Toyota Prius V (2018 year). Instruction - part 22
364
6-1. Using the air conditioning system and defogger
■Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after
is pressed.
■ When the outside temperature exceeds 75F (24C) and the air condition-
ing system is on
● In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically.
This may also reduce fuel consumption.
● Recirculated air mode is selected as a default mode when the power switch
is turned to ON mode.
●It is possible to switch to outside air mode at any time by pressing
■After pressing
The selection frame will automatically move to the fan speed display.
■Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Pressing
on will dehumidify the air from the outlets and defog the
windshield effectively.
● If you turn
off, the windows may fog up more easily.
●The windows may fog up if the recirculated air mode is used.
■Outside/recirculated air mode
●When driving on dusty roads such as tunnels or in heavy traffic, set
to the recirculated air mode. This is effective in preventing outside air from
entering the vehicle interior. During cooling operation, setting the recircu-
lated air mode will also cool the vehicle interior effectively.
●Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.
6-1. Using the air conditioning system and defogger
365
■Outside temperature display
In the following situations, the correct out-
side temperature may not be displayed, or
the display may take longer than normal
to change.
● When stopped, or driving at low speeds
(less than 16 mph [25 km/h])
● When the outside temperature has
changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)
■ When the outside temperature is low
The dehumidification function may not operate even when
is pressed.
■Operation of the air conditioning system in Eco drive mode
●In the Eco drive mode, the air conditioning system is controlled as follows to
prioritize fuel efficiency
• Engine speed and compressor operation controlled to restrict heating/
cooling capacity
• Fan speed restricted when automatic mode is selected
● To improve air conditioning performance, perform the following operations
• Adjust the fan speed
• Turn off Eco drive mode
• Customize the air conditioning control of Eco drive mode. (P. 565)
■ Ventilation and air conditioning odors
6
● To let fresh air in, set the air conditioning system to the outside air mode.
● During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.
● To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic
mode.
■Air conditioning filter
P. 445
■Customization
Settings (e.g. A/C auto switching operation) can be changed.
(Customizable features: P. 559)
366
6-1. Using the air conditioning system and defogger
WARNING
■ To prevent the windshield from fogging up
● Do not use
during cool air operation in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
●Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.
■ To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
NOTICE
■ To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.
6-1. Using the air conditioning system and defogger
367
Seat heaters
1
Heats the left front seat
2
Heats the right front seat
The indicator light comes on when
the seat heater is operating.
●The seat heaters can be used when the power switch is in ON mode.
● When not in use, turn off the switch. The indicator light goes off.
WARNING
●Care should be taken to prevent injury if anyone in the following categories
comes in contact with the seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
6
• Persons who have taken alcohol or drugs that induce sleep (sleeping
drugs, cold remedies, etc.)
●Observe the following precautions to prevent minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use seat heater more than necessary.
NOTICE
● Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.
● To prevent 12-volt battery discharge, do not use the functions when the
hybrid system is off.
: If equipped
368
6-2. Using the interior lights
Interior lights list
1
Rear interior light (P. 370)
2
Front personal/interior lights (P. 369)
3
Shift lever lighting
4
Footwell lights (if equipped)
5
Front door courtesy lights
6-2. Using the interior lights
369
Front interior light
Vehicles without panoramic roof
Vehicles with panoramic roof
1
Turns the lights off
1
Turns the lights off
2
Turns the door position on
2
Turns the door position on
3
Turns the lights on
3
Turns the lights on
Front personal lights
Vehicles without panoramic roof
Vehicles with panoramic roof
6
Turns the lights on/off
Turns the lights on/off
370
6-2. Using the interior lights
Rear interior light
Turns the door position on
1
When the front interior light main
switch is in the off position, the rear
interior light will not turn on even if
the door is opened with the rear
interior light switch in door position.
Turns the light on
2
●Illuminated entry system: The lights automatically turn on/off according to
power switch mode, the presence of the electronic key, whether the doors
are locked/unlocked, and whether the doors are opened/closed.
●If the interior lights remain on when the power switch is turned off, the light
will go off automatically after 20 minutes.
● Settings (e.g. the time elapsed before the lights turn off) can be changed.
(Customizable features: P. 559)
NOTICE
To prevent 12-volt battery discharge, do not leave the lights on longer than
necessary when the hybrid system is off.
6-3. Using the storage features
371
List of storage features
1
Card holder (P. 375)
4
Glove boxes (P. 372)
2
Auxiliary boxes (P. 375)
5
Bottle holders/door pockets
6
(P. 373)
3
Cup holders (P. 373)
6
Console box (P. 372)
WARNING
● Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release
gas, causing a fire hazard.
● When driving or when the storage compartments are not in use, keep the
lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
372
6-3. Using the storage features
Glove boxes
Upper glove box
Lower glove box
Pull up the lever.
Pull up the lever.
●If the lower glove box is opened when the parking lights are illuminated, the
light illuminates.
Console box
Push the button to open the lid.
The lid can be opened by pushing
either the front or rear button.
●The tray slides forward/backward and
can be removed.
6-3. Using the storage features
373
Cup holders/bottle holders/door pockets
■ Cup holders
Front passenger’s side
Center console (front)
Push the lid.
1
Type A
2
Type B
Pull out the lid.
Center console (rear)
6
Open the lid and adjust the holder.
When closing, stow the holder
before closing the lid.
374
6-3. Using the storage features
■ Bottle holders/door pockets
Front doors
Rear doors
●The type B cup holder on the center con-
sole (front side): The cup holder can be
used store small objects if the inner tray
is removed.
●When storing a bottle, close the cap.
●The bottle may not be stored depending on its size or shape.
WARNING
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.
NOTICE
Put the cap on before stowing a bottle. Do not place open bottles or glass
and paper cups containing liquid in the bottle holders.
The contents may spill and glasses may break.
6-3. Using the storage features
375
Auxiliary boxes
Type A (if equipped)
Type B
Press in the lid.
The overhead console is useful for
temporarily storing small items.
WARNING
Do not store items heavier than 0.44 lb. (200 g).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident. (type A)
6
Card holder
376
6-3. Using the storage features
Luggage compartment features
Cargo hooks
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
6-3. Using the storage features
377
Auxiliary boxes
Center
Side
Pull the lever upward to lift the
Lift the center deck board and
deck board.
then lift the side deck boards.
6
When using the auxiliary box on
Lift the side deck board from the
the front of the vehicle, fold and
front side of the vehicle to prevent
pick up the deck board and move it
hitting the cargo hook.
toward the front of the vehicle.
Behind the rear seats
Umbrellas (less than
30 in.
[77
cm] long) can be stored.
378
6-3. Using the storage features
Luggage cover
■ Installing the luggage cover
Set the holder of one side into
the installation position, then
install both holders from below
with the cover in its contracted
state.
■ Using the luggage cover
Pull out the luggage cover and
secure it to the hook brackets.
Attach the hooks to the head
restraints.
■ Removing the luggage cover
Retract the cover and release
both ends, then lift it out.
6-3. Using the storage features
379
■ Stowing the luggage cover
Lift the center deck board
1
and remove the side deck
boards.
Fold inwards together with
2
the head restraint installation
hooks and secure. Then,
stow in the auxiliary boxes.
WARNING
● To avoid injury, always return the cargo hooks to their stowed positions
6
when not in use.
● If the deck boards are removed, return them to their original positions
before driving. In the event of sudden braking, an accident may occur due
to an occupant being struck by the deck boards or the items stored in the
auxiliary box.
●Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.
380
6-4. Using the other interior features
Other interior features
Sun visors
To set the visor in the forward
1
position, flip it down.
To set the visor in the side posi-
2
tion, flip down, unhook, and
swing it to the side.
Vanity mirrors
Slide the cover to open.
The light turns on when the cover
is opened.
If the vanity light remain on when the power switch is turned off, the light will
go off automatically after 20 minutes.
NOTICE
To prevent 12-volt battery discharge, do not leave the vanity lights on for
extended periods while the hybrid system is off.
