447

6

Interior features

6-1. Using the air conditioning

system and defogger

Manual air conditioning

system .............................448

Automatic air conditioning

system .............................456

Seat heaters ......................465

6-2. Using the interior lights

Interior lights list.................466

• Personal/interior light

main switch....................467

• Personal/interior

lights ..............................467

• Interior light....................467

6-3. Using the storage features

List of storage features ......469

• Glove box ......................470
• Console box ..................470
• Cup holders ...................471
• Bottle holders ................472
• Auxiliary boxes ..............473

Luggage compartment

features............................476

6-4. Using the other interior

features

Other interior features........477

• Sun visors......................477
• Vanity mirror ..................477
• Clock .............................478
• Power outlets.................479
• Grocery bag hooks ........481
• Coat hooks ....................482
• Armrest..........................482

ERA-GLONASS.................483

448

6-1. Using the air conditioning system and defogger

Manual air conditioning system

∗

■

Adjusting the fan speed setting

Turn

 clockwise (increase) or counterclockwise (decrease).

Turning the dial to “OFF” turns off the fan.

■

Adjusting the temperature setting

Turn

 clockwise (warm) or counterclockwise (cool).

If

 (if equipped) is not pressed, the system will blow ambient tem-

perature air or heated air.

■

Changing the air flow mode

Set

 to the desired position.

The positions between the air outlet selections can also be selected for
more delicate adjustment.

∗

: If equipped

Air conditioning controls

449

6-1. Using the air conditioning system and defogger

6

In

teri
or f
eatu

res

■

Switching between outside air and recirculated air modes
Move the outside/recirculated air mode lever.

The mode switches between

 (introduces air from outside the vehi-

cle) and

 (recycles air inside the vehicle) each time the lever is

moved.

■

Defogging the windshield (vehicles with

)

Set

to



 position.

Set the outside/recirculated air mode lever to outside air mode if recircu-
lated air mode is used.

Perform the following operations accordingly:

● To adjust the fan speed, turn

.

● To adjust the temperature setting, turn

.

● If the dehumidification function is not operating, press

 to

operate the dehumidification function.

To defog the windshield and the side windows early, turn the air
flow and temperature up.

■

Defogging the rear window and outside rear view mirrors (if
equipped)
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.

Press

Other functions

1

2

450

6-1. Using the air conditioning system and defogger

■

Heater idle up (if equipped)
This feature is used to heat the engine coolant, speed up warming
of the cab in cold weather, and keep the cab warm when the vehicle
is not moving.

Press the switch to turn the
heater idle up on/off.

If you do not turn the switch to
off, the engine speed may be
increased when the engine is
started.

■

Power heater (if equipped)
This feature is used to heat the engine coolant, speed up warming
of the cab in cold weather, and keep the cab warm.
Press the switch to turn the
power heater on/off.

If you do not turn the switch to
off, the engine speed may be
increased when the engine is
started.
