143

2. Instrument cluster

2

In

st

rum

ent cl

ust
e

r

■

Setting display automatic cancelation
In the following situations, setting display in which the settings can be
changed through the meter control switches will automatically be turned off.

●

If a warning message appears while the setting display is displayed

●

When the vehicle begins to move while the setting display is displayed

■

When disconnecting and reconnecting battery terminals
The drive information data and settings will be reset.

■

Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

WARNING

■

Eco Score
Use the Eco Score as a reference. Always drive safely in accordance with
road and traffic conditions.

144

2. Instrument cluster

Fuel consumption information

∗

Press the “CAR” button.
Select “Trip information” or “Past record”.

■

Trip information
If the trip information screen does not appear, select “Trip informa-
tion”.

Average vehicle speed
Cruising range
Previous fuel consumption
per minute
Current fuel consumption
Reset the trip information
data
Elapsed time
“Past record” screen appears

Average fuel consumption for the past 15 minutes is divided by
color into past averages and averages attained since the engine
switch was last turned to the “ON” position (vehicles without smart
entry & start system) or IGNITION ON mode (vehicles with smart
entry & start system). Use the displayed average fuel consumption
as a reference.
These images are examples only, and may vary slightly from actual
conditions.

∗

: If equipped

The fuel consumption information can be displayed on the navi-
gation system or multimedia system screen.

Display the trip information or past record screen

Fuel consumption

1

2

1
2
3

4
5

6
7

145

2. Instrument cluster

2

In

st

rum

ent cl

ust
e

r

■

Past record
If the past record screen does not appear, select “Past record”.

Best recorded fuel consump-
tion
Previous fuel consumption
record
Current fuel consumption
Reset the past record data
Update the past record data
“Trip information” screen
appears

The average fuel consumption history is divided by color into past
averages and the average fuel consumption since the last updated.
Use the displayed average fuel consumption as a reference.
These images are examples only, and may vary slightly from actual
conditions.

■

Resetting the data
Selecting “Clear” on the “Trip information” screen will reset the trip informa-
tion data.
Selecting “Clear” on the “Past record” screen will reset the past record data.

■

Updating the past record data
Selecting “Update” on the “Past record” screen will update the past record
data.
Also, the average fuel consumption displayed in the multi-information display
will be reset at the same time.

■

Cruising range
Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
This distance is computed based on your average fuel consumption. As a
result, the actual distance that can be driven may differ from that displayed.

1

2

3
4
5
6

146

2. Instrument cluster
