b. Install the throttle body with the 4 bolts.

Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)

Fig. 35: Identifying Throttle Body With Bolts
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

5. INSTALL V-BANK COVER PIN

a. Install the 2 bolts to the intake manifold.

Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)

Fig. 36: Identifying Bolts From Intake Manifold
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

6. INSTALL V-BANK COVER BRACKET

a. Install the bracket with the 2 bolts.

Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)

2009 Toyota Tundra

2009 ENGINE Intake (3UR-FE) - Tundra

Fig. 37: Identifying V-Bank Cover Bracket
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

7. INSTALL VENTILATION HOSE ASSEMBLY

a. Install the ventilation hose to the intake manifold with the 2 bolts.

Torque: for bolt A

21 N*m (214 kgf*cm, 15 ft.*lbf)

for bolt B

10 N*m (102 kgf*cm, 7 ft.*lbf)

Fig. 38: Identifying Ventilation Hose Bolts

2009 Toyota Tundra

2009 ENGINE Intake (3UR-FE) - Tundra

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

8. INSTALL INTAKE MANIFOLD

a. Place 2 new gaskets on the intake manifold.

b. Place the intake manifold on the cylinder head.

Fig. 39: Identifying Gaskets On Intake Manifold
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

2009 Toyota Tundra

2009 ENGINE Intake (3UR-FE) - Tundra

c. Install and uniformly tighten the 8 bolts and 2 nuts in several steps.

Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)

Fig. 40: Identifying Intake Manifold Bolts
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

d. Install the wire bracket to the intake manifold with the bolt.

Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)

Fig. 41: Identifying Wire Bracket To Intake Manifold
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

e. Connect the 3 wire clamps to the 3 wire brackets.
