6-1. Specifications
Electrical system
Battery
Specific gravity reading at
1.250 1.290 Fully charged
20°C (68°F):
1.160 1.200 Half charged
1.060 1.100 Discharged
Charging rates
Quick charge
15 A max.
Slow charge
5 A max.
Differential
Oil capacity (Reference)
1.15 L (1.22 qt., 1.01 Imp. qt.)
Without LSD
• Toyota Genuine Differential Gear
Oil LT
• Other gear oil that meets API GL-5
and SAE 75W-85
Oil type and viscosity*
With LSD
• Toyota Genuine Differential Gear
Oil LX
• Other LSD gear oil that meets API
GL-5 and SAE 75W-85
*: Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the
factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an
equivalent of matching quality to satisfy the above specification. Please con-
tact any authorized Toyota dealer or repairer, or another duly qualified and
equipped professional for further details.
480
86_EE (OM18071E)
6-1. Specifications
NOTICE
■ Differential gear oil
Using a differential gear oil other than “Toyota Genuine Differential Gear Oil”
may cause occurrences of rattling noises and vibrations while idling and
poor fuel consumption.
Never use different brands together.
Automatic transmission
Fluid capacity*
7.5 L (7.9 qt., 6.6 Imp. qt.)
Fluid type
TOYOTA Genuine ATF WS
*: The fluid capacity is provided as a reference.
If replacement is necessary, contact any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional.
NOTICE
Using automatic transmission fluid other than “TOYOTA Genuine ATF WS”
may cause deterioration in shift quality, locking up of your transmission accom-
panied by vibration, and ultimately damage the automatic transmission of your
vehicle.
6
481
86_EE (OM18071E)
6-1. Specifications
Manual transmission
Gear oil capacity (Reference)
2.2 L (2.3 qt., 1.9 Imp. qt.)
Use either of the following:
• “TOYOTA Genuine MG Gear Oil special
Gear oil type and viscosity
II”
• Other gear oil that meets API GL-3* and
SAE 75W-90 specifications
*: The recommended oil grade is API GL-3. However, API GL-4 can also be
used.
NOTICE
■ Manual transmission gear oil
Using a manual transmission gear oil other than “TOYOTA Genuine MG
Gear Oil special II” may cause occurrences of rattling noises while idling and
poor fuel consumption.
Never use different brands together.
Clutch
Pedal free play
5 15 mm (0.2 0.6 in.)
SAE J1703 or FMVSS No.116 DOT 3 or
Fluid type
SAE J1704 or FMVSS No.116 DOT 4
482
86_EE (OM18071E)
6-1. Specifications
Brakes
Pedal clearance*1
55.0 mm (2.16 in.) min.
Pedal free play
0.5 2.7 mm (0.020 0.106 in.)
Parking brake lever travel*2
7 8 clicks
SAE J1703 or FMVSS No.116 DOT 3 or
Fluid type
SAE J1704 or FMVSS No.116 DOT 4
*1: Minimum pedal clearance when depressed with a force of 490 N (50 kgf,
110 lbf) while the engine is running.
*2: Parking brake lever travel when pulled up with a force of 200 N (20.4 kgf,
45.0 lbf).
Steering
Free play
Less than 30 mm (1.2 in.)
Tires and wheels
205/55R16 91V, 215/45R17 87W,
Tire size
T135/80D16 101M
Tire inflation pressure
(Recommended cold tire
240 kPa (2.4 kgf/cm2 or bar, 35 psi)
inflation pressure)
6
Tire inflation pressure
(compact spare)
420 kPa (4.2 kgf/cm2 or bar, 60 psi)
(Recommended cold tire
inflation pressure)
16 × 6 1/2 J, 17 × 7 J, 16 × 4T (compact
Wheel size
spare)
Wheel nut torque
120 N•m (12.2 kgf•m, 89 ft•lbf)
483
86_EE (OM18071E)
6-1. Specifications
Light bulbs
Light Bulbs
W
Type
Back-up lights
16
A
Rear fog lights
21
A
Exterior
License plate lights
5
A
Side turn signal lights
5
B
Vanity lights (if equipped)
2
C
Interior light
10
C
Interior
Door courtesy lights (if equipped)
5
B
Trunk light
5
B
A: Wedge base bulbs (clear)
B: Wedge base bulbs (amber)
C: Double end bulbs
484
86_EE (OM18071E)
6-1. Specifications
Fuel information
The engine is designed to operate at maximum performance using
unleaded gasoline with an octane rating of 98 or higher. If 98 RON
fuel is not readily available in your area, unleaded gasoline with an
octane rating of 95 RON may be used with no detriment to engine
durability or driveability. However, you may notice a slight decrease
in maximum engine performance and you may hear some knocking
(pinking) of an engine while using 95 RON fuel. Use of 95 RON fuel
will not affect your warranty coverage.
■ Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your Toyota has a fuel tank opening that
only accommodates the special nozzle on unleaded fuel pumps.
■ If your engine knocks
●Consult any authorized Toyota dealer or repairer, or another duly quali-
fied and equipped professional.
● You may occasionally notice light knocking for a short time while acceler-
ating or driving uphill. This is normal and there is no need for concern.
6
485
86_EE (OM18071E)
6-1. Specifications
NOTICE
■ Notice on fuel quality
●Do not use improper fuels. If improper fuels are used the engine will be
damaged.
●Do not use leaded gasoline.
Leaded gasoline will cause the three-way catalytic converter to lose its
effectiveness and the emission control system to function improperly.
●Do not use the methanol blended gasoline such as M15, M85, M100.
The use of gasoline containing methanol may cause engine damage or
failure.
● EU area: Bioethanol fuel sold under names such as “E50” or “E85” and
fuel containing a large amount of ethanol should not be used. The use of
these fuels will damage the vehicle's fuel system. In case of any doubt,
ask any authorized Toyota dealer or repairer, or another duly qualified and
equipped professional.
● Except EU area: Bioethanol fuel sold under names such as “E50” or “E85”
and fuel containing a large amount of ethanol should not be used. Your
vehicle can use gasoline mixed with 10% max ethanol. The use of fuel
with more than 10% ethanol content (E10) will damage the vehicle’s fuel
system. You must ensure that refueling is carried out only from a source
where fuel specification and quality can be guaranteed. In case of any
doubt, ask any authorized Toyota dealer or repairer, or another duly quali-
fied and equipped professional.
486
86_EE (OM18071E)
6-2. Customization
Customizable features
Your vehicle includes a variety of electronic features that can be per-
sonalized to your preferences. Programming these preferences
requires specialized equipment and may be performed by any autho-
rized Toyota dealer or repairer, or another duly qualified and
equipped professional.
Some function settings are changed simultaneously with other functions
being customized. Contact any authorized Toyota dealer or repairer, or
another duly qualified and equipped professional.
Customized
Item
Function
Default setting
setting
Smart entry & start sys-
On
Off
tem
Smart entry
Operation signal
& start sys-
On
Off
(Emergency flashers)
tem
(→P. 35)
Number of permissible
times of continuous
Twice
Unlimited
smart lock
Time elapsed before
60 seconds
automatic door lock
function is activated if
30 seconds
door is not opened after
120 seconds
being unlocked
Wireless
Operation signal
6
remote con-
On
Off
(Emergency flashers)
trol
(→P. 52)
Door lock buzzer
(vehicles with a smart
On
Off
entry & start system)
Trunk unlocking func-
On
Off
tion
487
86_EE (OM18071E)
6-2. Customization
Customized
Item
Function
Default setting
setting
Push and hold
Wireless
(long)
remote con-
Trunk unlocking opera-
Push and hold
One short push
trol
tion
(short)
(→P. 52)
Two short
pushes
Emergency
Operation signal
brake signal
On
Off
(Emergency flashers)
(→P. 246)
Automatic
light control
Light sensor sensitivity
±0%
-40% to +40%
system
(→P. 231)
60 seconds
Time that the low beam
Lights
headlights are on when
30 seconds
90 seconds
(→P. 231)
the vehicle is parked
120 seconds
Time elapsed before
Rear window
the rear window defog-
defogger
ger turn off (vehicles
15 minutes
Continue
(→P. 282)
with an automatic air
conditioning system)
7.5 seconds
Time elapsed before
15 seconds
lights turn off
30 seconds
Operation when the
On
Off
doors are unlocked
Operation after the
Illumination
engine switch is turned
On
Off
(→P. 286)
off
Interior light illumination
upon approach (vehi-
On
Off
cles with a smart entry
& start system)
Interior light illumination
On
Off
488
86_EE (OM18071E)
Index
Abbreviation list
490
Alphabetical index
491
What to do if
501
489
86_EE (OM18071E)
Abbreviation list
Abbreviation/Acronym list
ABBREVIATIONS
MEANING
ABS
Anti-lock Brake System
ACC
Accessory
AI-SHIFT
Artificial Intelligence Shift
CRS
Child Restraint System
DISP
Display
ECU
Electronic Control Unit
EDR
Event Data Recorder
ELR
Emergency Locking Retractor
EPS
Electric Power Steering
LED
Light Emitting Diode
LSD
Limited Slip Differential
SRS
Supplemental Restraint System
TPMS
Tire Pressure Warning System
TRC
Traction Control
VIN
Vehicle Identification Number
VSC
Vehicle Stability Control
490
86_EE (OM18071E)
Alphabetical index
Alphabetical index
A
A/C
266, 274
Anti-lock brake system
246
ABS
246
Ashtray
296
Air conditioning filter
357
Audio input
284
Air conditioning system
Audio system
Air conditioning filter
357
Audio input
284
Automatic air conditioning
AUX port
284
system
274
Portable music player
284
Manual air conditioning
Steering wheel audio
system
266
switches
285
Airbags
USB port
284
Airbag manual on/off
Automatic air conditioning
system
155
system
274
Airbag operating
Automatic headlight
conditions
115, 121
leveling system
234
Airbag precautions for
Automatic light
your child
127
control system
231
Airbag warning light
397
Automatic transmission
Curtain shield airbag
Automatic transmission
186
operating conditions
121
If the shift lever cannot be
Curtain shield airbag
shifted from P
453
precautions
127
Manual mode
189
General airbag precautions...127
Mode select switch
188
Locations of airbags
106
Paddle shift levers
189
Modification and
AUX port
284
disposal of airbags
132
Auxiliary box
304
Proper driving posture...104, 127
Side airbag operating
conditions
121
Side airbag precautions
127
Side and curtain shield
airbags operating
conditions
121
Side and curtain shield
airbags precautions
127
SRS airbags
106
491
86_EE (OM18071E)
Alphabetical index
B
Back-up lights
C
Care
Replacing light bulbs
372
Alcantara®
316
Wattage
484
Aluminum wheels
309
Battery
Exterior
308
Checking
335
Interior
312
If the vehicle has a
Seat belts
313
discharged battery
459
Chains
259
Preparing and checking
Child restraint system
before winter
259
Baby seats, definition
136
Bottle holders
290
Baby seats, installation
145
Brake
Child seats, definition
136
Parking brake
198
Child seats, installation
145
Brake assist
246
Installing CRS with ISOFIX
Break-in tips
163
rigid anchor
149
Brightness control
Installing CRS with
Instrument panel light
seat belts
146
control
202
Installing CRS with
top straps
150
Junior seats, definition
136
Junior seats, installation
145
492
86_EE (OM18071E)
Alphabetical index
Child safety
D
Daytime running light
Airbag precautions
127
system
233
Battery precautions
338, 462
Defogger
Child restraint system
136
Rear window
282
How your child should
Side mirror
282
wear the seat belt
75
Dimensions
472
Installing child restraints
145
Display
Power window lock switch
85
Drive information
218
Power window precautions
88
Multi-information
Removed key battery
display
210, 215
precautions
363
Trip information
213, 216
Seat belt guide
74
Warning messages
404
Seat belt precautions
76
Do-it-yourself maintenance
321
Seat heater precautions
299
Door courtesy lights
Trunk precautions
62
Door courtesy lights
286
Cleaning
Wattage
484
Alcantara®
316
Doors
Aluminum wheels
309
Door lock
35, 52, 57
Exterior
308
Door windows
85
Interior
312
Double locking system
102
Seat belts
313
Side mirrors
82
Clock
295
Drive information
218
Condenser
334
Driver's seat belt
Console tray
291
reminder light
399
Coolant
Driving
Capacity
479
Break-in tips
163
Checking
332
Correct posture
104
Cooling system
Procedures
160
Engine overheating
464
Winter drive tips
259
Cruise control
241
Cup holders
291
Curtain airbags
106
Customizable features
487
493
86_EE (OM18071E)
Alphabetical index
E
Electric power steering
246
Engine
Electronic key
Compartment
328
If the electronic key does
Engine switch
174, 183
not operate properly
455
Hood
324
Emergency brake signal
246
How to start the
Emergency flashers
engine
174, 183
Switch
384
Identification number
473
Emergency, in case of
If the engine will not start
450
If the electronic key does
Ignition switch
174, 183
not operate properly
455
Overheating
464
If the engine will not start
450
Engine coolant
If the shift lever cannot
Capacity
479
be shifted from P
453
Checking
332
If the vehicle has a
Engine coolant temperature
discharged battery
459
gauge
200
If the warning buzzer
Engine immobilizer system
93
sounds
395
Engine oil
If the warning light
Capacity
476
turns on
395
Checking
329
If the warning message
Preparing and checking
is displayed
404
before winter
259
If you have a flat tire
422, 438
Engine switch
174, 183
If you lose your keys
454
Engine switch light
286
If you think something is
EPS
246
wrong
393
Event data recorder
26
If your vehicle becomes
stuck
467
If your vehicle has to be
stopped in an
emergency
469
If your vehicle needs to
be towed
385
If your vehicle overheats
464
494
86_EE (OM18071E)
