5-9. Bluetooth® phone
391
Receiving a call
When a call is received, the following screen is displayed
together with a sound.
To answer the phone
Press the
switch on the steer-
ing wheel or select
To refuse a call
Press the
switch on the steering wheel or select
5
To adjust the incoming call volume
Turn the “PWR·VOL” knob. You can also adjust the volume using the
steering switches.
■International calls
Received international calls may not be displayed correctly depending on the
cellular phone in use.
392
5-9. Bluetooth® phone
Speaking on the phone
The following screen is displayed when speaking on the phone.
To adjust the call volume
Select “-” or “+”. You can also adjust the volume using the steering
switches or the volume knob.
To prevent the other party from hearing your voice
Select “Mute”.
Inputting tones
When using phone services such as an answering service or a bank,
you can store phone numbers and code numbers in the contact.
1
Select “0-9”.
2
Input the number.
■ Release Tones
“Release Tones” appear when a continuous tone signal(s) contain-
ing a (w) is registered in the contact list.
● Select “Release Tones”.
5-9. Bluetooth® phone
393
■ Release Tones
● A continuous tone signal is a character string that consists of numbers and
the characters “p” or “w”. (e.g.056133w0123p#1)
● When the “p” pause tone is used, the tone data up until the next pause tone
will be automatically sent after 2 seconds have elapsed. When the “w”
pause tone is used, the tone data up until the next pause tone will be auto-
matically sent after a user operation is performed.
● Release tones can be used when automated operation of a phone based
service such as an answering machine or bank phone service is desired. A
phone number with continuous tone signals can be registered in the contact
list.
● Tone data after a “w” pause tone can be operated on voice command during
a call.
To transfer a call
Select “Handset Mode” to on from a hands-free call to a cellular
phone call.
Select “Handset Mode” to off from a cellular phone call to a hands-free
call.
5
Transmit volume setting
1
Select “Transmit Volume”.
2
Select the desired level for the transmit volume.
3
Select “OK”.
To hang up
Press the
switch on the steering wheel or select
394
5-9. Bluetooth® phone
Call waiting
When a call is interrupted by a third party while talking, an incoming
call message will be displayed.
To talk with the other party:
• Press the
switch on the
steering wheel.
• Select
To refuse the call:
• Press the
switch on the
steering wheel.
• Select
Every time you press the
switch on the steering wheel or select
during call waiting, you will be switched to the other party.
■ Transferring calls
● If you transfer from the cellular phone to hands-free, the hands-free screen
will be displayed, and you can operate the system using the screen.
● Transfer method and operation may vary according to the cellular phone
used.
● For operation of the cellular phone in use, see the phone’s manual.
■ Call waiting operation
Call waiting operation may differ depending on your phone company and cel-
lular phone.
5-9. Bluetooth® phone
395
Bluetooth® phone message function
Received messages can be forwarded from the connected
Bluetooth® phone, enabling checking and replying using the
multimedia system.
Depending on the type of Bluetooth® phone connected, received
messages may not be transferred to the message inbox.
If the phone does not support the message function, this func-
tion cannot be used.
Displaying message inbox screen
1
Press the
button.
2
Select
Receiving a message
When an e-mail/SMS/MMS is received, the incoming message screen
5
pops up with sound and is ready to be operated on the screen.
1
Select to check the message.
2
Select to refuse the message.
3
Select to call the message
sender.
396
5-9. Bluetooth® phone
■ Receiving a message
● Depending on the cellular phone used for receiving messages, or its regis-
tration status with the navigation system, some information may not be dis-
played.
● The pop up screen is separately available for incoming e-mail and SMS/
MMS messages under the following conditions:
E-mail:
•
“Incoming E-mail Display” is set to “Full Screen”. (P. 409)
•
“E-mail Notification Popup” is set to on. (P. 409)
SMS/MMS:
•
“Incoming SMS/MMS Display” is set to “Full screen”. (P. 409)
•
“SMS/MMS Notification Popup” is set to on. (P. 409)
Checking the messages
1
Display the message inbox screen. (P. 395)
2
Select the desired message from the list.
3
Check that the message is dis-
played.
1
E-mails:
Select
“Mark
Unread” or “Mark Read” to
mark mail unread or read on
the message inbox screen.
This function is available when
“Update Read Status on Phone”
is set to on (P. 409)
2
Select to make a call to the sender.
3
Select to have messages read out. To cancel this function, select
“Stop”.
4
Select to display the previous or next message.
5
Select to reply the message.
5-9. Bluetooth® phone
397
■ Check the messages
● Depending on the type of Bluetooth® phone being connected, it may be nec-
essary to perform additional steps on the phone.
● Messages are displayed in the appropriate connected Bluetooth® phone’s
registered mail address folder.
Select the tab of the desired folder to be displayed.
● Only received messages on the connected Bluetooth® phone can be dis-
played.
● The text of the message is not displayed while driving.
● When “Automatic Message Readout” is set to on, messages will be auto-
matically read out. (P. 409)
● Turn the “PWRVOL” knob, or use the volume switch on the steering wheel
to adjust the message read out volume.
● The message read out function is available even while driving.
Replying to a message
1
Display the message inbox screen. (P. 395)
2
Select the desired message from the list.
5
3
Select “Quick Message”.
4
Select the desired message.
5
Select “Send”.
■ Editing quick reply message
1
Select “Quick Message”.
2
Select
corresponding to the desired message to edit.
3
Select “OK” when editing is completed.
398
5-9. Bluetooth® phone
Calling the message sender
Calls can be made to an e-mail/SMS/MMS message sender’s phone
number.
1
Display the message inbox screen. (P. 395)
2
Select the desired message.
3
Select
4
Check that the “Call” screen is displayed.
■ Calling from a number within a message
Calls can be made to a number identified in a message’s text area.
1
Display the message inbox screen. (P. 395)
2
Select the desired message.
3
Select the text area.
4
Select
corresponding to the desired number.
5
Check that the “Call” screen is displayed.
■ Calling from the incoming message screen
P. 394
5-9. Bluetooth® phone
399
Using the steering wheel switches
The steering wheel switches can be used to operate a connected
cellular phone.
Operating a telephone using the steering wheel switches
1
Volume switch
• Increase/Decrease the
vol-
ume
• Press and hold:
Continuously
increase/
decrease the volume
2
Off hook switch
• Make a call
• Receive a call
• Display “Phone” screen
3
On hook switch
5
• End a call
• Refuse a call
400
5-9. Bluetooth® phone
Bluetooth® phone settings
You can adjust the hands-free system to your desired settings.
“Phone/Message Settings” screen
To display the screen shown below, press the “SETUP” button, and
select “Phone” on the “Setup” screen.
1
Set the phone connection
(P. 379)
2
Sound Settings (P. 401)
3
Contact/Call History Settings
(P. 402)
4
Set the message settings
(P. 409)
5
Set the phone display
(P. 410)
5-9. Bluetooth® phone
401
Sound setting
1
Display the “Phone/Message Settings” screen. (P. 400)
2
Select “Sound Settings” on the
“Phone/Message
Settings”
screen.
1
Set the desired ringtone.
2
Adjust the ringtone volume.
3
Adjust the message readout
volume.
4
Set the desired incoming
SMS/MMS tone.
5
Adjust the incoming SMS/
MMS tone volume.
6
Set the incoming e-mail tone.
7
Adjust the incoming e-mail tone volume.
8
Adjust the default volume of the other party’s voice.
5
■ To return to the default volume settings
Select “Default”, and then “Yes”.
402
5-9. Bluetooth® phone
Contact/Call History Settings
The contacts can be transferred from a Bluetooth® phone to the sys-
tem. Contacts can also be added, edited and deleted.
The call history can be deleted and contacts and favorites can be
changed.
1
Display the “Phone/Message Settings” screen. (P. 400)
2
Select “Contact/Call History Settings”.
3
Select the desired item to be
set.
1
For
PBAP compatible
Bluetooth® phones, select to
set “Automatic Transfer” on/
off. When set to on, the
phone’s contact data and his-
tory are automatically trans-
ferred.
2
Select to update contacts
from the connected phone.
(P. 403)
3
Select to sort contacts by the first name or last name field.
4
Select to add contacts to the favorites list. (P. 406)
5
Select to delete contacts from the favorites list. (P. 408)
6
Select to display contact images.
7
Select to clear contacts from the call history.*
8
Select to add new contacts to the contact list.* (P. 404)
9
Select to edit contacts in the contact list.* (P. 405)
10
Select to delete contacts from the contact list.* (P. 406)
11
Select to reset all setup items.
*: For PBAP compatible Bluetooth® phones only, this function is available
when “Automatic Transfer” is set to off.
5-9. Bluetooth® phone
403
Update contacts from phone
Operation methods differ between PBAP compatible and PBAP
incompatible but OPP compatible Bluetooth® phones.
If your cellular phone is neither PBAP nor OPP compatible, the con-
tacts cannot be transferred.
■ For PBAP compatible Bluetooth® Phones
Select “Update Contacts from Phone”.
1
2
Check that a confirmation screen is displayed when the opera-
tion is complete.
This operation may be unnecessary depending on the type of cellular
phone.
Depending on the type of cellular phone, OBEX authentication may be
required when transferring contact data. Enter “1234” into the Blue-
tooth® phone.
If another Bluetooth® device is connected when transferring contact
data, depending on the phone, the connected Bluetooth® device may
need to be disconnected.
5
Depending on the type of Bluetooth® phone being connected, it may be
necessary to perform additional steps on the phone.
■ For PBAP Incompatible but OPP compatible Bluetooth®
Phones
1
Select “Update Contacts from Phone”.
2
Transfer the contact data to the system using a Bluetooth®
phone.
This operation may be unnecessary depending on the type of cellular
phone.
Depending on the type of cellular phone, OBEX authentication may be
required when transferring contact data. Enter “1234” into the Blue-
tooth® phone.
To cancel this function, select “Cancel”.
3
Check that a confirmation screen is displayed when the opera-
tion is complete.
404
5-9. Bluetooth® phone
■ Updating the contacts in a different way (from the “Call His-
tory” screen)
For PBAP compatible Bluetooth® phones, this function is available
when “Automatic Transfer” is set to off. (P. 402)
1
Display the phone screen. (P. 386)
2
Select the “Call History” tab and select a contact not yet regis-
tered in the contact list.
3
Select “Update Contact”.
4
Select the desired contact.
5
Select a phone type for the phone number.
Registering a new contact to the contact list
New contact data can be registered. Up to 4 numbers per person can
be registered. For PBAP compatible Bluetooth® phones, this function
is available when “Automatic Transfer” is set to off. (P. 402)
1
Select “New Contact”.
2
Enter the name and select “OK”.
3
Enter the phone number and select “OK”.
4
Select the phone type for the phone number.
5
To add another number to this contact, select “Yes”.
■ Registering a new contact in a different way (from the “Call
History” screen)
1
Display the phone screen. (P. 386)
2
Select the “Call History” tab and select a contact not yet regis-
tered in the contact list.
3
Select “Add to Contacts”.
4
Follow the steps in “Registering a new contact to the contact list”
from step
2
5-9. Bluetooth® phone
405
Editing the contact data
For PBAP compatible Bluetooth® phones, this function is available
when “Automatic Transfer” is set to off. (P. 402)
1
Select “Edit Contact”.
2
Select the desired contact.
3
Select
corresponding to the desired name or number.
For editing the name
4
Follow the steps in “Registering a new contact to the contact list”
from step
2
. (P. 404)
For editing the number
4
Follow the steps in “Registering a new contact to the contact list”
from step
3
. (P. 404)
■ Editing the contacts in a different way (from the “Contact
Details” screen)
1
Display the phone screen. (P. 386)
5
2
Select the “Contacts”, “Call History” tab or the “Favorites” tab and
select the desired contact.
3
Select “Edit Contact”.
“E-mail Addresses”: Select to display all registered e-mail addresses for
the contact.
4
Follow the steps in “Editing the contact data” from step
3
406
5-9. Bluetooth® phone
Deleting the contact data
For PBAP compatible Bluetooth® phones, this function is available
when “Automatic Transfer” is set to off. (P. 402)
1
Select “Delete Contacts”.
2
Select the desired contact and select “Delete”.
3
Select “Yes” when the confirmation screen appears.
■ Deleting the contact in a different way (from the “Contact
Details” screen)
1
Display the phone screen. (P. 386)
2
Select the “Contacts”, “Call History” tab or the “Favorites” tab and
select the desired contact.
3
Select “Delete Contact”.
4
Select “Yes” when the confirmation screen appears.
Favorites list setting
Up to 15 contacts (maximum of 4 numbers per contact) can be regis-
tered in the favorites list.
■ Registering the contacts in the favorites list
1
Select “Add Favorite”.
2
Select the desired contact to add to the favorites list.
Dimmed contacts are already stored as a favorite.
3
Check that a confirmation screen is displayed when the opera-
tion is complete.
5-9. Bluetooth® phone
407
When 15 contacts have already been registered to the favorites list
When 15 contacts have already been registered to the favorites
1
list, a registered contact needs to be replaced.
Select “Yes” when the confirmation screen appears to replace a
contact.
2
Select the contact to be replaced.
3
Check that a confirmation screen is displayed when the opera-
tion is complete.
Registering contacts in the favorites list in a different way (from the
“Contacts” screen)
1
Display the phone screen. (P. 386)
2
Select the “Contacts” tab.
3
Select
at the beginning of the desired contact list name to be
registered in the favorites list.
When selected,
is changed to
, and the contact is registered in
the favorites list.
Registering contacts in the favorites list in a different way (from the
5
“Contact Details” screen)
1
Display the phone screen. (P. 386)
2
Select the “Contacts” tab or the “Call History” tab and select the
desired contact.
3
Select “Add Favorite”.
4
Check that a confirmation screen is displayed when the opera-
tion is complete.
