INTERIOR  –  ROOF HEADLINING

IR–7

IR

x4

w/ Woofer:

AMPLIFIER BOX
SPEAKER ASSEMBLY

DECK SIDE GARNISH

PACKAGE HOLDER
NET HOOK

QUARTER TRIM POCKET

QUARTER TRIM POCKET TRAY

SIDE TRIM COVER

SPEAKER MOUNTING COVER

N*m (kgf*cm, ft*lbf)  : Specified torque

8.1 (85, 72 in.*lbf)

REAR DECK
TRIM COVER

POWER OUTLET
CONNECTOR

w/ Power Outlet Socket:

SPEAKER CONNECTOR

B134989E01

IR–8

INTERIOR  –  ROOF HEADLINING

IR

42 (430, 31)

N*m (kgf*cm, ft*lbf)  : Specified torque

x3

DECK TRIM SIDE PANEL
ASSEMBLY RH

LAP BELT OUTER
ANCHOR COVER

REAR SEAT OUTER
BELT ASSEMBLY RH

ROOF SIDE INNER
GARNISH RH

B130658E01

INTERIOR  –  ROOF HEADLINING

IR–9

IR

DECK TRIM SIDE PANEL
ASSEMBLY LH

LAP BELT OUTER
ANCHOR COVER

PACKAGE HOLDER
NET HOOK

REAR SEAT OUTER
BELT ASSEMBLY LH

42 (430, 31)

N*m (kgf*cm, ft*lbf)  : Specified torque

x3

ROOF SIDE INNER
GARNISH LH

B130659E01

IR–10

INTERIOR  –  ROOF HEADLINING

IR

ASSIST GRIP
ASSEMBLY

ASSIST GRIP PLUG

COAT HOOK

ASSIST GRIP
ASSEMBLY

ASSIST GRIP PLUG

COAT HOOK

ROOF HEADLINING
HOLE PLUG

ROOF HEADLINING
HOLE PLUG

w/ Curtain Shield Airbag:

B130660E01
