5-28

Audio/USB storage device / iPod

operations (type B audio)

iPod

cannot be operated using the

click wheel on the iPod

(except some

models).
. When using an iPod

by connecting

it to in-vehicle equipment, the order of
the list items displayed on the in-
vehicle equipment may be different
from that on the iPod

. However, this

does not indicate a malfunction.
. An iPod

battery that is connected

to in-vehicle equipment will be charged
when the ignition switch is in the “ON”
or “Acc” position. However, activation
of the iPod

may be delayed if the

battery charge of the iPod

is low.

. If an iPod

does not activate after

operation, disconnect the connection
cable from the iPod

and reset it. For

the resetting procedure, see the User’s
Guide of the iPod

. If an iPod

and the connection cable

are connected improperly, the iPod

cannot be powered on or will not be
recognized by in-vehicle equipment. In
this case, disconnect the connection
cable from the iPod

, and then connect

it again.

Except STI

STI

The USB connector is located in the
center console. Use the connector to
connect a USB storage device / iPod

How to play back

1. Connect a USB storage device /
iPod

2. Press the

button. Each time you

briefly press the button, the mode
changes in the following sequence.

*: Only when a Media Hub is connected.

When the USB/iPod

mode is selected,

the player will start playback of the USB
storage device / iPod

NOTE

. Depending on the number of files
stored on the iPod

and the firmware

version, the iPod

may not activate

smoothly after operation or not work
properly.
. Do not disconnect the connector
from the iPod

during iPod

operation.

To select a track from the
beginning

Select a track in the same way as for a
CD. For details, refer to “To select a track
from the beginning” F5-18.

To select a chapter from the
beginning when connecting
iPod

When playing podcasts or audiobooks,
select a chapter in the same way as for a
CD. For details, refer to “To select a track
from the beginning” F5-18.

Fast-forwarding and rewind-
ing

Fast-forwarding and rewinding are oper-
ated in the same way as for a CD. For
details, refer to “Fast-forwarding and
rewinding” F5-19.

NOTE

When connecting iPod

. When the end of a track is reached
while fast-forwarding, fast-forwarding
ends and play begins from the begin-
ning of the next track.

. When the beginning of a track is
reached while rewinding, rewinding
ends and play begins from the begin-
ning of the track.

Repeating

When connecting USB storage de-
vice

Repeating is operated in the same way as
for a CD. For details, refer to “Repeating”
F5-19.

When connecting iPod

Each time you briefly press the
button, the mode changes in the following
sequence.

NOTE

. The “ALL RPT” indication refers to
the repeat playback of all tracks on the
entire iPod

. The “SONG RPT” indication refers
to the repeat playback of a single track.
It repeats the track that is playing.
. When an audiobook is playing, the
mode does not change even if you
press the

button.

Random playback

To playback tracks at random, press and
hold the

button while a track is

playing.

Each time you press the button, the mode
changes in the following sequence.
When connecting USB storage device:

When connecting iPod

NOTE

. The “FOLDER RDM” indication re-
fers to the random playback in the
folders. It randomly repeats all of the
tracks in the folder.
. The “ALL RDM” indication refers to
the random playback on the entire USB
storage device. It randomly repeats all
of the tracks in the USB storage device.
. The “ALBUM RDM” indication refers
to the shuffle playback in the album. It
randomly repeats all of the tracks on
the album.
. The “SONG RDM” indication refers
to the shuffle playback in the entire

Audio/USB storage device / iPod

operations (type B audio)

5-29

– CONTINUED –

5-30

Audio/USB storage device / iPod

operations (type B audio)

iPod

. It randomly repeats all of the

tracks on the iPod

. When an iPod

is connected, the

files are played back at random by the
shuffle function of the iPod

. There-

fore, iPod

operation may be different

depending on the model of the con-
nected iPod

. When an audiobook or a podcast is
playing, the mode does not change
even if you press and hold the
button.

To cancel the random playback mode,
press and hold the

button and select

CANCEL. The “RDM” indication will turn
off, and the normal playback mode will
resume.

SCAN (only when connecting
USB storage device)

Scan is operated in the same way as for a
CD. For details, refer to “Scan” F5-20.

NOTE

When an iPod

is connected, you

cannot select the SCAN mode.

Selecting category (only
when connecting iPod

)

When the

button is pressed briefly,

the iPod

menu is displayed.

Each time you turn the “TUNE/TRACK/
CH” dial clockwise, the displayed category
changes in the following sequence. Each
time you turn the “TUNE/TRACK/CH” dial
counterclockwise, the displayed category
changes in the opposite sequence.

To select the category, press the “TUNE/
TRACK/CH” dial. To close the iPod

menu, press and hold the

button.

To return to the previous screen, briefly
press the

button.

Display selection

Refer to “Display selection” F5-21.

Page scroll

Refer to “Page (track/folder title) scroll”
F5-21.

Folder selection (only when
connecting USB storage de-
vice)

Refer to “Folder selection” F5-21.

NOTE

When an iPod

is connected, you

cannot select a folder.

When “CHECK DEVICE” is

displayed

This message is displayed under the
following conditions.
. When there is a short in the USB bus
. When an unsupported device (for ex-
ample a USB mouse) is connected
. When an unsupported iPod

is con-

nected
. When a connected iPod

is frozen

. When a transmission malfunction oc-
curs
. When an iPod

confirmation malfunc-

tion occurs
. When a HUB class USB storage
device is connected

Disconnect the USB storage device/iPod

and check it.

Audio control buttons

These buttons are located on the spokes
of the steering wheel. They allow the
driver to control audio functions without
taking his/her hands off the steering
wheel.

MODE button

Models without Hands-free system

Models with Hands-free system

The “MODE” button is used to select the
desired audio mode. Each time it is
pressed, the mode changes to the next
one in the following sequence:
Type A audio:

Type B audio:

*1: The frequency last received in the selected

waveband will be displayed.

*2: Only when a CD is in the player.

*3: Only when the device is connected.

Models with Hands-free system

Press and hold this button if you wish to
immediately cut the volume to zero.
The audio display will show “MUTE”.
If you press and hold the button again, the
original sound volume will return and
“MUTE” turns off.

“ ” and “ ” buttons

Models without Hands-free system

Audio/Audio control buttons

5-31

– CONTINUED –

5-32

Audio/Audio control buttons

Models with Hands-free system

With radio mode selected

Press the “ ” button or “ ” button. The
radio will seek the next receivable station
and stop on it. That station’s frequency will
be shown on the audio display.

With CD mode selected

Press the “ ” button to skip forward in the
track/file order. Press the “ ” button to
skip backward in the track/file order. The
track/file number will be shown on the
audio display.

For models with the Hands-free system,
press and hold the “ ” button to select
the next folder. Press and hold the “ ”
button to go back to the previous folder.

With SAT mode selected

Press the “ ” button to skip forward in the
channel order. Press the “ ” button to
skip backward in the channel order.
The channel will be shown on the audio
display.

Volume control buttons

Models without Hands-free system

Models with Hands-free system

Press the “+” button to increase the
volume. Press the “−” button to reduce
the volume.
A number indicating the volume will be
shown on the audio display.

MUTE button (models with-
out Hands-free system)

Press the “ ” button if you wish to
immediately cut the volume to zero.
The audio display will show “MUTE”.
If you press the button again, the original
sound volume will return and “MUTE”
turns off.

Bluetooth

audio (type B

audio)

NOTE

For models with the genuine SUBARU
navigation system, refer to the Owner’s
Manual supplement for the navigation
system.

NOTE

The Bluetooth word mark and logo are
registered trademarks of Bluetooth
SIG, Inc.

This function enables you to play back
audio sources recorded in Bluetooth

audio devices. You need to register the
Bluetooth

audio device in the system

before using it.

Media format

Bluetooth

audio devices cannot be

connected if they are not compatible with
the following Bluetooth

profiles.

. A2DP (Advanced Audio Distribution
Profile)
. AVRCP (Audio/Video Remote Control
Profile)

Setting Bluetooth

audio

1. Select the “BT-A SETUP” menu by
pressing the “MENU” button. For details,
refer to “Other sound setting controls” F5-
7.
2. Perform the following procedure by
operating the “TUNE/TRACK/CH” dial
while “BT-A” is displayed.

NOTE

You cannot set a Bluetooth

audio

while driving.

Registering (pairing) device

1. Select the “PAIR AUDIO” menu.

– If a device is already registered,
“MEMORY FULL” is displayed and the
mode changes to the Bluetooth

audio setting mode.

2. After the passkey is shown on the
display, input the passkey into the cell

Audio/Bluetooth

audio (type B audio)

5-33

– CONTINUED –

5-34

Audio/Bluetooth

audio (type B audio)

phone.

– If you input the correct passkey,
“PAIRED” is displayed and the regis-
tering procedure is finished.
– If you input an incorrect passkey,
“FAILED” is displayed, the registering
procedure was not successful and the
mode changes to the Bluetooth

audio setting mode.

Selecting device

1. Select the “SELECT AUDIO” menu.

– If no devices are registered,
“EMPTY” is displayed and the mode
changes to the Bluetooth

audio

setting mode.

2. Select the “CONFIRM” menu.

– If the device is connected, “SE-
LECTED” is displayed and the select-
ing procedure is finished.
– If the device cannot be connected,
“FAILED” is displayed and the select-
ing procedure was not successful.

Setting passkey

1. Select the “SET PASSKEY” menu.

– After the currently set passkey is
displayed, a new passkey can be
entered.

2. Input the new passkey by operating
the “TUNE/TRACK/CH” dial.

3. Select the “CONFIRM” menu.

– The new passkey is displayed, the
passkey is changed and the mode
changes to the Bluetooth

audio

setting mode.

Deleting device

1. Select the “DELETE AUDIO” menu.

– If no devices are registered,
“EMPTY” is displayed and the mode
changes to the Bluetooth

audio

setting mode.

2. Select the “CONFIRM” menu.

– “DELETED” is displayed and the
mode changes to the Bluetooth

audio setting mode.

Bluetooth

audio operation

NOTE

Depending on the connected device, it
may not activate as per the following
items or not work smoothly.

How to play back

Press the

button and select the “BT-

A” mode.
!

To select a track from its beginning

Select a track in the same way as for a
CD. Refer to “To select a track from the
beginning” F5-18.

Repeating

Repeating is operated in the same way as
for a CD. Refer to “Repeating” F5-19.
Each time you briefly press the
button, the mode changes in the following
sequence.

Random playback

Random playback is operated in the same
way as for a CD. Refer to “Random
playback” F5-20. Each time you press
and hold the

button, the mode

changes in the following sequence.

Display selection

Select an indication in the same way as
for a CD. Refer to “Display selection” F5-
21. Each time you briefly press the
button, the indication changes in the
following sequence.

Folder selection

Select a folder in the same way as for a
CD. Refer to “Folder selection” F5-21.

Hands-free system (if
equipped)

NOTE

. For models with the genuine
SUBARU navigation system, refer to
the Owner’s Manual supplement for the
navigation system.
. When selling your vehicle, make
sure that you initialize the Hands-free
system to prevent personal data from
being improperly accessed.

The Hands-free system operates while the
ignition switch is in the “Acc” or “ON”
position.

Tips for the Hands-free sys-
tem

Bluetooth

It is possible to connect a cell phone to the
in-vehicle equipment through the Blue-
tooth

format (wireless) to make a phone

call from the in-vehicle equipment or take
an incoming phone call.
Since the Bluetooth

format is wireless, a

connection between the in-vehicle equip-
ment and the cell phone can be made
without placing them in close proximity of
each other. The cell phone can be used
with it left in the breast pocket or bag.

NOTE

. The Hands-free system may not
operate properly under the following
conditions.

– The cell phone is turned off.
– The cell phone is not in the
phone call area.
– The battery of the cell phone has
run down.
– The cell phone is not connected
to the Hands-free system.
– The cell phone is behind the seat
or in the glove box.
– A metal material covers or
touches the cell phone.

. Depending on the type of cell phone
that is used, the screen on the cell
phone may remain illuminated while
the ignition switch is in the “ON”
position. If this occurs, turn the illumi-
nation off by adjusting the cell phone
settings.
. Depending on the setting of the cell
phone, the dial lock function may be
activated after making a call. Deacti-
vate the automatic dial lock function of
the cell phone before using the Hands-
free system.
. Depending on the type of cell phone
that is used, operation and the sound
volume may be different from those of
cell phones currently used.

Audio/Hands–free system

5-35

– CONTINUED –

5-36

Audio/Hands–free system

. When the ignition switch is turned to
the “LOCK” position during a call, the
call may be disconnected or continued
on the cell phone depending on the
type of cell phone that is used. Note
that operation of the cell phone may be
necessary if the call is continued on the
cell phone.
. Do not speak at the same time as the
other party during a call. If you and the
party speak at the same time, it may be
difficult for the other party to hear your
voice and vice versa. This is normal.
. The receiver sound volume should
be set as low as possible. Otherwise,
the party you are calling may notice an
undesirable echo sound.
. Speak clearly and loudly.
. Your voice may be difficult to be
heard by the party under the following
conditions.

– Driving on a rough road.
– Driving at a high speed.
– Driving with a window open.
– When air from the ventilator
blows directly towards the micro-
phone.
– When the sound coming from the
ventilator is loud.
– When the cell phone is too close
to the microphone.

. The sound quality may degrade due
to the influence of the cell phone that is
connected to the system or the circum-
stances of the Bluetooth network.
. When another Bluetooth

device is

simultaneously connected, noise may
be heard in the voice coming from the
hands-free phone.

Corresponding profiles for the cell
phone

. HFP (Hands Free Profile): Ver. 1.0
. OPP (Object Push Profile): Ver. 1.1

Certification for the Hands-
free system

CAUTION

FCC WARNING

Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.

NOTE

This device complies with Part 15 of
the FCC Rules and RSS-Gen of IC
Rules. Operation is subject to the
following two conditions: (1) this de-

vice may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.

NOTE

This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are
designed to provide reasonable protec-
tion against harmful interference in a
residential installation. This equipment
may cause harmful interference to
radio communications, if it is not
installed and used in accordance with
the instructions. However, there is no
guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful inter-
ference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the inter-
ference by one or more of the following
measures.
. Reorient or relocate the receiving
antenna.
. Increase the separation between the
equipment and receiver.
. Connect the equipment into an out-

let on a circuit different from that to
which the receiver is connected.
. Consult the dealer or an experi-
enced radio/TV technician for help.
. Changes or modifications not ex-
pressly approved by the party respon-
sible for compliance could void the
user’s authority to operate the equip-
ment.
. This equipment complies with FCC/
IC radiation exposure limits set forth
for an uncontrolled equipment and
meets the FCC radio frequency (RF)
Exposure Guidelines in Supplement C
to OET65 and RSS-102 of the IC radio
frequency (RF) Exposure rules. This
equipment has very low levels of RF
energy that it deemed to comply with-
out maximum permissive exposure
evaluation (MPE). But it is desirable
that it should be installed and operated
keeping the radiator at least 20 cm or
more away from person’s body (ex-
cluding extremities: hands, wrists, feet
and ankles).
. This transmitter must not be co-
located or operated in conjunction with
any other antenna or transmitter.

Safety precautions

WARNING

. For safety reasons, avoid operat-

ing the cell phone while driving.

. Do not make a phone call while

driving. When you have an in-
coming call, stop the vehicle in a
safe location before taking the
incoming phone call. When you
have to absolutely take a phone
call, tell the caller “I’ll call you
back”. And then call the caller
back after stopping the vehicle in
a safe location.

CAUTION

. Do not leave the cell phone in the

vehicle. The temperature in the
vehicle may become extremely
high and cause a malfunction of
the cell phone.

. When using the cell phone, be

careful not to get it close to the
in-vehicle equipment. Getting it
too close to the in-vehicle equip-
ment may result in deterioration
in tone quality or a poor connect-
ing condition.

. In the frequency band used by

this equipment, along with indus-
trial, scientific and medical
equipment such as a microwave
oven, radio stations (a license is
required) to be used by the
production line in the factory to
identify movable bodies, specific
small power radio stations (a
license is not required) and ama-
teur radio stations (a license is
required) are being operated.
(These three types of radio sta-
tions are hereinafter referred to
as “other radio stations.”) Before
using this equipment, be sure to
check to see if “other radio
stations” are being operated in
the vicinity. If there is detrimental
radio interference from this
equipment to “other radio sta-
tions,” move the equipment to
another location as soon as
possible to avoid radio interfer-
ence. The frequency band used
by this equipment is in the 2.4
GHz zone. The FH-SS modulation
is employed as a modulation
method. The expected inflicting
interference distance is less than
33 ft (10 m). This equipment uses
a full band and can avoid a band

Audio/Hands–free system

5-37

– CONTINUED –

5-38

Audio/Hands–free system

used by a movable body identifi-
cation device.

Using the Hands-free system

Turning on/off the Hands-free mode

OFF hook switch

ON hook switch

Talk switch

To turn on the Hands-free mode, press the
OFF hook switch

. To turn off the

Hands-free mode, press the ON hook
switch

Preparation for using the Hands-
free system

Before using the Hands-free system, it is
necessary to register a cell phone in the

system. Perform the following procedure
to register a cell phone.

1. Press the OFF hook switch

2. Select “ENGLISH”/“FRANÇAIS” by
operating the “TUNE/TRACK/CH” dial.

– Then “WELCOME!” will be dis-
played.

3. Press the “TUNE/TRACK/CH” dial or
the talk switch

4. Select the “RECORD NAME” menu.
5. Say the name to be registered.
6. Select the “CONFIRM” menu.

– After “CAR M_MEDIA” is displayed,
a pass key is displayed.

7. Input the displayed pass key into the
cell phone while “PKY: ****” is displayed.

– If you input the correct pass key,
“PAIRED” is displayed and the regis-
tration procedure is finished.
– If you input an incorrect pass key,
“FAILED” is displayed and the regis-
tration procedure was not successful.

NOTE

When the ignition switch is turned to
the “Acc” or “ON” position, the regis-
tered cell phone may be automatically
connected to the system.

Menu list of the Hands-free system

Turn the “TUNE/TRACK/CH” dial to select
a menu, and then press the dial to enter
the selected menu.

First menu

Second menu

Third menu

Details

Page

PHONE BOOK*

ADD ENTRY

BY VOICE

Adding a new number by voice

5-42

BY PHONE

Adding a new number by cell phone

5-42

MANUAL INPUT

Adding a new number by inputting manually

5-42

CALL HISTORY

Adding a new number from the call history

5-43

GO BACK

LIST NAMES

—

Showing the list of the names registered in the phonebook

5-43

CHANGE NAME

—

Changing a name registered in the phonebook

5-44

SET SPD DIAL

—

Registering a speed dial

5-44

DELETE ENTRY

—

Deleting phonebook data

5-44

DEL SPD DIAL

—

Deleting a registered speed dial

5-44

GO BACK

—

REDIAL

DIAL

—

Redialing

5-45

STORE

—

Adding a new number stored in the outgoing call history
memory

5-43

DELETE

—

Deleting a number stored in the outgoing call history memory

5-44

GO BACK

—

CALLBACK

DIAL

—

Dialing a number stored in the incoming call history memory

5-45

STORE

—

Adding a new number stored in the incoming call history
memory

5-43

DELETE

—

Deleting a number stored in the incoming call history memory

5-45

GO BACK

—

*: If a cell phone is not registered, the menu described in the chart is not indicated.

Audio/Hands–free system

5-39

– CONTINUED –

5-40

Audio/Hands–free system

First menu

Second menu

Third menu

Details

Page

SETUP

SECURITY

SET PIN

Setting a PIN code

5-46

PHBK LOCK*

Locking the phonebook

5-46

PHBK UNLOCK*

Unlocking the phonebook

5-46

GO BACK

PHONE SETUP

PAIR PHONE

Registering a new cell phone

5-38

SELECT PHONE

Selecting a cell phone to be used

5-47

CHANGE NAME

Changing the registered name of the cell phone

5-47

LIST PHONES

Showing the list of the registered cell phones

5-47

SET PASSKEY

Changing the pass key

5-48

DELETE

Deleting the registered cell phone

5-48

GO BACK

SYSTEM SETUP

GUIDANCE VOL

Setting the volume of the voice guidance

5-48

INITIALIZE

Initialization

5-48

SEL LANGUAGE

Selecting the language (using the Hands-free system)

5-48

GO BACK

—

*: If a PIN code is not registered, the menu described in the chart is not available.

Voice command system

OFF hook switch

ON hook switch

Talk switch

To turn on the voice command system,
press the talk switch

briefly. To turn off

the voice command system, wait for 5
seconds without using the voice command
system.

The commands available for the voice
command system are listed in the follow-
ing chart.

Command

English

Français

0 (zero, oh)

0 (zéro)

1 (one)

1 (un)

2 (two)

2 (deux)

3 (three)

3 (trois)

4 (four)

4 (quatre)

5 (five)

5 (cinq)

6 (six)

7 (seven)

7 (sept)

8 (eight)

8 (huit)

9 (nine)

9 (neuf)

* (star)

* (étoile)

# (pound)

# (carré, dièse)

+ (plus)

callback

rappel

redial

recomposer

dial by number

composer par nu-
méro

dial by name

composer par nom

phonebook

registre

setup

réglages

phone book add
entry

ajouter l’entrée

dans le registre

phone book
change name

modifier le nom
dans le registre

phone book delete
entry

supprimer l’entrée

du registre

phone book list
names

lister les noms du
registre

phone book set
speed dial

configurer compo-
sition abrégée pour
le registre

phone book delete
speed dial

supprimer compo-
sition abrégée pour
le registre

phone book unlock

déverrouiller le re-
gistre

cancel

annuler

help

aide

repeat

répéter

go back

retourner

mute

sourdine

dial

composer

delete

supprimer

store

enregistrer

confirm

confirmer

phone setup

réglages du télé-
phone

Audio/Hands–free system

5-41

– CONTINUED –

5-42

Audio/Hands–free system

security

sécurité

pair phone

jumeler le télé-
phone

change name

modifier le nom

select phone

sélectionner le tél-
éphone

list phones

lister les télé-
phones

set pass key

configurer le
passe-partout

add entry

ajouter l’entrée

delete entry

supprimer l’entrée

delete speed dial

supprimer compo-
sition abrégée

by voice

vocalement

by phone

par téléphone

call history

historique d’appels

set speed dial

configurer compo-
sition abrégée

incoming

entrant

outgoing

sortant

list names

lister les noms

set PIN

configurer NIP

phone book lock

verrouiller le regis-
tre

Updating phonebook data

Registering by voice

1. Select the “BY VOICE” menu.
2. Press the talk switch

3. Say the phone number to be regis-
tered.
4. Select the “CONFIRM” menu.
5. Perform either of the following proce-
dures.

– Select the “RECORD NAME” menu
by operating the “TUNE/TRACK/CH”
dial.
– Press the talk switch

6. Say the name (voice tag) to be
registered.
7. Select the “CONFIRM” menu.

– Then “STORED” is displayed and
the mode changes to the registering
speed dial mode. Refer to “Registering
speed dial” F5-43.

Registering by phone

1. Select the “BY PHONE” menu.
2. Select the “CONFIRM” menu.

– Then “TRANSFER” is displayed.

3. Transfer the data from the cell phone.
For details about transferring the data,
refer to the instruction manual of the cell
phone.

4. Perform either of the following proce-
dures.

– Select the “RECORD NAME” menu
by operating the “TUNE/TRACK/CH”
dial.
– Press the talk switch

5. Say the name (voice tag) to be
registered.
6. Select the “CONFIRM” menu.

– Then “STORED” is displayed and
the mode changes to the registering
speed dial mode. Refer to “Registering
speed dial” F5-43.

Registering by inputting manu-
ally

1. Select the “MANUAL INPUT” menu by
operating the “TUNE/TRACK/CH” dial.
2. Input the phone number to be regis-
tered.
3. Perform either of the following proce-
dures.

– Select the “RECORD NAME” menu
by operating the “TUNE/TRACK/CH”
dial.
– Press the talk switch

4. Say the name (voice tag) to be
registered.
5. Select the “CONFIRM” menu.

– Then “STORED” is displayed and
the mode changes to the registering

speed dial mode. Refer to “Registering
speed dial” F5-43.

NOTE

While inputting the phone numbers, if
“GO BACK” is chosen using the
“TUNE/TRACK/CH” dial, the character
that was input last is deleted.

Registering from call history

1. Select the “CALL HISTORY” menu.
2. Select “OUTGOING” or “INCOMING”
by operating the “TUNE/TRACK/CH” dial.
3. Select the phone number by operating
the “TUNE/TRACK/CH” dial.
4. Perform either of the following proce-
dures.

– Select the “RECORD NAME” menu
by operating the “TUNE/TRACK/CH”
dial.
– Press the talk switch

5. Say the name (voice tag) to be
registered.
6. Select the “CONFIRM” menu.

– Then “STORED” is displayed and
the mode changes to the registering
speed dial mode. Refer to “Registering
speed dial” F5-43.

Registering from redial

1. Select the “REDIAL” menu.
2. Select the phone number by operating
the “TUNE/TRACK/CH” dial.
3. Select the “STORE” menu.
4. Select the “CONFIRM” menu.
5. Perform either of the following proce-
dures.

– Select the “RECORD NAME” menu
by operating the “TUNE/TRACK/CH”
dial.
– Press the talk switch

6. Say the name (voice tag) to be
registered.
7. Select the “CONFIRM” menu.

– Then “STORED” is displayed and
the mode changes to the registering
speed dial mode. Refer to “Registering
speed dial” F5-43.

Registering from call back

1. Select the “CALL BACK” menu.
2. Select the phone number by operating
the “TUNE/TRACK/CH” dial.
3. Select the “STORE” menu.
4. Select the “CONFIRM” menu.
5. Perform either of the following proce-
dures.

– Select the “RECORD NAME” menu
by operating the “TUNE/TRACK/CH”

dial.
– Press the talk switch

6. Say the name (voice tag) to be
registered.
7. Select the “CONFIRM” menu.

– Then “STORED” is displayed and
the mode changes to the registering
speed dial mode. Refer to “Registering
speed dial” F5-43.

Registering speed dial

1. After registering phonebook data, se-
lect the “SPEED DIAL” menu.
2. Press the preset button (from

) to which you want to register the

phone number.

NOTE

If the number to be used is already
registered in speed dial, “OVER-
WRITE?” will be displayed.

List names function

The voice tags registered in the phone-
book are spoken by using the list names
function. To use the list names function,
perform the following procedure.

1. Select the “LIST NAMES” menu.
2. Select the registered data by perform-
ing either of the following procedures.

Audio/Hands–free system

5-43

– CONTINUED –

Subaru Impreza WRX (2014 year). Instruction - part 14
