496

6-4. Using the other interior features

The direction display deviates from the true direction determined by
the earth’s magnetic field. The amount of deviation varies according to
the geographic position of the vehicle.

If you cross over a map boundary shown in illustration, the compass will
deviate.
To obtain higher precision or perfect calibration, refer to the following.

■

Deviation calibration

Stop the vehicle.

Press and hold the button for
6 seconds.

A number (1 to 15) appears on
the compass display.

Press the switch and referring to the map above, select the num-
ber of the zone where you are.

If the direction is displayed several seconds after adjustment, the cali-
bration is complete.

Calibrating the compass

1
2

497

6-4. Using the other interior features

rior fe

atures

■

Circling calibration

Stop the vehicle in a place where it is safe to drive in a circle.

Press and hold the button for
9 seconds.

“C” appears on the compass
display.

Drive the vehicle at 5 mph (8
km/h) or less in a circle until
a direction is displayed.

If there is not enough space to
drive in a circle, drive around the
block until the direction is dis-
played.

1
2

498

6-4. Using the other interior features

■

Conditions unfavorable to correct operation
The compass may not show the correct direction in the following conditions:

●

The vehicle is stopped immediately after turning.

●

The vehicle is on an inclined surface.

●

The vehicle is in a place where the earth's magnetic field is subject to inter-
ference by artificial magnetic fields (underground car park/parking lot, under
a steel tower, between buildings, roof car park/parking lot, near an intersec-
tion, near a large vehicle, etc.).

●

The vehicle has become magnetized.
(There is a magnet or metal object near the inside rear view mirror.)

●

The battery has been disconnected.

●

A door is open.

WARNING

■

While driving the vehicle
Do not adjust the display. Adjust the display only when the vehicle is
stopped.

■

When doing the circling calibration
Secure a wide space, and watch out for people and vehicles in the neigh-
borhood. Do not violate any local traffic rules while performing circling cali-
bration.

NOTICE

■

To avoid compass malfunctions
Do not place magnets or any metal objects near the inside rear view mirror.
Doing this may cause the compass sensor to malfunction.

■

To ensure normal operation of the compass

●

Do not perform circling calibration of the compass in a place where the
earth's magnetic field is subject to interference by artificial magnetic fields.

●

During calibration, do not operate electric systems (moon roof, power win-
dows, etc.) as they may interfere with the calibration.
