PP42W–01

–

PREPARATION

ENGINE MECHANICAL

PP–3

61

ENGINE MECHANICAL

SST (Special Service Tools)

09201–01055

Valve Guide Bushing Remover & Re

placer 5.5

09201–41020

Valve Stem Oil Seal Replacer

09202–70020

Valve Spring Compressor

(09202–00010)

Attachment

09213–70011

Crankshaft Pully Holding Tool

(90105–08076)

Bolt

(90119–08216)

Bolt

09222–30010

Connecting Rod Bushing Remover

& Replacer

09223–46011

Crankshaft Front Oil Seal

Replacer

Crankshaft pulley

Crankshaft timing pulley

09223–56010

Crankshaft Rear Oil Seal

Replacer

09330–00021

Companion Flange Holding Tool

Crankshaft pulley

09843–18030

Tacho–pulse Pickup Wire No.2

PP–4

–

PREPARATION

ENGINE MECHANICAL

62

09843–18040

Diagnosis Check Wire No.2

09950–50013

Puller C Set

(09951–05010)

Hanger 150

Crankshaft pulley

Crankshaft timing pulley

(09952–05010)

Slide Arm

Crankshaft pulley

Crankshaft timing pulley

(09953–05010)

Center Bolt 100

Crankshaft pulley

Crankshaft timing pulley

(09953–05020)

Center Bolt 150

Crankshaft pulley

Crankshaft timing pulley

(09954–05011)

Claw No.1

Crankshaft timing pulley

(09954–05021)

Claw No.2

Crankshaft pulley

09950–60010

Replacer Set

(09951–00240)

Replacer 24

(09951–00440)

Replacer 44

(09952–06010)

Adapter

09950–70010

Handle Set

–

PREPARATION

ENGINE MECHANICAL

PP–5

63

(09951–07100)

Handle 100

Spark plug tube

Valve guide bushing

09960–10010

Variable Pin Wrench Set

(09962–01000)

Variable Pin Wrench Arm Assy

Camshaft sub–gear

(09963–00400)

Pin 4

Camshaft sub–gear

(09963–00500)

Pin 5

Camshaft sub–gear

(09963–01000)

Pin 10

Camshaft sub–gear

PP1BL–10

PP–6

–

PREPARATION

ENGINE MECHANICAL

64

RECOMMENDED TOOLS

09040–00011

Hexagon Wrench Set .

09090–04020

Engine Sling Device

For suspension engine

09200–00010

Engine Adjust Kit .

09258–00030

Hose Plug Set .

Plug for vacuum hose, fuel hose etc.

09904–00010

Expander Set .
