5-3. Using the radio

5

Au
dio
 sy
stem

X

Type B

Search for the desired stations by pressing the “TUNE >”,
“< SELECT”, “SEEK >” or “< TRACK” button.

Press and hold one of the station selectors (

) to be set until you

hear a beep.

Power
Volume
AM/FM mode button
AF/region code/TA mode setup
(type B only)

Adjusting the frequency
Seeking the frequency
Station selectors
Displaying the station list
(type B only)

Setting station presets

1
2
3
4

5
6
7
8

1

2

384

5-3. Using the radio

■

Updating the station list

Press

(LIST).

The station list will be displayed.

Press

 (UPDATE) to update the list.

“Updating” is displayed while the searching is in process, and then avail-
able stations will be listed on the display.
To cancel the updating process, press



(BACK).

■

Selecting a station from the station list

Press

(LIST).

The station list will be displayed.

Press the “TUNE >” or “< SELECT” button to select a station.
Press the “SETUP ENTER” button to tune in the station.

To return to the previous display, press



(BACK).

This feature allows your radio to receive station.

■

Listening to stations of the same network

Press the “SETUP ENTER” button.
Press the “TUNE >” or “< SELECT” button to select “RADIO”,
and press the “SETUP ENTER” button.
Press the “TUNE >” or “< SELECT” button as corresponds to the
desired mode: “FM AF” or “Region code”.
Press the “SETUP ENTER” button to select “ON” or “OFF”.
FM AF ON mode:
The station among those of the same network with strong recep-
tion is selected.
Region code ON mode:
The station among those of the same network with strong recep-
tion and broadcasting the same program is selected.

Using the station list (type B only)

RDS (Radio Data System) (type B only)

1

2

1

2

3

1

2

3

4

385

5-3. Using the radio

5

Au
dio
 sy
stem

■

Traffic information

Press the “SETUP ENTER” button.
Press the “TUNE >” or “< SELECT” button to select “RADIO”,
and press the “SETUP ENTER” button.
Press the “TUNE >” or “< SELECT” button to select “FM TA”
mode.
Press the “SETUP ENTER” button to select “ON” or “OFF”.
TP mode:
The system automatically switches to traffic information when a
broadcast with a traffic information signal is received.

The station returns to the previous one when the traffic information
ends.

TA mode:
The system automatically switches to traffic information when a
broadcast with a traffic information signal is received. In FM
modes, the system will be mute unless traffic information is being
broadcast.

The audio system returns to the previous mode when the traffic informa-
tion ends.

1

2

3

4

386

5-3. Using the radio

■

EON (Enhanced Other Network) system (for traffic announcement func-
tion) (type B only)
If the RDS station (with EON data) you are listening to is not broadcasting a
traffic information program and the audio system is in the TA (traffic
announcement) mode, the radio will be switched automatically to a station
broadcasting a traffic information program in the EON AF list when traffic
information begins.

■

When the battery is disconnected
Stations presets are erased.

■

Reception sensitivity

●

Maintaining perfect radio reception at all times is difficult due to the continu-
ally changing position of the antenna, differences in signal strength and sur-
rounding objects, such as trains, transmitters, etc.

●

The radio antenna is mounted on the roof. The antenna can be removed
from the base by turning it.

NOTICE

■

To prevent damage, remove the antenna in the following cases

●

The antenna will touch the ceiling of a garage.

●

A cover will be put on the roof.

●

When driving through an automatic car wash.

●

Any other cases where there is a risk of touching surrounding parts.
