Toyota Hilux (2017 year). Manual - part 131

531

7-3. Do-it-yourself maintenance

7

M

ai

nte
nan
ce and

 ca

re

Pull out the damper (if
equipped) as shown in the illus-
tration, and then remove the
glove box.

Remove the filter cover.

Remove the air conditioning fil-
ter and replace it with a new
one.

The “

↑UP” marks shown on the fil-

ter should be pointing up.

■

Changing interval
Inspect and replace the air conditioning filter according to the maintenance
schedule. In dusty areas or areas with heavy traffic flow, early replacement
may be required. (For scheduled maintenance information, please refer to the
“Toyota Service Booklet” or “Toyota Warranty Booklet”.)

■

If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.

4

5

6

NOTICE

■

When using the air conditioning system
Make sure that a filter is always installed.
Using the air conditioning system without a filter may cause damage to the
system.

532

7-3. Do-it-yourself maintenance

Wireless remote control/electronic key

battery

∗

● Flathead screwdriver
● Small flathead screwdriver
● Lithium battery

Vehicles without smart entry & start system: CR1620
Vehicles with smart entry & start system: CR2032

X

Vehicles without smart entry & start system

Remove the cover.

To prevent damage to the key,
cover the tip of the screwdriver with
a rag.

Remove the battery cover.

∗

: If equipped

Replace the battery with a new one if it is depleted.

You will need the following items:

Replacing the battery

1

2

533

7-3. Do-it-yourself maintenance

7

M

ai

nte
nan
ce and

 ca

re

Remove the depleted battery.

Insert a new battery with the “+”
terminal facing up.

X

Vehicles with smart entry & start system

Take out the mechanical key.

Remove the cover.

To prevent damage to the key,
cover the tip of the screwdriver with
a rag.

Remove the depleted battery.

Insert a new battery with the “+”
terminal facing up.

3

1

2

3

534

7-3. Do-it-yourself maintenance

■

Use a lithium battery
Vehicles without smart entry & start system: CR1620
Vehicles with smart entry & start system: CR2032

●

Batteries can be purchased at any authorized Toyota dealer or repairer, or
another duly qualified and equipped professional, local electrical appliance
shops or camera stores.

●

Replace only with the same or equivalent type recommended by the manu-
facturer.

●

Dispose of used batteries according to local laws.

■

If the key battery is depleted
The following symptoms may occur:

●

The smart entry & start system (if equipped) and wireless remote control will
not function properly.

●

The operational range will be reduced.

WARNING

■

Removed battery and other parts
These parts are small and if swallowed by a child, they can cause choking.
Keep away from children. Failure to do so could result in death or serious
injury.

■

Certification for the key battery
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS

NOTICE

■

For normal operation after replacing the battery
Observe the following precautions to prevent accidents:

●

Always work with dry hands.
Moisture may cause the battery to rust.

●

Do not touch or move any other component inside the remote control.

●

Do not bend either of the battery terminals.
