Toyota Prius V (2018 year). Instruction - part 23

6-4. Using the other interior features

381

Clock

The clock can be adjusted by pressing the buttons.

1

Adjusts the hours

2

Adjusts the minutes

3

Rounds to the nearest hour*

*: e.g. 1:00 to 1:291:00

1:30 to 1:592:00

●The clock is displayed when the power switch is in ACCESSORY or ON

mode.

●Even after the power switch has been turned off, the time will continue to be

displayed for approximately 30 seconds or until a door is locked.

Power outlet

Please use as a power supply for electronic goods that use less than

12 VDC/10 A (power consumption of 120 W).

 Front

 Rear

6

Open the cover.

Open the cover.

The power outlet can be used when the power switch is in ACCESSORY or

ON mode.

382

6-4. Using the other interior features

NOTICE

● To avoid damaging the power outlet, close the power outlet lid when the

power outlet is not in use.

Foreign objects or liquids that enter the power outlet may cause a short

circuit.

● To prevent 12-volt battery discharge, do not use the power outlet longer

than necessary when the hybrid system is off.

Armrest (if equipped for rear seats)

Pull the armrest down for use.

NOTICE

To prevent damage to the armrest, do not place too much strain on the arm-

rest.

Coat hooks

The coat hooks are provided with

the rear assist grips.

WARNING

Do not hang coat hangers or other hard or sharp objects on the hook. If the

SRS curtain shield airbags deploy, these items may become projectiles,

causing death or serious injury.

6-4. Using the other interior features

383

Assist grips

An assist grip installed on the ceil-

ing can be used to support your

body while sitting on the seat.

WARNING

Do not use the assist grip when getting in or out of the vehicle or rising from

your seat.

NOTICE

To prevent damage to the assist grip, do not hang any heavy object or put a

heavy load on the assist grip.

6

384

6-4. Using the other interior features

Panoramic roof shades (if equipped)

Use the overhead switches to

open/close the panoramic roof

shades.

1

Open*

2

Close*

*: To stop partway, press the switch

lightly.

■The panoramic roof shades can be operated when

The power switch is in ON mode.

■ Jam protection function

● If an object is detected between a panoramic roof shade and the frame

while closing, travel is stopped and the panoramic roof shades open slightly.

● When the jam protection function has operated, even if the “CLOSE” side of

the switch is pressed again, the shades will not move in the close direction

until the reverse operation has stopped completely.

● Depending on the driving conditions and the surroundings, the panoramic

roof shades may collide with something and operate in reverse.

■Door lock linked automatic close function

Operates when the power switch is turned off and the doors are locked from

inside or outside the vehicle using the wireless remote control, or are locked

from outside the vehicle using the smart key system or mechanical key.

■ If the panoramic roof shades do not close normally

Perform the following operations.

Stop the vehicle in a safe place.

1

With the panoramic roof shades stopped, push and hold the “CLOSE” side

2

of the switch for 10 seconds or more (until the panoramic roof shades have

closed completely).

If the panoramic roof shades continue to close but then re-open slightly even

after performing the above procedure correctly, have the vehicle inspected by

your Toyota dealer.

6-4. Using the other interior features

385

■Customization

The door lock linked automatic close function can be disabled.

(Customizable features: P. 559)

WARNING

Observe the following precautions.

Failing to do so may result in death or serious injury.

■ When closing the panoramic roof shades

●Check to make sure that all passengers

do not have any part of their bodies in a

position where they could be caught

when the panoramic roof shades are

being operated.

●Do not allow children to operate the

panoramic roof shades.

Closing the panoramic roof shades on

someone can cause death or serious

injury.

■ Jam protection function

● Never try jamming any part of your body to activate the jam protection

function intentionally.

● The jam protection function may not work if something gets caught just

before the panoramic roof shades fully close.

6

■ To prevent burns or injuries

Do not touch the gaps between the underside of the roof and the panoramic

roof shades.

Your hand may get caught and you could injure yourself. Also, if the vehicle

is left in direct sunlight for a long time, the underside of the roof could

become very hot and could cause burns.

NOTICE

The panoramic roof is made of resin. Follow these precautions to prevent

damage to the roof.

● When cleaning the roof, use a mild soap and a soft cloth or sponge to

remove dirt, then wash clean with plenty of water. (P. 397)

● When loading luggage onto the roof, make sure to use a roof rack

designed for this vehicle. (P. 164)

386

6-4. Using the other interior features

Garage door opener

The garage door opener can be programmed to operate garage

doors, gates, entry doors, door locks, home lighting systems,

security systems, and other devices.

The garage door opener (HomeLink® Universal Transceiver) is manu-

factured under license from HomeLink®.

Programming the HomeLink® (for U.S.A. owners)

The HomeLink® compatible transceiver in your vehicle has 3 buttons

which can be programmed to operate 3 different devices. Refer to the

programming method below appropriate for the device.

1

Buttons

2

Indicator light

: If equipped

6-4. Using the other interior features

387

■ Programming HomeLink®

Point the remote control

1

transmitter for the device 1 to

3 in. (25 to 75 mm) from the

HomeLink® buttons.

Keep the HomeLink® indicator

light in view while programming.

Press and hold one of the

2

HomeLink® buttons and the

transmitter button. When the

HomeLink® indicator light

changes from a slow to a

rapid flash, you can release

both buttons.

If the HomeLink® indicator light

comes on but does not flash, or

flashes rapidly for

2 seconds

and remains lit, the HomeLink®

button is already programmed.

6

Use the other buttons or follow

the

“Reprogramming

a

HomeLink® button” instructions.

(P. 391)

388

6-4. Using the other interior features

3

Test the HomeLink® opera-

tion by pressing the newly

programmed button.

If a HomeLink® button has been

programmed for a garage door,

check to see if the garage door

opens and closes. If the garage

door does not operate, see if

your garage transmitter is of the

rolling code type. Press and

hold

the

programmed

HomeLink® button. The remote

control transmitter is of the roll-

ing code type if the HomeLink®

indicator light flashes rapidly for

2 seconds and then remains lit.

If your transmitter is the rolling

code type, proceed to the head-

ing “Programming a rolling code

system”.

4

Repeat the steps above to program another device for any of the

remaining HomeLink® buttons.

6-4. Using the other interior features

389

■ Programming a rolling code system (for U.S.A. owners)

If your device is rolling code equipped, follow the steps under the

heading “Programming HomeLink®” before proceeding with the

steps listed below.

Locate the training button on the ceiling mounted garage door

1

opener motor. The exact location and color of the button may

vary by brand of garage door opener motor.

Refer to the operation manual supplied with the garage door opener for

the location of the training button.

Press the training button.

2

Following this step, you have 30 seconds in which to initiate step 3

below.

Press and hold the vehicle’s programmed HomeLink® button for

3

2 seconds and release it. Repeat this step once again. The

garage door may open.

If the garage door opens, the programming process is complete. If the

door does not open, press and hold the button a third time, and release

after 2 seconds. This third press and release will complete the program-

ming process by opening the garage door.

The ceiling mounted garage door opener motor should now recognize

the HomeLink® signal and operate the garage door.

6

Repeat the steps above to program another rolling code system

4

for any of the remaining HomeLink® buttons.

6-4. Using the other interior features

391

Operating HomeLink®

Press the appropriate HomeLink® button. The HomeLink® indicator

light should come on.

The HomeLink® compatible transceiver in your vehicle continues to send a

signal for up to 20 seconds as long as the button is pressed.

Reprogramming a HomeLink® button

Press and hold the desired HomeLink® button. After 20 seconds, the

HomeLink® indicator light will start flashing slowly. Keep pressing the

HomeLink® button and press and hold the transmitter button until the

HomeLink® indicator light changes from a slow to a rapid flash.

Release the buttons.

Erasing the entire HomeLink® memory (all three programs)

Press and hold the 2 outside but-

tons for 10 seconds until the indi-

cator light flashes.

If you sell your vehicle, be sure to

erase the programs stored in the

HomeLink® memory.

6

■Before programming

● Install a new battery in the remote control transmitter.

●The battery side of the remote control transmitter must be pointed away

from the HomeLink® button.

392

6-4. Using the other interior features

■Certification for the garage door opener

■ When support is necessary

Visit on the web at www.homelink.com or call 1-800-355-3515.

WARNING

■When programming a garage door or other remote control device

The garage door or other device may operate, so ensure people and

objects are out of danger to prevent potential harm.

■ Conforming to federal safety standards

Do not use the HomeLink® compatible transceiver with any garage door

opener or device that lacks safety stop and reverse features as required by

federal safety standards.

This includes any garage door that cannot detect an interfering object. A

door or device without these features increases the risk of death or serious

injury.

394

7-1. Maintenance and care

Cleaning and protecting the vehicle exterior

Perform the following to protect the vehicle and maintain it in

prime condition:

● Working from top to bottom, liberally apply water to the vehicle

body, wheel wells and underside of the vehicle to remove any dirt

and dust.

● Wash the vehicle body using a sponge or soft cloth, such as a

chamois.

● For hard-to-remove marks, use car wash soap and rinse thoroughly

with water.

● Wipe away any water.

● Wax the vehicle when the waterproof coating deteriorates.

If water does not bead on a clean surface, apply wax when the vehicle

body is cool.

■Automatic car washes

●Fold the mirrors and remove the antenna before washing the vehicle. Start

washing from the front of the vehicle. Make sure to re-install the antenna

and extend the mirrors before driving.

● Brushes used in automatic car washes may scratch the vehicle surface and

harm your vehicle’s paint.

● Roof antenna and rear spoiler may not be washable in some automatic car

washes. There may also be an increased risk of damage to vehicle.

■High pressure car washes

● Do not allow the nozzles of the car wash to come within close proximity of

the windows.

● Before using the car wash, check that the fuel filler door on your vehicle is

closed properly.

■Note for a smart key system

If the door handle becomes wet while the electronic key is within the effective

range, the door may lock and unlock repeatedly. In that case, follow the fol-

lowing correction procedures to wash the vehicle:

● Place the key in a position 6 ft. (2 m) or more separate from the vehicle

while the vehicle is being washed. (Take care to ensure that the key is not

stolen.)

● Set the electronic key to battery-saving mode to disable the smart key sys-

tem. (P. 126)

7-1. Maintenance and care

395

■Aluminum wheels

●Remove any dirt immediately by using a neutral detergent.

● Wash detergent off with water immediately after use.

● To protect the paint from damage, make sure to observe the following pre-

cautions.

• Do not use acidic, alkaline or abrasive detergent

• Do not use hard brushes

• Do not use detergent on the wheels when they are hot, such as after driv-

ing or parking in hot weather

■Bumpers

Do not scrub with abrasive cleaners.

WARNING

■ When washing the vehicle

Do not apply water to the inside of the engine compartment. Doing so may

cause the electrical components etc. to catch fire.

■ Precautions regarding the exhaust pipe

Exhaust gasses cause the exhaust pipe to become quite hot.

When washing the vehicle, be careful not to touch the pipe until it has

cooled sufficiently, as touching a hot exhaust pipe can cause burns.

7

396

7-1. Maintenance and care

NOTICE

■ To prevent paint deterioration and corrosion on the body and compo-

nents (aluminum wheels etc.)

● Wash the vehicle immediately in the following cases:

• After driving near the sea coast

• After driving on salted roads

• If coal tar or tree sap is present on the paint surface

• If dead insects, insect droppings or bird droppings are present on the

paint surface

• After driving in an area contaminated with soot, oily smoke, mine dust,

iron powder or chemical substances

• If the vehicle becomes heavily soiled with dust or mud

• If liquids such as benzene and gasoline are spilled on the paint surface

●If the paint is chipped or scratched, have it repaired immediately.

● To prevent the wheels from corroding, remove any dirt and store in a place

with low humidity when storing the wheels.

■ Cleaning the exterior lights

● Wash carefully. Do not use organic substances or scrub with a hard brush.

This may damage the surfaces of the lights.

● Do not apply wax to the surfaces of the lights.

Wax may cause damage to the lenses.

■ Antenna installation and removal precautions

●Before driving, ensure that the antenna is installed.

● When the antenna is removed, such as before entering an automatic car

wash, make sure to store it in a suitable place so as not to lose it. Also,

before driving, make sure to reinstall the antenna in its original position.

■ When using a high pressure car wash

Do not bring the nozzle tip close to boots (rubber or resin manufactured

cover), connectors or the following parts. The parts may be damaged if they

come into contact with high-pressure water.

● Traction related parts

● Steering parts

● Suspension parts

● Brake parts

7-1. Maintenance and care

397

NOTICE

■ To prevent damage to the panoramic roof (if equipped)

Observe the following precautions. Otherwise, the surface of the panoramic

roof may be damaged, or the deterioration of the coating may be acceler-

ated.

● Before washing the vehicle, remove any dust, sand or other foreign matter

using water.

● Do not use harsh brushes, scrubbing brushes or sharp objects to wash the

roof. Use only soft cloths or sponges.

● Use a mild soap when removing dirt, and avoid the use of oil-based prod-

ucts (such as glass coating or car wax), alcohol-based products (such as

glass cleaner), or abrasive cleansers.

After cleaning, wash away any remaining soap with water.

● If there is iron oxide on the vehicle, wash it away with water while wiping

gently without scrubbing.

● Do not attach suction cups or sticky objects, such as stickers.

Promptly remove the information label attached to the panoramic roof after

confirming the content.

●If snow has accumulated on the roof, remove it while being careful to avoid

scratching the roof.

If there is frost or ice on the roof, avoid the use of scrapers or de-icer.

7

Content   ..  21  22  23  24   ..
