PP–28

PREPARATION  –  VF2A TRANSFER

PP

LUBRICANT

Item

Capacity

Classification

Transfer oil

1.0 liters (1.1 US qts, 0.9 lmp. qts)

API GL-3 SAE 75W-90

PREPARATION  –  VF4B TRANSFER

PP–27

PP

PREPARATION

PREPARATION

VF4B TRANSFER

SST

09223-15020

Oil Seal & Bearing Replacer

09223-46011

Crankshaft Front Oil Seal
Replacer

09304-12012

Input Shaft Front Bearing
Replacer

09308-00010

Oil Seal Puller

09316-60011

Transmission & Transfer Bearing
Replacer

(09316-00011)

Replacer Pipe

(09316-00031)

Replacer B

(09316-00071)

Replacer F

09330-00021

Companion Flange Holding Tool

09515-30010

Rear Wheel Bearing Replacer

09554-30011

Differential Oil Seal Replacer

PP–28

PREPARATION  –  VF4B TRANSFER

PP

09555-55010

Differential Drive Pinion
Bearing Replacer

09612-65014

Steering Worm Bearing Puller

(09612-01030)

Claw C

(09612-01050)

Hanger Pin with Nut

09631-32020

Seal Ring Tool

09950-40011

Puller B Set

(09951-04020)

Hanger 200

(09952-04010)

Slide Arm

(09953-04030)

Center Bolt 200

(09954-04010)

Arm 25

(09955-04051)

Claw No.5

(09957-04010)

Attachment

PREPARATION  –  VF4B TRANSFER

PP–29

PP

(09958-04011)

Holder

09950-60010

Replacer Set

(09951-00320)

Replacer 32

(09951-00570)

Replacer 57

(09951-00590)

Replacer 59

09950-70010

Handle Set

(09951-07100)

Handle 100
