Subaru BRZ Electrical Manual - part 110

4

Code or Location

Parts

Electrical Source

7.5A DRL

Starter

S1

Location

Example

FR FOG Relay
(Point Side)

ACC1 Relay
(Point Side)

ACC2 Relay
(Point Side)

IG1 NO.2 Relay
(Point Side)

IG1 NO.3 Relay
(Point Side)

IG2 Relay
(Point Side)

IG1 NO.4 Relay
(Point Side)

7.5A HEATER-S

7.5A GAUGE

7.5A IG2

10A ECU IG2

15A AT UNIT

15A A/B MAIN

10A SEAT HTR RH

10A SEAT HTR LH

10A DRL

7.5A RADIO

15A P/POINT NO.1

10A ECU ACC

15A P/POINT NO.2

10A FR FOG RH

10A FR FOG LH

10A HEATER

3

1

ST CUT Relay
(Point Side)

1

1

7.5A PUSH-AT

1

1

3

3

3

3

3

3

3

3

TAIL Relay
(Point Side)

10A TAIL

10A PANEL

3

3

3

3

IG1 NO.1 Relay
(Point Side)

7.5A BK/UP LP

10A ECU IG1

3

3

3

3

3

7.5A ALT-S

20A F/PMP

15A HAZ

15A ETCS

7.5A MPX-B

20A D/L

7.5A STR LOCK

7.5A EFI (+B)

7.5A AM2 NO.2

15A EFI (IGN)

15A EFI (HTR)

15A EFI (CTRL)

7.5A AT+B

80A EPS

30A INJ

30A H-LP WASHER

1

(*2)

(*1)

(*1)

(*1 A/T)

(*3)

(*3)

ST Relay
(Point Side)

1

7.5A ST

1

J

BRZ (G4400GE)

437

Engine Room R/B and Engine Room J/B (See Page 24)

Fuse

System

Page

7.5A

ALT-S

Charging

106

7.5A

AM2 NO.2

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

Engine Immobiliser System (w/ Entry & Start System), Entry & Start
System, Starting (w/ Entry & Start System), Steering Lock
(w/ Entry & Start System) and Wireless Door Lock Control
(w/ Entry & Start System)

72

7.5A

AT+B

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

7.5A

ECU-B

ABS, TRC and VSC

250

Air Conditioner (LHD Automatic A/C)

380

Air Conditioner (Manual A/C)

404

Air Conditioner (RHD Automatic A/C)

392

Alarm Control System

420

Automatic Light Control and Light Auto Turn Off System

224

Combination Meter

362

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

Door Lock Control

300

Double Locking

324

Engine Immobiliser System (w/ Entry & Start System), Entry & Start
System, Starting (w/ Entry & Start System), Steering Lock
(w/ Entry & Start System) and Wireless Door Lock Control
(w/ Entry & Start System)

72

Engine Immobiliser System (w/o Entry & Start System)

152

Front Fog Light

210

Headlight

166

Headlight Beam Level Control

230

Headlight Cleaner

238

Illumination and Taillight

188

Interior Light

200

Key Reminder (w/o Entry & Start System) and Light Reminder

244

Luggage Compartment Door Opener

314

Mirror Heater and Rear Window Defogger

344

Power Window (LHD)

288

Power Window (RHD)

294

Rear Fog Light

218

Wireless Door Lock Control (w/o Entry & Start System)

306

7.5A

EFI(+B)

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

7.5A

HORN NO.1

Horn

352

7.5A

HORN NO.2

Horn

352

* These are the page numbers of the first page on which the related system is shown.

J  POWER SOURCE (Current Flow Chart)

BRZ (G4400GE)

438

Fuse

System

Page

7.5A

IG2

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

Engine Immobiliser System (w/ Entry & Start System), Entry & Start
System, Starting (w/ Entry & Start System), Steering Lock
(w/ Entry & Start System) and Wireless Door Lock Control
(w/ Entry & Start System)

72

7.5A

MIR HTR

Mirror Heater and Rear Window Defogger

344

7.5A

MPX-B

ABS, TRC and VSC

250

Air Conditioner (LHD Automatic A/C)

380

Air Conditioner (Manual A/C)

404

Air Conditioner (RHD Automatic A/C)

392

Alarm Control System

420

Automatic Light Control and Light Auto Turn Off System

224

Combination Meter

362

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

Door Lock Control

300

Double Locking

324

Engine Immobiliser System (w/ Entry & Start System), Entry & Start
System, Starting (w/ Entry & Start System), Steering Lock
(w/ Entry & Start System) and Wireless Door Lock Control
(w/ Entry & Start System)

72

Engine Immobiliser System (w/o Entry & Start System)

152

EPS

274

Front Fog Light

210

Headlight

166

Headlight Beam Level Control

230

Headlight Cleaner

238

Illumination and Taillight

188

Interior Light

200

Key Reminder (w/o Entry & Start System) and Light Reminder

244

Luggage Compartment Door Opener

314

Mirror Heater and Rear Window Defogger

344

Power Window (LHD)

288

Power Window (RHD)

294

Rear Fog Light

218

Seat Belt Warning

282

SRS

265

Wireless Door Lock Control (w/o Entry & Start System)

306

7.5A

PUSH-AT

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

* These are the page numbers of the first page on which the related system is shown.

J

BRZ (G4400GE)

439

Fuse

System

Page

7.5A

PUSH-AT

Engine Immobiliser System (w/ Entry & Start System), Entry & Start
System, Starting (w/ Entry & Start System), Steering Lock
(w/ Entry & Start System) and Wireless Door Lock Control
(w/ Entry & Start System)

72

7.5A

ST

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

Engine Immobiliser System (w/ Entry & Start System), Entry & Start
System, Starting (w/ Entry & Start System), Steering Lock
(w/ Entry & Start System) and Wireless Door Lock Control
(w/ Entry & Start System)

72

Starting (w/o Entry & Start System)

102

7.5A

STR LOCK

Engine Immobiliser System (w/ Entry & Start System), Entry & Start
System, Starting (w/ Entry & Start System), Steering Lock
(w/ Entry & Start System) and Wireless Door Lock Control
(w/ Entry & Start System)

72

10A

H-LP LH HI

Headlight

166

10A

H-LP RH HI

Headlight

166

10A

RR FOG

Rear Fog Light

218

10A

WASHER

Front Wiper and Washer

332

Headlight Cleaner

238

15A

A/B MAIN

SRS

265

15A

EFI(CTRL)

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

15A

EFI(HTR)

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

15A

EFI(IGN)

Ignition

110

15A

ETCS

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

15A

HAZ

ABS, TRC and VSC

250

Air Conditioner (LHD Automatic A/C)

380

Air Conditioner (Manual A/C)

404

Air Conditioner (RHD Automatic A/C)

392

Alarm Control System

420

Automatic Light Control and Light Auto Turn Off System

224

Combination Meter

362

Cruise Control, ECT and A/T Indicator (A/T), Engine Control, Shift
Indicator (M/T) and Shift Lock

114

Door Lock Control

300

Double Locking

324

Engine Immobiliser System (w/ Entry & Start System), Entry & Start
System, Starting (w/ Entry & Start System), Steering Lock
(w/ Entry & Start System) and Wireless Door Lock Control
(w/ Entry & Start System)

72

Engine Immobiliser System (w/o Entry & Start System)

152

Front Fog Light

210

* These are the page numbers of the first page on which the related system is shown.

J  POWER SOURCE (Current Flow Chart)

BRZ (G4400GE)

440
