Subaru Impreza WRX (2014 year). Instruction

5-44

Audio/Hands–free system

– Press the talk switch

– Operate the “TUNE/TRACK/CH”
dial.

3. After “SELECTED” is displayed, you
can select the following menus.

. “DIAL” to make a phone call
. “CHANGE NAME” to change the name
(voice tag)
. “SET SPD DIAL”/“SET SPEED DIAL”
to set the speed dial
. “DELETE ENTRY” to delete the name
(voice tag) from the phonebook
. “GO BACK” to go back to the menu
mode

NOTE

. After “LIST NAMES” is selected, if
the OFF hook switch

is pushed, the

selected number is called.
. After “LIST NAMES” is selected, if
no operation is performed, the mem-
ories are displayed and voice tags are
spoken.

Changing voice tag

1. Select the “CHANGE NAME” menu.
2. Select the phone number by perform-
ing either of the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the voice tag.

3. Select the “CONFIRM” menu.

– Then the selected phone number/
name is displayed.

4. Press the talk switch

5. Say the new voice tag.
6. Select the “CONFIRM” menu.

– Then “CHANGED” is displayed.

Set speed dial

1. Select “SET SPD DIAL” by operating
the “TUNE/TRACK/CH” dial or select
“SET SPEED DIAL” by using the voice
command system.
2. Select the phone number by perform-
ing either of the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the voice tag.

3. Select the “CONFIRM” menu.
4. Press the preset button (from

) to which you want to register the

phone number.

NOTE

If the number to be used is already
registered in speed dial, “OVER-
WRITE?” will be displayed.

Deleting the phonebook data

1. Select the “DELETE ENTRY” menu.
2. Select the phone number by perform-
ing either of the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the voice tag.

3. Select the “CONFIRM” menu.

– Then “DELETED” is displayed and
the selected phonebook data is de-
leted.

Deleting the speed dial

1. Select “DEL SPD DIAL” by operating
the “TUNE/TRACK/CH” dial or select
“DELETE SPEED DIAL” by using the
voice command system.
2. Press the preset button (from

) to which you want to delete the

speed dial.
3. Select the “CONFIRM” menu.

– Then “DELETED” is displayed and
the selected speed dial is deleted.

Deleting the redial data

1. Select the “REDIAL” menu.
2. Select the phone number by operating
the “TUNE/TRACK/CH” dial.
3. Select the “DELETE” menu.

4. Select the “CONFIRM” menu.

– Then “DELETED” is displayed and
the selected redial data is deleted.

Deleting the callback data

1. Select the “CALLBACK” menu.
2. Select the phone number by operating
the “TUNE/TRACK/CH” dial.
3. Select the “DELETE” menu.
4. Select the “CONFIRM” menu.

– Then “DELETED” is displayed and
the selected callback data is deleted.

Making a phone call

Making a phone call by saying
name

1. Press the talk switch

2. Say “DIAL BY NAME”.
3. Press the talk switch

again.

4. Say the desired name (voice tag) to be
called.
5. Select the “DIAL” menu or press the
OFF hook switch

Making a phone call by saying
number

1. Press the talk switch

2. Say “DIAL BY NUMBER”.
3. Press the talk switch

again.

4. Say the desired phone number to be
called.
5. Select the “DIAL” menu or press the
OFF hook switch

Making a phone call from speed
dial

It is possible to select a phone number
from speed dial registered with the in-
vehicle equipment to make a phone call.

1. Press the preset button (from

) to which the desired number is

registered.
2. Press the OFF hook switch

NOTE

When a preset button for which num-
bers are not registered is pressed, an
error message is indicated on the audio
screen.

Redial

1. Select the “REDIAL” menu.
2. Select the desired number by operat-
ing the “TUNE/TRACK/CH” dial.
3. Select the “DIAL” menu or press the
OFF hook switch

Callback

1. Select the “CALL BACK” menu.
2. Select the desired number by operat-
ing the “TUNE/TRACK/CH” dial.
3. Select the “DIAL” menu or press the
OFF hook switch

Making a phone call from list
name

It is possible to select a phone number
from the list name registered with the in-
vehicle equipment to make a phone call.
For details, refer to “List names function”
F5-43.

Top redial

1. Press the OFF hook switch

and

load the outgoing call history.
2. Select the “DIAL” menu or press the
OFF hook switch

Taking a phone call and declining
an incoming call

To take a phone call: Press the OFF
hook switch

To put an incoming call on hold (only if
the cell phone has this function): Press the
ON hook switch

briefly.

To decline an incoming call (only if the
cell phone has this function): Press and

Audio/Hands–free system

5-45

– CONTINUED –

5-46

Audio/Hands–free system

hold the ON hook switch

Ending a call

Press the ON hook switch

Volume control

You can adjust the phone call volume, the
voice volume and the voice guidance
volume. Refer to “Volume control buttons”
F5-32.

Adjustable level of each volume

Volume

Range

Initial setting

Phone call

0 to 14

Voice

0 to 14

Voice guidance

0 to 6

Bluetooth

setting

Security setting

After selecting the “SECURITY” menu,
perform the following procedures.

Setting PIN code

The PIN code is a 4-digit number and is
used when locking the phonebook.

1. Select the “SET PIN” menu.

– Then “CURRENT PIN?” is dis-
played.

2. Input the current PIN code by perform-
ing either of the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the number.

3. Select the “CONFIRM” menu.
4. Input the new PIN code by performing
either of the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the number.

5. Select the “CONFIRM” menu.

Locking the phonebook

1. Select “PHBK LOCK” by operating the
“TUNE/TRACK/CH” dial or say “PHONE-
BOOK LOCK”.

– Then “CURRENT PIN?” is dis-
played.

2. Input the PIN code by performing
either of the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the number.

3. Select the “CONFIRM” menu.

– If the inputted PIN code is correct,
“LOCKED” is displayed and the pho-
nebook is locked.

NOTE

While the phonebook is locked, if the
operation restricted menu is selected,
“PHBK LOCK” is displayed.

Unlocking the phonebook

1. Perform either of the following proce-
dures.

– Select the “PHBK UNLOCK” menu
by operating the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

“PHONEBOOK UNLOCK”.

NOTE

If the phonebook is not locked, “UN-
LOCK” is displayed and the mode
changes to the security mode.

2. After “CURRENT PIN?” is displayed,
input the PIN code by performing either of
the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the number.

3. Select the “CONFIRM” menu.

– If the inputted PIN code is correct,
“UNLOCKED” is displayed and the
phonebook is unlocked.

Phone setup

After selecting the “PHONE SETUP”
menu, perform the following procedures.

Setting pair phone

Refer to “Preparation for using the Hands-
free system” F5-38.

Selecting phone

To select the registered cell phone for
connecting to the in-vehicle equipment,
perform the following procedure.

1. Select the “SELECT PHONE” menu.

– If no cell phones are registered,
“EMPTY” is displayed and the mode
changes to the “PHONE SETUP”
mode.

2. Select the cell phone by performing
either of the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the voice tag.

3. Select the “CONFIRM” menu.

– “SELECTED” is displayed, the se-
lected cell phone is connected to the
in-vehicle equipment and the mode
changes to the “PHONE SETUP”
mode.

Changing the voice tag of the cell
phone

1. Select the “CHANGE NAME” menu.

– If no cell phones are registered,
“EMPTY” is displayed and the mode
changes to the “PHONE SETUP”
mode.

2. Select the cell phone by performing
either of the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the voice tag.

3. Select the “RECORD NAME” menu.
4. Register the voice tag. For details,
refer to “Preparation for using the Hands-
free system” F5-38.

List phones function

The cell phone voice tags saved in the cell
phone list are spoken by using the list
phones function.

1. Select the “LIST PHONES” menu.

– If no cell phones are registered,
“EMPTY” is displayed and the mode
changes to the “PHONE SETUP”
mode.

2. Registered cell phones are displayed
in the saved order. While displayed, if the
“TUNE/TRACK/CH” dial is turned, the
next registered cell phone is displayed.
Press the ON hook button

to close the

Hands-free menu.
3. Select the cell phone by performing
either of the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

4. After “SELECTED” is displayed, you
can select the following menus.

. “SELECT PHONE” to connect the
selected cell phone
. “CHANGE NAME” to change the voice
tag
. “DELETE” to delete the selected cell
phone from the list
. “GO BACK” to go back to the “PHONE
SETUP” mode

Audio/Hands–free system

5-47

– CONTINUED –

5-48

Audio/Hands–free system

Setting passkey

1. Select the “SET PASSKEY” menu.

– After the currently set passkey is
displayed, a new passkey can be
entered.

2. Input the new passkey by performing
either of the following procedures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the passkey.

3. Select the “CONFIRM” menu.

– The new passkey is displayed, the
passkey is changed and the mode
changes to the “PHONE SETUP”
mode.

Deleting registered cell phone
from the list

1. Select the “DELETE” menu.
2. Select a cell phone to be deleted by
performing either of the following proce-
dures.

– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch

and say

the voice tag.

3. Select the “CONFIRM” menu.

– “DELETED” is displayed, the data is
deleted and the mode changes to the
“PHONE SETUP” mode.

System setup

After selecting the “SYSTEM SETUP”
menu, perform the following procedure.
Select the following menus by operating
the “TUNE/TRACK/CH” dial.

Setting guidance volume

To set the guidance volume, perform the
following procedure.

1. Select the “GUIDANCE VOL” menu.
2. Set the guidance volume by operating
the “TUNE/TRACK/CH” dial.

Initializing the registered data

To initialize the registered data, perform
the following procedure.

1. Select the “INITIALIZE” menu.
2. Select the “CONFIRM” menu.

– First “PLEASE WAIT”, then “INITI-
ALIZED” is displayed. The registered
data is initialized and the mode
changes to the last mode.

Selecting language

To select the language, perform the
following procedure.

1. Select the “SEL LANGUAGE” menu.
2. Select the desired language by oper-
ating the “TUNE/TRACK/CH” dial.

Interior lights .......................................................

6-2

Dome light ..........................................................

6-2

Cargo area light (5-door models) .........................

6-2

Map lights ...........................................................

6-3

Sun visors ...........................................................

6-4

Vanity mirror .......................................................

6-4

Storage compartment .........................................

6-4

Glove box ...........................................................

6-5

Center console....................................................

6-5

Cup holders .........................................................

6-5

Front passenger’s cup holder ..............................

6-5

Rear passenger’s cup holder (if equipped) ...........

6-7

Bottle holders ......................................................

6-7

Accessory power outlets ....................................

6-8

Use with a cigarette lighter (if equipped)...............

6-9

Ashtray (if equipped).........................................

6-10

Floor mat ............................................................

6-10

Shopping bag hook (5-door).............................

6-11

Cargo area cover (5-door).................................

6-12

Using the cover .................................................

6-12

To remove the cover ..........................................

6-12

To install the cover housing ...............................

6-13

Cargo tie-down hooks (5-door).........................

6-13

Under-floor storage compartment (if

equipped) ........................................................

6-14

Interior equipment

6-2

Interior equipment/Interior lights

Interior lights

When leaving your vehicle, make sure the
lights are turned off to avoid battery
discharge.

Dome light

DOOR

OFF

The dome light switch has the following
three positions.

ON: The light remains on continuously.
OFF: The light remains off.
DOOR: The dome light illuminates auto-
matically in the following cases.
. Any of the doors or the rear gate (5-

door) is opened.
. The doors or the rear gate (5-door) are
unlocked using the remote keyless entry
transmitter.
. The ignition switch is turned from the
“Acc” position to the “LOCK” position.

The automatically illuminated dome light
remains on for several seconds and then
gradually turns off after all doors and the
rear gate (5-door) are closed.

While the light is illuminated, if any of the
following operations are performed, the
dome light turns off immediately.
. The ignition switch is turned from the
“LOCK” position to “Acc” or “ON” position.
. All doors and the rear gate (5-door) are
locked using the remote keyless entry
transmitter.

The setting of the period for which the light
remains on (OFF delay timer) can be
changed by a SUBARU dealer. Consult
your SUBARU dealer for details.

Cargo area light (5-door
models)

ON position: The light illuminates when
the rear gate is opened. The light remains
illuminated for several seconds and gra-
dually turns off after the rear gate is
closed.
OFF position: The light remains off.

Map lights

Type A

Type B

To turn on the map light, push the switch.
To turn it off, push the switch again.

When leaving the vehicle, make sure the
lights are turned off to avoid battery
discharge.

NOTE

For the type A map lights, although the
light switches are in the ON position,
the lights are automatically turned off
after approximately 30 seconds of
illumination to prevent the vehicle
battery from discharging. For details,
refer to “Battery drainage prevention
function” F2-5.

Automatic illumination (models
with moonroof)

The map lights illuminate automatically in
the following cases.
. Any of the doors other than the rear
gate is opened. (The map lights do not
illuminate when only the rear gate is
opened.)
. The doors are unlocked using the
remote keyless entry transmitter.
. The ignition switch is turned from the
“Acc” position to the “LOCK” position.

The automatically illuminated map lights
remain on for several seconds and then
gradually turn off after all doors are
closed.

While the lights are on, if any of the

following operations are performed, the
map lights turn off immediately.
. The ignition switch is turned from the
“LOCK” position to the “Acc” or “ON”
position.
. All doors and the rear gate (5-door) are
locked using the remote keyless entry
transmitter.

The setting of the period for which the
lights remain on (OFF delay timer) can be
changed by a SUBARU dealer. Consult
your SUBARU dealer for details.

Interior equipment/Interior lights

6-3

6-4

Interior equipment/Sun visors

Sun visors

To block out glare, swing down the visors.
To use the sun visor at a side window,
swing it down and move it sideways.

Vanity mirror

CAUTION

Keep the vanity mirror cover closed
while the car is being driven to avoid
being temporarily blinded by the
glare of bright light.

To use the vanity mirror, swing down the
sun visor and open the vanity mirror cover.

Storage compartment

CAUTION

. Always keep the storage com-

partment closed while driving to
reduce the risk of injury in the
event of a sudden stop or an
accident.

. Do not store spray cans, contain-

ers with flammable or corrosive
liquids or any other dangerous
items in the storage compart-
ment.

Glove box

Lock

Unlock

To open the glove box, pull the handle. To
close it, push the lid firmly upward.

To lock the glove box, insert the key and
turn it clockwise. To unlock the glove box,
insert the key and turn it counterclockwise.

Center console

To open the lid, pull up the lock release.

Cup holders

CAUTION

Take care to avoid spills. Beverages,
if hot, might burn you or your
passengers. Spilled beverages may
also damage upholstery, carpets or
audio equipment.

Front passenger’s cup holder

CAUTION

Do not pick up a cup from the cup
holder or put a cup in the holder
while you are driving, as this may
distract you and lead to an accident.

Interior equipment/Cup holders

6-5

– CONTINUED –

6-6

Interior equipment/Cup holders

Except STI

A dual cup holder is built into the center
console, beside the parking brake lever.

STI

The dual cup holder is built into the center

console near the parking brake lever.

To access the cup holder, pull the lid
toward the rear.

The divider in the cup holder can be pulled
out and inserted in a different position
(further toward the front or rear) to enable

cups of different sizes to be held.

NOTE

With the divider taken out, the cup
holder can be used as a storage box.

Rear passenger’s cup holder

(if equipped)

CAUTION

When not in use, always keep the
cup holder stored while driving to
reduce the risk of injury in the event
of a sudden stop or an accident.

A dual cup holder is located at the back of
the center console. To use the cup holder,
open the lid by pulling its upper edge.

Bottle holders

CAUTION

. Do not pick up a bottle from the

bottle holder or put a bottle in the
holder while you are driving, as
this may distract you and lead to
an accident.

. When placing a beverage in a

bottle holder, make sure it is
capped. Otherwise, the beverage
could spill when opening/closing
the door or while driving and, if
the beverage is hot, it could burn
you and/or your passengers.

The bottle holder equipped on each door

trim can be used to hold beverage bottles
and other items.

Interior equipment/Bottle holders

6-7

6-8

Interior equipment/Accessory power outlets

Accessory power outlets

Power outlet below the climate control
dials

Power outlet in the center console (except
STI)

Power outlet in the center console (STI)

Accessory power outlets are provided
below the climate control dials and in the
center console. Electrical power (12V DC)
from the battery is available at any of the
outlets when the ignition switch is in either
the “Acc” or “ON” position.
You can use an in-vehicle electrical
appliance by connecting it to an outlet.
The maximum power rating of an appli-
ance that can be connected is 120W. Do
not use an appliance which exceeds the
indicated wattage for each outlet.
When using appliances connected to two
outlets simultaneously, the total power
consumed by them must not exceed
120W.

CAUTION

. Do not attempt to use a cigarette

lighter in the accessory power
outlets.

. Do not place any foreign objects,

especially metal ones such as
coins or aluminum foil, into the
accessory power outlet. That
could cause a short circuit. Al-
ways put the cap on the acces-
sory power outlet when it is not
in use.

. Use only electrical appliances

which are designed for 12V DC.

The maximum power rating of an
appliance that can be connected
is 120W. Do not use an appliance
which exceeds the indicated wat-
tage for each outlet.

When using appliances con-
nected to two outlets simulta-
neously, the total power con-
sumed by them must not exceed
120W. Overloading the accessory
power outlet can cause a short
circuit. Do not use double adap-
ters or more than one electrical
appliance.

. If the plug on your electric appli-

ance is either too loose or too

tight for the accessory power
outlet, this can result in a poor
contact or cause the plug to get
stuck. Only use plugs that fit
properly.

. Use of an electric appliance in the

accessory power outlet for a long
period of time while the engine is
not running can cause battery
discharge.

. Before driving your vehicle, make

sure that the plug and the cord
on your electrical appliance will
not interfere with your shifting
gears and operating the accel-
erator and brake pedals. If they
do, do not use the electrical
appliance while driving.

Use with a cigarette lighter (if
equipped)

To use the accessory power outlet below
the climate control as a cigarette lighter
socket, purchase the cigarette lighter plug,
which is an optional accessory. A cigarette
lighter plug is available from your
SUBARU dealer.
The cigarette lighter operates only when
the ignition switch is in the “ON” or “Acc”
position.
To use the cigarette lighter, push in the
knob and wait a few moments. It will
automatically spring up when ready for
use.

WARNING

To avoid being burned, never grasp
the lighter by the end with the
heating element. Doing so could
result in injury and could also
damage the heating element.

CAUTION

. Do not hold the lighter pushed in,

because it will overheat.

. The electrical power socket lo-

cated in the center console is
originally designed to use a gen-

uine SUBARU cigarette lighter
plug. Do not use a non-genuine
cigarette lighter plug in the sock-
et. Doing so may cause a short-
circuit and overheating, resulting
in a fire.

. If the socket is ever used for a

plug-in accessory such as a cell
phone, that may damage the
portion of the socket’s internal
mechanism that causes a cigar-
ette lighter plug to “pop out”
after its lighter element is heated.
Therefore, do not place a cigar-
ette lighter plug in a socket that
has been used, even once, to
power a plug-in accessory. Doing
so may cause the plug to stick
and overheat, creating a potential
fire hazard.

Interior equipment/Accessory power outlets

6-9

6-10

Interior equipment/Ashtray

Ashtray (if equipped)

CAUTION

. Do not use ashtrays as waste

receptacles or leave a lighted
cigarette in an ashtray. This
could cause a fire.

. Always extinguish matches and

cigarettes before putting them
into the ashtray, and then close
the ashtray securely. If you keep
the ashtray open, the fire of the
cigarette may spread to another
cigarette butt and start a fire.

. Do not put flammable material in

the ashtray.

. Do not leave a lot of cigarette

butts in the ashtray.

NOTE

Particles of ash and tobacco will accu-
mulate around the hinges of the ash-
tray’s inner lid. Clean them off using a
toothbrush or a similar narrow-ended
implement.

The portable ashtray can be installed in
each cup holder. For the locations of the
cup holders, refer to “Cup holders” F6-5.
When using the ashtray, open the lid of the
ashtray. When removing the ashtray from
a cup holder, pull the ashtray upwards.
Fully close the lid after using the ashtray to
help reduce residual smoke.

Floor mat

Retaining pins are located on the driver’s
side floor.
The floor mat should be properly secured
using the built-in grommets, by placing the
grommets over the pins and pushing them
downward.

CAUTION

If the floor mat slips forward and
interferes with the movement of the
pedals during driving, it could cause
an accident. Observe the following
precautions to prevent the floor mat
from slipping forward.

. Be sure to use a genuine

SUBARU floor mat designed with
grommets in the correct loca-
tions.

. Make sure that the driver’s floor

mat is placed back in its proper
location and is correctly secured
on its retaining pins.

. Do not use more than one floor

mat.

Shopping bag hook (5-door)

CAUTION

Do not hang items on the shopping
bag hook that weigh 6 lbs (3 kg) or
more.

A shopping bag hook is attached to each
side of the cargo area.

Interior equipment/Shopping bag hook (5–door)

6-11

Subaru Impreza WRX (2014 year). Instruction - part 15
