Toyota FJ Cruiser (GSJ 10, 15 series). Instruction - part 240

INSTRUMENT PANEL  –  INSTRUMENT PANEL ASSEMBLY

IP–3

IP

CONSOLE UPPER REAR
PANEL SUB-ASSEMBLY

PARKING BRAKE HOLE
COVER SUB-ASSEMBLY

for Automatic Transmission 2WD:

for Manual Transmission 4WD:

CONSOLE UPPER
REAR PANEL
SUB-ASSEMBLY

PARKING BRAKE HOLE
COVER SUB-ASSEMBLY

BOX BOTTOM MAT

<D>

<D>

SHIFT LEVER KNOB
SUB-ASSEMBLY

SHIFT LEVER KNOB
SUB-ASSEMBLY

for Automatic Transmission 4WD:

SHIFT LEVER KNOB
SUB-ASSEMBLY

PARKING BRAKE HOLE
COVER SUB-ASSEMBLY

CONSOLE UPPER
REAR PANEL
SUB-ASSEMBLY

FRONT CONSOLE BOX

B133844E01

IP–4

INSTRUMENT PANEL  –  INSTRUMENT PANEL ASSEMBLY

IP

RADIO RECEIVER ASSEMBLY

INSTRUMENT LOWER
COVER SUB-ASSEMBLY

N*m (kgf*cm, ft*lbf)  : Specified torque

CLIP

CLIP

2.5 (25, 22 in.*lbf)

INSTRUMENT PANEL
GARNISH LH

INSTRUMENT PANEL
GARNISH RH

INTEGRATION CONTROL AND
PANEL ASSEMBLY

<F>

<H>

<H>

<F>

CONSOLE UPPER PANEL
NO. 1 GARNISH

<H>

B133845E01

INSTRUMENT PANEL  –  INSTRUMENT PANEL ASSEMBLY

IP–5

IP

COMBINATION METER
ASSEMBLY

GLOVE COMPARTMENT
DOOR ASSEMBLY

INSTRUMENT CLUSTER
FINISH PANEL

LOWER INSTRUMENT PANEL FINISH
PANEL SUB-ASSEMBLY LH

LOWER INSTRUMENT PANEL LH

NO. 1 INSTRUMENT
PANEL REGISTER
ASSEMBLY

NO. 2 INSTRUMENT
PANEL REGISTER
ASSEMBLY

INSTRUMENT PANEL
LOWER FINISH PANEL
SUB-ASSEMBLY RH

<A>

<F>

<F>

<F>

<F>

<F>

<F>

7.0 (71, 62 in.*lbf)

HOOD LOCK CONTROL LEVER SUB-ASSEMBLY

N*m (kgf*cm, ft.*lbf) : Specified torque

CLIP

B133846E01

IP–6

INSTRUMENT PANEL  –  INSTRUMENT PANEL ASSEMBLY

IP

FRONT NO. 2 SPEAKER ASSEMBLY

NO. 1 INSTRUMENT
PANEL SPEAKER PANEL
SUB-ASSEMBLY

NO. 2 INSTRUMENT PANEL SPEAKER
PANEL SUB-ASSEMBLY

FRONT NO. 2 SPEAKER ASSEMBLY

N*m (kgf*cm, ft*lbf)  : Specified torque

20 (204, 15)

2.5 (25, 22 in.*lbf)

2.5 (25, 22 in.*lbf)

<C>

<E>

<F>

<F>

<F>

<F>

<F>

<F>

<E>

<G>

<C>

<F>

INSTRUMENT PANEL SUB-ASSEMBLY

INSTRUMENT PANEL FINISH
PANEL END LH

B133847E01
