407

5-5. Using an external device

5

Au
dio
 sy
stem

■

Selecting folders one at a time
Press

 (<FOLDER) or

 (FOLDER>) to select the desired

folder.

■

Selecting a folder and file from folder list

Press

(LIST).

The folder list will be displayed.

Press the “TUNE >” or “< SELECT” button to select a folder and
file, and press the “SETUP ENTER” button.

To return to the previous display, press

 (BACK).

■

Returning to the first folder
Press and hold

 (<FOLDER) until you hear a beep.

Press the “SEEK >” or “< TRACK” button to select the desired file.

Press and hold the “SEEK >” or “< TRACK” button.

Pressing

 (RDM) changes modes in the following order:

Folder random

→All folder random→Off

Pressing

 (RPT) changes modes in the following order:

File repeat

→Folder repeat

*

→Off

*

: Available except when RDM (random play) is selected

Press

 (TEXT) to display or hide the album title.

If there are continuing texts,

 is displayed.

Press and hold

 (TEXT) to display the remaining texts.

Selecting a folder

Selecting a file

Fast-forwarding and rewinding files

Random play

Repeat play

Switching the display

1

2

408

5-5. Using an external device

■

USB memory functions

●

Depending on the USB memory that is connected to the system, the device
itself may not be operable and certain functions may not be available. If the
device is inoperable or a function is unavailable due to a malfunction (as
opposed to a system specification), disconnecting the device and recon-
necting it once again may resolve the problem.

●

If the USB memory still does not begin operation after being disconnected
and reconnected, format the memory.

■

Display
→P. 391

■

Error messages
If an error message is displayed, refer to the following table and take the
appropriate measures. If the problem is not rectified, take the vehicle to any
authorized Toyota dealer or repairer, or another duly qualified and equipped
professional.

■

USB memory

●

Compatible devices
USB memory that can be used for MP3 and WMA playback

●

Compatible device formats
The following device formats can be used:
• USB communication formats: USB2.0 FS (12mbps)
• File formats: FAT12/16/32 (Windows)
• Correspondence class: Mass storage class
MP3 and WMA files written in any format other than those listed above may
not play correctly, and their file names and folder names may not be dis-
played correctly.
Items related to standards and limitations are as follows:
• Maximum directory hierarchy: 8 levels
• Maximum number of folders in a device: 999 (including the root)
• Maximum number of files in a device: 9999
• Maximum number of files per folder: 255

Message

Cause/Correction procedures

“ERROR”

This indicates a problem in the USB memory
or its connection.

“NO MUSIC”

This indicates that no MP3/WMA files are
included in the USB memory.

409

5-5. Using an external device

5

Au
dio
 sy
stem

●

MP3 and WMA files
MP3 (MPEG Audio LAYER3) is a standard audio compression format.
Files can be compressed to approximately 1/10 of their original size by
using MP3 compression.
WMA (Windows Media Audio) is a Microsoft audio compression format.
This format compresses audio data to a size smaller than that of the MP3
format.
There is a limit to the MP3 and WMA file standards and to the media/for-
mats recorded by them that can be used.

●

MP3 file compatibility
• Compatible standards

MP3 (MPEG1 LAYER3, MPEG2 LSF LAYER3)

• Compatible sampling frequencies

MPEG1 LAYER3: 32, 44.1, 48 (kHz)
MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz)

• Compatible bit rates (compatible with VBR)

MPEG1 LAYER3: 32—320 (kbps)
MPEG2 LSF LAYER3: 8—160 (kbps)

• Compatible channel modes: stereo, joint stereo, dual channel and mon-

aural

●

WMA file compatibility
• Compatible standards

WMA Ver. 7, 8, 9

• Compatible sampling frequencies

32, 44.1, 48 (kHz)

• Compatible bit rates (only compatible with 2-channel playback)

Ver. 7, 8: CBR 48—192 (kbps)
Ver. 9: CBR 48—320 (kbps)

410

5-5. Using an external device

●

File names
The only files that can be recognized as MP3/WMA and played are those
with the extension .mp3 or .wma.

●

ID3 and WMA tags
ID3 tags can be added to MP3 files, making it possible to record the track
title, artist name, etc.
The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3
tags. (The number of characters is based on ID3 Ver. 1.0 and 1.1.)
WMA tags can be added to WMA files, making it possible to record the
track title and artist name in the same way as with ID3 tags.

●

MP3 and WMA playback
• When a device containing MP3 or WMA files is connected, all files in the

USB memory device are checked. Once the file check is finished, the first
MP3 or WMA file is played. To make the file check finish more quickly, we
recommend that you do not include any files other than MP3 or WMA
files or create any unnecessary folders.

• When the USB device is connected and the audio source is changed to

USB memory mode, the USB device will start playing the first file in the
first folder. If the same device is removed and reinserted (and the con-
tents have not been changed), the USB memory will resume play from
the same point in which it was last used.

●

Extensions
If the file extensions .mp3 and .wma are used for files other than MP3 and
WMA files, they will be skipped (not played).
