Toyota Highlander (2018 year). Manual - part 150

612

8-2. Steps to take in an emergency

Pull the strap upwards to open
the center deck board.

To secure the center deck
board, remove the hook on the
backside of the center deck
board and attach the hook to
the head restraint on the third
seats as shown.

Remove the mat.

Remove the cover.

If it is difficult to remove the
cover, you can use your key.

Taking out the spare tire

613

8-2. Steps to take in an emergency

en tro

uble

ris

Attach the adapter socket to the
spare tire clamp bolt.

Assembling the jack handle.

Remove the jack handle and
assemble it by following these
steps.

Loosen the screw.

Assemble the jack handle
and tighten the screw.

Check that the screw is firmly
tightened.

Connect the jack handle to the
adapter socket. Turn the jack
handle counterclockwise.

The tire will be lowered com-
pletely to the ground.

Turn the jack handle slowly to
lower the spare tire. If the handle
is turned quickly, the wire cable
may slip off of the shaft inside the
unit and the tire may not be low-
ered.

If the spare tire cannot be lowered:

→P. 620

1
2
