SUSPENSION AND AXLE

FRONT WHEEL ALIGNMENT

SA–5

3001

If the vehicle height is not as specified, try to adjust it by pushing
down on or lifting the body.

INSTALL CAMBER–CASTER–KINGPIN GAUGE OR
POSITION VEHICLE ON WHEEL ALIGNMENT TES-
TER

Follow the specific instructions of the equipment manufacturer.

INSPECT CAMBER, CASTER AND STEERING AXIS
INCLINATION

Camber, caster and steering axis inclination:

Camber

UCK35L–GKBSKA

Right–left error

UCK35L–GKBLKA

Right–left error

UCK45L–GKBSKA

Right–left error

UCK45L–GKBLKA

Right–left error

08’

45’ (0.14

0.75

)

30’ (0.5

) or less

06’

45’ (0.10

0.75

)

30’ (0.5

) or less

17’

45’ (0.28

0.75

)

30’ (0.5

) or less

16’

45’ (0.26

0.75

)

30’ (0.5

) or less

Caster (Except air suspension models)

UCK35L–GKBSKA

Tire size: P245/70R16

Tire size: P265/70R16 and P265/65R17

Right–left error

UCK35L–GKBLKA

Right–left error

UCK45L–GKBSKA

Right–left error

UCK45L–GKBLKA

Right–left error

2°

56’

45’ (2.93

0.75

)

2°

59’

45’ (2.98

0.75

)

30’ (0.5

) or less

3°

02’

45’ (3.04

0.75

)

30’ (0.5

) or less

2°

36’

45’ (2.60

0.75

)

30’ (0.5

) or less

2°

38’

45’ (2.64

0.75

)

30’ (0.5

) or less

R13227

SA–6

–

SUSPENSION AND AXLE

FRONT WHEEL ALIGNMENT

3002

Caster (Air suspension models)

UCK35L–GKBSKA

Tire size: P245/70R16

Tire size: P265/70R16 and P265/65R17

Right–left error

UCK35L–GKBLKA

Right–left error

UCK45L–GKBSKA

Right–left error

UCK45L–GKBLKA

Right–left error

3°

17’

45’ (3.28

0.75

)

3°

20’

45’ (3.33

0.75

)

30’ (0.5

) or less

3°

21’

45’ (3.35

0.75

)

30’ (0.5

) or less

2°

55’

45’ (2.91

0.75

)

30’ (0.5

) or less

2°

56’

45’ (2.93

0.75

)

30’ (0.5

) or less

Steering axis inclination

UCK35L–GKBSKA

Right–left error

UCK35L–GKBLKA

Right–left error

UCK45L–GKBSKA

Right–left error

UCK45L–GKBLKA

Right–left error

10°

14’

45’ (10.24

0.75

)

30’ (0.5

) or less

10°

16’

45’ (10.27

0.75

)

30’ (0.5

) or less

10°

05’

45’ (10.09

0.75

)

30’ (0.5

) or less

10°

07’

45’ (10.11

0.75

)

30’ (0.5

) or less

If the steering axis inclination is not within the specified values,
after the camber and caster have been correctly adjusted, re-
check the steering knuckle and front wheel bearing for loose-
ness.

ADJUST CAMBER AND CASTER

(a)

Loosen the front and/or rear adjusting cam set bolts.

(b)

Adjust the camber and caster by turning the front and/or
rear adjusting cams (See adjustment chart).

HINT:
Try to adjust the camber and caster to the center of the specified
values.

– direction

F17132

Example:

= Standard value point
= Measured value point

Camber
Caster

Front Cam

– direction

Rear Cam

F07284

F14732

Front

Front Cam

Rear Cam

–

Front Cam

Arm Longer

Arm Shorter

–

Rear Cam

Arm Shorter

Arm Longer

A view

B view

A view

–

SUSPENSION AND AXLE

FRONT WHEEL ALIGNMENT

SA–7

3003

(c)

How to read the adjustment chart (Example).
(1)

Find the applicable wheel alignment standard value
for the particular model.

(2)

Mark the selected standard value on the adjustment
chart.

Example:
Camber: 0

08’ (0.13

°)

Caster: 2

°59

’ (2.98

°)

(3)

Measure the present wheel alignment value with
the vehicle unloaded.

(4)

Mark the measured present value on the adjust-
ment chart.

Example:
Camber: 0

20’ (0.33

)

Caster: 2

°59

’ (2.98

)

(5)

As shown in the example chart, read the distance
from the measured value to the standard value, and
adjust the front and/or rear adjusting cams accord-
ingly.

Amount to turn the adjusting cams (by graduation):
Example:
Front cam: 1.4 (+ direction)
Rear cam: 1.3 (+ direction)

F16853

+ Direction
(Arm Longer)

Front Cam Graduation

– Direction (Arm Shorter)

Rear Cam
Graduation

– Direction
(Arm Shorter)

+ Direction (Arm Longer)

Camber

Caster

SA–8

–

SUSPENSION AND AXLE

FRONT WHEEL ALIGNMENT

3004

(d)

Torque the front and/or rear adjusting cam set bolts.
Torque: 130 N·m (1,325 kgf·cm, 96 ft·lbf)
