Toyota Highlander Hybrid (2018 year). Instruction - part 22

5-2. Setup

357

General settings

Settings are available for adjusting the operation sounds,

screen animation, etc.

Screen for general settings

1

Press the “SETUP” button.

2

Select “General” on the “Setup”

screen.

1

“English”,

“Français”

or

“Español” can be selected.

2

On/off can be selected to

sound beeps.

3

Select to change the screen

color.

4

Select to change the key-

board layout.

5

Select to change the capaci-

5

tive touch button sensor sen-

sitivity.

6

The animation effect for the screen can be set to on/off.

7

Select to delete personal data (→P. 357)

8

Select to update program versions. For details, contact your

Toyota dealer.

Select to display the software information. Notices related to third

9

party software used in this product are enlisted. (This includes

instructions for obtaining such software, where applicable.)

■ To return to the default volume settings

Select “Default”, and then “Yes”.

Delete personal data

1

Select “Delete Personal Data” on the “General Settings” screen.

2

Select “Delete”.

Check carefully beforehand, as data cannot be retrieved once deleted.

A confirmation screen will be displayed. Select “Yes”.

3

The following personal data will be deleted or changed to its default

settings.

• General settings

• Audio settings

• Phone settings

HIGHLANDER_HV_U (OM0E032U)

358

5-2. Setup

Audio settings

Settings are available for adjusting the radio operation, cover

art, etc.

Screen for audio settings

1

Press the “SETUP” button.

2

Select “Audio” on the “Setup” screen.

1

Number of Radio Presets

Select the number of radio

preset stations.

2

Display Cover Art on/off

3

Automatic Sound Levelizer

(→P. 358)

Automatic sound leveliser (ASL)

1

Select “Automatic Sound Levelizer”.

2

Select “High”, “Mid”, “Low” or “Off”.

■ About Automatic Sound Leveliser (ASL)

ASL automatically adjusts the volume and tone quality according to the vehi-

cle speed.

HIGHLANDER_HV_U (OM0E032U)

5-2. Setup

359

Display settings

Settings are available for adjusting the contrast and brightness

of the screen.

Screen for display settings

1

Press the “SETUP” button.

2

Select “Display” on the “Setup” screen.

1

Adjust screen contrast/bright-

ness

Adjust screen contrast/bright-

2

ness of the rear view monitor

camera

Changes to day mode.

3

5

Adjusting the screen contrast/brightness

1

Select “General” or “Camera” on the “Display Settings” screen.

2

Adjust the display as desired by selecting “+” or “-”.

Day mode

When the headlights are turned on, the screen dims.

However, the screen can be switched to day mode by selecting “Day

Mode”.

The screen will stay in day mode when the headlights are turned on until

“Day Mode” is selected again.

HIGHLANDER_HV_U (OM0E032U)

360

5-2. Setup

Voice settings

This screen is used for guidance for voice command systems

setting.

1

Adjust the voice guidance vol-

ume setting.

2

Set the voice recognition

prompts “High”, “Low” or “Off”.

3

Set the train voice recognition.

4

Set the voice prompt interrupt

on/off.

5

Set the voice recognition tuto-

rial.

■ To return to the default volume settings

Select “Default”, and then “Yes”.

HIGHLANDER_HV_U (OM0E032U)

5-3. Using Entune Audio

361

Selecting the audio source

Switching between audio sources such as radio and CD are

explained in this section.

Changing audio source

1

Press the “AUDIO” button to display the audio source selection

screen.

If the audio source selection screen is not displayed, press the “AUDIO”

button again.

2

Select the desired audio

source.

1

Select the desired audio

source then

or

to

reorder.

5

Using the steering wheel switches to change audio source

The audio source changes as follows each time the “MODE/HOLD”

switch is pressed.

HIGHLANDER_HV_U (OM0E032U)

362

5-3. Using Entune Audio

List screen operation

When a list screen is displayed, use the appropriate buttons to

scroll through the list.

How to scroll

: Select to scroll to the next

or previous page.

: If

appears to the right of

titles, the complete titles are

too long for the display. Select

this button to scroll the title.

Turn the “TUNE·SCROLL” knob

to move the cursor box to select a

desired item from the list, and

press the “TUNE·SCROLL” knob

to play it. The track that is being

played is highlighted.

To return to the top screen, select “Now Playing” on the list screen.

HIGHLANDER_HV_U (OM0E032U)

5-3. Using Entune Audio

363

Selecting, fast-forwarding and reversing tracks/files/songs

■ Selecting a track/file/song

Press the

“∧” or

“∨” button on

“SEEK/TRACK” or turn the

“TUNE·SCROLL” knob to select the desired track/file/song number.

To fast-forward or reverse, press and hold the “∧” or “∨” button on

“SEEK/TRACK”.

■ Selecting a track/file/song from the track/file/song list

1

Select “Browse” or cover art.

2

Select the desired play mode. (USB and iPod)

3

Select the desired track/file/

song.

5

When an MP3/WMA/AAC disc or USB memory device is being used,

the folder can be selected. When a Bluetooth® device or iPod is being

used, the album can be selected.

According to the audio device, the following is displayed.

Audio source

List name

Audio CD

Track

MP3/WMA/AAC disc

Folder, File

Bluetooth®

Album, Track

Artists, Albums, Songs, Genres,

USB

Composers

Artists, Albums, Songs, Genres,

iPod

Composers, Audiobooks, Videos

HIGHLANDER_HV_U (OM0E032U)

364

5-3. Using Entune Audio

Optimal use of Entune Audio

On the “Sound Settings” screen, sound quality (Treble/Mid/

Bass), volume balance can be adjusted.

How to adjust the sound settings and sound quality

1

2

3

Select “-” or “+” to adjust

the treble, mid or bass to

a level between -5 and 5.

4

5

Select

“Front” or

“Rear” to

adjust the front/rear audio

balance.

6

7

Select “L” or “R” to adjust the

left/right audio balance.

■ The sound quality level is adjusted individually

The treble, mid and bass levels can be adjusted for each audio mode sepa-

rately.

HIGHLANDER_HV_U (OM0E032U)

5-4. Using the radio

365

Radio operation

Select “AM” or “FM” on the audio source selection screen to

begin listening to the radio.

Audio control screen

Pressing the “AUDIO” button displays the audio control screen from

any screens of the selected source.

1

Audio source selection screen

appears

2

Preset stations

3

Select to display RBDS text

messages*

4

Scanning for receivable station

5

Select to display a list of receiv-

able stations

5

Setting the sound (→P. 364)

6

*: FM only

Selecting a station

Tune in to the desired station using one of the following methods.

■ Seek tuning

Press the “∧” or “∨” button on “SEEK/TRACK”.

The radio will begin seeking up or down for a station of the nearest

frequency and will stop when a station is found.

■ Manual tuning

Turn the “TUNE·SCROLL” knob.

■ Preset stations

Select the desired preset station.

HIGHLANDER_HV_U (OM0E032U)

366

5-4. Using the radio

Setting station presets

1

Search for desired stations by turning the “TUNE·SCROLL” knob or

pressing the “∧” or “∨” button on “SEEK/TRACK”.

2

Select “(add new)”.

To change the preset station to a different one, select and hold the preset

station.

3

Select “Yes”.

4

Select “OK” after setting the new preset station.

■ Refreshing the station list

Select “Refresh” on the “Station List” screen.

1

To cancel the refresh, select “Cancel Refresh”.

■ Reception sensitivity

● Maintaining perfect radio reception at all times is difficult due to the continu-

ally changing position of the antenna, differences in signal strength and sur-

rounding objects, such as trains, transmitters, etc.

●The radio antenna is mounted inside the rear quarter window. To maintain

clear radio reception, do not attach metallic window tinting or other metallic

objects to the antenna wire mounted inside the rear window.

HIGHLANDER_HV_U (OM0E032U)

5-5. Playing an audio CD and MP3/WMA/AAC discs

367

CD player operation

Insert disc or select “CD” on the audio source selection screen

with a disc inserted to begin listening to a CD.

Audio control screen

Pressing the “AUDIO” button displays the audio control screen from

any screens of the selected source.

1

Audio source selection screen

appears

2

Displaying the track/file list

5

 MP3/WMA/AAC

Displaying the folder list

3

Random playback (→P. 355)

4

Repeat play (→P. 355)

5

Pause

Select

to resume play

6

Setting the sound (→P. 364)

HIGHLANDER_HV_U (OM0E032U)

368

5-5. Playing an audio CD and MP3/WMA/AAC discs

■ Displaying the title and artist name

If a CD-TEXT disc is inserted, the title of the disc and track will be displayed.

■Error messages

If an error message is displayed, refer to the following table and take the

appropriate measures. If the problem is not rectified, take the vehicle to your

Toyota dealer.

Message

Cause

Correction procedures

• The disc is dirty or

• Clean the disc.

damaged.

• Insert the disc cor-

• The disc is inserted

rectly.

“Check DISC”

upside down.

• Confirm the disc is

• The disc is not play-

playable with the

able with the player.

player.

There is a malfunction

“Disc Error”

Eject the disc.

within the system.

No playable data is

“No music files found.”

Eject the disc.

included on the disc.

■ Discs that can be used

Discs with the marks shown below can be used.

Playback may not be possible depending on recording format or disc fea-

tures, or due to scratches, dirt or deterioration.

CDs with copy-protection features may not play correctly.

■ CD player protection feature

To protect the internal components, playback is automatically stopped when a

problem is detected.

■ If a disc is left inside the CD player or in the ejected position for

extended periods

Disc may be damaged and may not play properly.

■ Lens cleaners

Do not use lens cleaners. Doing so may damage the CD player.

HIGHLANDER_HV_U (OM0E032U)

372

5-5. Playing an audio CD and MP3/WMA/AAC discs

NOTICE

■ Discs and adapters that cannot be used

Do not use the following types of CDs.

Also, do not use 3 in. (8 cm) CD adapters, Dual Discs or printable discs.

Doing so may damage the CD player and/or the CD insert/eject function.

● Discs that have a diameter that is not 4.7 in. (12 cm).

● Low-quality or deformed discs.

● Discs with a transparent or translucent recording area.

● Discs that have tape, stickers or CD-R labels attached to them, or that

have had the label peeled off.

■ Player precautions

Failure to follow the precautions below may result in damage to the discs or

the player itself.

● Do not insert anything other than discs into the disc slot.

● Do not apply oil to the player.

● Store discs away from direct sunlight.

● Never try to disassemble any part of the player.

HIGHLANDER_HV_U (OM0E032U)

5-6. Using an external device

373

Listening to an iPod

Connecting an iPod enables you to enjoy music from the vehicle

speakers.

Select “iPod” on the audio source selection screen.

When the iPod connected to the system includes iPod video, the

system can only output the sound by selecting the browse

screen.

Connecting an iPod

→P. 353

Audio control screen

Pressing the “AUDIO” button displays the audio control screen from

any screens of the selected source.

1

Audio source selection screen

5

appears

2

Displays cover art

3

Selecting the play mode

(→P. 373)

4

Shuffle play (→P. 373)

5

Repeat play (→P. 373)

6

Pause

Select

to resume playback

7

Setting the sound (→P. 364)

Selecting a play mode

1

Select “Browse” on the screen.

2

Select the desired play mode. Then select a song to begin using

the selected play mode.

Shuffle play

Select

to change on/off.

Repeat play

Select

to change on/off.

HIGHLANDER_HV_U (OM0E032U)

Content   ..  20  21  22  23   ..
