199

3-4. Adjusting the steering wheel and mirrors

3

O

pe

rati

on
of e
ac

h c
om
pon
ent

WARNING

■

Important points while driving
Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.

■

When a mirror is moving (power adjustable type)
To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.

■

When the mirror defoggers are operating (vehicles with outside rear
view mirror defoggers)
Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.

NOTICE

■

If ice should jam the mirror
Do not operate the control or scrape the mirror face. Use a spray de-icer to
free the mirror.

200

3-5. Opening and closing the windows

Power windows

∗

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:

X

Type A

Closing
Opening
One-touch opening

*

(driver’s window only)

*

: To stop the window partway,

operate the switch in the opposite
direction.

X

Type B

Closing
Opening
One-touch opening

*

(driver’s window only)
One-touch closing

*

(driver’s window only)

*

: To stop the window partway,

operate the switch in the opposite
direction.

∗

: If equipped

Opening and closing procedures

1
2
3

1
2
3

4

201

3-5. Opening and closing the windows

3

O

pe

rati

on
of e
ac

h c
om
pon
ent

X

Type C

Closing
Opening
One-touch opening

*

One-touch closing

*

*

: To stop the window partway,

operate the switch in the opposite
direction.

Press the switch down to lock the
passenger window switches.

Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.

■

The power windows can be operated when

X

Vehicles without smart entry & start system

The engine switch is in the “ON” position.

X

Vehicles with smart entry & start system

The engine switch is in IGNITION ON mode.

■

Jam protection function (windows with one-touch function for type B
and C)
If an object becomes jammed between the window and the window frame
while the window is closing, window movement is stopped and the window is
opened slightly.

■

Catch protection function (windows with one-touch function for type B
and C)
If an object becomes caught between the door and window while the window
is opening, window movement is stopped.

1
2
3
4

Window lock switch

202

3-5. Opening and closing the windows

■

Operating the power windows after turning the engine off

X

Vehicles without smart entry & start system

The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to the “ACC” or “LOCK” position. They can-
not, however, be operated once either front door is opened.

X

Vehicles with smart entry & start system

The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to ACCESSORY mode or turned off. They
cannot, however, be operated once either front door is opened.

■

When the window cannot be opened or closed (windows with one-touch
function for type B and C)
When the jam protection function or catch protection function operates

unusually and the window cannot be opened or closed, perform the following

operations with the power window switch of that door.

●

Stop the vehicle. With the engine switch in the “ON” position (vehicles with-

out smart entry & start system) or IGNITION ON mode (vehicles with smart

entry & start system), within 4 seconds of the jam protection function or

catch protection function activating, continually operate the power window

switch in the one-touch closing direction or one-touch opening direction so

that the window can be opened and closed.

●

If the window cannot be opened and closed even when performing the

above operations, perform the following procedure for function initialization.

Turn the engine switch to the “ON” position (vehicles without smart entry

& start system) or IGNITION ON mode (vehicles with smart entry & start

system).
Pull and hold the power window switch in the one-touch closing direction

and completely close the window.
Release the power window switch for a moment, resume pulling the

switch in the one-touch closing direction, and hold it there for approxi-

mately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direc-

tion. After the window is completely opened, continue holding the switch

for an additional 1 second or more.
Release the power window switch for a moment, resume pushing the

switch in the one-touch opening direction, and hold it there for approxi-

mately 4 seconds or more.
Pull and hold the power window switch in the one-touch closing direction

again. After the window is completely closed, continue holding the switch

for a further 1 second or more.

If you release the switch while the window is moving, start again from the

beginning.

If the window reverses and cannot be fully closed or opened, have the vehi-

cle inspected by any authorized Toyota dealer or repairer, or another duly

qualified and equipped professional.

1

2

3

4

5

6
