Fig. 104: Identifying Tube Joint Clips And Fuel Tank Tubes b. Using SST, loosen the retainer. SST 09808-14020 (09808-01410, 09808-01420, 09808-01430) HINT: Fit the tips of SST onto the ribs of the retainer. NOTE: Remove any dirt and foreign matter on the fuel tube joint before Do not allow any scratches or foreign matter on the parts when Perform this work by hand. Do not use any tools. Do not forcibly bend, twist or turn the nylon tube. Protect the disconnected part by covering it with a plastic bag
2009 Toyota Tundra 2009 ENGINE Fuel (3UR-FE) - Tundra
|
