For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equipment,
including options. Therefore, you may find some explanations for equipment
not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of color and equipment.
Noise from under vehicle after turning off the hybrid system
Approximately five hours after the hybrid system is turned off, you may hear
sound coming from under the vehicle for several minutes. This is the sound of
a fuel evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Modi-
fication with non-genuine Toyota products could affect its performance, safety
or durability, and may even violate governmental regulations. In addition,
damage or performance problems resulting from the modification may not be
covered under warranty.
9
Installation of a mobile two-way radio system
The installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as:
●Multiport fuel injection system/sequential multiport fuel injection system
● Toyota Safety Sense P
● Anti-lock brake system
●SRS airbag system
●Seat belt pretensioner system
Be sure to check with your Toyota dealer for precautionary measures or spe-
cial instructions regarding installation of a mobile two-way radio system.
High voltage parts and cables on the hybrid vehicles emit approximately the
same amount of electromagnetic waves as the conventional gasoline pow-
ered vehicles or home electronic appliances despite of their electromagnetic
shielding.
Unwanted noise may occur in the reception of the mobile two-way radio.
10
Vehicle data recordings
Your Toyota is equipped with several sophisticated computers that will record
certain data, such as:
• Engine speed
• Electric motor speed (traction motor speed)
• Accelerator status
• Brake status
• Vehicle speed
• Shift position
• Hybrid battery (traction battery) status
The recorded data varies according to the vehicle grade level and options
with which it is equipped. These computers do not record conversations or
sounds, and only record images outside of the vehicle in certain situations.
● Data Transmission
Your vehicle may transmit the data recorded in these computers to Toyota
without notification to you.
● Data usage
Toyota may use the data recorded in these computers to diagnose malfunc-
tions, conduct research and development, and improve quality.
Toyota will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if
the vehicle is leased
• In response to an official request by the police, a court of law or a govern-
ment agency
• For use by Toyota in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or
vehicle owner
● To learn more about the vehicle data collected, used and shared by
Toyota, please visit www.toyota.com/privacyvts/.
11
Event data recorder
This vehicle is equipped with an event data recorder (EDR). The main pur-
pose of an EDR is to record, in certain crash or near crash-like situations,
such as an air bag deployment or hitting a road obstacle, data that will assist
in understanding how a vehicle’s systems performed. The EDR is designed to
record data related to vehicle dynamics and safety systems for a short period
of time, typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:
• How various systems in your vehicle were operating;
• Whether or not the driver and passenger safety belts were buckled/fas-
tened;
• How far (if at all) the driver was depressing the accelerator and/or brake
pedal; and,
• How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in
which crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situ-
ation occurs; no data are recorded by the EDR under normal driving condi-
tions and no personal data (e.g., name, gender, age, and crash location) are
recorded. However, other parties, such as law enforcement, could combine
the EDR data with the type of personally identifying data routinely acquired
during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access
to the vehicle or the EDR is needed. In addition to the vehicle manufacturer,
other parties, such as law enforcement, that have the special equipment, can
read the information if they have access to the vehicle or the EDR.
● Disclosure of the EDR data
Toyota will not disclose the data recorded in an EDR to a third party except
when:
• An agreement from the vehicle’s owner (or the lessee for a leased vehi-
cle) is obtained
• In response to an official request by the police, a court of law or a govern-
ment agency
• For use by Toyota in a lawsuit
However, if necessary, Toyota may:
• Use the data for research on vehicle safety performance
• Disclose the data to a third party for research purposes without disclosing
information about the specific vehicle or vehicle owner
12
Scrapping of your Toyota
The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by your Toyota dealer
before you scrap your vehicle.
Perchlorate Material
Special handling may apply,
Your vehicle has components that may contain perchlorate. These compo-
nents may include airbag, seat belt pretensioners, and wireless remote con-
trol batteries.
WARNING
■General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
■General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows or other features of the vehicle. In addition, heat build-up or
extremely cold temperatures inside the vehicle can be fatal to children.
13
14
Reading this manual
WARNING:
Explains something that, if not obeyed, could cause death or
serious injury to people.
NOTICE:
Explains something that, if not obeyed, could cause damage to
or a malfunction in the vehicle or its equipment.
1
2
3
Indicates operating or working procedures. Follow the steps
in numerical order.
Indicates the action
(push-
ing, turning, etc.) used to
operate switches and other
devices.
Indicates the outcome of an
operation (e.g. a lid opens).
Indicates the component or
position being explained.
Means “Do not”, “Do not do
this”, or “Do not let this hap-
pen”.
15
How to search
■ Searching by name
• Alphabetical index
P. 586
■ Searching by installation
position
• Pictorial index
P. 16
■ Searching by symptom or
sound
• What to do if...
(Troubleshooting)
P. 582
■ Searching by title
• Table of contents
P. 2
16
Pictorial index
Pictorial index
■Exterior
The shape of the headlights may differ depending on the grade, etc. (P. 454)
1
Side doors
P. 114
Locking/unlocking
P. 114
Opening/closing the door glasses
P. 146
Locking/unlocking by using the mechanical key
P. 521
Warning lights
P. 480
2
Back door
P. 119
Opening from outside
P. 119
Warning lights
P. 480
3
Outside rear view mirrors
P. 144
Adjusting the mirror angle
P. 144
Folding the mirrors
P. 144
Defogging the mirrors
P. 362
Pictorial index
17
4
Windshield wipers
P. 192
Precautions against winter season
P. 262
5
Fuel filler door
P. 195
Refueling method
P. 195
Fuel type/fuel tank capacity
P. 538
6
Tires
P. 431
Tire size/inflation pressure
P. 543
Winter tires/tire chain
P. 262
Checking/rotation/tire pressure warning system
P. 431
Coping with flat tires
P. 506
7
Hood
P. 409
Opening
P. 409
Engine compartment cover
P. 414
Engine oil
P. 539
Coping with overheat
P. 528
Light bulbs of the exterior lights for driving
(Replacing method: P. 454, Watts: P. 544)
8
Headlights
P. 182
9
Parking lights
P. 182
10
Daytime running lights
P. 182
11
Side marker lights
P. 182
12
Fog lights*
P. 191
13
Turn signal lights
P. 180
14
Tail lights
P. 182
15
License plate lights
P. 182
16
Back-up lights
Shifting the shift lever to R
P. 175
*: If equipped
18
Pictorial index
■Instrument panel
1
Power switch
P. 168
Starting the hybrid system/changing the modes
P. 168, 169
Emergency stop of the hybrid system
P. 471
When the hybrid system will not start
P. 519
Warning messages
P. 501
2
Shift lever
P. 175
Changing the shift position
P. 175
Precautions against towing
P. 472
3
Meters
P. 90
Reading the meters/adjusting the instrument panel light . . . P. 90, 92
Warning lights/indicator lights
P. 86
When the warning lights come on
P. 478
Pictorial index
19
4
Multi-information display
P. 94
Display
P. 94
Energy monitor
P. 96
When the warning messages are displayed
P. 487
5
Parking brake
P. 181
Applying/releasing
P. 181
Precautions against winter season
P. 262
Warning buzzer
P. 478
6
Turn signal lever
P. 180
Headlight switch
P. 182
Headlights/parking lights/tail lights/
daytime running lights*1
P. 182
Fog lights*1
P. 191
7
Windshield wipers and washer switch
P. 192
Rear window wiper and washer switch
P. 194
Usage
P. 192, 194
Adding washer fluid
P. 425
8
Emergency flasher switch
P. 470
9
Fuel filler door opener
P. 196
10
Hood lock release lever
P. 409
11
Tilt and telescopic steering lock release lever
P. 140
12
Air conditioning system
P. 360
Usage
P. 360
Rear window defogger
P. 362
13
Entune Audio*1
P. 268
Energy monitor
P. 103
Audio system
P. 269
Hands-free system
P. 319
Entune Premium Audio with Navigation*1, 2
14
P position switch
P. 176
*1: If equipped
*2: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
20
Pictorial index
■Switches
1
Outside rear view mirror switches
P. 144
2
Window lock switch
P. 146
3
Door lock switch
P. 116
4
Power window switches
P. 146
5
Instrument panel light control dial
P. 92
6
LDA (Lane Departure Alert with steering control)
switch
P. 217
7
Automatic High Beam switch
P. 185
8
VSC OFF switch
P. 254
Pictorial index
21
1
MPH or
km/h button
P. 91
2
Clock adjustment buttons
P. 381
3
Tire pressure warning reset switch
P. 433
22
Pictorial index
1
Audio remote control switches*1
P. 272
2
Meter control switches
P. 94
3
Cruise control switch
P. 227
4
Vehicle-to-vehicle distance switch
P. 234
5
TRIP button
P. 92
6
Telephone switches*1
P. 333
7
Talk switch*1
P. 353
Pictorial index
23
1
Seat heater switches*2
P. 367
2
EV drive mode switch
P. 173
3
Driving mode select switches
P. 251
*1: Vehicles with Entune Premium Audio with Navigation, refer to
“NAVIGATION SYSTEM OWNER’S MANUAL”.
*2: If equipped
|
|
|
