Toyota FJ Cruiser (GSJ 10, 15 series). Instruction - part 381

PREPARATION  –  A750E AUTOMATIC TRANSMISSION

PP–13

PP

PREPARATION

PREPARATION

A750E AUTOMATIC TRANSMISSION

SST

09023-12701

Union Nut Wrench 17mm

09223-15020

Oil Seal & Bearing Replacer

09308-00010

Oil Seal Puller

09320-89010

Transfer Clutch Spring
Compressor

09325-40010

Transmission Oil Plug

09350-30020

TOYOTA Automatic Transmission
Tool Set

(09350-07020)

Oil Pump Puller

(09350-07040)

No.2 Piston Spring Compressor

(09350-07050)

No.3 Piston Spring Compressor

(09350-07060)

No.1 Snap Ring Expander

(09350-07070)

No.2 Snap Ring Expander

PP–14

PREPARATION  –  A750E AUTOMATIC TRANSMISSION

PP

(09350-07080)

Brake Reaction Sleeve Puller

(09350-07090)

Brake No.1 Piston Puller

(09350-07110)

Oil Seal Replacer

(09351-32140)

Oil Seal Replacer

09350-32014

TOYOTA Automatic Transmission
Tool Set

(09351-32020)

Stator Stopper

09351-40010

Tool Set, TOYOTA Automatic
Transmission

09387-00070

First & Reverse Brake Wrench

09710-30050

Suspension Arm Bushing Replacer

09843-18040

Diagnosis Check Wire No.2

09950-70010

Handle Set

(09951-07100)

Handle 100

PREPARATION  –  A750E AUTOMATIC TRANSMISSION

PP–15

PP

09992-00095

Automatic Transmission Oil
Pressure Gauge Set

(09992-00231)

Adaptor C

(09992-00271)

Gauge Assy

PP–16

PREPARATION  –  A750E AUTOMATIC TRANSMISSION

PP

RECOMMENDED TOOLS

09040-00011

Hexagon Wrench Set

(09043-20060)

Socket Hexagon Wrench 6

(09043-20100)

Socket Hexagon Wrench 10

09082-00040

TOYOTA Electrical Tester

(09083-00150)

Test Lead Set
