Toyota Verso S (2014 year). Instruction - part 20

3-2. Using the audio system

Using the radio

Station selector

AF/region code/TA

Power

Volume

mode setup

Adjusting the

frequency or

selecting items

Seeking

3

the

frequency

Displaying

AM/FM mode

Back button

station list

button

Setting station presets

STEP

1

Search for desired stations by turning

or pressing “”

or “” on

STEP

2

Press and hold the button (from

[1] to

[6]) the

station is to be set to until you hear a beep.

: If equipped

285

3-2. Using the audio system

Using the station list

 Updating the station list

STEP

1

Press

The station list will be displayed.

STEP

2

Press

(UPDATE) to update the list.

“Updating” is displayed while the searching is in process, and then

available stations will be listed on the display.

To cancel the updating process, press

 Selecting a station from the station list

STEP

1

Press

The station list will be displayed.

STEP

2

Turn

to select a station.

STEP

3

Press

to tune in the station.

To return to the previous display, press

RDS (Radio Data System)

This feature allows your radio to receive RDS data.

 Listening to stations of the same network

STEP

1

Press

STEP

2

Turn

to “RADIO” and press

STEP

3

Turn

as corresponds to the desired mode: “FM AF” or

“Region code”.

286

3-2. Using the audio system

STEP

4

Press

to select “ON” or “OFF”.

FM AF ON mode:

The station among those of the same net-

work with strong reception is selected.

Region code ON mode: The station among those of the same net-

work with strong reception and broad-

casting the same program is selected.

 Traffic information

STEP

1

Press

STEP

2

Turn

to “RADIO” and press

3

STEP

3

Turn

to “FM TA” mode.

STEP

4

Press

to select “ON” or “OFF”.

TP mode: The system automatically switches to traffic information

when a broadcast with a traffic information signal is

received.

The station returns to the previous one when the traffic infor-

mation ends.

TA mode: The system automatically switches to traffic information

when a broadcast with a traffic information signal is

received. In FM modes, the system will be mute unless

traffic information is being broadcast.

The audio system returns to the previous mode when the traf-

fic information ends.

287

3-2. Using the audio system

Using the CD player

Power

Volume

CD eject

Random playback

Selecting a track or

displays text message

Repeat play

3

Displaying

Playback

Back button

track list

Selecting a track, fast-forwarding or reversing

Loading CDs

Insert a CD.

Ejecting CDs

Press

and remove the CD.

Selecting a track

Turn

or press “” to move up or “” to move down using

until the desired track number is displayed.

: If equipped

289

3-2. Using the audio system

Selecting a track from a track list

STEP

1

Press

The track list will be displayed.

STEP

2

Turn and press

to select a track.

To return to the previous display, press

or

Fast-forwarding and reversing tracks

To fast-forward or reverse, press and hold “” or “” on

Repeat play

Press

(RPT).

The current track is played repeatedly until

(RPT) is pressed

again.

Random playback

Press

(RDM).

Tracks are played in a random order until

(RDM) is pressed again.

290

3-2. Using the audio system

Switching the display

Press

Track name, Artist name and CD title are shown on the display.

To return to the previous display, press

or

Display

Up to 24 characters can be displayed.

Depending on the contents recorded, the characters may not be displayed

3

properly or may not be displayed at all.

 Error messages

“ERROR”:

This indicates a problem either in the CD or inside the player.

“CD CHECK”: The CD may be dirty, damaged or inserted up-side down.

“WAIT”:

Operation has stopped due to a high temperature inside the

player. Wait for a while and then press

. Contact

any authorized Toyota dealer or repairer, or another duly

qualified and equipped professional if the CD still cannot be

played.

 Discs that can be used

Discs with the marks shown below can be used.

Playback may not be possible depending on recording format or disc fea-

tures, or due to scratches, dirt or deterioration.

CDs with copy-protect features may not be used.

291

3-2. Using the audio system

 CD player protection feature

To protect the internal components, playback is automatically stopped when

a problem is detected while the CD player is being used.

 If a CD is left inside the CD player or in the ejected position for

extended periods

The CD may be damaged and may not play properly.

Lens cleaners

Do not use lens cleaners. Doing so may damage the CD player.

CAUTION

 Certification for the CD player

This product is a class I laser product.

 A laser beam leak may result in hazardous radiation exposure.

 Do not open the cover of the player or attempt to repair the unit yourself.

Refer servicing to qualified personnel.

 Laser power: No hazardous

NOTICE

 CDs and adapters that cannot be used

Do not use the following types of CDs. Also, do not use 8 cm (3 in.) CD

adapters, DualDiscs or printable discs.

Doing so may damage the CD player and/or the CD insert/eject function.

 CDs that have a diameter that is not 12

cm (4.7 in.)

292

3-2. Using the audio system

NOTICE

 Low-quality and deformed CDs

 CDs with a transparent or translucent

recording area

3

 CDs that have had tape, stickers or CD-

R labels attached to them, or that have

had the label peeled off

 CD player precautions

Failure to follow the precautions below may result in serious damage to the

CDs or the player itself.

 Do not insert anything other than CDs into the CD slot.

 Do not apply oil to the CD player.

 Store CDs away from direct sunlight.

 Never try to disassemble any part of the CD player.

293

3-2. Using the audio system

Playing back MP3 and WMA discs

Power

Volume

CD eject

Random playback

Selecting a file

or displays text

Repeat play

message

Selecting a

folder

Displays

Playback

Back button

folder lists

Selecting a track, fast-forwarding or reversing

Loading and ejecting MP3 and WMA discs

P. 289

Selecting a folder

To select the desired folder, press “” or “” on

To return to the first folder, press and hold “” on

until you hear a

beep.

: If equipped

294

3-2. Using the audio system

 Selecting a folder and file from folder lists

STEP

1

Press

The folder list will be displayed.

STEP

2

Turn and press

to select a folder and a file.

To return to the previous display, press

To exit, press

Selecting files

Turn

or press “” or “” on

to select the desired file.

3

Fast-forwarding and reversing files

To fast-forward or reverse, press and hold “” or “” on

Repeat play

Pressing

(RPT) changes modes in the following order:

File repeat  Folder repeat*  Off.

*: Available except when RDM (random playback) is selected

295

3-2. Using the audio system

Random playback

Pressing

(RDM) changes modes in the following order:

Folder random  Disc random  Off.

Switching the display

Press

Track title, Artist name and Album title (MP3 only) are shown on the dis-

play.

To return to the previous display, press

or

296

3-2. Using the audio system

Display

Up to 24 characters can be displayed.

Depending on the contents recorded, the characters may not be displayed

properly or may not be displayed at all.

 Canceling random and repeat playback

Press

(RPT) or

(RDM), or press and hold “” on

 Error messages

“ERROR”:

This indicates a problem either in the CD or inside the

player.

“CD CHECK”: The CD may be dirty, damaged or inserted up-side down.

3

“NO SUPPORT”: This indicates that the MP3/WMA file is not included in the

CD.

 Discs that can be used

Discs with the marks shown below can be used.

Playback may not be possible depending on recording format or disc fea-

tures, or due to scratches, dirt or deterioration.

 CD player protection feature

To protect the internal components, playback is automatically stopped when

a problem is detected while the CD player is being used.

297
