616

8-2. Steps to take in an emergency



Vehicles with a full-size spare tire

Remove the inside spare tire
cover.

Fully depress the secondary
latch (A) and remove the hold-
ing bracket (B) from the hoist
assembly (C).

Tilt the holding bracket (B) so
that it can easily be passed
through the wheel opening.
After passing the holding
bracket through the wheel
opening, remove the hoist
assembly (C).

9

10

11

617

8-2. Steps to take in an emergency

8

Wh

en tro

uble

 a

ris

es

Remove the outside spare tire
cover.

12

618

8-2. Steps to take in an emergency

Chock the tires.

Slightly loosen the wheel nuts
(one turn).

Turn the tire jack portion “A” by
hand until the notch of the jack
is in contact with the jack point.

The jack point guides are located
under the rocker panel. They
indicate the jack point positions.

Replacing a flat tire

1

Flat tire

Wheel chock positions

Front

Left-hand side

Behind the rear right-hand side tire

Right-hand side

Behind the rear left-hand side tire

Rear

Left-hand side

In front of the front right-hand side tire

Right-hand side

In front of the front left-hand side tire

2

3

619

8-2. Steps to take in an emergency

8

Wh

en tro

uble

 a

ris

es

Raise the vehicle until the tire is
slightly raised off the ground.

Remove all the wheel nuts and
the tire.

When resting the tire on the
ground, place the tire so that the
wheel design faces up to avoid
scratching the wheel surface.

4

5
