Toyota Verso S (2014 year). Instruction - part 21
3-2. Using the audio system
MP3 and WMA playback
When a disc containing MP3 or WMA files is inserted, all files on the disc
are first checked. Once the file check is finished, the first MP3 or WMA file
is played. To make the file check finish more quickly, we recommend you
do not write in any files other than MP3 or WMA files or create any unnec-
essary folders.
If the discs contain a mixture of music data and MP3 or WMA format data,
only music data can be played.
Extensions
If the file extensions .mp3 and .wma are used for files other than MP3 and
WMA files, they will be mistakenly recognized and played as MP3 and
WMA files. This may result in large amounts of interference and damage
to the speakers.
Playback
• To play MP3 files with steady sound quality, we recommend a fixed bit
rate of 128 kbps and a sampling frequency of 44.1 kHz.
• CD-R or CD-RW playback may not be possible in some instances,
depending on the characteristics of the disc.
• There is a wide variety of freeware and other encoding software for
MP3 and WMA files on the market, and depending on the status of the
encoding and the file format, poor sound quality or noise at the start of
playback may result. In some cases, playback may not be possible at
all.
• When files other than MP3 or WMA files are recorded on a disc, it may
take more time to recognize the disc and in some cases, playback may
not be possible at all.
• Microsoft, Windows, and Windows Media are the registered trade-
marks of Microsoft Corporation in the U.S. and other countries.
NOTICE
CDs and adapters that cannot be used (P. 292)
CD player precautions (P. 293)
300
3-2. Using the audio system
Operating an iPod
Connecting an iPod enables you to enjoy music from the vehicle
speakers.
Connecting an iPod
STEP
1
Open the auxiliary box.
3
STEP
2
Open the cover and connect
an iPod using an iPod cable.
Turn on the power of the iPod if
it is not turned on.
Close the auxiliary box and press
STEP
3
: If equipped
301
3-2. Using the audio system
Control panel
Shuffle playback
Power
Volume
iPod menu/Song
selector or
displays text
message
Repeat play
iPod
menu
mode
Displays lists
Playback
Back
button
Selecting a song, fast-forwarding or reversing
Selecting a play mode
STEP
1
Press
(MENU) to select iPod menu mode.
STEP
2
Turning
clockwise changes the play mode in the fol-
lowing order:
“Playlists”“Artists”“Albums”“Songs”“Podcasts”“Genres”
“Composers”“Audiobooks”
STEP
3
Press
to select the desired play mode.
302
3-2. Using the audio system
Play mode list
First
Second
Third
Fourth
Play mode
selection
selection
selection
selection
Playlists
Songs
“Playlists”
-
-
select
select
Albums
Songs
“Artists”
Artists select
-
select
select
Albums
Songs
“Albums”
-
-
select
select
“Songs”
Songs select
-
-
-
Podcasts
Episodes
“Podcasts”
-
-
3
select
select
Albums
Songs
“Genres”
Genre select
Artists select
select
select
Composers
Albums
Songs
“Composers”
-
select
select
select
Audiobooks
Chapters
“Audiobooks”
-
-
select
select
Selecting a list
STEP
1
Turn
to display the first selection list.
STEP
2
Press
to select the desired item.
Pressing the knob changes to the second selection list.
STEP
3
Repeat the same procedure to select the desired item.
To return to the previous selection list, press
303
3-2. Using the audio system
Selecting songs
Turn
or press “” or “” on
to select the desired song.
Selecting a song from the song list
STEP
1
Press
The song list will be displayed.
STEP
2
Turn
to select a song.
STEP
3
Press
to play the song.
To return to the previous display, press
Fast-forwarding and reversing songs
To fast-forward or reverse, press and hold “” or “” on
304
3-2. Using the audio system
Shuffle playback
Pressing
(RDM) changes modes in the following order:
Track shuffle Album shuffle Off.
Repeat play
Press
(RPT).
To cancel, press
(RPT) again.
Switching the display
3
Press
Track title, Artist name and Album title are shown on the display.
To return to the previous display, press
or
Adjusting sound quality and volume balance
STEP
1
Press
to enter iPod menu mode.
STEP
2
Turning
changes sound modes. (P. 317)
305
3-2. Using the audio system
About iPod
Apple is not responsible for the operation of this device or its compliance
with safety and regulatory standards.
iPod is a trademark of Apple Inc., registered in the U.S. and other coun-
tries.
iPod functions
When an iPod is connected and the audio source is changed to iPod
mode, the iPod will resume play from the same point in which it was last
used.
Depending on the iPod that is connected to the system, certain functions
may not be available. If a function is unavailable due to a malfunction (as
opposed to a system specification), disconnecting the device and recon-
necting it once again may resolve the problem.
While connected to the system, the iPod cannot be operated with its own
controls. It is necessary to use the controls of the vehicle’s audio system
instead.
iPod problems
To resolve most problems encountered when using your iPod, disconnect
your iPod from the vehicle iPod connection and reset it.
For instructions on how to reset your iPod, refer to your iPod Owner’s Man-
ual.
Display
P. 291
Error messages
“ERROR”:
This indicates a problem in the iPod or its connection.
“NO SONGS”: This indicates that there is no music data in the iPod.
“NO PLAYLISTS”: This indicates that some available songs are not found in
a selected playlist.
“UPDATE YOUR IPOD”: This indicates that the version of the iPod is not
compatible. Upgrade your iPod software to the lat-
est version.
306
3-2. Using the audio system
Compatible models
Model
Generation
Software version
iPod
5th generation
Ver. 1.3.0 or higher
1st generation
Ver. 1.3.1 or higher
2nd generation
Ver. 1.1.3 or higher
iPod nano
3rd generation
Ver. 1.1.3 or higher
4th generation
Ver. 1.0.4 or higher
5th generation
Ver. 1.0.1 or higher
1st generation
Ver. 3.1.2 or higher
2nd generation
Ver. 3.1.2 or higher
iPod touch
3
Late 2009 (8 GB)
Ver. 3.1.2 or higher
Late 2009 (32 GB/64 GB)
Ver. 3.1.2 or higher
1st generation
Ver. 1.1.2 or higher
iPod classic
2nd generation (120 GB)
Ver. 2.0.1 or higher
Late 2009 (160 GB)
Ver. 2.0.3 or higher
1st generation (iPhone)
Ver. 3.1.2 or higher
2nd generation (iPhone 3G)
Ver. 3.1.2 or higher
iPhone
3rd generation (iPhone
Ver. 3.1.2 or higher
3GS)
4th generation (iPhone 4)
Ver. 4.0.0 or higher
Depending on differences between models or software version etc., some
models listed above might be incompatible with this system.
iPod 4th generation and earlier models are not compatible with this system.
iPod mini, iPod shuffle and iPod photo are not compatible with this system.
Items related to standards and limitations are as follows:
Maximum number of lists in device: 9999
Maximum number of songs in device: 65535
Maximum number of songs per list: 65535
307
3-2. Using the audio system
CAUTION
Caution while driving
Do not connect iPod or operate the controls.
NOTICE
To prevent damage to iPod
Do not leave iPod in the vehicle. The temperature inside the vehicle may
become high, resulting in damage to the iPod.
Do not push down on or apply unnecessary pressure to the iPod while it is
connected as this may damage the iPod or its terminal.
Do not insert foreign objects into the port as this may damage the iPod or
its terminal.
308
3-2. Using the audio system
Operating a USB memory
Connecting a USB memory enables you to enjoy music from the
vehicle speakers.
Connecting a USB memory
STEP
1
Open the auxiliary box.
3
STEP
2
Open the cover and connect a
USB memory.
Turn on the power of the USB
memory if it is not turned on.
Close the auxiliary box and press
STEP
3
: If equipped
309
3-2. Using the audio system
Control panel
File selector
Power
Volume
or displays
text message
Repeat play
Random
playback
Selecting
a folder
Displays folder lists
Playback Back button
Selecting a file, fast-forwarding or reversing
Selecting a folder
Selecting folders one at a time
Press “” or “” on
to select the desired folder.
Selecting from folder lists
STEP
1
Press
The folder list will be displayed.
STEP
2
Turn and press
to select a folder and a file.
To return to the previous display, press
310
3-2. Using the audio system
Returning to the first folder
Press and hold “” on
until you hear a beep.
Selecting files
Turn
or press “” or “” on
to select the desired file.
Fast-forwarding and reversing files
To fast-forward or reverse, press and hold “” or “” on
3
Random playback
Pressing
(RDM) changes modes in the following order:
Folder random Disc random Off.
Repeat play
Pressing
(RPT) changes modes in the following order:
File repeat Folder repeat* Off.
*: Available except when RDM (random playback) is selected
311
3-2. Using the audio system
Switching the display
Press
Track title, Artist name and Album title (MP3 only) are displayed on the
display.
To return to the previous display, press
or
USB memory functions
Depending on the USB memory that is connected to the system, the
device itself may not be operable and certain functions may not be avail-
able. If the device is inoperable or a function is unavailable due to a mal-
function (as opposed to a system specification), disconnecting the device
and reconnecting it once again may resolve the problem.
If the USB memory still does not begin operation after being discon-
nected and reconnected, format the memory.
Display
P. 291
Error messages
“ERROR”: This indicates a problem in the USB memory or its connection.
“NO MUSIC”: This indicates that no MP3/WMA files are included in the USB
memory.
312
3-2. Using the audio system
USB memory
Compatible devices
USB memory that can be used for MP3 and WMA playback
Compatible device formats
The following device formats can be used:
• USB communication formats: USB2.0 FS (12 mbps)
• File formats: FAT16/32 (Windows)
• Correspondence class: Mass storage class
MP3 and WMA files written in any format other than those listed above
may not play correctly, and their file names and folder names may not be
displayed correctly.
Items related to standards and limitations are as follows:
• Maximum directory hierarchy: 8 levels
3
• Maximum number of folders in a device: 999 (including the root)
• Maximum number of files in a device: 9999
• Maximum number of files per folder: 255
MP3 and WMA files
MP3 (MPEG Audio LAYER 3) is a standard audio compression format.
Files can be compressed to approximately 1/10 of their original size using
MP3 compression.
WMA (Windows Media Audio) is a Microsoft audio compression format.
This format compresses audio data to a size smaller than that of the MP3
format.
There is a limit to the MP3 and WMA file standards that can be used and
to the media/formats on which the files are recorded.
313
3-2. Using the audio system
MP3 file compatibility
• Compatible standards
MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III,
MPEG2.5)
• Compatible sampling frequencies
MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz)
MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz)
MPEG2.5: 8, 11.025, 12 (kHz)
• Compatible bit rates (compatible with VBR)
MPEG1 AUDIO LAYERII, III: 32-320 (kbps)
MPEG2 AUDIO LAYERII, III: 32-160 (kbps)
MPEG2.5: 32-160 (kbps)
• Compatible channel modes: stereo, joint stereo, dual channel and
monaural
WMA file compatibility
• Compatible standards
WMA Ver. 9
• Compatible sampling frequencies
HIGH PROFILE 32, 44.1, 48 (kHz)
• Compatible bit rates
HIGH PROFILE 32-320 (kbps, VBR)
File names
The only files that can be recognized as MP3/WMA and played are those
with the extension .mp3 or .wma.
ID3 and WMA tags
ID3 tags can be added to MP3 files, making it possible to record the track
title, artist name, etc.
The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3
tags. (The number of characters is based on ID3 Ver. 1.0 and 1.1.)
WMA tags can be added to WMA files, making it possible to record the
track title and artist name in the same way as with ID3 tags.
314
