78



4.2-inch display



7-inch display

The units used on the meters and some indicators may differ depending on
the target region.

Warning lights and indicators

The warning lights and indicators on the instrument cluster, cen-
ter panel and outside rear view mirrors inform the driver of the
status of the vehicle’s various systems.

For the purpose of explanation, the following illustrations dis-
play all warning lights and indicators illuminated.

79

2. Instrument cluster

2

Instrum

e

nt clus

ter

Warning lights

*

1

(U.S.A.)

Brake system warning
light (

→P. 497)

*

2

(Canada)

Parking brake indicator
(

→P. 498)

*

1

(Canada)

(Red)

Brake system warning
light (

→P. 497)

*

1, 2

(if equipped)

Brake hold operated
indicator (

→P. 498)

*

1

(if equipped)

(Yellow)

Brake system warning
light (

→P. 497)

*

1

(Red/yellow)

Electric power steering
system warning light
(

→P. 498)

*

1

(U.S.A.)

Malfunction indicator
lamp (

→P. 497)

*

1, 2

(if equipped)

PCS warning light
(

→P. 499)

*

1

(Canada)

Malfunction indicator
lamp (

→P. 497)

*

1, 2

(if equipped)

ICS OFF indicator
(

→P. 499)

*

1

SRS warning light
(

→P. 497)

(if equipped)

(Yellow)

LDA (Lane Departure
Alert) indicator
(

→P. 498)

*

1

(U.S.A.)

ABS warning light
(

→P. 497)

*

1

Slip indicator (

→P. 499)

*

1

(Canada)

ABS warning light
(

→P. 497)

Low fuel level warning
light (

→P. 500)

*

2

(U.S.A.)

Parking brake indicator
(

→P. 498)

Driver’s and front
passenger’s seat belt
reminder light (

→P. 500)

80

2. Instrument cluster

1

: These lights turn on when the engine switch is turned to the “ON” position

(vehicles without a smart key system) or IGNITION ON mode (vehicles
with a smart key system) to indicate that a system check is being per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or turn
off. Have the vehicle inspected by your Toyota dealer.

*

2

: This light flashes to indicate a malfunction.

*

3

: This light illuminates on the center panel.

*

3

(Type A)

Rear passengers’ seat
belt reminder lights
(

→P. 500)

*

1

Master warning light
(

→P. 500)

*

3

(Type B)

Rear passengers’ seat
belt reminder lights
(

→P. 500)

*

1

Tire pressure warning
light (

→P. 500)

81

2. Instrument cluster

2

Instrum

e

nt clus

ter

Indicators

Turn signal indicator
(

→P. 211)

*

1

Brake hold standby
indicator (

→P. 217)

(U.S.A.)

Headlight indicator
(

→P. 219)

Cruise control indicator
(

→P. 263, 276, 289)

(Canada)

Tail light indicator
(

→P. 219)

(if equipped)

Radar cruise control
indicator (

→P. 263, 276)

Headlight high beam
indicator (

→P. 220)

Cruise control “SET”
indicator
(

→P. 263, 276, 289)

*

1

(if equipped)

Automatic High Beam
indicator (

→P. 223)

*

1, 3

(if equipped)

PCS warning light
(

→P. 245)

*

1, 2

Eco driving indicator
(

→P. 111, 343)

*

1, 3

(if equipped)

ICS OFF indicator
(

→P. 325)

(U.S.A.)

Parking brake indicator
(

→P. 213, 212)

(if equipped)

(White)

LDA (Lane Departure
Alert) indicator
(

→P. 253)

(Canada)

Parking brake indicator
(

→P. 213, 212)

(if equipped)

(Green)

LDA (Lane Departure
Alert) indicator
(

→P. 253)

*

1

(if equipped)

Brake hold operated
indicator (

→P. 217)

*

4

(if equipped)

(Yellow)

LDA (Lane Departure
Alert) indicator
(

→P. 253)
