455

6-1. Using the air conditioning system and defogger

6

In

teri
or f
eatu

res

WARNING

■

To prevent the windshield from fogging up

●

Do not set

 to

 during cool air operation in extremely humid

weather. The difference between the temperature of the outside air and
that of the windshield can cause the outer surface of the windshield to fog
up, blocking your vision.

■

To prevent burns (vehicles with outside rear view mirror defoggers)
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is not running.

●

Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

456

6-1. Using the air conditioning system and defogger

Automatic air conditioning system

∗

This illustration is for a left-hand drive vehicle. Some button positions
differ for right-hand drive vehicles.

■

Adjusting the fan speed setting

Turn

 clockwise (increase) or counterclockwise (decrease).

Press

 to turn the fan off.

■

Adjusting the temperature setting

Turn

 clockwise (warm) or counterclockwise (cool).

If

 is not pressed, the system will blow ambient temperature air or

heated air.

∗

: If equipped

Air outlets and fan speed are automatically adjusted according
to the temperature setting.

Air conditioning controls

457

6-1. Using the air conditioning system and defogger

6

In

teri
or f
eatu

res

■

Changing the air flow mode

Press

 to change the air

outlets.

The air outlets used are
switched each time the button is
pressed.

Press .

The dehumidification function begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature set-
ting.

Turn

 clockwise (warm) or counterclockwise (cool) to adjust

the temperature.

To stop the operation, press

.

■

Automatic mode indicator
If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.

Using automatic mode

1

2

458

6-1. Using the air conditioning system and defogger

■

Switching between outside air and recirculated air modes

Press

 to switch to recirculated air mode and press

 to

switch to outside air mode.

■

Defogging the windshield

Press .

The dehumidification function operates and fan speed increases.

Press

 if the recirculated air mode is used. (It may switch automati-

cally.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.

To return to the previous mode, press

 again when the windshield

is defogged.

■

Defogging the rear window and outside rear view mirrors (if
equipped)
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.

X

Vehicles without outside rear view mirror defoggers

Press

The defoggers will automatically turn off after approximately 15 minutes.

X

Vehicles with outside rear view mirror defoggers

Press

The defoggers will automatically turn off after approximately 15 minutes.

Other functions
