PP–22

PREPARATION  –  RA61F MANUAL TRANSMISSION

PP

(09951-00300)

Replacer 30

(09951-00320)

Replacer 32

(09951-00470)

Replacer 47

(09951-00510)

Replacer 51

(09951-00540)

Replacer 54

(09951-00650)

Replacer 65

09950-60020

Replacer Set No.2

(09951-00790)

Replacer 79

09950-70010

Handle Set

(09951-07100)

Handle 100

(09951-07200)

Handle 200

(09951-07360)

Handle 360

PREPARATION  –  RA61F MANUAL TRANSMISSION

PP–23

PP

RECOMMENDED TOOLS

09031-00040

Pin Punch .

09040-00011

Hexagon Wrench Set

(09043-20100)

Socket Hexagon Wrench 10

(09043-30240)

Straight  Hexagon Wrench 24

09905-00012

Snap Ring No.1 Expander

09905-00013

Snap Ring Pliers

PP–24

PREPARATION  –  RA61F MANUAL TRANSMISSION

PP

EQUIPMENT

Cylinder gauge

Dial indicator

Feller gauge

Micrometer

Torque wrench

Vernier calipers

Press

V-block

PREPARATION  –  RA61F MANUAL TRANSMISSION

PP–25

PP

LUBRICANT

Item

Capacity

Classification

Manual transmission oil

1.8 liters (1.9 US qts, 1.6 lmp. qts)

API GL-4 or GL-5
SAE 75W-90
