Toyota Camry (2018 year). Manual - part 22

98

2. Instrument cluster

■

Caution for use while driving

●

When operating the multi-information display while driving, pay extra
attention to the safety of the area around the vehicle.

●

Do not look continuously at the multi-information display while driving as
you may fail to see pedestrians, objects on the road, etc. ahead of the
vehicle.

■

The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the information display
monitor may respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the driver to down-
shift again, causing rapid and excessive engine braking and possibly an
accident resulting in death or injury.

■

Cautions during setting up the display
As the engine needs to be running during setting up the display, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area
such as a garage, exhaust gases including harmful carbon monoxide (CO)
may collect and enter the vehicle. This may lead to death or a serious
health hazard.

NOTICE

■

While setting up the display
To prevent battery discharge, ensure that the engine is running while setting
up the display features.

99

2. Instrument cluster

2

Instrum

e

nt clus

ter

Indicators (

→P. 81)

Dynamic radar cruise control with full-speed range/LDA (Lane
Departure Alert with steering control) display area

Displays the operational status of the following systems:

• Dynamic radar cruise control with full-speed range (→P. 263)
• LDA (Lane Departure Alert with steering control) (→P. 253)

Speed limit display (vehicles with a navigation system)
Speedometer

The speedometer display can be enabled/disabled in

 on the multi-

information display. (

→P. 104)

Content display area

A variety of information can be displayed by selecting a menu icon. Addi-
tionally, warning or suggestion/advice pop-up displays will be displayed in
some situations.

• Menu icon content (

→P. 101)

• Suggestion function (

→P. 110)

• Warning message (

→P. 507)

Multi-information display (7-inch display)

Summary of functions

1
2

3
4

5

100

2. Instrument cluster

→P. 110)

Shift position (

→P. 205)

Outside temperature (

→P. 84)

Menu icons (

→P. 101)

“ODO/TRIP” switch (

→P. 100)

Meter control switches (

→P. 100)

◆

Using the content display area

The content display area is operated using the meter control
switches.

Scroll screens

*

, change the

displayed content

*

 and move

the cursor
Press: Enter/Set
Press and hold: Reset/Dis-
play the next screen
Return to the previous
screen

Pressing and holding the switch will display the first screen of the
selected menu icon.

*

: When the screen can be scrolled or different content can be displayed,

a mark, such as an arrow, will be displayed to suggest which switch to
operate.

◆

Using the odometer/trip meter

Items in this area are operated using the “ODO/TRIP” switch.
Press: Change displayed item

Each time the switch is pressed,
the displayed item will be
changed.

Press and hold: Reset

Display the desired trip meter
and press and hold the switch to
reset the trip meter.

Using the multi-information display

6
7
8
9

10

11

1

2

3

101

2. Instrument cluster

2

Instrum

e

nt clus

ter

Warning message display (

→P. 507)

This menu icon will be displayed only when a warning message can be
displayed.
Select to display warning messages and measures to be taken if a mal-
function is detected.

Eco-friendly driving information (

→P. 102)

Select to display fuel consumption data in various forms.

Driving assist system information

Select to perform the following:
Display the operational status of the following systems:

• Dynamic radar cruise control with full-speed range (→P. 263)
• LDA (Lane Departure Alert with steering control) (→P. 253)

Display the following navigation system-linked information (if equipped):

• Route guidance
• Compass display (heading-up display)

Audio system-linked display

Select to enable selection of an audio source or track on the meter
using the meter control switches.

Vehicle information

Select to perform the following:
Display the following information:

• Tire inflation pressure (→P. 445)

Enable/Disable the following systems:

• Intuitive parking assist (if equipped) (→P. 314)
• BSM (Blind Spot Monitor) function (if equipped) (→P. 300)
• RCTA (Rear Cross Traffic Alert) function (if equipped) (→P. 300)

This function can also be enabled/disabled on

.

Settings display (

→P. 104)

Select to change the meter display settings and other settings.

Menu icons
