windshield

Defoggers  are  used  to  defog  the  windshield  and  front  side  win-
dows.
Press

.

Set

 to outside air mode if the recirculated air mode is used.

(It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.
The switch indicator illuminates when the defoggers are on.

To return to the previous mode, press

 again when the windshield is

defogged. Also, turning the power switch off during operation can return
to the previous mode.

■

Defogging the rear window and outside rear view mirrors

Defoggers are used to defog the rear window and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Press

.

Defoggers switch between on and off each time

 is pressed.

The switch indicator illuminates when the defoggers are on.
The defoggers will automatically turn off after approximately 15 minutes.

■

Eco score (A/C score)



P. 146

PRIUS_OM_OM47D44U_(U)

439

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

■

Location of air outlets

The  air  outlets  and  air  volume
change

according

to

the

selected airflow mode.

■

Adjusting the air flow direction

Direct air flow to the left or right,
up or down.

■

Opening and closing the air outlets

Air outlets



Left side outlet/right side outlet



Center outlets

Open the vent
Close the vent

Open the vent
Close the vent

1

2

1

2

440

5-1. Using the air conditioning system and defogger

PRIUS_OM_OM47D44U_(U)

■

Using automatic mode

Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after

 is selected.

■

Setting confirmation screen

■

S-FLOW mode operation

■

Changing from manual S-FLOW mode to automatic S-FLOW mode

Select

 to disable S-FLOW mode.

The

 indicator will go off.

Turn the power switch off.
After 60 minutes have elapsed, change the power switch to ON mode.

■

Changing settings using the multi-information display

The air conditioning system settings can be changed on the

 screen of

the multi-information display. (



P. 144)

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high.
Turning

 on will dehumidify the air from the outlets and defog the

windshield effectively.

●

If you turn

 off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

When  changing  the  settings  of  the  air
conditioning system, the setting confirma-
tion screen is shown as a pop-up on the
multi-information display.
Press

 of the meter control switches to

go back to the previous screen.

When

  is  selected,  the  S-FLOW

mode  status  is  displayed  on  the  multi-
information display.

1

2

3

PRIUS_OM_OM47D44U_(U)

441

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

■

Windshield fog detection function

When automatic mode is set, the humidity sensor (



P. 443) detects fog on

the windshield and controls the air conditioning system to prevent fog.

■

When driving on dusty roads

Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air intake mode be
set to outside air mode and the fan speed to any setting except off.

■

Outside/recirculated air mode

●

Setting to the recirculated air mode temporarily is recommended in prevent-
ing dirty air from entering the vehicle interior and helping to cool the vehicle
when the outside air temperature is high.

●

Outside/recirculated  air  mode  may  automatically  switch  depending  on  the
temperature setting or the inside temperature.

■

Fresh air intake system while parking

When  parking,  the  system  automatically  switches  to  outside  air  mode  to
encourage  better  air  circulation  throughout  the  vehicle,  helping  to  reduce
odors that occur when starting the vehicle.

■

Operation  of  the  air  conditioning  system  in  the  air  conditioning  eco
mode

●

In the air conditioning eco mode, the air conditioning system is controlled as
follows to prioritize fuel efficiency:
• Engine  speed  and  compressor  operation  controlled  to  restrict  heating/

cooling capacity

• Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations:
• Adjust the fan speed
• Adjust the temperature setting
• Turn off the air conditioning eco mode

●

When the driving mode is set to Eco driving mode, the air conditioning eco
mode will be turned on automatically. Even in this case, the air conditioning
eco mode can be turned off by selecting

. (



P. 336)

■

When the outside temperature falls to nearly 32



F (0



C)

The  dehumidification  function  may  not  operate  even  when

  is

selected.

442

5-1. Using the air conditioning system and defogger

PRIUS_OM_OM47D44U_(U)

■

Ventilation and air conditioning odors

●

To let the fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

In  order  to  suppress  odors  that  occur  when  the  air  conditioning  system
starts, fresh air is automatically taken in when parked.

●

To reduce potential odors from occurring, the start timing of the blower may
be delayed for a short period of time immediately after the air conditioning
system is started in automatic mode.

■

Air conditioning filter



P. 536

■

Customization

Settings (e.g. A/C auto switching operation) can be changed. (Customizable
features:



P. 678)

WARNING

■

To prevent the windshield from fogging up

●

Do not use

 during cool air operation in extremely humid weather. The

difference between the temperature of the outside air and that of the wind-
shield  can  cause  the  outer  surface  of  the  windshield  to  fog  up,  blocking
your vision.

■

To prevent burns

Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.

●

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

PRIUS_OM_OM47D44U_(U)

443

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

NOTICE

■

Humidity sensor

●

Do not spray the glass cleaner on the sensor or subject it to strong impacts

●

Do not stick anything on the sensor

■

To prevent 12-volt battery discharge

Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.

■

Air outlets

The air outlets become hot when used for heating. Therefore, use caution
and adjust the air outlets accordingly.

In order to detect fog on the windshield, a
sensor  which  monitors  the  temperature
of the windshield, the surround humidity,
etc. is installed. (



P. 441)

Follow  these  points  to  avoid  damaging
the sensor:

●

Do not disassemble the sensor

444

PRIUS_OM_OM47D44U_(U)

5-1. Using the air conditioning system and defogger

Heated steering wheel



/seat heaters





: If equipped

●

Heated steering wheel
Warm up the grip of the steering wheel

●

Seat heaters (front seats)
Warm up the seat upholstery

WARNING

●

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on:
• Babies,  small  children,  the  elderly,  the  sick  and  the  physically  chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

●

Observe the following precautions to prevent minor burns or overheating:
• Do  not  cover  the  seat  with  a  blanket  or  cushion  when  using  the  seat

heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

●

To  prevent  12-volt  battery  discharge,  do  not  use  the  functions when  the
hybrid system is off.

PRIUS_OM_OM47D44U_(U)

445

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

Turns  the  heated  steering  wheel
on/off

The  indicator  in  the  instrument
cluster comes on when the heated
steering wheel is operating.

●

The  heated  steering  wheel  can  be  used  when  the  power  switch  is  in  ON
mode.

●

The heated steering wheel will automatically turn off after about 30 minutes.

Heats the seat at low tempera-
ture (LO)
Heats the seat at high tempera-
ture (HI)

The indicator light comes on when
one side of the switch is pressed.
To stop the operation, gently press
the other side of the switch.

●

The seat heaters can be used when the power switch is in ON mode.

●

When not in use, turn off the switch. The indicator light goes off.

Heated steering wheel (if equipped)

Seat heaters (if equipped)

Indicator

Indicator

1

2

446

PRIUS_OM_OM47D44U_(U)

5-2. Using the interior lights

Interior lights list

Rear interior light (



P. 448)

Front personal/interior lights (



P. 447)

Shift lever lighting
Footwell lights (if equipped)
Front door courtesy lights

1

2

3

4

5

PRIUS_OM_OM47D44U_(U)

447

5-2. Using the interior lights

5

In

te

rior

fe

at

ures

Front interior light



Vehicles without moon roof



Vehicles with moon roof

Turns the lights off
Turns the door position on
Turns the lights on

Turns the door position on/off
Turns the lights on/off

Front personal lights

1

2

3

1

2



Vehicles without moon roof



Vehicles with moon roof

Turns the lights on/off

Turns the lights on/off

448

PRIUS_OM_OM47D44U_(U)

5-2. Using the interior lights

Turns  the  switch  to  the  door
position (door linked)

Operation  is  linked  with  the  front
interior light main switch. When the
switch is off, the light does not illu-
minate.

Turns the light on

■

Illuminated entry system

The lights automatically turn on/off according to power switch mode, the pres-
ence  of  the  electronic  key,  whether  the  doors  are  locked/unlocked,  and
whether the doors are opened/closed.

■

To prevent the 12-volt battery from being discharged

If the interior lights remain on when the power switch is turned off, the light
will go off automatically after 20 minutes.

■

Customization

Settings (e.g. the time elapsed before the lights turn off) can be changed.
(Customizable features:



P. 678)

Rear interior light

1

2

NOTICE

To prevent 12-volt battery discharge, do not leave the lights on longer than
necessary when the hybrid system is off.

449

PRIUS_OM_OM47D44U_(U)

5-3. Using the storage features

5

In

te

rior

fe

at

ures

List of storage features

Auxiliary boxes (



P. 453)

Glove box (



P. 450)

Bottle holders/door pockets
(



P. 452)

Cup holders (



P. 451)

Seat back pockets (



P. 454)

Console box (



P. 450)

1

2

3

4

5

6

WARNING

●

Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact

with other stored items.

• Lighters or spray cans may explode. If they come into contact with other

stored  items,  the  lighter  may  catch  fire  or  the  spray  can  may  release
gas, causing a fire hazard.

●

When driving or when the storage compartments are not in use, keep the
lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.

450

PRIUS_OM_OM47D44U_(U)

5-3. Using the storage features

Pull up the lever.

The glove box light turns on when the tail lights are on.

Press the knob and open the lid.

Glove box

Console box

The tray slides forward/backward and can
be removed.

PRIUS_OM_OM47D44U_(U)

451

5-3. Using the storage features

5

In

te

rior

fe

at

ures



Front



Rear

Pull down the armrest.

Cup holders

WARNING

Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden  braking,  causing  injury.  If  possible,  cover  hot  drinks  to  prevent
burns.

452

PRIUS_OM_OM47D44U_(U)

5-3. Using the storage features

●

When storing a bottle, close the cap.

●

The bottle may not be stored depending on its size or shape.

Bottle holders/door pockets



Front doors



Rear doors

NOTICE

Put the cap on before stowing a bottle. Do not place open bottles or glass
and paper cups containing liquid in the bottle holders.
The contents may spill and glasses may break.

PRIUS_OM_OM47D44U_(U)

453

5-3. Using the storage features

5

In

te

rior

fe

at

ures



Type A (if equipped)

Press in the lid.

The overhead console is useful for
temporarily storing small items.



Type B

Vehicles  with  the  wireless  char-
ger:



P. 465



Type C (if equipped)

Auxiliary boxes

WARNING

Do not store items heavier than 0.44 lb. (200 g).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident. (type A)

454

PRIUS_OM_OM47D44U_(U)

5-3. Using the storage features

Owner’s  manual  etc.  can  be
stored  in  the  left-side  seatback
pocket with the fastener.

Seat back pockets (if equipped)

455

PRIUS_OM_OM47D44U_(U)

5-3. Using the storage features

5

In

te

rior

fe

at

ures

Luggage compartment features

Pull the lever upwards.

Secure  it  with  the  grocery  bag
hooks.

Deck Board

1

2

WARNING

●

If the deck board is opened, close it before driving. In the event of sudden
braking,  an  accident  may  occur  due  to  an  occupant  being  struck by  the
deck board or the items stored in the auxiliary box.

●

Do not place an object which is easy to roll or taller than the storable por-
tion on the deck under box.

NOTICE

To prevent damage to the deck board, do not apply too much load on the
deck board.

456

PRIUS_OM_OM47D44U_(U)

5-3. Using the storage features



Vehicles with emergency tire puncture repair kit

Raise the hook to use.

The  cargo  hooks  are  provided  for
securing loose items.



Vehicles with spare tire

Open  the  deck  board,  then
raise the hook to use.

Return  the  deck  board  to  its
original position and close it.

Cargo hooks

1

2

PRIUS_OM_OM47D44U_(U)

457

5-3. Using the storage features

5

In

te

rior

fe

at

ures

When using the hooks, press the
bottom side to lift it up.

There  also  is  a  hook  on  the  other
side.

WARNING

To  avoid  injury,  always  return  the  cargo  hooks  to  their  stowed  positions
when not in use.

Grocery bag hooks

NOTICE

In  order to  prevent  damage  to  the  grocery  bag  hooks,  do  not  place  large
objects or objects that weight more than 8.8 lb. (4 kg) onto the hooks.

458

PRIUS_OM_OM47D44U_(U)

5-3. Using the storage features

The warning reflector can be stowed on the center auxiliary box.
(The warning reflector itself is not included as an original equipment)

Depending on the size and shape of the warning reflector case, etc., you may
not be able to store it.

Warning reflector storage space



Vehicles  with  emergency  tire
puncture  repair  kit  (2WD  mod-
els)



Vehicles  with  emergency  tire
puncture repair kit (AWD mod-
els)



Vehicles  with  compact  spare
tire



Vehicles  with  full-size  spare
tire

WARNING

When storing the warning reflector, etc., make sure that it is properly stored.
If  the  warning  reflector  is  not  properly  stored,  it  may  fly  out  during  emer-
gency braking and lead to an accident.

PRIUS_OM_OM47D44U_(U)

459

5-3. Using the storage features

5

In

te

rior

fe

at

ures

■

Installing the luggage cover

Install  one  side  of  the  luggage
cover to the holder. While push-
ing that side in, install the other
side to the opposite holder.

■

Using the luggage cover

Pull out the luggage cover and
secure it to the hook brackets.

■

Removing the luggage cover

Push  one  end  of  the  luggage
cover  inward  and  remove  it
from the holder.

Luggage cover (if equipped)

460

PRIUS_OM_OM47D44U_(U)

5-3. Using the storage features

■

Stowing the luggage cover (except vehicles with full-size spare
tire)

Open  the  deck  board  and
secure it with the grocery bag
hooks.

Store cover in the deck under
box.

Close the deck board.

1

2

WARNING

●

Do not place anything on the luggage cover. In the event of sudden brak-
ing or turning, the item may go flying and strike an occupant. This could
lead to an unexpected accident, resulting in death or serious injury.

●

Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.

●

Make  sure  that  the  rear  edge  of  the  cover  is  laying  flat.  If  the  cover  is
installed with the rear edge raised, the view from the rear window may be
obstructed, which could cause an accident.

●

Make sure that seat belts are not caught up in the luggage cover. If a seat
belt is caught up in the cover, it may not be able to restrain  passengers
properly.

3

461

PRIUS_OM_OM47D44U_(U)

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

Other interior features

To  set  the  visor  in  the  forward
position, flip it down.
To set the visor in the side posi-
tion,  flip  down,  unhook,  and
swing it to the side.
To use the side extender, place
the  visor  in  the  side  position,
then slide it backward.

Slide the cover to open.

The  light  turns  on  when  the  cover
is opened.

If the vanity light remain on when the power switch is turned off, the light will
go off automatically after 20 minutes.

Sun visors

1

2

3

Vanity mirrors

NOTICE

To  prevent  12-volt  battery  discharge,  do  not  leave  the  vanity  lights  on  for
extended periods while the hybrid system is off.

462

PRIUS_OM_OM47D44U_(U)

5-4. Using the other interior features

Please use as a power supply for electronic goods that use less than
12 V DC/10 A (power consumption of 120 W).
Open the lid.

■

The power outlet can be used when

The power switch is in ACCESSORY or ON mode.

■

When stopping the hybrid system

Disconnect electrical devices with charging functions, such as mobile battery
packs.
If such devices are left connected, the hybrid system may not stop normally.

Power outlets

NOTICE

●

To avoid damaging the power outlets, close the lid when the power outlet
is not in use.
Foreign objects or liquids that enter the power outlets may cause a short
circuit.

●

To prevent 12-volt battery discharge, do not use the power outlet longer
than necessary when the hybrid system is off.

PRIUS_OM_OM47D44U_(U)

463

5-4. Using the other interior features

5

In

te

rior

fe

at

ures

The USB charging ports are used to supply 2.1 A of electricity at 5 V
to  external  devices.  The  USB  charging  ports  are  for  charging  only.
They are not designed for data transfer or other purposes.
Depending on the external device, it may not charge properly. Refer to
the  manual  included  with  the  device  before  using  a  USB  charging
port.
Open the lid.

■

The USB charging ports can be used when

The power switch is in ACCESSORY or ON mode.

■

Situations in which the USB charging ports may not operate correctly

●

If a device which consumes more than 2.1 A at 5 V is connected

●

If a device designed to communicate with a personal computer, such as a
USB memory device, is connected

●

If the connected external device is turned off (depending on device)

●

If the temperature inside the vehicle is high, such as after the vehicle has
been parked in the sun

■

About connected external devices

Depending on the connected external device, charging may occasionally be
suspended and then start again. This is not a malfunction.

USB charging ports
