Toyota FJ Cruiser (GSJ 10, 15 series). Instruction - part 250

INTERIOR  –  ROOF HEADLINING

IR–3

IR

BODY

INTERIOR

ROOF HEADLINING

COMPONENTS

REAR SEATBACK
ASSEMBLY LH

REAR SEATBACK
ASSEMBLY RH

REAR SEATBACK BOARD
CARPET ASSEMBLY LH

REAR SEATBACK BOARD
CARPET ASSEMBLY RH

37 (375, 27)

N*m (kgf*cm, ft*lbf)  : Specified torque

37 (375, 27)

37 (375, 27)

42 (430, 31)

37 (375, 27)

REAR SEAT INNER
BELT ASSEMBLY RH

REAR CENTER SEAT
INNER BELT ASSEMBLY

REAR SEAT INNER
BELT ASSEMBLY LH

B130654E01

IR–4

INTERIOR  –  ROOF HEADLINING

IR

REAR FLOOR BOARD

REAR FLOOR MAT
ASSEMBLY

REAR FLOOR MAT
SUPPORT PLATE

LUGGAGE HOLD BELT
STRIKER ASSEMBLY

LUGGAGE HOLD BELT
STRIKER ASSEMBLY

x2

x5

LUGGAGE HOLD BELT
STRIKER ASSEMBLY

B130655E01

INTERIOR  –  ROOF HEADLINING

IR–5

IR

ASSIST GRIP
ASSEMBLY

ASSIST GRIP PLUG

COWL SIDE TRIM
BOARD RH

FRONT DOOR OPENING
TRIM WEATHERSTRIP RH

FRONT DOOR SCUFF
PLATE RH

FRONT PILLAR
GARNISH RH

ACCESS DOOR
SCUFF PLATE RH

ROOF SIDE INNER
GARNISH COVER RH

ROOF SIDE RAIL
GARNISH RH

B130656E01

IR–6

INTERIOR  –  ROOF HEADLINING

IR

ASSIST GRIP
ASSEMBLY

ASSIST GRIP PLUG

COWL SIDE TRIM
BOARD LH

FOOTREST CLIP

FRONT DOOR OPENING
TRIM WEATHERSTRIP LH

FRONT DOOR SCUFF
PLATE LH

FRONT FLOOR
FOOTREST

FRONT PILLAR
GARNISH LH

ACCESS DOOR
SCUFF PLATE LH

ROOF SIDE INNER
GARNISH COVER LH

ROOF SIDE RAIL
GARNISH LH

B130657E01
