PP–10

PREPARATION  –  1GR-FE LUBRICATION

PP

EQUIPMENT

Feeler gauge

Precision straight edge

Torque wrench

Vernier caliper

Dial indicator with magnetic base

Wooden block

Seal Packing Black

Seal Packing 1282B

Adhesive 1344

PREPARATION  –  1GR-FE LUBRICATION

PP–11

PP

LUBRICANT

Item

Capacity

Classification

Oil grade

-

ILSAC multigrade engine oil, SAE 5W-30

with Oil filter change

5.2 liter (5.5 US qts, 4.6 lmp. qts)

-

without Oil filter change

4.9 liter (5.2 US qts, 4.3 lmp. qts)

-

Dry fill

6.0 liter (6.3 US qts, 5.3lmp. qts)

-

PP–10

PREPARATION  –  1GR-FE IGNITION

PP

PREPARATION

PREPARATION

1GR-FE IGNITION

RECOMMENDED TOOLS

09082-00040

TOYOTA Electrical Tester

(09083-00150)

Test Lead Set

09200-00010

Engine Adjust Kit

(09857-00031)

Spark Plug Gap Gauge

PREPARATION  –  1GR-FE IGNITION

PP–11

PP

EQUIPMENT

Ohmmeter

Torque wrench

Spark plug cleaner
