Fuse
System
Page
10A
ECU IG1
Front Fog Light
210
Headlight
166
Headlight Beam Level Control
230
Headlight Cleaner
238
Illumination and Taillight
188
Interior Light
200
Key Reminder (w/o Entry & Start System) and Light Reminder
244
Luggage Compartment Door Opener
314
Mirror Heater and Rear Window Defogger
344
Power Window (LHD)
288
Power Window (RHD)
294
Rear Fog Light
218
Wireless Door Lock Control (w/o Entry & Start System)
306
10A
ECU IG2
Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock
114
DLC3
158
Option Connector
416
10A
FR FOG LH
Front Fog Light
210
10A
FR FOG RH
Front Fog Light
210
10A
HEATER
Air Conditioner (LHD Automatic A/C)
380
Air Conditioner (Manual A/C)
404
Air Conditioner (RHD Automatic A/C)
392
Cooling Fan
376
Engine Immobiliser System (w/ Entry & Start System), Entry & Start
System, Starting (w/ Entry & Start System), Steering Lock
(w/ Entry & Start System) and Wireless Door Lock Control
(w/ Entry & Start System)
72
10A
PANEL
Illumination and Taillight
188
10A
SEAT HTR LH
Seat Heater
350
10A
SEAT HTR RH
Seat Heater
350
10A
TAIL
Front Fog Light
210
Illumination and Taillight
188
Rear Fog Light
218
15A
AT UNIT
Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock
114
15A
P/POINT NO.1
Power Outlet
354
15A
P/POINT NO.2
Power Outlet
354
Fusible Link Block Assembly (See Page 36)
Fuse
System
Page
80A
MAIN
Automatic Light Control and Light Auto Turn Off System
224
Charging
106
* These are the page numbers of the first page on which the related system is shown.
J
BRZ (G4400GE)
445
