RM-5

Recommended Materials

RECOMMENDED MATERIALS

8. ADHESIVE

Use the adhesives shown in the table below, or equivalent.

9. SEAL MATERIAL

Use the seal material shown in the table below, or equivalent.

Adhesive

Application point

Recommended materials

Item number

Alternative

Adhesive

Windshield glass, rear
quarter glass, rear win-
dow glass and body

Dow Automotive’s

Adhesive: ESSEX U-400HV or equivalent

Glass primer: U-401 and U-402

Painted surface primer: U-413

—

Seal material

Application point

Recommended materials

Item number

Alternative

Seal material

• Bearing retainer FR
• MT transmission case
• MT extension hous-
ing sub-assembly
• Rear differential

Seal Packing 1281

—

• Oil pressure switch
• PCV valve

THREE BOND 1324

004403042

—

Service hole plug

THREE BOND 1105

004403010

DOW CORNING No. 7038

Steering adjusting screw

THREE BOND 1141G or

THREE BOND 1102

—

• Front sealing cover
• Rear sealing cover

3M Butyl Rubber 8626

—

• Engine oil pan
• Separator cover
• Camshaft cap
• Cylinder block
• Rocker cover
• Chain cover
• Oil pan upper
• Cylinder head
• Camshaft carrier
• Camshaft bearing cap

THREE BOND 1217G

K0877Y0100

—

PI-2

Pre-delivery Inspection

PRE-DELIVERY INSPECTION

1. Pre-delivery Inspection

A: GENERAL DESCRIPTION

The purposes of the pre-delivery inspection (PDI) are as follows.

• Remove the additional parts used for ensuring the vehicle quality during transportation and restore the ve-

hicle to its normal condition.

• Check the vehicle before delivery is in normal condition.

• Check the vehicle or parts for any damage occurred during transportation or storage.

• Check the vehicle after repair is in normal condition.

• Make sure to provide a complete vehicle to customer.

For above reasons, all SOAs (dealerships) must carry out the PDIs before delivery of vehicle.

Refer to this manual unless otherwise specified.

B: PRE-DELIVERY INSPECTION (PDI) PROCEDURE

Perform the procedures indicated in the table below.

Static Checks Just after Vehicle Receipt

Step

Check point

1. Appearance

1. If the vehicle is covered with protective coating, visually check the vehicle
body for damage and dents. If the protective coating has been removed,
visually check the painted body surfaces in detail for damage or rust.
2. Visually check the glass and light lenses for any damage, cracks or exces-
sive gaps between body sheet metal.
3. Visually check the plated parts for any damage.
4. Check the instrument panel, console and trim for stains or dirt.

2. Tire

1. Check the tires for damage, defective, and dents on wheels.
2. Check the tire air pressure.

3. Fuse installation

If the vehicle is about to be delivered to customer, attach a DCC (back-up)
fuse.

4. Door lock/unlock and open/close operations

1. Using the key, check the door can be locked or unlocked normally.
2. Open and close all doors to check that there are no problems.
3. Operate the power door lock switch to check that all doors are locked and
unlocked normally.

5. Trunk lid open/close operations

1. Using the key, check that the trunk lid can be locked or unlocked normally.
2. Operate the trunk opener button to check that the trunk opens normally.
3. Use the valet key to check that the lock cannot be released.
4. Open and close the trunk lid to check that there are no problems.

6. Operation check of trunk lid release lever

Operate the trunk lid release lever to check that the trunk lock is unlocked
normally.

7. Fuel lid opener lever

Operate the fuel lid opener to check that the fuel filler lid can be unlocked
normally.

8. Towing hook (eyebolt)

At factory shipment, the towing hook (eyebolt) is installed to the rear bumper.
Remove the towing hook (eyebolt), store it in the holder.

9. Accessory

Check that the following accessories are equipped.
• Owner’s manual
• Warranty booklet
• Maintenance note
• Spare key
• Key No. plate
• Jack
• Tool set
• Spare tire
• Towing hook

10. Front hood lock release

Operate the front hood lock release lever to check that the front hood opens
normally.

11. Battery

Check the battery for any abnormal conditions such as rust or traces of bat-
tery fluid leaks.

12. Brake fluid

Check the brake fluid amount.
