187

3-3. Adjusting the seats

3

O

pe

rati

on
of e
ac

h c
om
pon
ent

X

Power seat (driver’s seat only)

Seat position adjustment switch
Seatback angle adjustment
switch
Seat cushion (front) angle
adjustment switch
Vertical height adjustment
switch

1
2

3

4

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.

●

Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

■

Seat adjustment

●

To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

●

Manual seat: After adjusting the seat, make sure that the seat is locked in
position.

188

3-3. Adjusting the seats

Rear seats

∗

Unhook the lock release lever.
Pull the seat cushions up and
then pull toward the front of
vehicle.

The seat cushions can be removed
separately.

X

Type A

Pull the head restraint up.

Pull the strap and raise the bot-
tom cushion.

The latch under the bottom cush-
ion will release allowing the bottom
cushion to be raised.

∗

: If equipped

Removing the rear seat cushions (if equipped for smart-cab
models)

1
2

Raising the bottom cushion (double-cab models)

1

2

189

3-3. Adjusting the seats

3

O

pe

rati

on
of e
ac

h c
om
pon
ent

Anchor the strap to the head
restraint.

Vehicles without the rear center
seat head restraint: Anchor the
strap to the rear outboard seat
head restraint.

X

Type B

Pull the head restraints up.

Pull the straps and raise the
bottom cushions.

The latch under the bottom cush-
ions will release allowing the bot-
tom cushions to be raised.

3

1

2

190

3-3. Adjusting the seats

Anchor the straps to the head
restraints.

3

WARNING

Observe the following precautions. Failure to do so may result in death or
serious injury.

■

When removing the rear seat cushions

●

Do not remove the rear seat cushions while driving.

●

Be careful not to hit the removed rear seat cushions against a person or
drop it on yourself.

■

When reinstalling the rear seat cushions or returning the bottom cush-
ions to their original position

●

Be careful not to get your hands or feet pinched in the seat.

●

Make sure there are no obstacles under the seat which would prevent the
seat from properly locking into place.

●

Make sure the rear seat cushions and bottom cushion are securely locked
by pushing it upward and downward.

●

Check that the seat belts are not twisted or caught in the bottom cushions.
