142

4-2. Opening, closing and locking the doors

MIRAI_OM_USA_OM62073U

WARNING

■

Using the trunk

Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in seri-
ous injury.

●

Remove any heavy loads, such as snow and ice, from the trunk lid before
opening it. Failure to do so may cause the trunk lid to suddenly shut again
after it is opened.

●

When opening or closing the trunk lid, thoroughly check to make sure the
surrounding area is safe.

●

If anyone is in the vicinity, make sure they are safe and let them know that
the trunk is about to open or close.

●

Use caution when opening or closing the trunk lid in windy weather as it
may move abruptly in strong wind.

●

Do not attach any accessories other than genuine Toyota parts to the trunk
lid. Such additional weight on the trunk lid may cause the lid to suddenly
shut again after it is opened.

●

The  trunk  lid  may  suddenly  shut  if  it  is
not  opened  fully.  It  is  more  difficult  to
open or close the trunk lid on an incline
than  on  a  level  surface,  so  beware  of
the  trunk  lid  unexpectedly  opening  or
closing  by  itself.  Make  sure  that  the
trunk lid is fully open and secure before
using the trunk.

●

When  closing  the  trunk  lid,  take  extra
care  to  prevent  your  fingers,  etc.,  from
being caught.

●

When closing the trunk lid, make sure to
press it lightly on its outer surface. If the
trunk  handle  is  used  to  fully  close  the
trunk lid, it may result in hands or arms
being caught.

143

4-2. Opening, closing and locking the doors

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

Smart key system

●

Locks and unlocks the doors (



P. 132)

●

Opens the trunk (



P. 138)

●

Starts and stops the fuel cell system (



P. 186)

■

Antenna location

The  following  operations  can  be  performed  simply  by  carrying
the electronic key on your person, for example in your pocket.
The driver should always carry the electronic key.

Antennas outside the cabin
Antennas inside the cabin
Antenna inside the trunk
Antenna outside the trunk

144

4-2. Opening, closing and locking the doors

MIRAI_OM_USA_OM62073U

■

Effective range (areas within which the electronic key is detected)

■

Alarms and warning indicators

A combination of  exterior and interior alarms as well as warning messages
shown on the multi-information display are used to prevent theft of the vehicle
and  accidents  resulting  from  erroneous  operation.  Take  appropriate  mea-
sures in response to any warning message on the multi-information display.
(



P. 426)

The following table describes circumstances and correction procedures when
only alarms are sounded.

When locking or unlocking the
doors

The  system  can  be  operated
when  the  electronic  key  is  within
about 2.3 ft. (0.7 m) of an outside
door  handle.  (Only  the  doors
detecting  the  key  can  be  oper-
ated.)

When opening the trunk

The  system  can  be  operated  when  the  electronic  key  is  within
about 2.3 ft. (0.7 m) of the trunk release button.

When starting the fuel cell system or changing power switch
modes

The system can be operated when the electronic key is inside the
vehicle.

Alarm

Situation

Correction procedure

Exterior  alarm  sounds
once for 5 seconds

The  trunk  was  closed
while the electronic key
was still inside the trunk
and  all  the  doors  were
locked.

Retrieve  the  electronic
key  from  the  trunk  and
close the trunk lid.

An  attempt  was  made
to lock the vehicle while
a door was open.

Close  all  of  the  doors
and  lock  the  doors
again.

Interior  alarm  sounds
continuously

The  power  switch  was
turned to ACCESSORY
mode while the driver’s
door  was  open  (or  the
driver’s

door

was

opened

while

the

power  switch  was  in
ACCESSORY mode).

Turn  the  power  switch
off  and  close  the
driver’s door.

145

4-2. Opening, closing and locking the doors

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

■

When “Smart Key System Malfunction See Owner’s Manual” will be dis-
played on the multi-information display

The  system  may  be  malfunctioning.  Have  the  vehicle  inspected  by  your
Toyota dealer immediately.

■

Battery-saving function

The battery-saving function will be activated in order to prevent the electronic
key battery and the 12-volt battery from being discharged while the vehicle is
not in operation for a long time.

●

In  the  following  situations,  the  smart  key  system  may  take  some  time  to
unlock the doors.
• The electronic key has been left in an area of approximately 6 ft. (2 m) of

the outside of the vehicle for 10 minutes or longer.

• The smart key system has not been used for 5 days or longer.

●

If the smart key system has not been used for 14 days or longer, the doors
cannot be unlocked at any doors except the driver’s door. In this case, take
hold of the driver’s door handle, or use the wireless remote control or the
mechanical key, to unlock the doors.

■

Electronic Key battery-Saving Function

When battery-saving mode is set, battery depletion is minimized by stopping
the electronic key from receiving radio waves.

Press

  twice  while  pressing  and

holding

. Confirm that the electronic

key indicator flashes 4 times.
While the battery-saving mode is set, the
smart  key  system  cannot  be  used.  To
cancel the function, press any of the elec-
tronic key buttons.

146

4-2. Opening, closing and locking the doors

MIRAI_OM_USA_OM62073U

■

Conditions affecting operation

The smart key system uses weak radio waves. In the following situations, the
communication between the electronic key and the vehicle may be affected,
preventing  the  smart  key  system,  wireless  remote  control  and  immobilizer
system from operating properly. (Ways of coping:



P. 449)

●

When the electronic key battery is depleted

●

Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise

●

When  the  electronic  key  is  in  contact  with,  or  is  covered  by  the  following
metallic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs

●

When other wireless keys (that emit radio waves) are being used nearby

●

When  carrying  the  electronic  key  together  with  the  following  devices  that
emit radio waves
• Portable radio, cellular phone, cordless phone or other wireless commu-

nication devices

• Another vehicle’s electronic key or a wireless key that emits radio waves
• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems

●

If window tint with a metallic content or metallic objects are attached to the
rear window

●

When  the  electronic  key  is  placed  near  a  battery  charger  or  electronic
devices

147

4-2. Opening, closing and locking the doors

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

■

Note for the entry function

●

Even when the electronic key is within the effective range (detection areas),
the system may not operate properly in the following cases:
• The electronic key is too close to the window or outside door handle, near

the ground, or in a high place when the doors are locked or unlocked.

• The electronic key is near the ground or in a high place, or too close to

the rear bumper center when the trunk is opened.

• The electronic key is on the instrument panel, rear package tray or floor,

or in the door pockets or glove box when the fuel cell system is started or
power switch modes are changed.

●

Do not leave the electronic key on top of the instrument panel or near the
door pockets when exiting the vehicle. Depending on the radio wave recep-
tion conditions, it may be detected by the antenna outside the cabin and the
door will become lockable from the outside, possibly trapping the electronic
key inside the vehicle.

●

As long as the electronic key is within the effective range, the doors may be
locked or unlocked by anyone. However, only the doors detecting the elec-
tronic key can be used to unlock the vehicle.

●

Even if the electronic key is not inside the vehicle, it may be possible to start
the fuel cell system if the electronic key is near the window.

●

The  doors may unlock or lock  if a  large  amount  of water  splashes on  the
door handle, such as in the rain or in a car wash when the electronic key is
within  the  effective  range.  (The  doors  will  automatically  be  locked  after
approximately 60 seconds if the doors are not opened and closed.)

●

If the wireless remote control is used to lock the doors when the electronic
key  is  near  the  vehicle,  there  is  a  possibility  that  the  door  may  not  be
unlocked by the entry function. (Use the wireless remote control to unlock
the doors.)

●

Touching the door lock or unlock sensor while wearing gloves may prevent
lock or unlock operation.

●

When the lock operation is performed using the lock sensor, recognition sig-
nals  will  be  shown  up  to  two  consecutive  times. After  this,  no  recognition
signals will be given.

●

If the door handle becomes wet while the electronic key is within the effec-
tive range, the door may lock and unlock repeatedly. In this case, follow the
following correction procedures to wash the vehicle:
• Place the electronic key in a location 6 ft. (2 m) or more away from the

vehicle. (Take care to ensure that the key is not stolen.)

• Set  the  electronic  key  to  battery-saving  mode  to  disable  the  smart  key

system. (



P. 145)

●

If the electronic key is inside the vehicle and a door handle becomes wet
during a car wash, a message may be shown on the multi-information dis-
play and a buzzer will sound outside the vehicle. To turn off the alarm, lock
all the doors.

148

4-2. Opening, closing and locking the doors

MIRAI_OM_USA_OM62073U

●

The  lock  sensor  may  not  work  properly  if  it  comes  into  contact  with  ice,
snow, mud, etc. Clean the lock sensor and attempt to operate it again.

●

A sudden approach to the effective range or door handle may prevent the
doors from being unlocked. In this case, return the door handle to the origi-
nal position and check that the doors unlock before pulling the door handle
again.

●

If there is another electronic key in the detection area, it may take slightly
longer to unlock the doors after the door handle is gripped.

■

When the vehicle is not driven for extended periods

●

To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m)
of the vehicle.

●

The smart key system can be deactivated in advance. (



P. 486)

■

To operate the system properly

●

Make sure to carry the electronic key when operating the system. Do not get
the electronic key too close to the vehicle when operating the system from the
outside of the vehicle.
Depending on the position and holding condition of the electronic key, the key
may not be detected correctly and the system may not operate properly. (The
alarm may go off accidentally, or the door lock prevention function may not
operate.)

●

Do not leave the electronic key inside the trunk.
The  key  confinement  prevention  function  may  not  operate,  depending  on
the location of the key (close to the emergency tire puncture repair kit, the
inside edge of the trunk), conditions (inside a metal bag, close to metallic
objects) and the radio waves in the surrounding area. (



P. 140)

■

If the smart key system does not operate properly

●

Locking and unlocking the doors and opening the trunk:
Use the mechanical key. (



P. 449)

●

Starting the fuel cell system:



P. 450

■

Customization

Settings (e. g. smart key system) can be changed.
(Customizable features:



P. 486)

■

If the smart key system has been deactivated in a customized setting

●

Locking and unlocking the doors and opening the trunk:
Use the wireless remote control or mechanical key. (



P. 132, 138, 449)

●

Starting the fuel cell system and changing power switch modes:



P. 450

●

Stopping the fuel cell system:



P. 187

149

4-2. Opening, closing and locking the doors

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

■

Certification for the smart key system



For U.S.A.



For Canada

150

4-2. Opening, closing and locking the doors

MIRAI_OM_USA_OM62073U

WARNING

■

Caution regarding interference with electronic devices

●

People  with  implantable  cardiac  pacemakers,  cardiac  resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should keep
away from the smart key system antennas. (



P. 144)

The radio waves may affect the operation of such devices. If necessary,
the entry function can be disabled. Ask your Toyota dealer for details, such
as  the  frequency  of  radio  waves  and  timing  of  the  emitted  radio  waves.
Then, consult your doctor to see if you should disable the entry function.

●

User of any electrical medical device other than implantable cardiac pace-
makers,  cardiac  resynchronization  therapy-pacemakers  or  implantable
cardioverter defibrillators should consult the manufacturer of the device for
information about its operation under the influence of radio waves.
Radio  waves  could  have  unexpected  effects  on  the  operation  of  such
medical devices.

Ask your Toyota dealer for details for disabling the entry function.

151

4-3. Adjusting the seats

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

Front seats

■

Power easy access system

The driver’s seat and steering wheel move in accordance with power switch
mode and the driver’s seat belt condition. (



P. 153)

■

Adjusting the seat

Be careful to not allow the head restraint to touch the ceiling.

Adjustment procedure

Seat position adjustment
Seatback angle adjustment
Seat  cushion  (front)  angle
adjustment

Vertical height adjustment
Lumbar support adjustment

152

4-3. Adjusting the seats

MIRAI_OM_USA_OM62073U

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.

●

Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

●

Make sure to leave enough space around the feet so they do not get stuck.

■

Seat adjustment

To  reduce  the  risk  of  sliding  under  the  lap  belt  during  a  collision,  do  not
recline the seat more than necessary.
If  the  seat  is  too  reclined,  the  lap  belt  may  slide  past  the  hips  and  apply
restraint  forces  directly  to  the  abdomen,  or  your  neck  may  contact  the
shoulder belt, increasing the risk of death or serious injury in the event of an
accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

153

4-3. Adjusting the seats

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

Driving position memory

The seat and steering wheel are automatically adjusted to allow the
driver to enter and exit the vehicle easily.
When  all  of  the  following  have
been  performed, the driver’s seat
and  steering  wheel  are  automati-
cally  adjusted  to  a  position  that
allows driver to enter and exit the
vehicle easily.

• The  power  switch  has  been

turned off.

• The driver’s seat belt has been unfastened.

When any of the following has been performed, the driver’s seat and
steering wheel automatically return to their original positions.

• The power switch  has been turned  to ACCESSORY  mode  or  ON

mode.

• The driver’s seat belt has been fastened.

■

Operation of the power easy access system

When exiting the vehicle, the power easy access system may not operate if
the seat is already close to the rearmost position, etc.

■

Customization

The seat movement amount settings of the power easy access system can
be customized.
(Customizable features:



P. 487)

This feature automatically adjusts the front seats, steering wheel
and outside rear view mirrors to make entering and exiting the
vehicle easier or to suit your preferences.

Power easy access system

154

4-3. Adjusting the seats

MIRAI_OM_USA_OM62073U

Your preferred driving position (the position of the driver’s seat, steer-
ing wheel and outside rear view mirrors) can be recorded and recalled
by pressing a button.
Two different driving positions can be recorded into memory.

■

Recording procedure

Turn the power switch to ON mode.
Check that the shift position is in P.
Adjust  the  driver’s  seat,  steering  wheel  and  outside  rear  view
mirrors to the desired positions.
While  pressing  the  “SET”
button,  or  within  3  seconds
after  the  “SET”  button  is
pressed,  press  button  “1”  or
“2” until the buzzer sounds.

If  the  selected  button  has
already  been  preset,  the  previ-
ously  recorded  position  will  be
overwritten.

■

Recall procedure

Turn the power switch to ON mode.
Check that the shift position is in P.
Press  one  of  the  buttons  for
the driving position you want
to  recall  until  the  buzzer
sounds.

Driving position memory

1

2

3

4

1

2

3

155

4-3. Adjusting the seats

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

■

To stop the position recall operation part-way through

Perform any of the following:

●

Press the “SET” button.

●

Press button “1” or “2”.

●

Operate  any  of  the  seat  adjustment  switches  (only  cancels  seat  position
recall).

●

Operate the tilt and telescopic steering control switch (only cancels steering
wheel position recall).

■

Seat positions that can be memorized (



P. 151)

The  adjusted  positions  other  than  the  position  adjusted  by  lumbar  support
switch can be recorded.

■

Operating the driving position memory after turning the power switch off

Recorded seat positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again.

■

In order to correctly use the driving position memory function

If a seat position is already in the furthest possible position and the seat is
operated in the same direction, the recorded position may be slightly different
when it is recalled.

Each electronic key can be registered to recall your preferred driving
position.

■

Registering procedure

Record your driving position to button “1” or “2” before performing
the following:
Carry only the key you want to register, and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
recorded properly.

Turn the power switch to ON mode.
Check that the shift position is in P.
Recall the driving position that you want to record.

Memory recall function

1

2

3

156

4-3. Adjusting the seats

MIRAI_OM_USA_OM62073U

While  pressing  the  recalled
button,  press  and  hold  the
door  lock  switch  (either  lock
or  unlock)  until  the  buzzer
sounds.

If the button could not be regis-
tered, the buzzer sounds contin-
uously

for

approximately

3 seconds.

■

Recall procedure

Make sure that the doors are locked before recalling the driving
position. Carry the electronic key that has been registered to the
driving position, and then unlock and open the driver’s door using
the smart key system or wireless remote control.

The driving position will move to the recorded position (not including the
steering  wheel).  However,  the  seat  will  move  to  a  position  slightly
behind the recorded position in order to make entering the vehicle eas-
ier.
If the driving position is in a position that has already been recorded, the
seat and outside rear view mirrors will not move.

Turn  the  power  switch  to ACCESSORY  mode  or  ON  mode,  or
fasten a seat belt.

The seat and steering wheel will move to the recorded position.

■

Cancelation procedure

Carry only the key you want to cancel and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
canceled properly.

Turn the power switch to ON mode.
While  pressing  the  “SET”  button,  press  and  hold  the  door  lock
switch (either lock or unlock) until the buzzer sounds twice.

If it could not be canceled, the buzzer sounds continuously for approxi-
mately 3 seconds.

4

1

2

1

1

2

157

4-3. Adjusting the seats

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

■

Recalling the driving position using the memory recall function

●

Different driving positions can be registered for each electronic key. There-
fore, the driving position that is recalled may be different depending on the
key being carried.

●

If a door other than the driver’s door is unlocked with the smart key system,
the driving position cannot be recalled. In this case, press the driving posi-
tion button which has been set.

■

Customization

The unlock door settings of the memory recall function can be customized.
(Customizable features:



P. 487)

WARNING

■

Seat adjustment caution

Take care during seat adjustment so that the seat does not strike the rear
passenger or squeeze your body against the steering wheel.

158

4-3. Adjusting the seats

MIRAI_OM_USA_OM62073U

Head restraints



Vertical adjustment

Up

Pull the head restraint up.

Down

Push the head restraint down while
pressing the lock release button.



Horizontal adjustment

The position of the head restraint
can  be  adjusted  forward  in  4
stages.

If the head restraint is pulled forward
from  the  foremost  position,  it  will
return to the rearmost position.

Up

Pull the head restraint up.

Down

Push the head restraint down while
pressing the lock release button.

Head restraints are provided for all seats.

Front seats

Lock release button

Rear seats

Lock release button

159

4-3. Adjusting the seats

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

■

Removing the head restraints

■

Installing the head restraints

■

Adjusting the height of the head restraints (front seats)

■

Adjusting the rear seat head restraint

Always raise the head restraint from the stowed position when using.

Pull  the  head  restraint  up  while  pressing
the lock release button.
If  the  head  restraint  touches  the  ceiling,
making  the  removal  difficult,  change  the
seat height or angle. (



P. 151)

Align  the  head  restraint  with  the  installa-
tion  holes  and  push  it  down  to  the  lock
position.
Press  and  hold  the  lock  release  button
when lowering the head restraint.

Make  sure  that  the  head  restraints  are
adjusted  so  that  the  center  of  the  head
restraint is closest to the top of your ears.

WARNING

■

Head restraint precautions

Observe the following precautions regarding the head restraints.
Failure to do so may result in death or serious injury.

●

Use the head restraints designed for each respective seat.

●

Adjust the head restraints to the correct position at all times.

●

After  adjusting  the  head  restraints,  push  down  on  them  and  make  sure
they are locked in position.

●

Do not drive with the head restraints removed.

Lock
release
button

Lock
release
button

160

4-4. Adjusting the steering wheel and mirrors

MIRAI_OM_USA_OM62073U

Steering wheel

Operating the switch moves the steering wheel in the following direc-
tions:

Up
Down
Toward the driver
Away from the driver

To  sound  the  horn,  press  on  or
close to the

 mark.

■

The steering wheel can be adjusted when

The power switch is in ACCESSORY or ON mode

*

.

*

: If  the  driver’s  seat  belt  is  fastened,  the  steering  wheel  can  be  adjusted

regardless of power switch mode.

■

Automatic adjustment of the steering wheel position

A  desired  steering  wheel  position  can  be  entered  to  memory  and  recalled
automatically by the driving position memory system. (



P. 154)

■

Power easy access system

The steering wheel and driver’s seat move in accordance with power switch
mode and the driver’s seat belt condition. (



P. 153)

Adjustment procedure

Horn

161

4-4. Adjusting the steering wheel and mirrors

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

WARNING

Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.

162

4-4. Adjusting the steering wheel and mirrors

MIRAI_OM_USA_OM62073U

Inside rear view mirror

The height of the rear view mirror can be adjusted to suit your driving
posture.
Adjust the height of the rear view
mirror by moving it up and down.

Responding  to  the  level  of  brightness  of  the  headlights  of  vehicles
behind, the reflected light is automatically reduced.
Changing  automatic  anti-glare
function mode
ON/OFF

When  the  automatic  anti-glare
function is in ON mode, the indica-
tor illuminates.
The  function  will  set  to  ON  mode
each  time  the  power  switch  is
turned to ON mode.
Pressing  the  button  turns  the  function  to  OFF  mode.  (The  indicator  also
turns off.)

The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.

Adjusting the height of rear view mirror

Anti-glare function

Indicator

163

4-4. Adjusting the steering wheel and mirrors

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

■

To prevent sensor error

To ensure that the sensors operate prop-
erly, do not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.
Doing  so  may  lead  to  mishandling  of  the  vehicle  and  cause  an  accident,
resulting in death or serious injury.

164

4-4. Adjusting the steering wheel and mirrors

MIRAI_OM_USA_OM62073U

Outside rear view mirrors

To select a mirror to adjust, turn
the switch.

Left
Right

To adjust the mirror, operate the
switch.

Up
Right
Down
Left

Folds the mirrors
Extends the mirrors

Putting  the  outside  rear  view
mirror folding switch in the neu-
tral  position  sets  the  mirrors  to
automatic

mode.  Automatic

mode  allows  the  folding  or
extending  of  the  mirrors  to  be
linked to locking/unlocking of the
doors.

Adjustment procedure

1

2

Folding and extending the mirrors

165

4-4. Adjusting the steering wheel and mirrors

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

When the mirror select switch is in the “L” or “R” position, the outside
rear view mirrors will automatically angle downwards when the vehicle
is reversing in order to give a better view of the ground.
To disable this function, move the mirror select switch to the neutral
position (between “L” or “R”)

■

Adjusting the mirror angle when the vehicle is reversing

With the shift position in R, adjust the mirror angle at a desired posi-
tion.
The adjusted angle will be memorized and the mirror will automati-
cally  tilt  to  the  memorized  angle  whenever  the  shift  position  is
shifted to R from next time.

The memorized downward tilt position of the mirror is linked to the nor-
mal  position  (angle  adjusted  with  the  shift  position  in  other  than  R).
Therefore,  if  the  normal  position  is  changed  after  adjustment,  the  tilt
position will also change.
When the normal position is changed, readjust the angle in reversing.

■

Mirror angle can be adjusted when

The power switch is in ACCESSORY or ON mode.

■

Rain clearing mirrors

The coating on the mirror has the rain clearing (hydrophilic) effect to make the
rear view clearer in raining. When water droplets collect on the mirror surface,
this effect causes the droplets to be spread out into a film.

●

The rain clearing effect will be reduced temporarily, when the dirt is adhered
to the mirror or after your vehicle is parked for a long time in underground or
indoor parking lots, etc., where there is no direct sunlight.
However, the effect will gradually recover after 1- or 2-day exposure to direct
sunlight.

●

If you want to restore the rain clearing effect immediately, conduct the resto-
ration work. (



P. 353)

■

When the mirrors are fogged up

The outside rear view mirrors can be cleared using the mirror defoggers. Turn
on the rear window defogger to turn on the outside rear view mirror defog-
gers. (



P. 309)

■

Automatic adjustment of the mirror angle

A desired mirror face angle can be entered to memory and recalled automati-
cally by the driving position memory. (



P. 154)

Linked mirror function when reversing

166

4-4. Adjusting the steering wheel and mirrors

MIRAI_OM_USA_OM62073U

■

Using automatic mode in cold weather

When automatic mode is used in cold weather, the door mirror could freeze
up  and  automatic  stowing  and  return  may  not  be  possible.  In  this  event,
remove any ice and snow from the door mirror, then either operate the mirror
using manual mode or move the mirror by hand.

■

Customization

The automatic mirror folding and extending operation can be changed.
(Customizable features:



P. 488)

WARNING

■

Important points while driving

Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.

■

When a mirror is moving

To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.

■

When the mirror defoggers are operating

Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.

NOTICE

■

Handling the rain clearing mirror

The rain clearing effect is finite. Observe the following precautions in order
to retain the rain-clearing properties of the mirrors:

●

When using water repellent, oil film remover, wax, or any other car mainte-
nance product that contains silicone, pay full attention not to adhere it to
the mirror surface.

●

Do not wipe the mirror surface by using any cloth smeared with sand, oil
film remover, abrasive agent, or any other thing that may scratch the mir-
ror surface.

●

When  the  mirrors  become  iced  up,  remove  the  ice  by  applying  warm
water, or operating the outside rear view mirror defoggers.
But, do not attempt to scrape the ice off by using the plastic plate, etc.

●

When washing your vehicle using car shampoo with water repellent effect,
rinse the mirror surface with a lot of water, and remove the water drops by
using a clean and soft cloth.

167

4-5. Opening and closing the windows

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

Power windows

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:

Closing
One-touch closing

*

Opening
One-touch opening

*

*

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.

Press  the  switch  to  lock  the  pas-
senger window switches.

Use this switch to prevent children
from  accidentally  opening  or  clos-
ing a passenger window.

■

The power windows can be operated when

The power switch is in ON mode.

■

Operating the power windows after turning the fuel cell system off

The  power  windows  can  be  operated  for  approximately  45  seconds  even
after  the  power  switch  is  turned  to ACCESSORY  mode  or  turned  off. They
cannot, however, be operated once either front door is opened.

■

Jam protection function

If  an  object  becomes  jammed  between  the  window  and  the  window  frame
while the window is closing, window movement is stopped and the window is
opened slightly.

■

Catch protection function

If an object becomes caught between the door and window while the window
is opening, window movement is stopped.

Opening and closing procedures

Window lock switch

168

4-5. Opening and closing the windows

MIRAI_OM_USA_OM62073U

■

When the window cannot be opened or closed

When  the  jam  protection  function  or  catch  protection  function  operates
unusually and the door window cannot be opened or closed, perform the fol-
lowing operations with the power window switch of that door.

●

Stop the vehicle. With the power switch in ON mode, within 4 seconds of the
jam protection function or catch protection function activating, continuously
operate the power window switch in the one-touch closing direction or one-
touch opening direction so that the door window can be opened and closed.

●

If the door window cannot be opened and closed even when performing the
above operations, perform the following procedure for function initialization.

Turn the power switch to ON mode.
Pull and hold the power window switch in the one-touch closing direction
and completely close the door window.
Release  the  power  window  switch  for  a  moment,  resume  pulling  the
switch  in  the  one-touch  closing  direction,  and  hold  it  there  for  approxi-
mately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direc-
tion. After  the  door  window  is  completely  opened,  continue  holding  the
switch for an additional 1 second or more.
Release  the  power  window  switch  for  a  moment,  resume  pushing  the
switch in the one-touch opening direction, and hold it there for approxi-
mately 4 seconds or more.
Pull and hold the power window switch in the one-touch closing direction
again. After the door window is completely closed, continue holding the
switch for a further 1 second or more.

If  you  release  the  switch  while  the  window  is  moving,  start  again  from  the
beginning. If the window reverses and cannot be fully closed or opened, have
the vehicle inspected by your Toyota dealer.

■

Door lock linked window operation

●

The power windows can be opened using the mechanical key.

*

 (



P. 450)

●

The  power  windows  can  be  opened  using  the  wireless  remote  control.

*

(



P. 132)

*

: These settings must be customized at your Toyota dealer.

■

Power windows open warning buzzer

The buzzer sounds and a message is shown on the multi-information display
in the instrument cluster when the power switch is turned off and the driver’s
door is opened with the power windows open.

■

Customization

Settings (e.g. key linked operation) can be changed.
(Customizable features:



P. 488)

1

2

3

4

5

6

169

4-5. Opening and closing the windows

4

Op
eration

 o

f each

 compo

nen
t

MIRAI_OM_USA_OM62073U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

Closing the windows

●

The driver is responsible for all the power window operations, including the
operation  for  the  passengers.  In  order  to  prevent  accidental  operation,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts caught in
the power window. Also, when riding with a child, it is recommended to use
the window lock switch. (



P. 167)

●

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

●

When using the wireless remote control or mechanical key and operating
the  power  windows,  operate  the  power  window  after  checking  to  make
sure that there is no possibility of any passenger having any of their body
parts caught in the window. Also do not let a child operate window by the
wireless remote control or mechanical key. It is possible for children and
other passengers to get caught in the power window.

●

When exiting the vehicle, turn the power switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The jam protection function may not work if something gets jammed just
before  the  window  is  fully  closed.  Be  careful  not  to  get  any  part  of  your
body jammed in the window.

■

Catch protection function

●

Never  use  any  part  of  your  body  or  clothing  to  intentionally  activate  the
catch protection function.

●

The catch protection function may not work if something gets caught just
before the window is fully opened. Be careful not to get any part of your
body or clothing caught in the window.

170

4-5. Opening and closing the windows

MIRAI_OM_USA_OM62073U

171

5

Driving

MIRAI_OM_USA_OM62073U

5-1. Before driving

Driving the vehicle............. 172
Cargo and luggage ........... 180
Vehicle load limits ............. 183
Trailer towing..................... 184
Dinghy towing ................... 185

5-2. Driving procedures

Power switch ..................... 186
Transmission..................... 193
Turn signal lever................ 199
Parking brake .................... 200

5-3. Operating the lights

and wipers

Headlight switch ................ 201
Automatic High Beam ....... 205
Windshield wipers and

washer ............................ 210

5-4. Refueling

Opening the fuel door ....... 213

5-5. Using the driving

support systems

Toyota Safety Sense 2.0... 218
PCS

 (Pre-Collision System) ... 226

LDA (Lane Departure Alert

with steering control)....... 238

RSA (Road Sign Assist).... 248
Dynamic radar cruise

control ............................. 253

Intuitive parking assist....... 265
Parking Support Brake

function
(for static objects) ........... 274

BSM

(Blind Spot Monitor) ........ 286
• The Blind Spot Monitor

function ......................... 289

• The Rear Cross Traffic

Alert function................. 292

Driving assist systems ...... 295

5-6. Driving tips

Winter driving tips ............. 301

172

5-1. Before driving

MIRAI_OM_USA_OM62073U

Driving the vehicle



P. 186

With the brake pedal depressed, shift the shift position to D.
(



P. 193)

Check that the shift position indicator shows D.

Release the parking brake. (



P. 200)

Gradually release the brake pedal and gently depress the accelera-
tor pedal to accelerate the vehicle.

With the shift position in D, depress the brake pedal.
If necessary, set the parking brake.

If the vehicle is to be stopped for an extended period of time, shift the shift
position to P. (



P. 194)

With the shift position in D, depress the brake pedal.
Set the parking brake. (



P. 200)

Shift the shift position to P. (



P. 194)

Check that the shift position indicator shows P.

Press the power switch to stop the fuel cell system.
Lock the door, making sure that you have the key on your person.

If parking on a hill, block the wheels as needed.

Firmly set the parking brake and then shift the shift position to D.
Gently depress the accelerator pedal.
Release the parking brake.

The  following  procedures  should  be  observed  to  ensure  safe
driving:

Starting the fuel cell system

Driving

Stopping

Parking the vehicle

Starting off on a steep uphill

1

2

3

1

2

1

2

3

4

5

1

2

3

173

5-1. Before driving

5

Drivin

g

MIRAI_OM_USA_OM62073U

■

When starting off on an uphill

The hill-start assist control will activate. (



P. 295)

■

For fuel-efficient driving

Keep in mind that fuel cell vehicles are similar to conventional vehicles, and it
is necessary to refrain from activities such as sudden acceleration. (



P. 102)

■

Driving in the rain

●

Drive carefully when it is raining, because visibility will be reduced, the win-
dows may become fogged-up, and the road will be slippery.

●

Drive carefully when it starts to rain, because the road surface will be espe-
cially slippery.

●

Refrain  from  high  speeds  when  driving  on  an  expressway  in  the  rain,
because there may be a layer of water between the tires and the road sur-
face, preventing the steering and brakes from operating properly.

■

Restraining the fuel cell system output (Brake Override System)

●

When the accelerator and brake pedals are depressed at the same time, the
fuel cell system output may be restrained.

●

A warning message is displayed on the multi-information display while the
system is operating. If a warning message is shown on the multi-information
display, read the message and follow the instructions.

■

Restraining sudden start (Drive-Start Control)

●

When the following unusual operation is performed, the fuel cell system out-
put may be restrained.
• When the shift lever is shifted from R to D, D to R, N to R, P to D, or P to

R with the accelerator pedal depressed, a warning message appears on
the multi-information display. If a warning message is shown on the multi-
information display, read the message and follow the instructions.

• When  the  accelerator  pedal  is  depressed  too  while  the  vehicle  is  in

reverse.

●

While Drive-Start Control is being activated, your vehicle may have trou-
ble escaping from the mud or fresh snow. In such case, deactivate TRAC
(



P. 296) to cancel Drive-Start Control so that the vehicle may become

able to escape from the mud or fresh snow.

174

5-1. Before driving

MIRAI_OM_USA_OM62073U

■

Breaking in your new Toyota

To extend the life of the vehicle, observing the following precautions is recom-
mended:

●

For the first 200 miles (300 km):
Avoid sudden stops.

●

For the first 1000 miles (1600 km):
• Do not drive at extremely high speeds.
• Avoid sudden acceleration.
• Do not drive at a constant speed for extended periods.

■

Drum-in-disc type parking brake system

Your vehicle has a drum-in-disc type parking brake system. This type of brake
system needs bedding-down of the brake shoes periodically or whenever the
parking brake shoes and/or drum are replaced. Have your Toyota dealer per-
form the bedding down operation.

■

Operating your vehicle in a foreign country

Comply with the relevant vehicle registration laws and confirm the availability
of the correct fuel. (



P. 468)

175

5-1. Before driving

5

Drivin

g

MIRAI_OM_USA_OM62073U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

When starting the vehicle

Always keep your foot on the brake pedal while stopped with the “READY”
indicator is illuminated. This prevents the vehicle from creeping.

■

When driving the vehicle

●

Do not drive if you are unfamiliar with the location of the brake and accel-
erator pedals to avoid depressing the wrong pedal.
• Accidentally  depressing  the  accelerator  pedal  instead  of  the  brake

pedal will result in sudden acceleration that may lead to an accident.

• When backing up, you may twist your body around, leading to difficulty

in operating the pedals. Make sure to operate the pedals properly.

• Make  sure  to  keep  a  correct  driving  posture  even  when  moving  the

vehicle only slightly. This allows you to depress the brake and accelera-
tor pedals properly.

• Depress  the  brake  pedal  using  your  right  foot.  Depressing  the  brake

pedal using your left foot may delay response in an emergency, result-
ing in an accident.

●

The driver should pay extra attention to pedestrians when the fuel cell sys-
tem is on. As there are no engine sounds, pedestrians may misjudge the
vehicle’s movement.

●

During normal driving, do not turn off the fuel cell system. Turning the fuel
cell system off while driving will not cause loss of steering or braking con-
trol,  however,  power  assist  to  the  steering  will  be  lost.  This  will  make  it
more difficult to steer smoothly, so you should pull over and stop the vehi-
cle as soon as it is safe to do so.
In the event of an emergency, such as if it becomes impossible to stop the
vehicle in the normal way:



P. 409

●

Do not adjust the positions of the steering wheel, the seat, or the inside or
outside rear view mirrors while driving.
Doing so may result in a loss of vehicle control.

●

Always check that all passengers’ arms, heads or other parts of their body
are not outside the vehicle.

176

5-1. Before driving

MIRAI_OM_USA_OM62073U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

When driving the vehicle

●

Do not drive in excess of the speed limit. Even if the legal speed limit per-
mits it, do not drive over 85 mph (140 km/h) unless your vehicle has high-
speed capability tires. Driving over 85 mph (140 km/h) may result in tire
failure, loss of control and possible injury. Be sure to consult a tire dealer
to  determine whether the  tires on your  vehicle are high-speed capability
tires or not before driving at such speeds.

■

When driving on slippery road surfaces

●

Sudden  braking,  acceleration  and  steering  may  cause  tire  slippage  and
reduce your ability to control the vehicle.

●

Sudden acceleration or regenerative braking due to shifting could cause
the vehicle to skid.

●

After  driving  through  a  puddle,  lightly  depress  the  brake  pedal  to  make
sure that the brakes are functioning properly. Wet brake pads may prevent
the brakes from functioning properly. If the brakes on only one side are wet
and not functioning properly, steering control may be affected.

■

When changing the shift position

●

Do  not  let  the  vehicle  roll  backward  while  a  forward  driving  position  is
selected, or roll forward while the shift position is in R.
Doing so may result in an accident or damage to the vehicle.

●

Do not shift the shift position to P while the vehicle is moving.
Doing so can damage the transmission and may result in a loss of vehicle
control.

●

Do not shift the shift position to R while the vehicle is moving forward.
Doing so can damage the transmission and may result in a loss of vehicle
control.

●

Do not shift the shift position to a driving position while the vehicle is mov-
ing backward.
Doing so can damage the transmission and may result in a loss of vehicle
control.

●

Shifting the shift position to N while the vehicle is moving will disengage
the fuel cell system. Regenerative braking is not available with the fuel cell
system disengaged.

●

Be  careful  not  to  shift  the  shift  position  with  the  accelerator  pedal
depressed. Shifting the shift position to any position other than P or N may
lead  to  unexpected  rapid  acceleration  of  the  vehicle  that  may  cause  an
accident and result in death or serious injury.
After shifting the shift position, make sure to check the current shift posi-
tion using the shift position indicator. (



P. 193)

177

5-1. Before driving

5

Drivin

g

MIRAI_OM_USA_OM62073U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

If you hear a squealing or scraping noise (brake pad wear limit indica-
tors)

Have the brake pads checked and replaced by your Toyota dealer as soon
as possible.
Rotor damage may result if the pads are not replaced when needed.
It is dangerous to drive the vehicle when the wear limits of the brake pads
and/or those of the brake discs are exceeded.

■

When the vehicle is stopped

●

Do not depress the accelerator pedal unnecessarily.
If the shift position is in any position other than P or N, the vehicle may
accelerate suddenly and unexpectedly, causing an accident.

●

In order to prevent accidents due to the vehicle rolling away, always keep
depressing the  brake  pedal while stopped with the  “READY” indicator  is
illuminated, and apply the parking brake as necessary.

●

If the vehicle is stopped on an incline, in order to prevent accidents caused
by the vehicle rolling forward or backward, always depress the brake pedal
and securely apply the parking brake as needed.

■

When the vehicle is parked

●

Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in
the vehicle when it is in the sun.
Doing so may result in the following:
• Gas may leak from a cigarette lighter or spray can, and may lead to a

fire.

• The  temperature  inside  the  vehicle  may  cause  the  plastic  lenses  and

plastic material of glasses to deform or crack.

• Soft  drink  cans  may  rupture,  causing  the  contents  to  spray  over  the

interior of the vehicle, and may also cause a short circuit in the vehicle’s
electrical components.

●

Do not leave cigarette lighters in the vehicle. If a cigarette lighter is in a
place such as the glove box or on the floor, it may be lit accidentally when
luggage is loaded or the seat is adjusted, causing a fire.

●

Do not attach adhesive discs to the windshield or windows. Do not place
containers such as air fresheners on the instrument panel or dashboard.
Adhesive discs or containers may act as lenses, causing a fire in the vehi-
cle.

178

5-1. Before driving

MIRAI_OM_USA_OM62073U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

When the vehicle is parked

●

Do not leave a door or window open if the curved glass is coated with a

metallized film such as a silver-colored one. Reflected sunlight may cause

the glass to act as a lens, causing a fire.

●

Always apply the parking brake, shift the shift position to P, stop the fuel

cell system and lock the vehicle.

Do not leave the vehicle unattended while the “READY” indicator is illumi-

nated.

If the vehicle is parked with the shift position in P but the parking brake is

not set, the vehicle may start to move, possibly leading to an accident.

■

When taking a nap in the vehicle

Always turn the fuel cell system off. Otherwise, if you accidentally move the

shift lever or depress the accelerator pedal, causing the vehicle to uninten-

tionally move, which can lead to an accident, resulting in death or serious

injury.

■

When braking

●

When the brakes are wet, drive more cautiously.

Braking distance increases when the brakes are wet, and this may cause

one side of the vehicle to brake differently than the other side. Also, the

parking brake may not securely hold the vehicle.

●

If the electronically controlled brake system does not operate, do not fol-

low other vehicles closely and avoid hills or sharp turns that require brak-

ing.

In  this  case,  braking  is  still  possible,  but  the  brake  pedal  should  be

depressed more firmly than usual. Also, the braking distance will increase.

Have your brakes fixed immediately.

●

The  brake  system  consists  of  2  or  more  individual  hydraulic  systems;  if

one  of  the  systems  fails,  the  other(s)  will  still  operate.  In  this  case,  the

brake pedal should be depressed more firmly than usual and the braking

distance will increase. Have your brakes fixed immediately.

NOTICE

■

When driving the vehicle

●

Do not depress the accelerator and brake pedals at the same time during
driving, as this may restrain the fuel cell system output.

●

Do  not  use  the  accelerator  pedal  or  depress  the  accelerator  and  brake
pedals at the same time to hold the vehicle on a hill.

■

When parking the vehicle

Always set the parking brake, and shift the shift position to P. Failure to do
so may cause the vehicle to move or the vehicle may accelerate suddenly if
the accelerator pedal is accidentally depressed.

179

5-1. Before driving

5

Drivin

g

MIRAI_OM_USA_OM62073U

NOTICE

■

Avoiding damage to vehicle parts

●

Do not turn the steering wheel fully in either direction and hold it there for
an extended period of time.
Doing so may damage the power steering motor.

●

When driving over bumps in the road, drive as slowly as possible to avoid
damaging the wheels, underside of the vehicle, etc.

■

If you get a flat tire while driving

A flat or damaged tire may cause the following situations. Hold the steering
wheel firmly and gradually depress the brake pedal to slow down the vehi-
cle.

●

It may be difficult to control your vehicle.

●

The vehicle will make abnormal sounds or vibrations.

●

The vehicle will lean abnormally.

Information on what to do in case of a flat tire (



P. 432)

■

When encountering flooded roads

Do not drive on a road that has flooded after heavy rain, etc. Doing so may
cause the following serious damage to the vehicle:

●

Fuel cell system stalling

●

Short in electrical components

●

Fuel cell system damage caused by water immersion

In the event that you drive on a flooded road and the vehicle is flooded, be
sure to have your Toyota dealer check the following:

●

Fuel cell system

●

Brake function

●

Changes in quantity and quality of transmission fluid, etc.

●

Lubricant condition for the bearings and suspension joints (where possi-
ble), and the function of all joints, bearings, etc.

If the shift control system is damaged by flooding, it may not be possible to
shift the shift position to P, or from P to other positions. When the shift posi-
tion cannot be changed from P to any other position, the front wheels will
lock, and you will be unable to tow the vehicle with the front wheels on the
ground, as the front wheels may be locked. In this case, transport the vehi-
cle with both front wheels or all four wheels lifted.

■

If the vehicle will not shift out of the P position

There  is  a  possibility  that  the  12-volt  battery  is  discharged.  Check  the
12-volt battery in this situation.

180

5-1. Before driving

MIRAI_OM_USA_OM62073U

Cargo and luggage

Cargo capacity depends on the total weight of the occupants.
(Cargo capacity) = (Total load capacity) — (Total weight of occupants)

Steps for Determining Correct Load Limit —

(1) Locate  the  statement  “The  combined  weight  of  occupants  and

cargo should never exceed XXX kg or XXX lbs.” on your vehicle’s
placard.

(2) Determine the combined weight of the driver and passengers that

will be riding in your vehicle.

(3) Subtract  the  combined  weight  of  the  driver  and  passengers  from

XXX kg or XXX lbs.

(4) The resulting figure equals the available amount of cargo and lug-

gage load capacity.
For example, if the “XXX” amount equals 1400 lbs. and there will be
five  150  lb  passengers  in  your  vehicle,  the  amount  of  available
cargo and luggage load capacity is 650 lbs. (1400



 750 (5



150) =

650 lbs.)

(5) Determine the combined weight of luggage and cargo being loaded

on  the  vehicle.  That  weight  may  not  safely  exceed  the  available
cargo and luggage load capacity calculated in Step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will be

transferred to your vehicle. Consult this manual to determine how
this reduces the available cargo and luggage load capacity of your
vehicle.
 (



P. 183)

Toyota  does  not  recommend  towing  a  trailer  with  your  vehicle.  Your

vehicle is not designed for trailer towing.

Take  notice of the following information about storage  precau-
tions, cargo capacity and load.

Capacity and distribution

181

5-1. Before driving

5

Drivin

g

MIRAI_OM_USA_OM62073U

Cargo capacity
Total  load  capacity  (vehicle
capacity weight) (



P. 466)

When  2  people  with  the  combined  weight  of A  lb.  (kg)  are  riding  in
your vehicle, which has a total load capacity (vehicle capacity weight)
of B lb. (kg), the available amount of cargo and luggage load capacity
will be C lb. (kg) as follows:
B*

2

 lb. (kg) - A*

1

 lb. (kg) = C*

3

 lb. (kg)

*

1

: A =Weight of people

*

2

: B =Total load capacity

*

3

: C =Available cargo and luggage load

In this condition, if 3 more passengers with the combined weight of D

lb. (kg) get on, the available cargo and luggage load will be reduced E

lb. (kg) as follows:

C lb. (kg) - D*

4

 lb. (kg) = E*

5

 lb. (kg)

*

4

: D =Additional weight of people

*

5

: E =Available cargo and luggage load

As  shown  in  the  example  above,  if  the  number  of  occupants
increases, the cargo and luggage load will be reduced by an amount
that equals the increased weight due to the additional occupants. In
other  words,  if  an  increase  in  the  number  of  occupants  causes  an
excess of the total load capacity (combined weight of occupants plus
cargo and luggage load), you must reduce the cargo and luggage on
your vehicle.

Calculation formula for your vehicle

182

5-1. Before driving

MIRAI_OM_USA_OM62073U

WARNING

■

Things that must not be carried in the trunk

The following things may cause a fire if loaded in the trunk:

●

Vehicle receptacle containing gasoline

●

Aerosol cans

■

Storage precautions

Observe the following precautions.

Failure to do so may prevent the pedals from being depressed properly,

may block the driver’s vision, or may result in items hitting the driver or

passengers, possibly causing an accident.

●

Stow cargo and luggage in the trunk whenever possible.

●

Do not place cargo or luggage in or on the following locations.
• At the feet of the driver

• On the front passenger or rear seats (when stacking items)

• On the package tray

• On the instrument panel

• On the dashboard

●

Secure all items in the occupant compartment.

■

Capacity and distribution

●

Do  not  exceed  the  maximum  axle  weight  rating  or  the  total  vehicle

weight rating.

●

Even if the total load of occupant’s weight and the cargo load is less

than the total load capacity, do not apply the load unevenly. Improper

loading  may  cause  deterioration  of  steering  or  braking  control  which

may cause death or serious injury.

183

5-1. Before driving

5

Drivin

g

MIRAI_OM_USA_OM62073U

Vehicle load limits

◆

Total load capacity (vehicle capacity weight): (



P. 466)

Total load capacity means the combined weight of occupants, cargo
and luggage.

◆

Seating capacity: 4 occupants (Front 2, Rear 2)

Seating capacity means the maximum number of occupants whose
estimated average weight is 150 lb. (68 kg) per person.

◆

Towing capacity

Toyota does not recommend towing a trailer with your vehicle.

◆

Cargo capacity

Cargo capacity may increase or decrease depending on the weight
and the number of occupants.

■

Total load capacity and seating capacity

These details are also described on the tire and loading information label.

(



P. 393)

Vehicle load limits include total load capacity, seating capacity,
towing capacity and cargo capacity.

WARNING

■

Overloading the vehicle

Do not overload the vehicle.

It  may  not  only  cause  damage  to  the  tires,  but  also  degrade  steering

and braking ability, resulting in an accident.

184

5-1. Before driving

MIRAI_OM_USA_OM62073U

Trailer towing

Toyota does not recommend towing a trailer with your vehicle.
Toyota also does not recommend the installation of a tow hitch
or the use of a tow hitch carrier for a wheelchair, scooter, bicy-
cle, etc. Your vehicle is not designed for trailer towing or for the
use of tow hitch mounted carriers.

185

5-1. Before driving

5

Drivin

g

MIRAI_OM_USA_OM62073U

Dinghy towing

Your vehicle is not designed to be dinghy towed (with 4 wheels
on the ground) behind a motor home.

NOTICE

■

To avoid serious damage to your vehicle

Do not tow your vehicle with four wheels on the ground.

186

5-2. Driving procedures

MIRAI_OM_USA_OM62073U

Power switch

Check that the parking brake is set.
Firmly depress the brake pedal.

 will be displayed on the multi-information display.

If it is not displayed, the fuel cell system cannot be started.
When shift position N is selected, the fuel cell system cannot start. Select
the P position when starting the fuel cell system. (



P. 194)

Press  the  power  switch  shortly
and firmly.

When  operating  the  power  switch,
one short, firm press is enough.
It  is  not  necessary  to  press  and
hold the switch.
If  the  “READY”  indicator  turns  on,
the  fuel  cell  system  will  operate
normally.
Continue  depressing  the  brake
pedal  until  the  “READY”  indicator
is illuminated.
The fuel cell system can be started
from any power switch mode.

Check that the “READY” indicator is illuminated.

The vehicle will not move when the “READY” indicator is off.

Performing  the  following  operations  when  carrying  the  elec-
tronic key on your person starts the fuel cell system or changes
power switch modes.

Starting the fuel cell system

1

2

3

4

187

5-2. Driving procedures

5

Drivin

g

MIRAI_OM_USA_OM62073U

Stop the vehicle completely.
Set the parking brake. (



P. 200)

Press  the  P  position  switch.
(



P. 194)

Check that the shift position indica-
tor shows P. (



P. 193)

Press the power switch.

The meter display will turn off, indicating the fuel cell system has stopped.
(The shift position indicator is displayed for several seconds)
The H

2

O indicator will illuminate, indicating exhaust water is being purged.

Release the brake pedal and check that the meter display is off.

When the fuel cell system is stopped, water is automatically purged
from the tailpipe. To minimize water accumulation at parking garages,
etc., purge can be done manually before parking.
While  the  “READY”  indicator  is
on, press the H

2

O switch.

The  H

2

O  indicator  on  the  meter

turns on.

Press the switch again to stop the
purge.
Remember that water is being gen-
erated as long as the fuel cell sys-
tem  is  operating.  So  a  small
amount of water will be generated
after  manual  purging  and  before
parking.

Stopping the fuel cell system

1

2

3

Water release (H

2

O switch)

4

5

188

5-2. Driving procedures

MIRAI_OM_USA_OM62073U

Modes can be changed by pressing the power switch with brake pedal
released. (The mode changes each time the switch is pressed.)

Off

The  emergency  flashers  can  be
used.

ACCESSORY mode

Some  electrical  components  such
as the audio system can be used.
“Accessory”  will  be  displayed  on
the main display.

ON mode

All  electrical  components  can  be
used.
“Ignition  On”  will  be  displayed  on
the main display.

■

Auto power off function

If the vehicle is left in ACCESSORY mode for more than 20 minutes or ON
mode (the fuel cell system is not operating) for more than an hour with the
shift position in P, the power switch will automatically turn off. However, this
function cannot entirely prevent 12-volt battery discharge. Do not leave the
vehicle with the power switch in ACCESSORY or ON mode for long periods
of time when the fuel cell system is not operating.

■

Sounds and vibrations specific to a fuel cell vehicle



P. 88

■

Electronic key battery depletion



P. 130

Changing power switch modes

189

5-2. Driving procedures

5

Drivin

g

MIRAI_OM_USA_OM62073U

■

Starting the fuel cell system in cold temperatures

●

When the power switch is pressed and the fuel cell system starts (



P. 186)

during cold temperatures, the fuel cell stack is quickly warmed up using the
waste heat during power generation.

●

When  the  temperatures  is  cold,  it  may  take  some  time  until  the  “READY”
indicator turns on.

●

When starting the fuel cell system during cold weather, “FC System Shut-
down  due  to  Freezing  conditions  Stop  Your  Vehicle  in  a  Safe  Place  and
Contact Your Dealer” may be displayed in the multi-information display.
The  fuel  cell  system  is  frozen  and  can  not  be  started.  Contact  a  Toyota
dealer.

●

The  power  output  will  be  temporarily  limited  until  the  fuel  cell  system
reaches full operating temperature.

●

The  fuel  cell  system  noises  may  become  louder  when  the  temperature  is
cold.  This  is  the  normal  warm-up  operation  and  is  not  a  malfunction.  In
some cases, operation noises may continue for a some time even after the
“READY” indicator has turned on. (



P. 88)

■

Stopping the fuel cell system in cold temperatures

●

When  the  power  switch  is  pressed  and  the  fuel  cell  system  is  stopped
(



P. 187) during cold temperatures, the time for water purge from the tail-

pipe may be longer than usual to prevent liquid in the fuel cell stack from
freezing.

●

The water purge time may also be long if the system is stopped before fuel
cell system warm-up is completed.

●

It is normal to hear hissing and other sounds during purge. (



P. 88)

●

The H

2

O indicator on the meter will illuminate during purge.

●

In  extremely  cold  temperatures,  the
“READY”  indicator  may  take  more  than
10  seconds  to  illuminate.  In  this  case,
the  status  progression  of  the  fuel  cell
system startup is displayed on the multi-
information display.

190

5-2. Driving procedures

MIRAI_OM_USA_OM62073U

■

Parking the vehicle during cold weather

●

Water  may  automatically  purge  from  the  tailpipe,  even  when  the  fuel  cell
system is off, in order to prevent liquid in the fuel cell stack, hydrogen pipe-
lines, etc., from freezing.

●

It is normal to hear hissing and other sounds during purge. (



P. 88)

●

The H

2

O indicator on the meter will illuminate during purge.

■

Water release function during cold weather

In the following cases, the fuel cell system automatic drainage may not oper-
ate.  It  may  not  be  possible  to  start  the  fuel  cell  system  due  to  the  fuel  cell
stack, hydrogen pipes, etc, being frozen.

• When transporting or towing the vehicle in frozen areas
• When the 12-volt battery terminals are disconnected and remain as such

in frozen areas

Operate the water release function with the following procedure beforehand
to prevent water from freezing in the system.

Turn the power switch to ON mode and press the H

2

O switch.

Check that the H

2

O indicator on the meter turns on.

While depressing the brake, press the power switch to start the fuel cell
system.
Check that the “READY” indicator turns on.
Press the power switch to stop the fuel cell system.
The  water  release  is  automatically  performed.  During  water  purge,  the
H

2

O indicator turns on. (Longer than normal water purge)

■

Conditions affecting operation



P. 146

■

Notes for the entry function



P. 147

■

If the fuel cell system does not start

●

The immobilizer system may not have been deactivated. (



P. 78)

Contact your Toyota dealer.

●

Check that the shift position is P. (



P. 193)

The fuel cell system cannot be started when the shift position is N.
If P position is not selected, “Shift to P position to start” will be displayed on
the multi-information display.

●

Check that the fuel door is closed.
When the fuel door is open, the fuel cell system cannot be started.
Close the fuel door before starting the system. (



P. 216)

1

2

3

191

5-2. Driving procedures

5

Drivin

g

MIRAI_OM_USA_OM62073U

■

If “Smart Key System Malfunction See Owner’s Manual” is displayed on
the multi-information display

The  system  may  be  malfunctioning.  Have  the  vehicle  inspected  by  your
Toyota dealer immediately.

■

If the “READY” indicator does not come on

In the event that the “READY” indicator does not come on even after perform-
ing the proper procedures for starting the vehicle, contact your Toyota dealer
immediately.

■

If the fuel cell system is malfunctioning



P. 426

■

If the electronic key battery is depleted



P. 400

■

Operation of the power switch

If the switch is not pressed shortly and firmly, the power switch mode may not
change or the fuel cell system may not start.

■

Automatic P position selection function

●

When the shift position is other than P, pressing the power switch with the
vehicle stopped completely will cause the shift position to change to P auto-
matically, and then the power switch will turn off.

●

When turning the power switch off with the shift position other than P, firmly
depress the brake pedal and confirm that the shift position* has changed to
P before slowly releasing the brake pedal.

*

: Even  after  the  instrument  panel  display  has  been  turned  off,  the  shift

position indicator will continue to be displayed for several seconds.

■

If the shift control system malfunctions

The power switch will not be able to be turned off. In this occurs, the switch
can be turned off by applying the parking brake.
If the system malfunctions, have your vehicle serviced by your Toyota dealer
immediately.

■

If the smart key system has been deactivated in a customized setting



P. 486

192

5-2. Driving procedures

MIRAI_OM_USA_OM62073U

WARNING

■

When starting the fuel cell system

Always  start  the  fuel  cell  system  while  sitting  in  the  driver’s  seat.  Do  not
depress the accelerator pedal while starting the fuel cell system under any
circumstances.
Doing so may cause an accident resulting in death or serious injury.

■

Stopping the fuel cell system in an emergency

If you want to stop the fuel cell system in an emergency while driving the
vehicle, press and hold the power switch for more than 2 seconds, or press
it briefly 3 times or more in succession. (



P. 409)

However, do not touch  the power switch  while driving  except in  an  emer-
gency. Turning  the  fuel  cell  system  off while  driving will  not  cause loss  of
steering  or  braking  control,  however,  power  assist  to  the  steering  will  be
lost. This will make it more difficult to steer smoothly, so you should pull over
and stop the vehicle as soon as it is safe to do so.

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the power switch in ACCESSORY or ON mode for long peri-
ods if the fuel cell system is off.

■

When starting the fuel cell system

If the fuel cell system becomes difficult to start, have your vehicle checked
by your Toyota dealer immediately.

■

Symptoms indicating a malfunction with the power switch

If the power switch seems to be operating somewhat differently than usual,
such  as  the  switch  sticking  slightly,  there  may  be  a  malfunction.  Contact
your Toyota dealer immediately.

193

5-2. Driving procedures

5

Drivin

g

MIRAI_OM_USA_OM62073U

Transmission

Shift lever
Operate  the  shift  lever  gently
and  ensure  correct  shifting
operation.
Release  the  shift  lever  after
each shifting operation to allow
it return to the

 position.

When  shifting  to  the  D
or  R  positions,  move
the shift lever along the
shift gate.
To  shift  to  the  N  posi-
tion, slide the shift lever
to  the  left  and  hold  it.
The  shift  position  will
change to N.
To shift to the Br mode, pull the shift lever to the rear along
the shift gate. Shifting to Br mode is only possible when the
shift position D is selected.

When  shifting  from  P  to  N,  D  or  R,  from  D  to  R,  or  from  R  to  D,
ensure that the brake pedal is being depressed and that the vehicle
is stationary.
Shift position indicator
When  selecting  a  shift  position,  make  sure  that  the  shift  position
has  been  changed  to  the  desired  position  by  checking  the  shift
position indicator provided on the instrument panel.

Shifting the shift lever

194

5-2. Driving procedures

MIRAI_OM_USA_OM62073U

The shift position can be changed to P through the use of the P posi-
tion switch.
Fully  stop  the  vehicle  and  keep
depressing  the  brake  pedal,  and
then press the P position switch.

When the shift position is changed
to P, the switch indicator comes on.
Check that the P position indicator
is  illuminated  on  the  shift  position
indicator.

■

Shifting the shift position from P to other positions

While depressing the brake pedal firmly, operate the shift lever. If
the  shift  lever  is  operated  without  depressing  the  brake  pedal,  a
buzzer will sound and the shifting operation will be disabled.

Shift position purpose

Shift position

Objective or function

P

Parking the vehicle/starting the fuel cell system

R

Reversing

N

Neutral

D

Normal driving

P position switch

195

5-2. Driving procedures

5

Drivin

g

MIRAI_OM_USA_OM62073U

The following modes can be selected to suit driving conditions.

■

Eco drive mode/Power mode

Eco drive mode
Suitable  for  improving  the
fuel  economy,  because  the
torque  corresponding  to  the
accelerator  pedal  depres-
sion  amount  can  be  gener-
ated more smoothly than it is
in normal conditions.

 is displayed on the air conditioning screen and the system

goes into ECO HEAT/COOL mode. (



P. 308)

When  the  “ECO  MODE”  switch  is  pressed,  the  “ECO  MODE”
indicator will illuminate on the main display.
To cancel Eco drive mode, press the “ECO MODE” switch again.
At this time, the ECO HEAT/COOL mode is canceled.
Power mode
Use when high levels of response and feeling are desirable, such
as when driving in mountainous regions or when overtaking.
When  the  “POWER  MODE”  switch  is  pressed,  the  POWER
MODE indicator will illuminate on the main display.
To cancel power mode, press the “POWER MODE” switch again.

■

Br mode

Suitable for driving that requires
strong  regenerative  braking,
such as down-hill driving, etc.
To select Br mode, shift the shift
lever down. (



P. 193)

The Br mode indicator will illumi-
nate on the meter.

To return to normal driving mode, depress the accelerator pedal or
select the D position again with the shift lever.

Selecting a drive mode

196

5-2. Driving procedures

MIRAI_OM_USA_OM62073U

■

For the shift positions

●

When the power switch is off, the shift position cannot be changed.

●

When the power switch is in ON mode (the fuel cell system is not operating),
the  shift  position  can  only  be  changed  to  N.  The  shift  position  will  be
changed to N even if the shift position is shifted to D or R and held in that
position.

●

When the “READY” indicator is on, the shift position can be changed from P
to D, N or R.

●

When  the  “READY”  indicator  is  flashing,  the  shift  position  cannot  be
changed from P to another position even if the shift lever is operated.
Wait until the “READY” indicator changes from a flashing to a solid light, and
then operate the shift lever again.

In addition, if an attempt is made to change the shift position by moving the
shift lever or by pressing the P position switch in any of the following situa-
tions,  a  buzzer  will  sound  and  the  shifting  operation  will  be  disabled  or  the
shift  position  will  automatically  change  to  N.  When  this  happens,  select  an
appropriate shift position.

●

When attempting to change the shift position from P without depressing the
brake pedal, the shift position change is invalidated.

●

Situations where the shift position will automatically change to N:
• When the P position switch is pressed while the vehicle is running.

*

1

• When  an  attempt  is  made  to  select  the  R  position  by  moving  the  shift

lever when the vehicle is moving forward.

*

2

• When  an  attempt  is  made  to  select  the  D  position  by  moving  the  shift

lever when the vehicle is moving in reverse.

*

3

• When an attempt is made to change the shift position from R to Br mode

by moving the shift lever.

*

1

: Shift position may be changed to P when driving at extremely low speeds.

*

2

: Shift position may be changed to R when driving at low speeds.

*

3

: Shift position may be changed to D when driving at low speeds.

■

Br mode

Depending on the condition of the traction battery, Br mode may not be avail-
able.
In that case, a message is displayed on the multi-information display.

■

Sounds when in Br mode



P. 88

■

Restraining sudden start (Drive-Start Control)



P. 173

■

Reverse warning buzzer

When  shifting  into  R,  a  buzzer  will  sound  to  inform  the  driver  that  the  shift
position is in R.

197

5-2. Driving procedures

5

Drivin

g

MIRAI_OM_USA_OM62073U

■

Regenerative Braking

When the shift position is in D, regenerative braking is engaged when the foot
is released from the accelerator pedal.

■

ECO HEAT/COOL mode operation for Eco drive mode

●

When  the  “ECO  MODE”  switch  is  pressed,  the  system  switches  over  to
ECO HEAT/COOL mode. (



P. 311) During the use of Eco drive mode, only

the ECO HEAT/COOL mode can be canceled.

●

When it is desired to improve the effectiveness of the air conditioning sys-
tem, perform the following operations.
• Adjust the temperature settings and airflow mode.
• Press

 of the air conditioning operation panel (



P. 306) and can-

cel the ECO HEAT/COOL mode, or cancel Eco drive mode.

■

Power mode automatic deactivation

Power mode is automatically deactivated if the power switch is turned off after
driving in power mode.

■

Shifting from P on a slope

When changing to another position from P when parked on a slope in the P
position, vibrations may be felt.

WARNING

■

When driving on slippery road surfaces

Do not accelerate or shift the shift position suddenly.
Sudden changes in regenerative braking may cause the vehicle to spin or
skid, resulting in an accident.

■

For the shift lever

Do not  remove  the shift  lever knob  or  use  anything  but  a genuine Toyota
shift lever knob. Also, do not hang anything on the shift lever.
Doing  so  could  prevent  the  shift  lever  from  returning  to  position,  causing
unexpected accidents to occur when the vehicle is in motion.

■

P position switch

Do not press the P position switch while the vehicle is moving.
If  the  P  position  switch  is  pressed  when  driving  at  very  low  speeds  (for
example,  directly  before  stopping  the  vehicle),  the  vehicle  may  stop  sud-
denly when the shift position switches to P, which could lead to an accident.

198

5-2. Driving procedures

MIRAI_OM_USA_OM62073U

NOTICE

■

Situations where shift control system malfunctions are possible

If  any  of  the  following  situations  occurs,  shift  control  system  malfunctions
are possible.
Immediately stop the vehicle in a safe place on level ground, apply the park-
ing brake, and then contact your Toyota dealer.

●

When  a  warning  message  indicating  malfunction  appears  on  the  multi-
information display. (



P. 426)

●

When the shift position indicator remains off.

■

If the vehicle cannot be shifted out of P

There  is  a  possibility  that  the  12-volt  battery  is  discharged.  Check  the
12-volt battery in this situation.

■

Notes regarding shift lever and P position switch operation

Avoid repeatedly operating the shift lever and P position switch in quick suc-
cession.
The system protection function may activate and it will not be temporarily
possible to shift the shift position other than P. If this happens, please wait
for a while before attempting to change the shift position again.

199

5-2. Driving procedures

5

Drivin

g

MIRAI_OM_USA_OM62073U

Turn signal lever

Right turn
Lane change to the right (move
the  lever  partway  and  release
it)

The  right  hand  signals  will  flash  3
times.

Lane  change  to  the  left  (move
the  lever  partway  and  release
it)

The  left  hand  signals  will  flash  3
times.

Left turn

■

Turn signals can be operated when

The power switch is in ON mode.

■

If the indicator flashes faster than usual

Check that a light bulb in the front or rear turn signal lights has not burned
out.

Operating instructions

200

5-2. Driving procedures

MIRAI_OM_USA_OM62073U

Parking brake

To  set  the  parking  brake,  fully
depress  the  parking  brake  pedal
with  your  left  foot  while  depress-
ing the brake pedal with your right
foot.
(Depressing  the  pedal  again
releases the parking brake.)

■

Parking the vehicle



P. 172

■

Parking brake engaged warning buzzer

A buzzer will sound if the vehicle is driven with the parking brake engaged.
“Release Parking Brake” is displayed on the multi-information display.

■

Warning messages and buzzers

Warning messages and buzzers are used to indicate a system malfunction or
to inform the driver of the need for caution. If a warning message is shown on
the multi-information display, read the message and follow the instructions.

■

If the brake system warning light comes on



P. 418

■

Usage in winter time



P. 302

Operating instructions

(U.S.A.)

(Canada)

NOTICE

■

When parking the vehicle

Before  you  leave  the  vehicle,  shift  the  shift  position  to  P,  set  the  parking
brake and make sure that the vehicle does not move.

■

Before driving

Fully release the parking brake.
Driving the vehicle with the parking brake set will lead to brake components
overheating,  which  may  affect  braking  performance  and  increase  brake
wear.

201

5-3. Operating the lights and wipers

5

Drivin

g

MIRAI_OM_USA_OM62073U

Headlight switch

Operating the

 switch turns on the lights as follows:



For U.S.A.

The  side  marker,  park-
ing,  tail,  license  plate,
instrument  panel  lights,
and  daytime  running
lights  (



P.  203)  turn

on.
The  headlights  and  all
lights

listed

above

(except  daytime  run-
ning lights) turn on.
The  headlights,  park-
ing,  daytime  running
lights (



P. 203) and all

the  lights  listed  above
turn  on  and  off  auto-
matically  (when  the
power  switch  is  in  ON
mode).
The daytime running lights turn off. (



P. 203)

The headlights can be operated manually or automatically.

Operating instructions

202

5-3. Operating the lights and wipers

MIRAI_OM_USA_OM62073U



For Canada

The  side  marker,  park-
ing,  tail,  license  plate,
instrument  panel  lights,
and  daytime  running
lights  (



P.  203)  turn

on.
The  headlights  and  all
lights

listed

above

(except  daytime  run-
ning lights) turn on.
The  headlights,  park-
ing,  daytime  running
lights (



P. 203) and all

the  lights  listed  above
turn  on  and  off  auto-
matically  (when  the
power  switch  is  in  ON
mode).
The daytime running lights turn on. (



P. 203)

203

5-3. Operating the lights and wipers

5

Drivin

g

MIRAI_OM_USA_OM62073U

With  the  headlights  on,  push
the lever away from you to turn
on the high beams.

Pull  the  lever  toward  you  to  the
center  position  to  turn  the  high
beams off.

Pull  the  lever  toward  you  and
release  it  to  flash  the  high
beams once.

You can flash the high beams with the headlights on or off.

■

Daytime running light system

●

The daytime running lights illuminate using the same lights as the parking
lights and illuminate brighter than the parking lights.

●

To make your vehicle more visible to other drivers during daytime driving,
the  daytime  running  lights  turn  on  automatically  when  all  of  the  following
conditions are met. (The daytime running lights are not designed for use at
night.)
• The fuel cell system is operating
• The parking brake is released
• The headlight switch is in the

 (Canada only),

 or

*

 position

*

: When the surroundings are bright

The daytime running lights remain on after they illuminate, even if the parking
brake is set again.

●

For  the  U.S.A.:  Daytime  running  lights  can  be  turned  off  by  operating  the
switch.

●

Compared  to  turning  on  the  headlights,  the  daytime  running  light  system
offers greater durability and consumes less electricity, so it can help improve
fuel economy.

■

Headlight control sensor

Turning on the high beam headlights

The sensor may not function properly if an
object is placed on the sensor, or anything
that  blocks  the  sensor  is  affixed  to  the
windshield.
Doing  so  interferes  with  the  sensor
detecting  the  level  of  ambient  light  and
may  cause  the  automatic  headlight  sys-
tem to malfunction.

204

5-3. Operating the lights and wipers

MIRAI_OM_USA_OM62073U

■

Automatic light off system

●

When the headlights are on: The headlights and tail lights turn off 30 sec-
onds  after  a  door  is  opened  and  closed  if  the  power  switch  is  turned  to
ACCESSORY mode or turned off. (The lights turn off immediately if
on the key is pressed after all the doors are locked.)

●

When only the tail lights are on: The tail lights turn off automatically if the
power switch is turned to ACCESSORY mode or turned off and the driver’s
door is opened.

To turn the lights on again, turn the power switch to ON mode, or turn the light
switch

 or

 once and then back to

or

.

If any of the doors or trunk lid is kept open, the lights automatically turn off
after 20 minutes.

■

Automatic headlight leveling system

The level of the headlights is automatically adjusted according to the number
of  passengers  and  the  loading  condition  of  the  vehicle  to  ensure  that  the
headlights do not interfere with other road users.

■

Light reminder buzzer

A buzzer sounds when the power switch is turned off or turned to ACCES-
SORY mode and the driver’s door is opened while the lights are turned on.

■

12-volt battery-saving function

In order to prevent the 12-volt battery of the vehicle from discharging, if the
headlights  and/or  tail  lights  are  on  when  the  power  switch  is  turned  off  the
12-volt battery saving function will operate and automatically turn off all the
lights after approximately 20 minutes. When the power switch is turned to ON
mode, the 12-volt battery-saving function will be disabled.
When any of the following are performed, the 12-volt battery-saving function
is canceled once and then reactivated. All the lights will turn off automatically
20 minutes after the 12-volt battery-saving function has been reactivated:

●

When the headlight switch is operated

●

When a door is opened or closed

■

Customization

Settings (e.g. light sensor sensitivity) can be changed.
(Customizable features:



P. 488)

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the lights on longer than necessary when the fuel cell system
is off.

205

5-3. Operating the lights and wipers

5

Drivin

g

MIRAI_OM_USA_OM62073U

Automatic High Beam

Push  the  lever  away  from  you
with  the  headlight  switch  in

 or

 position.

Press  the  Automatic  High
Beam switch.

The Automatic  High  Beam  indica-
tor  will  come  on  when  the  head-
lights  are  turned  on  automatically
to  indicate  that  the  system  is
active.

The Automatic High Beam uses an in-vehicle camera sensor to
assess the brightness of streetlights, the lights of oncoming and
preceding vehicles, etc., and automatically turns high beam on
or off as necessary.

Activating the Automatic High Beam system

1

2
