Toyota Camry (2018 year). Manual - part 116

474

6-3. Do-it-yourself maintenance

Front turn signal/parking lights (bulb type)

Turn the bulb base counter-
clockwise.

Remove the light bulb.

Install a new light bulb and
then install the bulb base to
the light unit by inserting it
and turning it clockwise.

Replacing light bulbs

1

2

3

475

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

re

■

Front side marker lights (bulb type)

To ensure enough space to
perform work, turn the steer-
ing wheel to move the front
wheel away from the light
bulb to be replaced.

Turn the steering wheel to the
left when replacing the right side
light bulb, and turn the steering
wheel to the right when replac-
ing the left side light bulb.

Remove the fender liner
clips.

To protect the front bumper
from being damaged, apply
protective tape around the
clip as shown in the illustra-
tion.

Use masking tape, etc. Do not
use duct tape, as it may leave
residue or damage the paint
when removed.

1

2

3

476

6-3. Do-it-yourself maintenance

∇” and then separate the

front bumper from the fender
liner.

To separate the front bumper
from the fender liner, pry up the
fender liner while pulling the
front bumper outward as shown
in the illustration.

Pull back the fender liner and
turn the bulb base counter-
clockwise.

Remove the light bulb.

Install a new light bulb and
then install the bulb base to
the light unit by inserting it
and turning it clockwise.

4

5

6

7

477

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

re

Return the fender liner to its
original position, and install
the clips.

Make sure that the fender liner
is correctly positioned on the
inner side of the front bumper.

To Install the fender liner to
the front bumper, engage the
clip to the front bumper.

Remove the protective tape.

8

9

10
