Toyota Hilux (2017 year). Manual - part 46

191

3

3-3. Adjusting the seats

O

pe

rati

on
of e
ac

h c
om
pon
ent

Head restraints

X

Adjustable type

Up

Pull the head restraints up.

Down

Push the head restraint down while
pressing the lock release button.

X

Integrated type

Head restraints cannot be adjusted and removed.

X

Adjustable type

Up

Pull the head restraints up.

Down

Push the head restraint down while
pressing the lock release button.

X

Integrated type

Head restraints cannot be adjusted and removed.

Head restraints are provided for driver’s seat, front passenger’s
seat, outboard rear seats and center rear seats (if equipped).

Front seats

Lock release button

1

2

Rear seats (if equipped)

Lock release button

1

2

192

3-3. Adjusting the seats

■

Removing the head restraints

■

Installing the head restraints

■

Adjusting the height of the head restraints

■

Adjusting the rear center seat head restraint (if equipped)
Always raise the head restraint one level from the stowed position when
using.

Pull the head restraint up while pressing
the lock release button.

Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.

Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.

Lock release

button

Lock release

button

193

3-3. Adjusting the seats

3

O

pe

rati

on
of e
ac

h c
om
pon
ent

WARNING

■

Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.

●

Use the head restraints designed for each respective seat.

●

Adjust the head restraints to the correct position at all times.

●

After adjusting the head restraints, push down on them and make sure
they are locked in position.

●

Do not drive with the head restraints removed.

194

3-4. Adjusting the steering wheel and mirrors

Steering wheel

Hold the steering wheel and
push the lever down.

X

Type A

Adjust to the ideal position by
moving the steering wheel verti-
cally.

After adjustment, pull the lever up
to secure the steering wheel.

X

Type B

Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.

After adjustment, pull the lever up
to secure the steering wheel.

Adjustment procedure

1

2

2
