5-1. Using the air conditioning system and defogger

Rear air conditioning system

■

Adjusting the temperature setting

Press “



” to increase the temperature and “



” to decrease the tem-

perature on

The temperature for the right-hand and left-hand seats can be set sepa-
rately.

■

Adjusting the fan speed setting

Press “



” (increase) or “



” (decrease) on

The fan speed is shown on the display. (7 levels)

Press

to turn the fan off.

Air outlets and fan speed are automatically adjusted according
to the temperature setting.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

403

5-1. Using the air conditioning system and defogger

■

Using the automatic mode

Press

Adjust the temperature setting.

To stop the operation, press

■

If the system is operated manually in automatic mode

If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.

■

Location of air outlets

The air outlets and air volume
changes according to the
selected air flow mode.

■

Adjusting the position of and opening and closing the air out-
lets

Direct  air  flow  to  the  left  or
right, up or down.
Turn  the  knob  fully  to  the
back  of  the  vehicle  to  close
the vent.

Air conditioning controls

Air outlets

-------------------------------------------------------------------------------------------------------------------------------------------------------------

405

LC200_OM_OM60R53U_(U)

5-1. Using the air conditioning system and defogger

Heated steering wheel



/seat heaters/seat

ventilators



: If equipped

Heated steering wheel and seat heaters heat the side grips of the
steering wheel and seats. Seat ventilators maintain good airflow
by blowing air from the seats.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

●

Observe the following precautions to prevent the minor burns or overheat-
ing:
• Do not cover the seat with a blanket or cushion when using the seat

heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is
not running.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

406

LC200_OM_OM60R53U_(U)

Turns the heated steering wheel
on/off

The indicator light comes on when
the heated steering wheel is oper-
ating.

●

The heated steering wheel can be used when the engine switch is in IGNI-
TION ON mode.

●

The heated steering wheel will automatically turn off after about 30 minutes.

●

If the indicator light flashes, press the switch to turn the heated steering
wheel off and then press the switch again. If the indicator light still flashes, a
malfunction may be occurring. Turn the heated steering wheel off and have
the vehicle inspected by your Toyota dealer.

Seat heater switches

The indicator light (yellow) on the
switch comes on when the seat
heater is operating.

Seat ventilator switches

The indicator light (green) on the
switch comes on when the seat
ventilator is operating.

Level indicator lights

The  seat  heater  temperature  level
or  the  seat  ventilator  fan  speed
level  (for  front  seats  only)  is  dis-
played.

“AUTO” indicator lights

Heated steering wheel (if equipped)

Front seat heaters and ventilators

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

407

5-1. Using the air conditioning system and defogger

5-1. Using the air conditioning system and defogger

■

Modes and indicators

The mode can be changed by pressing the switch.

: When automatic mode is selected, the level automatically changes

depending on the air conditioning settings.

■

The seat heaters and ventilators can be used when

The engine switch is in IGNITION ON mode.

■

Replacing the air filters

Filters are installed in the seat ventilators. For replacement of the filters, con-
tact your Toyota dealer.

■

Customization

The automatic mode settings for the seat heaters and ventilators can be
changed. (



P. 590)

Mode

“AUTO” indicator light

Level indicator lights

Off

Automatic*

3 to 1, or off

Off

Mid

Off

-------------------------------------------------------------------------------------------------------------------------------------------------------------

408

LC200_OM_OM60R53U_(U)

For left-hand second seat
For right-hand second seat
High heating temperature
Low heating temperature

To turn on the seat heater, press
“HI” or “LO”.

Off

■

The seat heaters can be used when

The engine switch is in IGNITION ON mode.

Second outboard seat heaters (if equipped)

1
2
3
4

-------------------------------------------------------------------------------------------------------------------------------------------------------------

409

LC200_OM_OM60R53U_(U)

5-2. Using the interior lights

Interior lights list

Front interior lights (



P. 410)

Front personal lights (

P. 411)

Rear interior lights (

5-2. Using the interior lights

P. 410)

Rear personal lights (



P. 411)

Inside door handle lights

Footwell lights
Scuff lights
Engine switch light
Door courtesy lights
Door trim lights

1
2
3
4
5

6
7
8
9

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

411



Front

Turns the light on/off



Rear

Turns the light on/off

■

Illuminated entry system

The lights automatically turn on/off according to engine switch mode, the
presence of the electronic key, whether the doors are locked/unlocked, and
whether the doors are open/closed.

■

To prevent battery discharge

If the interior lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes:

■

Customization

Settings (e.g. adjust the time elapsed before the interior lights automatically
turn off) can be changed. (Customizable features:



P. 590)

Personal lights

NOTICE

To prevent battery discharge, do not leave the lights on longer than neces-
sary when the engine is not running.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

412

LC200_OM_OM60R53U_(U)

List of storage features

Card holders (



Overhead console (

Glove box (

Bottle holders (



P. 418)

Door pockets
Auxiliary boxes (

Console box (

Cool box (if equipped)
(

Cup holders (

Auxiliary box (if equipped)
(

P. 419)

Wireless charger (if equipped)
(

P. 429)

WARNING

■

Items that should not be left in the storage spaces

Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:

●

Glasses may be deformed by heat or cracked if they come into contact
with other stored items.

●

Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.

1
2
3
4
5
6

8
9

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

413

Open (push button)
Lock with the mechanical key
Unlock with the mechanical key

■

Glove box light

The glove box light turns on when the tail lights are on.

■

Removing the separate tray

Glove box

1
2
3

Pull out the separate tray while releasing
the clips.

WARNING

Keep the glove box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

414

LC200_OM_OM60R53U_(U)

Your vehicle is equipped with either a lower console box or cool box.
For vehicles with the cool box, refer to page 423.



Upper console box

Press the tab to open.



Lower console box (if equipped)

Lift the lever to open.

Remove the tray.

Console box

WARNING

Keep the console box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

415

Press the button.

Overhead console

WARNING

■

Items unsuitable for storing

Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the overhead console to open and the items inside
may fall out, resulting in an accident.

■

While driving

Do not leave the overhead console open.
Items may fall out and cause injury.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

416

LC200_OM_OM60R53U_(U)

Cup holders



Front seats



Second seats

Press down and release the lid.

You can adjust or remove the sep-
arator inside.

To open, pull down the armrest,
press the button and release the
rear cup holder on the armrest.



Third seats (if equipped)



Luggage

compartment

(if

equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

417

■

Removing the cup holder insert (front cup holders)

Pull up the insert.

Cup holder insert may be removed for
cleaning.

WARNING

■

Items unsuitable for the cup holder

Do not place anything other than cups or beverage cans in the cup holders.
Even with the lid is closed, items must not be stored in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, cause injury. If possible, cover hot drinks to prevent burns.

■

When not in use

Keep the cup holders closed.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.

NOTICE

■

To prevent damage to the cup holders (vehicles with a rear cup holder)

Stow the cup holders before stowing the rear armrest.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

418

LC200_OM_OM60R53U_(U)

Bottle holders



Front seats



Second seats

NOTICE

■

Items that should not be stowed in the bottle holders

Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

419

Your vehicle is equipped with either a front auxiliary box or wireless
charger.
For vehicles with wireless charger, refer to page 429.

Card holders



Sun visor



Instrument panel

Auxiliary boxes



Front (if equipped)



Rear (type A)

Press the lid to open.



Rear (type B)

Press the button to open.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

420

LC200_OM_OM60R53U_(U)

Luggage compartment features

Raise the hook to use.

The cargo hooks are provided for
securing loose items.

To hang the cargo net, use the
cargo net hooks and rear tie-down
hooks.

The cargo net itself is not included
as an original equipment.

Remove the cover. Hold the warn-
ing reflector with the bands.

The warning reflector itself is not
included as an original equipment.

Cargo hooks

Cargo net hooks

Warning reflector holder

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

421

Remove the cover. Hold the first-
aid kit with a band.

The first-aid kit itself is not included
as an original equipment.

■

Using the luggage cover

Pull out the luggage cover and
hook it on the anchors.

■

Removing the luggage cover

Retract the cover and release
both ends, then lift it out.

After removing the luggage
cover, place it somewhere other
than the passenger compart-
ment.

First-aid kit holder

Luggage cover (if equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

422

LC200_OM_OM60R53U_(U)

■

When installing the luggage cover (if equipped)

Keep the “TOP” mark on the luggage
cover ends upward.

WARNING

●

To avoid injury, always return the cargo hooks to their positions when not
in use.

●

Keep the auxiliary box closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by an
open auxiliary box or the items stored inside.

●

Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.

NOTICE

■

To prevent damage to the cargo net hooks

Avoid hanging things other than a cargo net on it.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

423

LC200_OM_OM60R53U_(U)

Other interior features

While the engine is running, the cool box, which is cooled by the air
conditioning, can be used.

Lift the lid while pulling up the
lower lever to release the lock.

Turns the cool box on/off

When on, the indicator light comes
on.
If the front air conditioning system
is not in use, the front air condition-
ing system is automatically turned
on when the cool box is turned on.

■

While the cool box is on

The front air conditioning system cannot be turned off.

■

When the outside temperature is 32



F (0



C) or below

The cool box may not operate.

Cool box (if equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

425



Main sun visor

To  set  the  visor  in  the  forward
position, flip it down.
To set the visor in the side posi-
tion,  flip  down,  unhook,  and
swing it to the side.
To use the side extender, place
the  visor  in  the  side  position,
then slide it backward.



Sub sun visor

Flip down with the main sun visor
in position

Slide the cover to open.

The light turns on when the cover
is opened.

If the vanity lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes.

Sun visors

Vanity mirror

NOTICE

To prevent battery discharge, do not leave the vanity lights on for extended
periods when the engine is not running.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

426

LC200_OM_OM60R53U_(U)

Refer to “NAVIGATION SYSTEM
OWNER’S MANUAL” for adjust-
ment.

■

The clock is displayed when

The engine switch is in ACCESSORY or IGNITION ON mode.

The

displayed

temperature

ranges from -22



F (-30



C) up to

122



F (50



C).

■

The outside temperature is displayed when

The engine switch is in IGNITION ON mode.

■

When --- is displayed

The system may be malfunctioning. Take your vehicle to your Toyota dealer.

■

Display

In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.

●

When stopped, or driving at low speeds (less than 12 mph [20 km/h])

●

When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)

Clock

Outside temperature display

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

427

The power outlet can be used for the following components:
12 V DC: Accessories that run on less than 10 A
120 V AC: Accessories that use less than 100 W

■

Center of console



Front (12 V DC)

Press the lid to open.



Rear (12 V DC)

Power outlets

-------------------------------------------------------------------------------------------------------------------------------------------------------------

428

LC200_OM_OM60R53U_(U)

■

Luggage compartment (120 V AC)

■

The power outlet can be used when

12 V DC: The engine switch is in ACCESSORY or IGNITION ON mode.
120 V AC: The engine switch is in IGNITION ON mode.

■

When turning the engine switch off

Disconnect electrical devices with charging functions, such as mobile battery
packs.
If such devices are left connected, the engine switch may not be turned off
normally.

NOTICE

■

To avoid damaging the power outlets

Close the power outlet lid when not in use.
Foreign objects or liquids that enter the power outlet may cause a short cir-
cuit.

■

To prevent the fuse from being blown

12 V DC: Do not use an accessory that uses more than 12 V 10 A.
120 V AC: Do not use a 120 V AC appliance that requires more than 100 W.

If a 120 V AC appliance that consumes more than 100 W is used, the pro-
tection circuit will cut the power supply.

■

To prevent the battery from being discharged

Do not use the power outlet longer than necessary when the engine is not
running.

■

Appliances that may not operate properly (120 V AC)

The following 120 V AC appliances may not operate even if their power
consumption is under 100 W.

●

Appliances with high initial peak wattage

●

Measuring devices that process precise data

●

Other appliances that require an extremely stable power supply

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

429

A portable device can be charged by just placing Qi standard wireless
charge compatible portable devices according to the Wireless Power
Consortium, such as smart phones and mobile batteries, etc., on the
charge area.
This function cannot be used with portable devices that are larger
than the charging area. Also, depending on the portable device, it may
not operate as normal. Please read the operation manual for portable
devices to be used.

■

The “Qi” symbol

The “Qi” symbol is a trademark of the Wireless Power Consortium.

■

Name for all parts

Power supply switch
Operation indicator light
Charge area

Wireless charger (if equipped)

1
2
3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

430

LC200_OM_OM60R53U_(U)

■

Using the wireless charger

Press the lid to open.

Press the power supply
switch of the wireless char-
ger.

Switches  on  and  off  with  each
press  of  the  power  supply
switch.
When  turned  on,  the  operation
indicator light (green) comes on.
Even with the engine off, the on/
off  state  of  the  power  supply
switch is memorized.

Place the charging side of
the portable device down.

When  charging,  the  operation
indicator  light  (orange)  comes
on.
If  charging  is  not  occurring,  try
placing  the  portable  device  as
close  to  the  center  of  the
charging area as possible.
When charging is complete, the operation indicator light (green) comes
on.

●

Recharging function

• When charging is complete and after a fixed time in the charge

suspension state, charging restarts.

• When the portable device is moved, charging is stopped for a

moment and then it restarts.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

431

■

Lighting conditions of operation indicator light

: Depending on the portable device, there are cases where the operation

indicator light will continue being lit up orange even after the charging is
complete.

●

When the operation indicator light flashes
When an error occurs, the operation indicator light flashes an
orange color. Handle the error based on the following table.

Operation indicator light

Conditions

Turning off

When the Wireless charger power supply is
off

Green (comes on)

On Standby (charging possible state)

When charging is complete

Orange (comes on)

When placing the portable device on the
charging area (detecting the portable device)

Charging

Operation indicator

light

Suspected causes

Handling method

Flashing

repeatedly

once every second
(Orange)

Vehicle to charger com-
munication failure.

Contact your Toyota
dealer.

Repeatedly

flashes

3 times continuously
(Orange)

A foreign substance is
between the portable
device and charge area.

Remove the foreign
substance

from

between

portable

device and the charge
area.

The portable device is
out of sync due to the
device being shifted from
its position.

Place

the

portable

device near the center
of the charge area.

Repeatedly

flashes

4 times continuously
(Orange)

Temperature

rising

within the wireless char-
ger.

Stop charging at once
and

start

charging

again after for a while.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

432

LC200_OM_OM60R53U_(U)

■

The wireless charger can be operated when

The engine switch is in ACCESSORY or IGNITION ON mode.

■

Usable portable devices

Qi standard wireless charge standard can be used on compatible devices.
However, not all Qi standard devices and compatibility are guaranteed.
Starting with mobile phones and smart phones, it is aimed for low power elec-
trically supplied portable devices of no more than 5W.

■

When covers and accessories are attached to portable devices

Do not charge in situations where cover and accessories not able to handle
Qi are attached to the portable device. Depending on the type of cover and
accessory, it may not be possible to charge. When charging is not performed
even with the portable device placed on the charge area, remove the cover
and accessories.

■

While charging, noise enters the AM radio

Turn off the wireless charger and confirm that the noise has decreased. If the
noise decreases, continuously pushing the power supply switch of the wire-
less charger for 2 seconds, the frequency of the charger can be changed and
the noise can be reduced.
Also, on that occasion, the operation indicator light will flash orange 2 times.

■

Important points of the wireless charger

●

If the electronic key cannot be detected within the vehicle interior, charging
cannot be done. When the door is opened and closed, charging may be
temporarily suspended.

●

When charging, the wireless charging device and portable device will get
warmer, however this is not a malfunction.
When a portable device gets warm while charging, charging may stop due
to the protection function on the portable device side. In this case, when the
temperature of the portable device drops significantly, charge again.

■

Operation sounds

When the power supply is turned on, while searching for the portable device a
sound will be produced, however this is not a malfunction.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

435

WARNING

■

Caution while driving

When charging a portable device, for safety reasons, the driver should not
operate the portable device while driving.

■

Caution regarding interference with electronic devices

People with implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators, as well as
any other electrical medical device, should consult their physician about the
usage of the wireless charger. The operations of the wireless charger may
have an affect on medical devices.

■

To prevent damage or burns

Observe the following precautions.
Failure to do so may result in a possibility of equipment failure and damage,
catch fire, burns due to overheat.

●

Do not insert any metallic objects between the charging area and the por-
table device while charging

●

Do not attach stickers, metallic objects, etc., to the charger area or porta-
ble device

●

Do not cover with cloth, etc., and charge

●

Do not charge portable devices other than designated

●

Do not attempt to dismantle for disassembly or modifications

●

Do not hit or apply a strong force

-------------------------------------------------------------------------------------------------------------------------------------------------------------

436

LC200_OM_OM60R53U_(U)

NOTICE

■

Conditions in which the function may not operate correctly

In the following conditions, the wireless charger may not operate correctly

●

The portable device is fully charged

●

There is foreign matter between the charge area and portable device

●

The temperature of the portable device gets higher from charging

●

The charging surface of the portable device is facing up

●

The placement of the portable device is out of alignment with the charge
area

●

Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise

●

When the electronic key is in contact with, or is covered by the following
metallic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs

●

When other wireless keys (that emit radio waves) are being used nearby

In addition, excluding the above-mentioned, when the charger does not per-
form normally or the operation indicator light is flashing continuously, it is
considered that the wireless charger is malfunctioning. Contact your Toyota
dealer.

■

To prevent failure or damage to data

●

Do not bring magnetic cards, such as credit cards, or magnetic recording
media, etc., close to the charger while charging, otherwise, data may dis-
appear under the influence of magnetism. Also, do not bring precision
instruments such as wrist watches, etc., close to the charger, as such
objects may break.

●

Do not leave portable devices in the cabin. The temperature inside the
cabin may become high, when under the sun, and cause damage to the
device.

■

To prevent battery discharge

When the engine is stopped, do not use the wireless charger for a long
time.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

437

Fold down the armrest for use.

The coat hooks are provided with
the second seat assist grips.

Armrest

NOTICE

To prevent damage, do not apply too much load on the armrest.

Coat hooks

WARNING

Do not hang coat hangers or other hard or sharp objects on the hook. If the
SRS curtain shield airbags deploy, these items may become projectiles,
causing death or serious injury.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

438

LC200_OM_OM60R53U_(U)

An assist grip (Type A) can be used to support your body while sitting
on the seat.
An assist grip (Type B) can be used when getting in or out of the vehi-
cle and others.

Assist grip (Type A)
Assist grip (Type B)

Assist grips

1
2

WARNING

Do not use the assist grip (Type A) when getting in or out of the vehicle or
rising from your seat.

NOTICE

To prevent damage, do not hang heavy objects or put a heavy load on the
assist grip.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

439

LC200_OM_OM60R53U_(U)

Garage door opener

The HomeLink

wireless control system in your vehicle has 3 buttons

which can be programmed to operate 3 different devices. Refer to the
programming methods on the following pages to determine the
method which is appropriate for the device.

HomeLink

indicator light

Garage door operation indica-
tors
HomeLink

icon

Illuminates while HomeLink

operating.

Buttons

■

Before programming HomeLink

●

During programming, it is possible that garage doors, gates, or
other devices may operate. For this reason, make sure that peo-
ple and objects are clear of the garage door or other devices to
prevent injury or other potential harm.

●

It is recommended that a new battery be placed in the remote
control transmitter for more accurate programming.

●

Garage door opener motors manufactured after 1995 may be
equipped with rolling code protection. If this is the case, you may
need a stepladder or other sturdy, safe device to reach the
“Learn” or “Smart” button on the garage door opener motor.

The garage door opener can be programmed to operate garage
doors, gates, entry doors, door locks, home lighting systems,
security systems, and other devices.

Programming the HomeLink

1
2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

440

LC200_OM_OM60R53U_(U)

■

Programming HomeLink

Steps

through

must be performed within 60 seconds, other-

wise the indicator light will stop flashing and programming will not
be able to be completed.

Press and release the HomeLink

button you want to program

and check that the HomeLink

indicator light flashes (orange).

Point  the  remote  control
transmitter  for  the  device  at
the rear view mirror, 1 to 3 in.
(25  to  75  mm)  from  the
HomeLink

buttons.

Keep the HomeLink

indicator

light in view while programming.

Program a device.



Programming a device other than an entry gate (for U.S.A.
owners)

Press and hold the remote control transmitter button until the
HomeLink

indicator light changes from slowly flashing orange to

rapidly flashing green (rolling code) or continuously lit green
(fixed code), then release the button.



Programming an entry gate (for U.S.A. owners)

Press and release the remote control transmitter button at 2 sec-
ond intervals, repeatedly, until the HomeLink

indicator light

changes from slowly flashing (orange) to rapidly flashing (green)
(rolling code) or continuously lit (green) (fixed code).

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

441

Test the HomeLink

operation by pressing the newly pro-

grammed button and observing the indicator light:

●

Indicator light illuminates: Programming of a fixed code device
has completed. The garage door or other device should oper-
ate when a HomeLink

button is pressed and released.

●

Indicator light flashes rapidly: The garage door opener motor
or other device is equipped with a rolling code. To complete
programming, firmly press and hold the HomeLink

button for

2 seconds then release it.

●

If the garage door or other device does not operate, proceed
to “Programming a rolling code system”.

Repeat the steps above to program another device for any of the
remaining HomeLink

buttons.

■

Programming a rolling code system

2 or more people may be necessary to complete rolling code pro-
gramming.

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

This button can usually be found
where the hanging antenna wire
is  attached  to  the  unit.  The
name  and  color  of  the  button
may  vary  by  manufacturer.
Refer  to  the  owner’s  manual
supplied  with  the  garage  door
opener motor for details.

Press and release the
“Learn” or “Smart” button.
Perform

within 30 sec-

onds after performing

-------------------------------------------------------------------------------------------------------------------------------------------------------------

442

LC200_OM_OM60R53U_(U)

Press and hold the desired
HomeLink

button (inside the

vehicle) for 2 seconds and
release it. Repeat this
sequence

(press/hold/

release)  up  to  3  times  to
complete programming.
If  the  garage  door  opener
motor  operates  when  the
HomeLink

button

pressed, the garage door
opener motor recognizes the
HomeLink

signal.

■

Enabling 2-way communication with a garage door (only avail-
able for compatible devices)

When enabled, 2-way communication allows you to check the sta-
tus of the opening and closing of a garage door through indicators
in your vehicle.
2-way communication is only available if the garage door opener
motor used is a compatible device. (To check device compatibility,
refer to www.HomeLink.com.)

Within 5 seconds after programming the garage door opener has
been completed, if the garage door opener motor is trained to
HomeLink

, both garage door operation indicators will flash rap-

idly (green) and the light on the garage door opener motor will
blink twice, indicating that 2-way communication is enabled.

If the indicators do not flash, perform

and

within the first 10

presses of the HomeLink

button after programming has been

completed.

Press a programmed HomeLink

button to operate a garage

door.
Within 1 minute of pressing the HomeLink

button, after the

garage door operation has stopped, press the “Learn” or “Smart”
button on the garage door opener motor. Within 5 seconds of the
establishment of 2-way communication with the garage door
opener, both garage door operation indicators in the vehicle will
flash rapidly (green) and the light on the garage door opener motor
will blink twice, indicating that 2-way communication is enabled.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

443

■

Reprogramming a single HomeLink

button

When the following procedure is performed, buttons which already
have devices registered to them can be overwritten:

With one hand, press and hold the desired HomeLink

button.

When the HomeLink

indicator starts flashing (orange), continue

to hold the HomeLink

button and perform “Programming Home-

Link

”

(it takes 20 seconds for the HomeLink

indicator to

start flashing).

Press the appropriate HomeLink

button. The HomeLink

indicator

light should turn on.

The status of the opening and
closing of a garage door is shown
by the indicators.

Opening
Closing

This function is only available if the
garage door opener motor used is
a compatible device. (To check
device compatibility, refer to
www.HomeLink.com.)

The indicators can operate within approximately 820 ft. (250 m) of the
garage door. However, if there are obstructions between the garage
door and the vehicle, such as houses and trees, feedback signals
from the garage door may not be received.
To recall the previous door operation status, press and release either

HomeLink

buttons

and

simultaneously.

The last recorded status will be displayed for 3 seconds.

Operating HomeLink

Garage door operation indicators

1
2

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

-------------------------------------------------------------------------------------------------------------------------------------------------------------

444

LC200_OM_OM60R53U_(U)

Press and hold the 2 outside but-
tons for 10 seconds until the
HomeLink

indicator

light

changes from continuously lit
(orange) to rapidly flashing
(green).

If you sell your vehicle, be sure to
erase the programs stored in the
HomeLink

memory.

■

Codes stored in the HomeLink

memory

●

The registered codes are not erased even if the battery cable is discon-
nected.

●

If learning failed when registering a different code to a HomeLink

button

that already has a code registered to it, the already registered code will not
be erased.

■

Before programming

●

Install a new battery in the transmitter.

●

The battery side of the transmitter must be pointed away from the
HomeLink



■

Certification for the garage door opener

■

When support is necessary

Visit on the web at www.homelink.com/toyota or call 1-800-355-3515.

Erasing the entire HomeLink

memory (all three codes)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

445

WARNING

■

When programming a garage door or other remote control devices

The garage door or other devices may operate, so ensure people and
objects are out of danger to prevent potential harm.

■

Conforming to federal safety standards

Do not use the HomeLink



compatible transceiver with any garage door

opener or device that lacks safety stop and reverse features as required by
federal safety standards.
This includes any garage door that cannot detect an interfering object. A
door or device without these features increases the risk of death or serious
injury.

■

When operating or programming HomeLink



Never allow a child to operate or play with the HomeLink



buttons.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

447

LC200_OM_OM60R53U_(U)

Maintenance and care

6-1. Maintenance and care

Cleaning and protecting

the vehicle exterior.......... 448

Cleaning and protecting

the vehicle interior........... 452

6-2. Maintenance

Maintenance

requirements................... 455

General maintenance........ 458
Emission inspection and

maintenance (I/M)
programs......................... 461

6-3. Do-it-yourself maintenance

Do-it-yourself service

precautions ..................... 462

Hood ................................. 464
Engine compartment......... 465
Tires .................................. 478
Tire inflation pressure ....... 487
Wheels .............................. 490
Air conditioning filter.......... 492
Electronic key battery........ 494
Checking and replacing

fuses ............................... 496

Headlight aim .................... 500
Light bulbs......................... 502

-------------------------------------------------------------------------------------------------------------------------------------------------------------

448

LC200_OM_OM60R53U_(U)

Cleaning and protecting the vehicle exterior

●

Working from top to bottom, liberally apply water to the vehicle
body, wheel wells and underside of the vehicle to remove any dirt
and dust.

●

Wash the vehicle body using a sponge or soft cloth, such as a
chamois.

●

For hard-to-remove marks, use car wash soap and rinse thoroughly
with water.

●

Wipe away any water.

●

Wax the vehicle when the waterproof coating deteriorates.

If water does not bead on a clean surface, apply wax when the vehicle
body is cool.

■

Automatic car washes

●

Fold the mirrors back before washing the vehicle. Start washing from the
front of the vehicle. Make sure to extend the mirrors before driving.

●

Brushes used in automatic car washes may scratch the vehicle surface and
harm your vehicle’s paint.

●

Rear spoiler (if equipped) may not be washable in some automatic car
washes. There may also be an increased risk of damage to vehicle.

■

High pressure car washes

As water may enter the cabin, do not bring the nozzle tip near the gaps
around the doors or perimeter of the windows, or spray these areas continu-
ously.

■

Wheels (Including surrounding parts)

●

Remove any dirt immediately by using a neutral detergent.

●

Wash detergent off with water immediately after use.

●

To protect the paint from damage, make sure to observe the following pre-
cautions.
• Do not use acidic, alkaline or abrasive detergent
• Do not use hard brushes
• Do not use detergent on the wheels when they are hot, such as after driv-

ing or parking in hot weather

■

Bumpers and side moldings

Do not scrub with abrasive cleaners.

Perform the following to protect the vehicle and maintain it in
prime condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

449

Mainten

■

Plated portions

If dirt cannot be removed, clean the parts as follows:

●

Use a soft cloth dampened with an approximately 5% solution of neutral
detergent and water to clean the dirt off.

●

Wipe the surface with a dry, soft cloth to remove any remaining moisture.

●

To remove oily deposits, use alcohol wet wipes or a similar product.

■

Notes for a smart key system

●

If the door handle becomes wet while the electronic key is within the effec-
tive range, the door may lock and unlock repeatedly. Place the key in a posi-
tion 6 ft. (2 m) or more separate from the vehicle while the vehicle is being
washed. (Take care to ensure that the key is not stolen.)

●

If the electronic key is inside the vehicle and a door handle becomes wet
during a car wash, a message may be shown on the multi-information dis-
play and a buzzer will sound outside the vehicle. To turn off the alarm, lock
all the doors.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

450

LC200_OM_OM60R53U_(U)

WARNING

■

When washing the vehicle

Do not apply water to the inside of the engine compartment. Doing so may
cause the electrical components etc. to catch fire.

■

When cleaning the windshield (vehicles with rain-sensing windshield
wiper)

●

When the upper part of the windshield where the raindrop sensor is
located is touched by hand

●

When a wet rag or similar is held close to the raindrop sensor

●

If something bumps against the windshield

●

If you directly touch the raindrop sensor body or if something bumps into
the raindrop sensor

■

Precautions regarding the exhaust pipe

Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has
cooled sufficiently, as touching a hot exhaust pipe can cause burns.

■

Precautions regarding the Blind Spot Monitor (if equipped)

If the paint of the rear bumper is chipped or scratched, the system may mal-
function.
If this occurs, consult your Toyota dealer.

Set the wiper switch to off.
If the wiper switch is in “AUTO”, the wip-
ers may operate unexpectedly in the fol-
lowing situations, and may result in
hands being caught or other serious inju-
ries and cause damage to the wiper
blades.

OFF

AUTO

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

451

Mainten

NOTICE

■

To prevent paint deterioration and corrosion on the body and compo-
nents (aluminum wheels etc.)

●

Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If you see dead insects, insect droppings or bird droppings on the paint
• After driving in an area contaminated with soot, oily smoke, mine dust,

iron powder or chemical substances

• If the vehicle becomes heavily soiled in dust or mud
• If liquids such as benzene and gasoline are spilled on the paint surface

●

If the paint is chipped or scratched, have it repaired immediately.

●

To prevent the wheels from corroding, remove any dirt and store in a place
with low humidity when storing wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.

●

Do not apply wax on the surfaces of the lights.
Wax may cause damage to the lenses.

■

When using an automatic car wash (vehicles with rain-sensing wind-
shield wiper)

Turn off the wiper switch.
If the wiper switch is in “AUTO”, the wipers may operate and the wiper
blades may be damaged.

■

When using a high pressure car wash

●

Do not bring the nozzle tip close to boots (rubber or resin manufactured
cover), connectors or the following parts. The parts may be damaged if
they come into contact with high-pressure water.
• Traction related parts
• Steering parts
• Suspension parts
• Brake parts

●

Keep the cleaning nozzle at least 11.9 in. (30 cm) away from the vehicle
body. Otherwise resin section, such as moldings and bumpers, may be
deformed and damaged. Also, do not continuously hold the nozzle in the
same place.

●

Do not spray the lower part of the windshield continuously. If water enters
the air conditioning system intake located near the lower part of the wind-
shield, the air conditioning system may not operate correctly.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

452

LC200_OM_OM60R53U_(U)

Cleaning and protecting the vehicle interior

●

Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces
with a cloth dampened with lukewarm water.

●

If dirt cannot be removed, wipe it off with a soft cloth dampened with
neutral detergent diluted to approximately 1%.

●

Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.

●

Remove dirt and dust using a vacuum cleaner.

●

Wipe any excess dirt and dust with a soft cloth dampened with
diluted detergent.

Use a diluted water solution of approximately 5% neutral wool detergent.

●

Wring out any excess water from the cloth and thoroughly wipe off
all remaining traces of detergent.

●

Wipe the surface with a dry, soft cloth to remove any remaining
moisture. Allow the leather to dry in a shaded ventilated area.

●

Remove dirt and dust using a vacuum cleaner.

●

Wipe it off with a soft cloth dampened with neutral detergent diluted
to approximately 1%.

●

Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.

The following procedures will help protect your vehicle’s interior
and keep it in top condition:

Protecting the vehicle interior

Cleaning the leather areas

Cleaning the synthetic leather areas

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

453

Mainten

■

Caring for leather areas

Toyota recommends cleaning the interior of the vehicle at least twice a year to
maintain the quality of the vehicle’s interior.

■

Shampooing the carpets

There are several commercial foaming-type cleaners available. Use a sponge
or brush to apply the foam. Rub in overlapping circles. Do not use water. The
excellent results are obtained when keeping the carpet as dry as possible.

■

Seat belts

Clean with mild soap and lukewarm water using a cloth or sponge. Also
check the belts periodically for excessive wear, fraying or cuts.

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in the vehicle.
Doing so may cause electrical components etc. to malfunction or catch
fire.

●

Do not get any of the SRS components or wiring in the vehicle interior wet.
(

P. 42)

An electrical malfunction may cause the airbags to deploy or not function
properly, resulting in death or serious injury.

■

Cleaning the interior (especially instrument panel)

Do not use polish wax or polish cleaner. The instrument panel may reflect
off the windshield, obstructing the driver’s view and leading to an accident,
resulting in death or serious injury.

NOTICE

■

Cleaning detergents

●

Do not use the following types of detergent, as they may discolor the vehi-
cle interior or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline,

alkaline or acidic solutions, dye, and bleach

• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alco-

hol

●

Do not use polish wax or polish cleaner. The instrument panel’s or other
interior part’s painted surface may be damaged.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

454

LC200_OM_OM60R53U_(U)

NOTICE

■

Preventing damage to leather surfaces

Observe the following precautions to avoid damage to and deterioration of
leather surfaces:

●

Remove any dust or dirt from leather surfaces immediately.

●

Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.

●

Do not place items made of vinyl, plastic, or containing wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.

■

When cleaning the inside of the windshield (vehicles with Toyota
Safety Sense P)

Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
(

P. 247)

■

Water on the floor

Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components such as the audio system above or
under the floor of the vehicle. Water may also cause the body to rust.

■

Cleaning the inside of the rear quarter windows and rear window

●

Do not use glass cleaner to clean the rear quarter windows and rear win-
dow, as this may cause damage to the rear window defogger heater wires
or antenna. Use a cloth dampened with lukewarm water to gently wipe the
window clean. Wipe the window in strokes running parallel to the heater
wires or antenna.

●

Be careful not to scratch or damage the heater wires or antenna.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

455

LC200_OM_OM60R53U_(U)

Mainten

Maintenance requirements

General maintenance should be performed on a daily basis. This can
be done by yourself or by a Toyota dealer.

Scheduled maintenance should be performed at specified intervals
according to the maintenance schedule.
For details about maintenance items and schedules, refer to the
“Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.

You can perform some maintenance procedures by yourself.
Please be aware that do-it-yourself maintenance may affect warranty
coverage.

The use of Toyota repair manuals is recommended.
For details about warranty coverage, see the “Owner’s Warranty Informa-
tion Booklet” or “Owner’s Manual Supplement”.

To ensure safe and economical driving, day-to-day care and reg-
ular maintenance are essential. It is the owner’s responsibility to
perform regular checks. Toyota recommends the following main-
tenance:

General maintenance

Scheduled maintenance

Do-it-yourself maintenance

-------------------------------------------------------------------------------------------------------------------------------------------------------------

456

LC200_OM_OM60R53U_(U)

■

Repair and replacement

It is recommended that genuine Toyota parts be used for repairs to ensure
performance of each system. If non-Toyota parts are used in replacement or if
a repair shop other than a Toyota dealer performs repairs, confirm the war-
ranty coverage.

■

Resetting the message indicating maintenance is required

After the required maintenance is performed according to the maintenance
schedule, please reset the message.
To reset the message, follow the procedures described below:

Press

of the meter control switches, select

Press

of the meter control switches, select “Scheduled

Maintenance” and then press

Select the “Yes” and press

A message is displayed on the multi-information display.

■

Allow inspection and repairs to be performed by a Toyota dealer

●

Toyota technicians are well-trained specialists and are kept up to date with
the latest service information. They are well informed about the operation of
all systems on your vehicle.

●

Keep a copy of the repair order. It proves that the maintenance that has
been performed is under warranty coverage. If any problem should arise
while your vehicle is under warranty, your Toyota dealer will promptly take
care of it.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

457

Mainten

WARNING

■

If your vehicle is not properly maintained

Improper maintenance could result in serious damage to the vehicle and
possible serious injury or death.

■

Handling of the battery

●

Engine exhaust, some of its constituents, and a wide variety of automobile
components contain or emit chemicals known to the State of California to
cause cancer and birth defects and other reproductive harm. Work in a
well ventilated area.

●

Oils, fuels and fluids contained in vehicles as well as waste produced by
component wear contain or emit chemicals known to the State of Califor-
nia to cause cancer and birth defects or other reproductive harm. Avoid
exposure and wash any affected area immediately.

●

Battery posts, terminals and related accessories contain lead and lead
compounds which are known to cause brain damage. Wash your hands
after handling. (

P. 474)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

458

LC200_OM_OM60R53U_(U)

General maintenance

Listed below are the general maintenance items that should be
performed at the intervals specified in the “Warranty and Service
Guide” or “Owner’s Manual Supplement”. It is recommended
that any problem you notice should be brought to the attention
of your Toyota dealer or qualified service shop for advice.

Engine compartment

Items

Check points

Battery

Check the connections.

(

P. 474)

Brake fluid

Is the brake fluid at the correct level? (

Engine coolant

Is the engine coolant at the correct level?

(

P. 470)

Engine oil

Is the engine oil at the correct level? (

P. 467)

Exhaust system

There should not be any fumes or strange
sounds.

Power steering fluid

Is the power steering fluid at the correct level?

(

P. 473)

Radiator/condenser

The radiator and condenser should be free from
foreign objects.

(

Washer fluid

Is there sufficient washer fluid?

(

P. 477)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

459

Mainten

Vehicle interior

Items

Check points

Accelerator pedal

• The accelerator pedal should move smoothly

(without uneven pedal effort or catching).

Automatic transmission
“Park” mechanism

• When parked on a slope and the shift lever is

in P, is the vehicle securely stopped?

Brake pedal

• Does the brake pedal move smoothly?
• Does the brake pedal have appropriate clear-

ance from the floor?

(

P. 574)

• Does the brake pedal have the correct

amount of free play?

(

P. 574)

Brakes

• The vehicle should not pull to one side when

the brakes are applied.

• The brakes should work effectively.
• The brake pedal should not feel spongy.
• The brake pedal should not get too close to

the floor when the brakes are applied.

Head restraints

• Do the head restraints move smoothly and

lock securely?

Indicators/buzzers

• Do the indicators and buzzers function prop-

erly?

Lights

• Do all the lights come on?
• Are the headlights aimed correctly? (

P. 500)

Parking brake

• Does the parking brake lever move smoothly?
• When parked on a slope and the parking

brake is on, is the vehicle securely stopped?

Seat belts

• Do the seat belts operate smoothly?
• The seat belts should not be damaged.

Seats

• Do the seat controls operate properly?

Steering wheel

• Does the steering wheel rotate smoothly?
• Does the steering wheel have the correct

amount of free play?

• There should not be any strange sounds com-

ing from the steering wheel.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

460

LC200_OM_OM60R53U_(U)

Vehicle exterior

Items

Check points

Doors

• Do the doors operate smoothly?

Engine hood

• Does the engine hood lock system work prop-

erly?

Fluid leaks

• There should not be any signs of fluid leakage

after the vehicle has been parked.

Tires

• Is the tire inflation pressure correct?

• The tires should not be damaged or exces-

sively worn.

• Have the tires been rotated according to the

maintenance schedule?

• The wheel nuts should not be loose.

Windshield wipers/rear
window wiper

• The wiper blades should not show any signs

of cracking, splitting, wear, contamination or
deformation.

• The wiper blades should clear the windshield/

rear window without streaking or skipping.

WARNING

■

If the engine is running

Turn off the engine and ensure that there is adequate ventilation before per-
forming maintenance checks.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

461

LC200_OM_OM60R53U_(U)

Mainten

6-3. Do-it-yourself maintenance

Emission inspection and maintenance (I/M)

programs

The OBD system determines that a problem exists somewhere in the
emission control system. Your vehicle may not pass the I/M test and
may need to be repaired. Contact your Toyota dealer to service the
vehicle.

●

When the battery is disconnected or discharged
Readiness codes that are set during ordinary driving are erased.
Also, depending on your driving habits, the readiness codes may
not be completely set.

●

When the fuel tank cap is loose
The malfunction indicator lamp comes on indicating a temporary
malfunction and your vehicle may not pass the I/M test.

The error code in the OBD system will not be cleared unless the vehi-
cle is driven 40 or more times.

Contact your Toyota dealer to prepare the vehicle for re-testing.

Some states have vehicle emission inspection programs which
include OBD (On Board Diagnostics) checks. The OBD system
monitors the operation of the emission control system.

If the malfunction indicator lamp comes on

Your vehicle may not pass the I/M test in the following situations:

When the malfunction indicator lamp still remains on after sev-
eral driving trips

If your vehicle does not pass the I/M test

-------------------------------------------------------------------------------------------------------------------------------------------------------------

462

LC200_OM_OM60R53U_(U)

Do-it-yourself service precautions

If you perform maintenance yourself, be sure to follow the cor-
rect procedures as given in these sections.

Items

Parts and tools

Battery condition
(



P. 474)

• Warm water

• Baking soda

• Grease

• Conventional wrench (for terminal clamp bolts)

Brake fluid level
(



• FMVSS No.116 DOT 3 or SAE J1703 brake fluid
• Rag or paper towel
• Funnel (used only for adding brake fluid)

Engine coolant
level (



P. 470)

• “Toyota Super Long Life Coolant” or similar high

quality ethylene glycol-based non-silicate, non-
amine, non-nitrite and non-borate coolant with long-
life hybrid organic acid technology.
“Toyota Super Long Life Coolant” is pre-mixed with
50 % coolant and 50 % deionized water.

• Funnel (used only for adding coolant)

Engine oil level
(



P. 467)

• “Toyota Genuine Motor Oil” or equivalent
• Rag or paper towel
• Funnel (used only for adding engine oil)

Fuses
(



P. 496)

• Fuse with same amperage rating as original

Headlight aim
(



P. 500)

• Phillips-head screwdriver

Light bulbs
(



P. 502)

• Bulb with same number and wattage rating as origi-

nal

• Phillips-head screwdriver • Flathead screwdriver
• Wrench

Power steering
fluid level
(



P. 473)

• Automatic transmission fluid DEXRON

II or III

• Rag or paper towel
• Funnel (used only for adding power steering fluid)

Radiator and con-
denser (

6-3. Do-it-yourself maintenance



Tire inflation

pressure

(



P. 487)

• Tire pressure gauge

• Compressed air source

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LC200_OM_OM60R53U_(U)

463

Mainten

Washer fluid
(



P. 477)

• Water or washer fluid containing antifreeze (for win-

ter use)

• Funnel (used only for adding water or washer fluid)

WARNING

The engine compartment contains many mechanisms and fluids that may
move suddenly, become hot, or become electrically energized. To avoid death
or serious injury, observe the following precautions:

■

When working on the engine compartment

●

Keep hands, clothing and tools away from the moving fan and engine
drive belt.

●

Be careful not to touch the engine, radiator, exhaust manifold, etc. right
after driving as they may be hot. Oil and other fluids may also be hot.

●

Do not leave anything that may burn easily, such as paper or rags, in the
engine compartment.

●

Do not smoke, cause sparks or expose an open flame to fuel or the bat-
tery. Fuel and battery fumes are flammable.

●

Be extremely cautious when working on the battery. It contains poisonous
and corrosive sulfuric acid.

■

When working near the electric cooling fans or radiator grille

Be sure the engine switch is off. With the engine switch in IGNITION ON
mode, the electric cooling fans may automatically start to run if the air condi-
tioning is on and/or the coolant temperature is high. (


