Toyota Camry (2018 year). Manual - part 18

82

2. Instrument cluster

1, 4

Slip indicator (

→P. 295)

*

1, 7

(Type A for

Canada)

“AIRBAG ON/OFF”
indicator (

→P. 45)

*

1, 3

VSC OFF indicator
(

→P. 296)

*

1, 7

(Type B for

Canada)

“AIRBAG ON/OFF”
indicator (

→P. 45)

(if equipped)

“BSM” indicator
(

→P. 300)

*

7

Security indicator
(

→P. 71, 74)

(if equipped)

“RCTA” indicator
(

→P. 300)

(if equipped)

Intuitive parking assist
indicator (

→P. 314)

*

5, 6

(if equipped)

BSM (Blind Spot Moni-
tor) outside rear view
mirror indicators
(

→P. 300)

(if equipped)

“SPORT” indicator
(

→P. 343)

*

1, 7

(Type A for

U.S.A.)

“AIRBAG ON/OFF”
indicator (

→P. 45)

(if equipped)

“ECO MODE” indicator
(

→P. 343)

*

1, 7

(Type B for

U.S.A.)

“AIRBAG ON/OFF”
indicator (

→P. 45)

*

8

Low outside tempera-
ture indicator (

→P. 84)

83

2. Instrument cluster

2

Instrum

e

nt clus

ter

1

: These lights turn on when the engine switch is turned to the “ON” position

(vehicles without a smart key system) or IGNITION ON mode (vehicles
with a smart key system) to indicate that a system check is being per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or turn
off. Have the vehicle inspected by your Toyota dealer.

*

2

: This light does not turn on when the system is disabled.

*

3

: This light turns on when the system is off.

*

4

: This light flashes to indicate that the system is operating.

*

5

: These indicators will illuminate in the following situations to indicate that

the system initial check is being performed:

• When the BSM function or RCTA function is enabled and the engine

switch is turned to the “ON” position (vehicles without a smart key sys-
tem) or IGNITION ON mode (vehicles with a smart key system).

• When the engine switch is in the “ON” position (vehicles without a smart

key system) or IGNITION ON mode (vehicles with a smart key system)
and the BSM function is enabled.

• When the engine switch is in the “ON” position (vehicles without a smart

key system) or IGNITION ON mode (vehicles with a smart key system)
and the RCTA function is enabled. (At this time, a buzzer will also
sound.)
The indicators will turn off after a few seconds. If the indicators do not
illuminate or turn off, or if a buzzer does not sound when the RCTA func-
tion is enabled, the system may be malfunctioning. Have the vehicle
inspected by your Toyota dealer.

*

6

: This light illuminates on the outside rear view mirrors.

*

7

: This light illuminates on the center panel.

*

8

: When the outside temperature is approximately 37°F (3°C) or lower, this

indicator will flash for approximately 10 seconds, then stay on.

WARNING

■

If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning lights not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by your Toyota dealer immedi-
ately if this occurs.

84

2. Instrument cluster

4.2-inch display



7-inch display

Gauges and meters

85

2. Instrument cluster

2

Instrum

e

nt clus

ter

Displays the engine speed in revolutions per minute

Shift position (

→P. 205)

Outside temperature

Displays the outside temperature within the range of -40°F (-40°C) to
122°F (50°C). Low outside temperature indicator comes on when the
ambient temperature is 37°F (3°C) or lower.

Multi-information display

Presents the driver with a variety of vehicle data (

→P. 87, 99)

Displays warning messages in case of a malfunction (

→P. 507)

Speedometer
Fuel gauge
Odometer and trip meter

(→P. 96, 110)

Engine coolant temperature gauge

Displays the engine coolant temperature

The brightness of the instrument panel lights can be adjusted.

Darker
Brighter

• The brightness of the instrument

panel lights can be adjusted
individually for day mode and
night mode

*

.

• If the brightness is adjusted

when the surroundings are
bright and the tail lights are on
(day mode brightness adjust-
ment), the brightness level of
night mode will be adjusted at
the same time.

*

: Day mode and night mode:

→P. 86

Instrument panel light control

1

2
3

4

5
6
7
8

1
2
